KitchenAid 5KHBV53Z User manual
Corded Hand Blender
5KHBV53Z, KEB53AXANA
7KHBV53Z, KEB53AXBNA
W11433660A.indb 1W11433660A.indb 1 23-06-2020 12:03:1223-06-2020 12:03:12
2
PARTS AND FEATURES
1Variable Speed Controller
2Speed Controller Guard
3Motor Body
4
Blending Arm 8" (20.3 cm)
5Pan Guard - Use the Pan Guard to
avoid damage to cookware while
using the Hand Blender
6Mounting Clips
7Power Cord (5 ft.)
8
3 Cup (700 ml) BPA
-
free Blending Jar
with Lid
5
4
3
1
2
7
8
6
W11433660A.indb 2W11433660A.indb 2 23-06-2020 12:03:1323-06-2020 12:03:13
ENGLISH
3
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be
followed, including the following:
1. Read all instructions. Misuse of appliance may result in personal injury.
2. To protect against risk of electrical shock do not put Motor Body, Cord, or
electrical plug of this Hand Blender in water or other liquid.
3. This appliance is not intended for use by persons (including children) with
reduced physical sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance in a safe way by a person responsible for their safety and if
they understand the hazards involved.
4. This appliance should not be used by children and care should be taken when
used near children. Children should be supervised to ensure that they do not
play with the appliance.
5. Avoid contacting moving parts.
6. Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions, or is dropped or damaged in any manner. Contact the
manufacturer at their customer service telephone number for information on
examination, repair, or adjustment.
7. The use of attachments not recommended or sold by the manufacturer may
cause fire, electric shock, or injury.
8. Be certain the Chopper Adapter is securely locked in place before operating
appliance.
9. Be careful if hot liquid is poured into the Food Processor or Blender as it can be
ejected out of the appliance due to a sudden steaming.
10. Turn the appliance OFF, then unplug from the outlet when not in use, before
assembling or disassembling parts and before cleaning. To unplug, grasp the plug
and pull from the outlet. Never pull from the Power Cord.
PRODUCT SAFETY
W11433660A.indb 3W11433660A.indb 3 23-06-2020 12:03:1423-06-2020 12:03:14
4
11. Do not use the appliance outdoors.
12. Do not let cord hang over edge of table or counter. Keep the appliance and its
cord out of reach of children.
13. Do not let cord contact hot surfaces, including the stove.
14. When mixing liquids, especially hot liquids, use a tall container or make
small quantities at a time to reduce spillage.
15. Keeps hands and utensils out of the container while blending to prevent the
possibility of severe injury to persons or damage to the unit. A scraper may be
used but must be used only when the unit is not running.
16. Blade is sharp, handle carefully. Care shall be taken when handling sharp
cutting blades, emptying the bowl, and during cleaning.
17. To disconnect, turn any control to “OFF,” then remove plug from wall outlet.
18. Refer to the “Care and Cleaning” section for instructions on cleaning the
surfaces in contact with food.
19. If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
20. This appliance is intended to be used in household and similar applications such
as:
- staff kitchen areas in shops, offices, or other working environments;
- farmhouses;
- by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments.
SAVE THESE INSTRUCTIONS
PRODUCT SAFETY
W11433660A.indb 4W11433660A.indb 4 23-06-2020 12:03:1423-06-2020 12:03:14
ENGLISH
5
ELECTRICAL REQUIREMENTS
5KHBV53Z, KEB53AXBNA
Voltage: 220 V
Frequency: 60 Hz
Wattage: 180 W
7KHBV53Z, KEB53AXANA
Voltage: 127 V
Frequency: 60 Hz
Wattage: 180 W
NOTE: If the plug does not fit in the
outlet, contact a qualified electrician. Do
not modify the plug in any way. Do not use
an adapter.
Do not use an extension cord. If the power
supply cord is too short, have a qualified
electrician or service technician to install an
outlet near the appliance.
The cord should be arranged so that it will
not drape over the countertop or tabletop
where it can be pulled on by children or
tripped over unintentionally.
NOTE: Maximum rating is based on
the chopper accessory, included with
KitchenAid model 5KHBV83.
Other attachments may draw different
power or current.
PRODUCT SAFETY
Electrical Shock Hazard
Plug into an earthed outlet.
Do not remove earth prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these
instructions can result in
death, fire, or electrical shock.
W11433660A.indb 5W11433660A.indb 5 23-06-2020 12:03:1423-06-2020 12:03:14
6
PRODUCT USAGE
Before first use, clean all parts (see “Care and Cleaning” section).
IMPORTANT: Always unplug the Hand Blender, before attaching or removing parts.
Insert the Blending Arm into the Motor
Body and twist until it clicks to lock in
place.
1
If using a Pan Guard, place it on a flat
surface.
To insert the Pan Guard, angle the
Blending Arm to one side of the
mounting clip. Then, gently pull the other
mounting clip outward and push down
the Blending Arm. Ensure the Mounting
Clips are secured into place.
2
ASSEMBLING THE BLENDING ARM
NOTE: U.S. patent pending removable
Pan Guard to help protect your
cookware.
W11433660A.indb 6W11433660A.indb 6 23-06-2020 12:03:1523-06-2020 12:03:15
ENGLISH
7
USING THE BLENDING ARM
Use for smoothies, milkshakes, soup, cooked vegetables, frosting, or baby food, etc.
Plug the Hand Blender into an earthed
electrical outlet.
1
Insert the Hand Blender into the mixture.
Press the Variable Speed Controller to
start.
Use your free hand to cover the top of
the blending jar for better stability and
avoid splashing.
NOTE: Do not immerse Motor Body into
liquids or other mixtures.
2
Blending
PRODUCT USAGE
Use the draw up motion with the Hand
Blender to move the ingredients within
the Jar.
Slowly draw it upwards against the side
of the Jar. Repeat the process until the
ingredients are at the desired consistency.
3
With your wrist, make a circular motion to
draw the Hand Blender up slightly and let
it blend again into the ingredients.
4
Drawing up Wrist
movement
W11433660A.indb 7W11433660A.indb 7 23-06-2020 12:03:1723-06-2020 12:03:17
8
PRODUCT USAGE
CARE AND CLEANING
Dishwasher safe parts - top rack only:
Blending Jar, Lid, Blending Arm and Pan
Guard in the top rack.
Wipe the Motor Body with a damp cloth.
Mild dish soap may be used, but do not
use abrasive cleansers.
IMPORTANT: Always unplug the Hand Blender before attaching or removing parts.
For detailed information on the Hand Blender:
Visit www.kitchenaid.com.br/quickstart for additional instructions with videos, inspiring
recipes, and tips on how to use and clean your Hand Blender.
12
NOTE: Chopper and Whisk accessories included with KitchenAid Model 5KHBV83 can
be used on this model.
Release the Variable Speed Controller to
stop; then remove Hand Blender from
mixture.
Unplug the Hand Blender before
removing or attaching the parts.
5
W11433660A.indb 8W11433660A.indb 8 23-06-2020 12:03:1823-06-2020 12:03:18
ENGLISH
9
TROUBLESHOOTING GUIDE
Problem Solution
If the Hand Blender fails to
start:
Check to see if the Hand Blender is securely plugged
into an earthed electrical outlet.
If you have a circuit breaker box, check to make sure
that the circuit is closed.
If the Hand Blender stops while
blending:
When overloaded or jammed, it will automatically shut
off to prevent motor damage. Divide contents into
smaller batches. For certain recipes, adding liquid in
the Jar may also reduce the load.
If the problem cannot be
corrected:
See the “Product Warranty” section.
Do not return the Hand Blender to the retailer.
Retailers do not provide service.
©2020 All rights reserved.
