Introduction

The magicolor®2450 is an ultra-compact color laser printer that delivers

the best graphical performance in its class. Fast and with superb print

quality, its power gives it wide-ranging compatibility.

As the magicolor 2450 demonstrates, size is no indication of strength.

Taking up little space on a desk, it prints at 20 ppm black-&-white and

five ppm color, with first page print-out in just 12 seconds. This power is

delivered by means of a next-generation Emperon®controller which

provides excellent compatibility and versatility for printing from any

major application and environment.

For superb color printing, this PostScript®- and PCL®-compatible laser

delivers 9600 x 600 dpi-class resolution. When combined with Simitri®

polymerized toner and eAIDC (enhanced Automatic Image Density

Control) results in photo-quality prints that have to be seen to be

believed.

Premium color for power users with easy operation for the novice, the

magicolor 2450 is ideal for the demanding, graphics-intense workloads of

small to medium-sized businesses and business workgroups.

This Sales & Technical Guide is intended for use by KONICA

MINOLTA sales personnel and reseller partners. It includes

complete information about the magicolor 2450 and provides data

that can help you explain the features of the printer to customers.

For the most complete and up-to-date information on the printer,

check our password-protected Reseller Partner Program web site

at: printer.konicaminolta.com/reseller

Specs at a Glance

An overview of the magicolor 2450’s features.

Print Method Electrophotographic color laser

Processor PowerPC, 300 MHz

Print Speed Up to 20 monochrome ppm (letter/A4)

Up to 5 color ppm (letter/A4)

Resolution Up to 9600 x 600 dpi-class

Duty Cycle Up to 35,000 letter/A4 prints/month

Memory 128 MB DDR SDRAM on the controller,

Upgradeable to 640 MB via 1 DIMM

slot

Standard Interfaces Ethernet (10/100BaseTX), USB 2.0,

Parallel

Media Sizes Up to legal (8.5" x 14" / 216 x 356 mm)

Media Weights Up to 90 lb. Index (163 g/m2)

Media Input 200-sheet multipurpose tray

Optional 500-sheet Lower Feeder Unit

Optional Automatic Duplexer

Media Output 200-sheet face-down tray

Print Media Types Plain/recycled paper, glossy stock,

thick stock, transparencies, postcards,

laser-quality labels, envelopes

Software Utilities Drivers for Windows Server 2003/XP/

2000/NT4/Me/98SE; Macintosh OS 9

(v9.1+), OS X (v10.2+)

PageScope Management Suite,

Print Monitor, Status Monitor

Color Control Enhanced Automatic Image Density

Control (eAIDC) built-in calibration;

Automatic ICC-based color matching;

ICC Device Profiles; Dynamic Contone;

Screening; SWOP, Commercial,

EuroColor, TOYO, and DIC press

emulations; PANTONE Color tables

Language Compatibility PostScript 3, PCL 6, PDF 1.4

Typefaces 144 PostScript, 93 PCL, 10 line printer

Warranty One-year exchange

Premium color for power users.

Specs at a Glance

An overview of the magicolor 2450’s features.

200-sheet output tray

200-sheet multipurpose tray

Optional 500-sheet lower feeder

Intuitive LCD control panel

with gas gauges

Optional automatic duplexer

Ethernet, USB & Parallel interfaces

128 MB DDR SRAM std. / 640 MB max.

Optional 40 GB hard disk

Easy-access cover for supplies replacement

Target Markets

For general business and the creative mind.

Robust performance and networking, coupled with superb color and

affordability give the magicolor 2450 an advantage. It’s appealing to

small business and workgroups that perform a good deal of general

printing along with a touch of creative design. And it’s perfect for

creative services professionals who demand great color, but also need

a productive printer for general printing.

Professional desktop publishing and design services

Advertising agencies

In-house marketing departments

Small businesses

Small workgroups (2 - 10 people)

Real Estate agencies

Automotive dealerships

Convention centers

Tourism departments

Hotels

Sales departments

Human resources departments

Use this powerhouse printer to create:

Brochures Flyers

Reports Spreadsheets

Invoices Sales sheets

Real Estate listings Client proofs

Digital photo archiving Business correspondence

Presentations CD & address labels

Key Selling

Features

Compact

With its small footprint and front-loading consumables, this little color

laser dynamo takes up much less room on a desktop than its nearest

competitor, making it perfect for the space-compromised environment.

Like other magicolor 2400 models, the magicolor 2450 has simple, full-

front access for reloading supplies and clearing paper jams, so there's

no need to waste desk space to access the back of the machine.

Affordable

Besides its affordable price, the magicolor 2450 boasts a cost per page

of only pennies per print in both color and black and white, making it

budget-friendly for the small business and home office user.

Long-lasting toner yields 1,500 or 4,500

prints for low cost-per-page printing.

11¢ 2.2¢

magicolor 2450

Footprint: W16.9" x D19.8" = 334.6"

Operation Area: W16.9" x D21.4" = 362.6"

HP 2550

Footprint: W18.8" x D26" = 489”

Operation Area: W18.8" x D30.8" = 579.4"

Jam Clear

Paper Set Jam Clear

Consumable Change

Space Requirement

37%

less operation area

Ease of Use

A hallmark of KONICA MINOLTA printing solutions is their ease of use,

and the magicolor 2450 is no exception. Simple set-up and operation

make the magicolor 2450 a breeze to use.

Pre-installed supplies: When the printer arrives, owners will find

the supplies have been pre-installed at the factory to save

valuable time during set up.

Front-access to supplies: When supplies do run low,

replacement is easy. Toner cartridges are accessible from the

front of the printer, and the inside of the front panel features toner

replacement guidelines.

Auto-install software: The Software Utilities CD-ROM features

an auto-install interface that guides users, step-by-step, through

the installation of drivers and printer management utilities. It even

automatically detects the printer on the network.

LCD display and keypad: The magicolor 2450 features an LCD

keypad display. It has a 2-line LCD window that displays the

current state of the printer, shows options when navigating the

menu system, displays toner supply levels, and offers information

when an offline printer condition occurs.

Printer management with desktop convenience: Don’t leave

your desk to check the status of your print job or to see if there’s

enough supplies to handle a large print run. Rely on PageScope

Web Connection to view this information. Simply use your web

browser and the printer’s IP address to access real-time printer

data.

Another desktop management tool included with the magicolor

2450 is the Status Monitor. It resides on your screen for easy

accessibility, and shows detailed information about the printer

including current status, current consumable levels, and

explanations of any errors that may have occurred. It provides

this information in a helpful, graphical format.

PageScope Web Connection

makes it easy to check printer

supply status from your desktop.

Other manuals for Magicolor 2450

Table of contents

Other Konica Minolta Printer manuals

Konica Minolta

Konica Minolta A0VD011 Original instructions

Konica Minolta

Konica Minolta DRYPRO793 User manual

Konica Minolta

Konica Minolta PagePro 1350W User manual

Konica Minolta

Konica Minolta bizhub C4000i User manual

Konica Minolta

Konica Minolta bizhub 4422 User manual

Konica Minolta

Konica Minolta Magicolor 4750DN User manual

Konica Minolta

Konica Minolta magicolor 5670EN User manual

Konica Minolta

Konica Minolta PagePro 9100 User manual

Konica Minolta

Konica Minolta bizhub PRO 950 Series User manual

Konica Minolta

Konica Minolta PAGEPRO 4650EN User manual

Konica Minolta

Konica Minolta bizhub PRESS C70hc User manual

Konica Minolta

Konica Minolta PagePro 1380 MF Quick start guide

Konica Minolta

Konica Minolta bizhub pro 1100 User manual

Konica Minolta

Konica Minolta magicolor 3730DN Mounting instructions

Konica Minolta

Konica Minolta KM256 User manual

Konica Minolta

Konica Minolta Magicolor 5440 dl Configuration guide

Konica Minolta

Konica Minolta 2230 User manual

Konica Minolta

Konica Minolta 7820n User manual

Konica Minolta

Konica Minolta AccurioPrint 2100 User manual

Konica Minolta

Konica Minolta magicolor 1650EN Original instructions

Konica Minolta

Konica Minolta BIZHUB PRO C6500 User manual

Konica Minolta

Konica Minolta bizhub PRESS C6000 Manual

Konica Minolta

Konica Minolta AccurioPress C2070 User manual

Konica Minolta

Konica Minolta bizhub Colour Series Administrator Guide

Popular Printer manuals by other brands

Lexmark

Lexmark 1400 Series Manual

Canon

Canon i70 Series quick start guide

Evolis

Evolis Elypso user guide

Kyocera

Kyocera FS-9530DN specification

Canon

Canon LASER SHOT LBP-1210 Specifications

Samsung

Samsung BIXOLON SRP-350plusF user manual

Canon

Canon PIXMA PRO-1 Series Getting started

Canon

Canon PIXMA G3560 Online manual

Dell

Dell Color Laser Printer 2130cn user guide

Tektronix

Tektronix Phaser 840 user guide

Epson

Epson ET-7750 Programming guide

Canon

Canon CLBR 460ps Service manual

Eltron

Eltron P210 Guide manual

Ricoh

Ricoh MD-P1 Service manual

Epson

Epson SC-F7100 series user guide

Epson

Epson Stylus C40UX Service manual

Canon

Canon imagePASS-A2 Service guide

Canon

Canon S820D user guide
