KWC QBIX Quick guide

Montage- und Serviceanleitung

Instructions de montage et d'entretien

Istruzioni di montaggio e di assistenza

Instrucciones de montaje y servicio

Installation and service instructions

RMATUREN

ROBINETTERIE

RUBINETTERIA

GRIFERIA

FAUCETS

12/05

802207

Waschtisch-,Bad-,DuschenmischerundZubehör

Mitigeur pour lavabo, bain-douche, douche et accessoires

Miscelatore per lavabo, bagno-doccia, doccia e accessori

Mezclador bara lavabo, baño, ducha y accesorios

Lavatory-,bath-, showermixer andaccessoires

KWC QBIX

KWC QBIX-ART

2Betriebsdaten

Caractéristiques de fonctionnement

Caratteristiche di funzionamento

Datos de servicio

Operating data

D Schäden, die infolge unsachgemässer Behandlung, natürlicher Abnützung oder zu grosser

Inanspruchnahme entstanden sind, sind von unseren Garantieleistungen ausgeschlossen!

F Ces dommages survenus en raison d'un traitement inadéquat, des signes d'usure traitement inadéquat,

naturels ou du grand utilisation, sont exclus de notre garantie.

I Danni ai rubinetti, conseguenti da un trattamento non appropriato, sono esclusi dalla nostra garanzia!

Sp Daños, debidos a un tratamiento inadecuado, son exclusos de la nuestra garantia.

E Damages on the faucet resulting from incorrect handling are excluded from the manufacturers warranty!

Achtung:

Vor Montage die Leitungen gründlich

durchspülen!

Idealer Betriebsdruck : 3 bar

Max. Betriebsdruck : 5 bar

Druckgleichheit empfehlenswert.

Ideale Wassertemperatur : 60 ˚C

Max.Wassertemperatur : 80 ˚C

Weitere Informationen finden Sie in unseren

detaillierten Verkaufsunterlagen.

Attenzione:

Risciacquare bene le tubazioni

prima del montaggio!

Pressione di servizio ideale : 3 bar

Pressione di servizio mass. : 5 bar

Si raccomanda pressioni uguali.

Temperatura acqua calda ideale : 60˚C

Temperatura acqua calda mass. : 80˚C

Ulteriori informazioni le troverete nelle nostre

dettagliate documentazioni.

Atención:

Enjuagar escrupulosamente las tuberías

antes del montaje!

Presión ideal de servicio : 3 bar

Presión máxima de servicio : 5 bar

Se recomienda la igualdad de las presiones.

Temperatura ideal del agua : 60 ˚C

Temperatura máxima del agua : 80 ˚C

Información más detallada en nuestra

documentación de ventas.

Attention:

Flush pipes thoroughly before installation!

Ideal operating pressure : 3 bar (45 PSI)

Max. operating pressure : 5 bar (70 PSI)

Equal pressures are recommended.

Ideal water temperature : 60 ˚C (140˚F)

Max. water temperature : 80 ˚C (180˚F)

For further information refer to our detailed sales

literature.

Attention:

Rincer à fond la tuyauterie avant le

montage!

Pression de service idéale : 3 bar

Pression de service max. : 5 bar

Egalité de pression recommandée.

Température idéale de l'eau : 60˚C

Température max.de l'eau : 80˚C

Pour informations supplémentaires voir nos

documentations de vente détaillées.

Sortiment

Sommaire

Sommario

Assortimento

Product Range

12.241.171.000 12.251.171.006

21.244.240.000 21.254.240.006

27.240.050.000 27.250.050.006

26.254.083.000 Z.506.288.000.10

KWC QBIX KWC QBIX-ART

KWC QBIX & KWC QBIX-ART

4Masse

Dimensions

Dimensioni

Dimensiones

Dimensions

1" 5 1/2"

2 3/4"

~2 1/2" - 4 7/16"

~1" - 3 3/4"

12.241.171.000 21.244.240.000

27.241.050.000

26.254.083.000 Z.506.288.000.10

14 5/16"

max. 1 1/4"

9/16"

M 33

11 13/16"

5 5/8"

KWC QBIX

KWC QBIX & KWC QBIX-ART

8 1/4"

3 9/16"

1 1/8" 1 1/4" 2 3/8"

FTP 1/2"

ø15/16"

2 3/8"

Masse

Dimensions

Dimensioni

Dimensiones

Dimensions

1" 5 1/2"

2 3/4"

~2 1/2" - 4 7/16"

~1" - 3 3/4"

9/16"

14 5/16"

M 33

max. 1 1/4"

14 3/16"

12.251.171.006 21.254.240.006

27.251.050.006

KWC QBIX-ART

6Befestigung

Fixation

Fissaggio

Fijación

Connection

Max. 1 1/4"

M33 x 1.5

S 36 mm

R min = 2"

ø 1 3/8"

9/16 - 24 UNEF

min. 2 3/8"

Inbetriebsetzung

Mise en service

Messa in funzione

Puesta en servicio

Initial operation

D spülen

F rincer

I sciacquate

Sp enjuagar

E flush

Kalt- und Warmwasser schliessen.

Fermer eau froide et chaude.

Chiudere acqua fredda e calda.

Interrumpir la salida de agua fría y caliente.

Turn off cold and hot water.

1.)

2.)

3.) 4.)

Demontage des Griffes und Austausch des Oberteils

Démontage de la poignée et remplacement de la tête à robinet

Demontagio della manopola e sostituzione della vitone fino

Demontaje del mando y recambio de la válvula

Disassembling of the grip and replacing of the valve

Ersatzteile

Pièces de rechange

Pezzi di ricambio

Repuestos

Spare parts

Z.506.039

Z.534.449

Z.200.223

Z.600.515

Z.506.161

Z.200.176

M16 x 1

Z.633.627

Z.633.626

Z.506.313

Z.506.312

Z.504.824

9/16"

12.241.171.000

10 Ersatzteile

Pièces de rechange

Pezzi di ricambio

Repuestos

Spare parts

Z.200.223

Z.506.040

Z.534.450

Z.534.449

Z.600.515

Z.506.311

Z.200.176

Z.506.161

M18 x 1

Z.633.627 Z.633.626

Z.506.310

Z.504.824

9/16"

12.251.171.006

Other manuals for QBIX

This manual suits for next models
