Lenovo A6000 User manual
English/Bahasa Indonesia
Quick Start Guide v1.0
Lenovo A6000
English
Learning more
Getting support
Read this guide carefully before using your smartphone.
To learn more information about your
Lenovo smartphone and obtain the latest
smartphone manuals, go to:
http://support.lenovo.com/.
For support on network service and billing,
contact your wireless network operator.
For instructions on how to use your
device, go to:
http://support.lenovo.com/.
Legal notices Lenovo and the Lenovo logo are
trademarks of Lenovo in the United States,
other countries, or both.
Other company, product, or service names
may be trademarks or service marks of
others.
Manufactured under license from Dolby
Laboratories. Dolby and the double-D
symbol are trademarks of Dolby
Laboratories.
Type: CMOS
Pixels: 8.0 megapixels (back) + 2.0 megapixels (front)
Processor: Qualcomm MSM8916, Quad Core, 1.2 GHz
Size: 5.0 inches Screen: multi-touch
Resolution: 1280 × 720 pixels LCD type: IPS
Model: Lenovo A6000 System: Android
Battery: 2300 mAh
Height: 140.9 mm (5.547 inches) Width: 70.55 mm (2.778 inches)
Depth: 8.2 mm (0.323 inch) Weight: 129.6 g (0.286 lb)
Model and system
① Depending on the measuring method, the dimensions and weight
might vary slightly.
② In some countries, LTE is not supported. To know if your
smartphone works with LTE networks in your country, contact
your carrier.
Display
Battery
Processor
①Dimensions and weight
Camera
Wireless Communication
Technical specifications
Bluetooth 4.0; WLAN 802.11 b/g/n; ②LTE, WCDMA, GSM; GPS
654
Microphone
Flashlight
Micro USB
connector
Speaker On/Off button
Volume buttons
Home key
7
10
13
8
11
9
12
Front-facing
camera
Headset
connector
Rear-facing
camera
1 2 Receiver 3Back key
Menu key
First glance
You must insert the SIM card provided by your carrier to use cellular
services. Set up your smartphone as shown.
Step 1. Open the back cover.
Step 2. Insert the SIM cards and
the memory card.
Tip: Insert the (U)SIM card into
SIM1 slot and SIM card
into SIM2 slot.
Step 3. Install the battery.
a. Align the battery
connectors on the battery
with the pins in the
battery compartment.
b. Push the battery down
into place.
Step 4. Install the back cover.
Always turn off your smartphone first before you insert or remove a
SIM card. Insert or remove a SIM card with your smartphone on may
damage your SIM card or smartphone permanently.
a
b
SIM1
SIM2
SIM1
SIM2
Preparing your smartphone
Turning on or turning off your smartphone
Turn on: Press and hold the On/Off button until
the Lenovo logo appears.
Tur n of f: Press and hold the On/Off button for a
few seconds, then tap Power off.
Reboot: Press and hold the On/Off button for a
few seconds, then tap Reboot.
Your smartphone has a rechargeable battery. For more information
about battery safety, see the “Rechargeable battery notice” in the
Important Product Information Guide shipped with your smartphone.
Low battery power Fully charged Charging
2
1
Charge the battery as shown.
Method 1.
Method 2.
Connect your smartphone to a power outlet using the
cable and USB power adapter that come with your
smartphone.
Connect your smartphone to a computer using the cable
that comes with your smartphone.
Charging the battery
Pelajari lebih lanjut Untuk mengetahui informasi
selengkapnya tentang ponsel cerdas
Lenovo dan mendapatkan panduan
ponsel cerdas terbaru, kunjungi:
http://support.lenovo.com/.
Untuk dukungan penagihan dan
layanan jaringan, hubungi operator
jaringan nirkabel Anda. Untuk petunjuk
cara menggunakan perangkat Anda,
kunjungi: http://support.lenovo.com/.
Lenovo dan logo Lenovo adalah merek
dagang dari Lenovo di Amerika Serikat,
negara lain, atau keduanya.
Perusahaan, produk, atau nama layanan
lainnya mungkin merek dagang atau
merek layanan dari pihak lain.
Manufactured under license from Dolby
Laboratories. Dolby and the double-D
symbol are trademarks of Dolby
Laboratories.
Bahasa Indonesia
Baca panduan ini dengan saksama sebelum menggunakan
ponsel cerdas.
Mendapatkan
dukungan
Pemberitahuan
hukum
Jenis: CMOS
Piksel: 8,0 megapiksel (belakang) + 2,0 megapiksel (depan)
Prosesor: Qualcomm MSM8916, Quad Core, 1,2 GHz
Ukuran: 5,0 inci Layar: multisentuh
Resolusi: 1280 × 720 piksel Tipe LCD: IPS
Model: Lenovo A6000 Sistem: Android
Bluetooth 4.0; WLAN 802.11 b/g/n; LTE, WCDMA, GSM;
GPS
Baterai: 2300 mAh
Tinggi: 140,9 mm (5,547 inci) Lebar: 70,55 mm (2,778 inci)
Tebal: 8,2 mm (0,323 inci) Bobot: 129,6 g (0,286 lb)
Model dan sistem
Tergantung pada metode pengukuran, ukuran dan berat mungkin
sedikit berbeda.
Di beberapa negara, LTE tidak didukung.Untuk mengetahui apakah
ponsel cerdas Anda dapat digunakan dengan jaringan LTE di negara
Anda, hubungi operator Anda.
Display
Baterai
Prosesor
Ukuran dan berat
Kamera
Komunikasi Nirkabel
Spesifikasi teknis
②
②
Tampilan sekilas
Speaker
Kamera
belakang
Tombol Home
Konektor USB
Mikro
Tombol
Kembali
Kamera depan
1
4
7
10
2
5
8
3
6
9
Konektor
headset
Unit penerima
Senter
Tombol Menu
Mikrofon Tombol
Nyala/Mati
11 12
13 Tombol Volume
Untuk menggunakan layanan seluler, pasang kartu SIM yang
disediakan oleh operator seluler Anda. Siapkan ponsel cerdas Anda
seperti yang ditunjukkan.
Selalu matikan ponsel cerdas Anda lebih dulu sebelum Anda
memasukkan atau melepaskan kartu SIM. Memasukkan atau
melepaskan kartu SIM dengan ponsel cerdas masih menyala dapat
merusak kartu SIM atau ponsel cerdas Anda secara permanen.
Menyiapkan ponsel cerdas
Langkah 1. Buka penutup belakang.
Langkah 2. Masukkan kartu SIM
dan kartu memori.
Saran: Masukkan kartu (U)SIM
ke slot SIM1 dan kartu
SIM ke slot SIM2.
Langkah 3. Pasang baterai.
a. Sejajarkan konektor
baterai pada baterai
dengan pin di ruang
baterai.
b. Tekan baterai masuk ke
tempatnya.
Langkah 4. Pasang penutup
belakang.
a
b
SIM1
SIM2
SIM1
SIM2
