LevelOne USB-0301 User manual

USB Fast Ethernet Adapter USB-0301

Fast and easy connection with USB

LevelOne USB Fast Ethernet Adapter allows you to

connect to the internet easily through the built-in port

on your laptop or gaming console. Now you no longer

need to have an Ethernet connection in order to surf

the web. This is an ideal solution for MacBook Air

(100% Mac compatible) or other computers that may

have wireless built-in but don’t come with an Ethernet

port. Sometimes you need to physically connect to a

network cable to help transfer les or access secure

information. USB-0301 easily does the job, all through

your USB port.

Reliable, ecient and standards compliant

USB-0301 is USB 1.0, 1.1, and 2.0 compliant. It also

follows the Ethernet standards set by the IEEE 802.3

and 802.3u, allowing you to take advantage of the

Fast Ethernet speeds of up to 100 Mbps. This provides

a strong backbone for any high-speed broadband

connection to the internet as well as fast speeds for

the Local Area Network le transfers.

Also great for the Wii

Not only for laptops or notebook computers, LevelOne

Net Connector will also bring fast internet speeds to

your Wii for online gaming with your friends, even if

they’re miles away!

Key Features

- High-speed USB2.0, and 1.0 standard compliant

- Powered through USB port with low power

consumption

- IEEE802.3 10Base-T , 802.3U 100 Base-Tx standard

compilant

- Automatically negotiates 10/100 Mbps connections

- Supports Windows 2000/XP/Vista/7,

Mac 10.3/10.4/10.5

- Supports hot-swap and hot-insert

Works Well With

PLI-3210

HomePlug Pro 4-Port Switch

1. USB 2.0 Connector

2. RJ-45 Ethernet Port

3. LED Indicator

H/W Version: 1

FNS-1020

1-Bay Simple Network Storage

Network Cards/Wired and Fast Ethernet

www.level1.com

one world_one brand_one level_

Network Standards

IEEE 802.3: 10Base-T

IEEE 802.3u: 100Base-T

Data Transfer Rates

Ethernet: 10Mbps (Half/Full Duplex)

Fast Ethernet: 100Mbps (Half/Full Duplex)

Data Bus

USB 2.0 (1.1 compliant)

LED Indicators

Power, Link

Power Consumption

850mW

Power Management

Suspend mode

hibernation mode

Technical Specication

Network Interface

Female RJ45 jack

RAM

Embedded 20KB SRAM for RX packet buering and 20KB SRAM

for TX packet buering

Operating System Support

Windows® 2000, XP, Vista™, Windows®7; Mac OS X 10.x

Dimensions (L x W x H)

66 mm x 22 mm x 15 mm

Weight

25g

Operating Temperature

0°C to 70°C

Product Diagram

Internet

USB-0301

ADSL/Modem Wired Router

Order Information USB-0301: USB Fast Ethernet Adapter

Package Content USB-0301, Quick Installation Guide, CD Manual/Utility

V1.0

All mentioned brand names are registered trademarks and property of their owners. Technical specications are subject to change without notice.

Wii: Wired Environment

Wii USB Port

Internet

USB-0301

ADSL/Modem Wired Router

PC/Mac: Wired Environment

PC/Mac USB Port
