Kitsound BOOGIE BUDDY User manual

USER MANUAL

JB. 6094-b / REG00 / Made in China. © KitSound is a trademark of

Kondor Limited, 2018. Christchurch, Dorset, BH23 4FL, UK

All trademarks are acknowledged as the property of their respective owners.

Unless otherwise stated their use does not imply that the trademark owner is

aliated with KitSound or endorses the products herein.

Products showing the ‘Crossed Through’ wheelie bin symbol must be recycled

separately from household waste at the end of their useful life. Please DO NOT

dispose of this appliance in normal household waste. Your local appliance

retailer may operate a ‘take-back’ scheme when you are ready to purchase a

replacement product, alternatively contact your local government authority for

further help and advice on where to take your appliance for recycling.

Please recycle this packaging responsibly.

BOOGIE BUDDY

BLUETOOTH®

SPEAKER

kitsound.co.uk

2 3

Please read this manual carefully before use.

Box contents

• KS Boogie Buddy Bluetooth speaker

• USB charge cable

• User manual

Functions

1. Multi-function button (MFB)

2. Volume+ / Next track

3. Volume– / Previous track

4. Micro USB charging port

5. LED indicator

6. Micro SD card slot

4 5

Pairing the speaker to your device

1. Press the MFB (1) to turn the speaker on. It will enter

pairing mode, with the LED indicator (5) ashing

blue quickly

2. Turn your iOS, Android, or Windows device’s Bluetooth

ON and search for new devices

3. Select ‘KS Boogie’. If asked for a passcode, enter

‘0000’, and the device will pair. The LED indicator (5)

will be solid blue once device paired

Instructions for use

Charging the speaker

Give the speaker a full charge before its rst use.

1. Connect the USB charging cable supplied, to the

Micro USB charging port (4) and plug into power

2. The LED indicator (5) will be red whilst charging which

will take up to 2 hours

3. Once fully charged the LED indicator (5) will turn o

Note: Allow up to 3 hours for the rst charge.

[continued...]

6 7

Re-pairing or pairing new devices

1. Turn Bluetooth connectivity o on any previously

paired devices

2. Follow the ‘Pairing the speaker to your device’ instructions

3. If a previously paired device is not present within the

Bluetooth range then the speaker will re-enter

pairing mode

Call handling

Answer a call short press MFB (1) to answer

Decline a call long press MFB (1) to decline

Using a micro SD card to play music on

your speaker

1. Press the MFB (1) to turn the speaker on. Insert a micro

SD card into the Micro SD card slot (6)

2. The music on the micro SD card will automatically begin

to play

3. If you want to switch back to Bluetooth mode – double

click the MFB (1) and follow the ‘Pairing the speaker to

your device’ instructions

8 9

Playing music on your speaker

When connected via Bluetooth, play the music on your

device and the sound will play through the speaker.

Some devices may require you to select the audio output.

Play/Pause Press MFB (1)

Volume+/– Short press Volume+ (2) or

Volume– (3). The volume can

also be adjusted on your device

Track change Long press Next track (2) or

Previous track (3). You can also

skip tracks on your device

Please note:

Your device will have an internal amplier and if it is playing

digital les like MP3s it will also have an integrated DAC

(Digital Audio Converter). If you turn the volume up to 100%,

your device will be sending a distorted signal. To avoid this,

and to get the best quality from the speaker, we recommend

that you do not run your device any higher than 95% volume.

Some devices output higher than others, so you may need

to reduce the volume if you experience distortion.

10 11

Care for your Boogie Buddy

Please DON’T:

• Submerge the Boogie Buddy speaker in water

• Drop the Boogie Buddy speaker as this will invalidate

your warranty

• Open up the Boogie Buddy speaker. There are no user

serviceable parts inside

• Expose the Boogie Buddy speaker to extreme temperatures

or rapid changes of hot to cold or vice versa

• Place naked ame sources, such as lighted candles, on or

near the Boogie Buddy speaker

• Expose the batteries (battery pack or batteries installed)

to excessive heat such as direct sunlight, re or other

sources of high temperature

Please DO:

• Clean the Boogie Buddy speaker with a soft dry cloth and

no detergents

• Pay attention on environmental aspect of battery disposal

Bluetooth®technology v4.1

Bluetooth connectivity distance up to 10 m

S/N ≥ 85 dB

Frequency response 150 Hz – 20 kHz

Drivers 1 x 40 mm

Play time up to 3 hours

Charge time up to 2 hours

Maximum micro SD card size 32 GB

Transmission frequency 2402 – 2480 MHz

Transmission power 0 dBM

Specications

12 13

Troubleshooting

We hope you’ve now got all the information you need to get

started, but if you’re having problems with anything, please

feel free to contact us at: support@kitsound.co.uk

Hereby, Kondor Ltd declares that the radio equipment

type, KSBOG Boogie Buddy Bluetooth speaker,

is in compliance with Directive 2014/53/EU.

The full text of the EU declaration of conformity is

available at the following internet address:

http://kondor.co.uk/product-documents

The use and operation of this speaker is beyond our control. Warranty of the

KS Boogie Buddy is limited to defects caused by faulty manufacture or

defects in materials only. No warranty whatsoever is given or implied for

damage caused by the user under any circumstances.

This does not aect your statutory rights.

Please do not attempt to open this product. There are no user serviceable

parts inside, in particular if your product has an embedded, non-replaceable

battery, do not attempt to access or remove the battery as this may cause

personal injury and will damage the product.

Making any attempt to open the product or carry out repair voids any and

all warranties.

We apologise for any inconvenience caused by minor inconsistencies in

these instructions, which may occur as a result of product improvement

and development.

The Bluetooth®word mark and logos are registered trademarks owned by the

BluetoothSIG, Inc. and any use of such marks by Kondor Ltd. is under license.

Other trademarks and trade names are those of their respective owners.
