Kohler K-498 Assembly instructions

Homeowners Guide

Wall-Mount Showering Tower

Mproduct numbers are for Mexico (i.e. K-12345M)

Los números de productos seguidos de Mcorresponden a México

(Ej. K-12345M)

Français, page “Français-1”

Español, página “Español-1”

K-498

1000706-5-D

Table of Contents

Thank You For Choosing Kohler Company .............................................. 2

IMPORTANT INSTRUCTIONS ....................................................... 3

Features – Shower Customization .................................................... 4

Features – Controls ............................................................... 5

Operation – Controls and Shower Arms ................................................ 6

Operation – Sidesprays and Handshower ............................................... 7

Optional Temperature Limiting Adjustment ............................................... 8

Correcting Reduced Water Flow – Showerheads .......................................... 9

Correcting Reduced Water Flow – Sprayheads .......................................... 11

Correcting Reduced Water Flow – Handshower ......................................... 12

Care and Cleaning Instructions – Shower Components .................................... 13

Warranty Information ............................................................. 13

Limited One-Year Warranty ......................................................... 13

Lifetime Limited Warranty .......................................................... 13

One-Year Warranty .............................................................. 14

Troubleshooting Procedures ........................................................ 15

Service Parts ................................................................... 17

Thank You For Choosing Kohler Company

Thank you for choosing Kohler Company. Your Kohler Company product reﬂects the true passion for design,

craftsmanship, artistry, and innovation Kohler Company stands for. We are conﬁdent its dependability and

beauty will surpass your highest expectations, satisfying you for years to come.

All information in this guide is based upon the latest product information available at the time of

publication. At Kohler Company, we strive to fulﬁll our mission of improving the level of gracious living for

each person who is touched by our products and services. We reserve the right to make changes in product

characteristics, packaging, or availability at any time without notice.

Please take a few minutes to review this guide. Pay special attention to the care and cleaning instructions.

1000706-5-D 2 Kohler Co.

IMPORTANT INSTRUCTIONS

READ AND SAVE FOR THE CONSUMER

WARNING: Risk of scalding or other severe injury.

•Before completing installation, the installer must set the maximum water temperature setting of this

valve to minimize the risks associated with scalding hazards according to ASTM F 444.

•Do not install a shut-off device on either outlet of this valve. The installation of any such device

may create a cross-ﬂow condition at the valve and affect the water temperature.

•Factors that change the temperature of the water supplied to the valve, such as seasonal water

temperature changes, and water heater replacement or servicing, will change the maximum water

temperature supplied by the valve and may create a scalding hazard. The pressure-balanced valve

will not compensate for changes in the water supply temperature; adjust the maximum water

temperature setting of this pressure-balanced valve when such changes occur.

•Pressure-balanced valves may not provide protection against scalding if there is a failure of other

temperature-limiting devices elsewhere in the plumbing system.

NOTICE: Only apply silicone based lubricants to these valves. Do not use petroleum based lubricants.

Petroleum based lubricants will harm the O-rings, seals, and plastic components.

The installer is responsible for installing the valve and adjusting the maximum water temperature of this

pressure-balanced valve according to instructions.

This valve meets or exceeds ANSI A112.18.1 and ASSE 1016.

If you do not understand any of the installation or temperature adjustment instructions in this document, in

the United States please contact our Customer Service Department at 1-800-4-KOHLER. Outside the U.S.,

please contact your distributor.

IMPORTANT NOTICE TO INSTALLERS! Please ﬁll in the blanks in the adjacent box and on the valve

label. Then insert these instructions into the plastic bag included with the valve package, and attach the

plastic bag to the valve handle for the homeowner’s reference.

NOTICE TO HOMEOWNERS! This device has been preset by _______________________ of

_______________________________ to ensure a safe maximum temperature. Any change in the setting may

raise the discharge temperature above the limit considered safe, and lead to scalds.

Date: ______________

Kohler Co. 3 1000706-5-D

Features – Shower Customization

Your shower destination combines the industry’s latest cutting-edge technology with our commitment to

unsurpassed quality and innovation. With your new shower, you and your family can instantly customize

each showering adventure to suit your mood and needs. In essence, you can enjoy a totally different

experience every time you step inside.

Telescopic Shower Arms

These two overhead shower arms are designed so you can adjust their height and orientation with a little

more than a touch. A counterweight system inside the tower keeps the telescopic shower arms in place until

you move them.

The telescopic shower arms are matched with Kohler’s 3-way relaxing showerheads to wash your stress

away.

•Use the Wide-Soft spray to relax your mind and body.

•Enjoy a gentle hydro-massage from the Slow-Pulse spray.

•Calm yourself in the warmth of the Soft-Aerated spray.

Sidesprays

A total of four sidesprays are height adjustable for your comfort and convenience. Position the sidesprays at

any height and setting to individualize your shower experience.

Rotate the grip rings on the sidespray to change the ﬂow to Pulse, Spray, or to turn the sidesprays off.

Personal Handshower

The 3-way invigorating handshower will revive your senses with three deep massaging spray patterns.

•Enjoy a deep massage to key areas of your body with the Wide-Strong spray.

•Use the Concentrated-Pulse spray for an all-body hydro-massage.

•Energize yourself with the exhilarating effects of the Wide-Pulse spray.

Wide-Soft

Slow-Pulse

Soft-Aerated

Telescopic Shower Arms Personal Handshower

Sidespray

Pulse

Spray

Wide-Strong

Concentrated-Pulse

Wide-Pulse

1000706-5-D 4 Kohler Co.

Features – Controls

Shower Valve — Water and Temperature Control

Your shower uses a pressure balancing valve to turn on the water for temperature adjustment.

The valve offers a number of special features, including:

•sensitivity to water pressure ﬂuctuations.

•one handle to adjust both temperature and turn the valve on/off.

•resistance to hard water freeze-up.

•efficient design to supply the water needs of your shower.

You can adjust the high temperature setting if the temperature is either too hot or too cold. Refer to the

″Optional Temperature Limiting Adjustment″section to change the maximum allowable temperature.

Spray Options

The Spray Option Control (transfer valve) allows you to choose from six spray combinations to create the

showering effect you desire. Use these spray options in coordination with the four sidesprays to further

customize your experience.

NOTE: The sidesprays are controlled individually and are not selected by the control dial.

The spray options, as shown in the illustration, include:

•both telescopic shower arms.

•the right telescopic shower arm alone.

•the left telescopic shower arm alone.

•the right telescopic shower arm and the personal handshower.

•the left telescopic shower arm and the personal handshower.

•the handshower alone.

Spray Option Control

Water and Temperature Control

Kohler Co. 5 1000706-5-D

Operation – Controls and Shower Arms

Adjust the Water Flow and Temperature

CAUTION: Risk of product damage. Do not force the handle in any direction. The shower valve

shuts off by water pressure.

Rotate the shower valve handle clockwise to turn on the water and set the water temperature.

To turn the valve off, gently turn the handle counterclockwise to the OFF position.

Select Spray Options

Rotate the transfer valve handle to select one of the six available shower settings.

Adjust the Telescopic Shower Arms

Adjust the height of the shower arms by gripping the shower arms and sliding them up or down.

The shower arms can also swing from side-to-side.

Rotate the easy-grip rings on the showerhead to change the spray pattern.

Counterclockwise

Shower Valve

Transfer Valve

OFF Position

Clockwise Open

Telescopic Shower Arms

Easy-Grip Rings

1000706-5-D 6 Kohler Co.

Operation – Sidesprays and Handshower

Adjust the Sidesprays

Adjust the position of the sidesprays by gently pulling out and sliding them up or down.

Rotate the easy-grip rings on the sidespray to change the spray pattern.

Adjust the Personal Handshower

Rotate the easy-grip rings on the showerhead to change the spray pattern.

Easy-Grip Rings

Pull out, then slide

up or down.

Sidespray

Easy-Grip Rings

Personal Handshower

Kohler Co. 7 1000706-5-D

Optional Temperature Limiting Adjustment

CAUTION: Risk of personal injury. The water temperature should never be set above 120°F

(49°C).

NOTE: Do not remove the O-ring and collar at this time. Removing the O-ring and collar will change the

factory setting for the maximum water temperature.

Remove the shower valve trim.

Minor Water Temperature Adjustment

Turn the setscrew.

Major Water Temperature Adjustment

Remove the O-ring and collar from the valve stem.

Slowly rotate the valve stem until the water temperature is 120°F (49°C) or less.

Reinstall the collar onto the valve stem so the setscrew is against the side of the tab as shown in the

illustration.

Reinstall the O-ring to the valve stem.

Turn the valve stem counterclockwise to turn the water off.

Verify New Temperature Setting

Turn the water on to full hot and recheck the water temperature to verify that the temperature is

still acceptable. Make adjustments as needed.

Reinstall the shower valve trim.

Tab

Collar

O-Ring

Setscrew

Valve Stem

1000706-5-D 8 Kohler Co.

Correcting Reduced Water Flow – Showerheads

If your showerheads begin to show reduced ﬂow or performance, follow these steps. If performance does not

improve, contact your local service representative.

Clean the Showerhead Spray Holes

With the water running, ﬁrmly rub the holes in the face of the showerhead to dislodge any mineral

build-up or debris. If this does not improve performance, follow the ″Clean the Aerator″steps

below.

Clean the Aerator

Turn off the water to the showerhead off.

Insert the showerhead tool (provided) into the holes in the face of the showerhead.

Turn the tool counterclockwise to loosen the aerator housing.

Carefully remove the aerator housing, aerator, gasket, and the aerator plate.

Clean both sides of the aerator.

Reinstall the aerator into the aerator plate.

Align the notches in the aerator plate with the raised ″keys″of the aerator housing.

Insert the aerator plate into the aerator housing.

Reinstall the rubber gasket into the aerator housing.

Carefully thread the aerator housing into the showerhead with the showerhead tool.

Clean the Showerhead Screen Washer

Using an adjustable wrench, carefully remove the collar and showerhead from the shower arm.

Gasket

Notches Aerator

Aerator Housing

Showerhead

Tool

Aerator Plate

Clean the Aerator

Shower Arm

Socket

Ball

Showerhead

Clean the Screen Washer

Collar

Screen Washer

Hose

Kohler Co. 9 1000706-5-D

Correcting Reduced Water Flow – Showerheads (cont.)

Firmly grasp the hose and turn the socket counterclockwise to loosen from the hose.

Remove the socket and screen washer from the hose.

NOTE: Do not attempt to remove the ﬂow control.

Clean the screen washer.

Reinstall the screen washer, tapered end ﬁrst, into the hose.

Securely hand tighten the socket to the hose.

Fit the collar over the ball.

Snap the ball into the socket.

Push the hose all the way into the shower arm.

Thread the collar to the shower arm. Carefully wrench tighten.

1000706-5-D 10 Kohler Co.

Other manuals for K-498

Table of contents

Languages:

Other Kohler Plumbing Product manuals

Kohler

Kohler K-2271 User manual

Kohler

Kohler K-8807 User manual

Kohler

Kohler COMPOSED K-25421T User manual

Kohler

Kohler K-4918 User manual

Kohler

Kohler K-13453 Operating manual

Kohler

Kohler K-10086 Assembly instructions

Kohler

Kohler K-9486 User manual

Kohler

Kohler K-8973 Assembly instructions

Kohler

Kohler K-169 User manual

Kohler

Kohler K-8855 User manual

Kohler

Kohler K-7128 Assembly instructions

Kohler

Kohler CUFF 37305M-4 Operation manual

Kohler

Kohler K-1124-G Quick start guide

Kohler

Kohler COUTURE ECO-LITE User manual

Kohler

Kohler K-411 User manual

Kohler

Kohler K-13108 Assembly instructions

Kohler

Kohler K-1110-G Quick start guide

Kohler

Kohler K-15003 User manual

Kohler

Kohler K-6130 Assembly instructions

Kohler

Kohler Loure K-15285 Assembly instructions

Kohler

Kohler C3-050 Assembly instructions

Kohler

Kohler 6625-0 User manual

Kohler

Kohler FAIRFAX 12177T-B User manual

Kohler

Kohler K-2313 User manual

Popular Plumbing Product manuals by other brands

Weka

Weka 506.2020.00E ASSEMBLY, USER AND MAINTENANCE INSTRUCTIONS

UBERHAUS DESIGN

UBERHAUS DESIGN 75175017 Operator's manual

American Standard

American Standard DetectLink 6072121 manual

Uponor

Uponor Contec TS Mounting instructions

Pfister

Pfister Selia 49-SL Quick installation guide

Fortis

Fortis VITRINA 6068700 quick start guide

Fortis

Fortis MILANO 78211JS installation instructions

Maxxus

Maxxus MX-M206-01 instruction manual

Moen

Moen 5922 Series installation instructions

Viega

Viega Prevista Pure 8512 Instructions for use

Viega

Viega Prevista Dry 8522.33 Instructions for use

Sanela

Sanela Lema SLP 59RB Instructions for use

Elkay

Elkay EDF15AC Installation, care & use manual

Hans Grohe

Hans Grohe AXOR Citterio E 36702000 Instructions for use/assembly instructions

baliv

baliv WT-140 manual

BELLOSTA

BELLOSTA romina 0308/CC Installation instruction

Bristan

Bristan PS2 BAS C D2 Installation instructions & user guide

Crosswater

Crosswater Heir 18-31 installation instructions
