Lexmark C792 Family Quick reference guide

Media guide

The printer supports the following paper and other specialty media sizes. Select custom sizes up to the maximum specified for

the Universal setting.

Supported paper sizes

Measurements apply to simplex (one-sided) printing only. For duplex (two-sided) printing, the minimum size is 139.7 x 210 mm

(5.50 x 8.27 in.).

Paper size Dimensions Standard

550-sheet tray

(Tray 1)

Optional

550-sheet tray

Optional

2,000-sheet tray

Multipurpose feeder Duplexer

A4 210 x 297 mm

(8.27 x 11.7 in.)

A5 148 x 210 mm

(5.83 x 8.27 in.)

A6 105 x 148 mm

(4.13 x 5.83 in.)

X X X X

JIS B5 182 x 257 mm

(7.17 x 10.1 in.)

Letter 215.9 x 279.4 mm

(8.5 x 11 in.)

Legal 215.9 x 355.6 mm

(8.5 x 14 in.)

Executive 184.2 x 266.7 mm

(7.25 x 10.5 in.)

Oficio (México) 215.9 x 340.4 mm

(8.5 x 13.4 in.)

Folio 215.9 x 330.2 mm

(8.5 x 13 in.)

Statement 139.7 x 215.9 mm

(5.5 x 8.5 in.)

1Supported by C792 models only.

2This formats the envelope size setting for 215.9 x 355.6 mm (8.5 x 14 in.) unless the size is specified by the software application.

Media guide

Page 1 of 3

Paper size Dimensions Standard

550-sheet tray

(Tray 1)

Optional

550-sheet tray

Optional

2,000-sheet tray

Multipurpose feeder Duplexer

Universal

Note: Turn size

sensing off to

support universal

sizes that are close

to standard media

sizes.

148 x 210 mm to

215.9 x 355.6 mm

(5.83 x 8.27 in. to

8.5 x 14 in.)

76.2 x 127 mm

(3 x 5 in.) to

215.9 x 355.6

mm (8.5 x 14 in.)

X X X X

76.2 x 127 mm

(3 x 5 in.) to

215.9 x 914.4

mm (8.5 x 36 in.)1

X X X X

76.2 x 127 mm

(3 x 5 in.) to

215.9 x 1219.2

mm (8.5 x 48 in.)1

X X X X

7 3/4 Envelope

(Monarch)

98.4 x 190.5 mm

(3.875 x 7.5 in.)

X X X X

9 Envelope 98.4 x 226.1 mm

(3.875 x 8.9 in.)

X X X X

Com 10 Envelope 104.8 x 241.3 mm

(4.12 x 9.5 in.)

X X X X

DL Envelope 110 x 220 mm

(4.33 x 8.66 in.)

X X X X

C5 Envelope 162 x 229 mm

(6.38 x 9.01 in.)

X X X X

B5 Envelope 176 x 250 mm

(6.93 x 9.84 in.)

X X X X

Other Envelope285.7 x 165 mm to

215.9 x 355.6 mm

(3.375 x 6.50 in. to

8.5 x 14 in.)

X X X X

1Supported by C792 models only.

2This formats the envelope size setting for 215.9 x 355.6 mm (8.5 x 14 in.) unless the size is specified by the software application.

Storing paper

Use these paper storage guidelines to help avoid jams and uneven print quality:

•For best results, store paper where the temperature is 21°C (70°F) and the relative humidity is 40%. Most label manufacturers

recommend printing in a temperature range of 18 to 24°C (65 to 75°F) with relative humidity between 40 and 60%.

•Store paper in cartons when possible, on a pallet or shelf, rather than on the floor.

•Store individual packages on a flat surface.

•Do not store anything on top of individual paper packages.

Media guide

Page 2 of 3

Avoiding jams

Paper tray recommendations

•Make sure the paper lies flat in the tray.

•Do not remove a tray while the printer is printing.

•Do not load a tray while the printer is printing. Load it prior to printing, or wait for a prompt to load it.

•Do not load too much paper. Make sure the stack height does not exceed the indicated maximum height.

•Make sure the guides in the tray or the multipurpose feeder are properly positioned and are not pressing too tightly against

the paper or envelopes.

•Push the tray in firmly after loading paper.

Paper recommendations

•Use only recommended paper or specialty media.

•Do not load wrinkled, creased, damp, bent, or curled paper.

•Flex and straighten paper before loading it.

•Do not use paper that has been cut or trimmed by hand.

•Do not mix paper sizes, weights, or types in the same stack.

•Make sure all sizes and types are set correctly in the printer control panel menus.

•Store paper per manufacturer recommendations.

Media guide

Page 3 of 3
