Lenovo S960 User manual
Lenovo S960
Quick Start Guide v1.0
Read this guide carefully before using your phone.
Type: CMOS
Pixels: 13.0 MP (back) + 5.0 MP (front)
GPS
Height: 144.3 mm Width: 72 mm Depth: 6.95 mm
Weight: 121 g
CPU: MTK6589W Quad Core 1.5 GHz
Capacity: 16GB
Size: 5.0 inches (diagonal)Screen: Multi-touch display
Resolution: 1080P LCD type: IPS
Model: Lenovo S960 System: Android 4.2.2
Bluetooth 4.0 WLAN WCDMA, GSM
①Based on actual measurements.
Battery: 2050 mAh (Built-in rechargeable lithium-ion battery)
Wireless communication
Display
Model and system
Power and battery
CPU and capacity
① Size and weight
Camera
Technical specifications
Microphone
Micro USB
On/Off button
Front camera
Earphone jack
Volume up
Back camera
5
Receiver+ Speaker 2
6
3
789
4
1
Volume down
2
3
4
56
7
First glance
9
8
1
Step 1. Insert the SIM eject tool into the hole on the Micro SIM card
tray.
Step 2. Pull out the Micro SIM card tray and place the Micro SIM card
in the tray.
Step 3. Carefully replace the tray.
You need to insert the Micro SIM card provided by your carrier to use
cellular services. Insert the Micro SIM card as shown.
Only Micro SIM card work with your phone.
Do not insert or remove the Micro SIM card while your phone is turned on.
Doing so may permanently damage your Micro SIM card or phone.
Installing the Micro SIM card
Method 1. Connect your phone to a power outlet using the included
cable and USB power adapter.
Method 2. Charge the battery using a computer.
Low battery Fully charged Charging
For more information about battery safety, see the Important Product
Information Guide.
2
1
Before using your phone, you might need to charge the battery.
Charge the battery as shown.
Charging the battery
5SC9A464BJ
Printed in China
Legal notices
Lenovo and the Lenovo logo are trademarks of Lenovo in the
United States, other countries, or both.
Other company, product, or service names may be trademarks
or service marks of others.
First Edition (October 2013)
© Copyright Lenovo 2013.
Learn More
For more information about Lenovo Mobile Phone functions,
Regulatory Notices and other useful manuals, go to
http://support.lenovo.com/.
