Intermec EasyCoder 301 User manual

EasyCoder 301

Paper Cutter Kit

P/N 1-960457-00

Edition 1

April 1999

Installation Instructions

Intermec EasyCoder 301 Paper Cutter– Installation Instructions Ed. 1

Paper Cutter

Description

The EasyCoder 301 can easily be fitted with an optional Paper

Cutter. The cutter unit is fitted on the same hinges as the front

door,whichitreplaces,andisconnectedbyasinglecabletothe

upper-most connector on the printer's front.

The paper cutter is available as a field-installable upgrading kit

only.

The paper cutter is intended to cut through continuous non-

adhesive paper strip or through the backing paper between

labels. It must not be used to cut through any kind of adhesive

or other soft material, that may stick to the cutting parts and

render the cutter inoperable, which may damage the electric

motor.

Allowedpaperthicknessis60µm–175µm(≈60–175grammes/

m2) for normal paper-based materials.

Minimum practical copy length is 38.1 mm (1.5").

The Paper Cutter increases the printer’s total weight to approx.

5.6 kgs (= 15 lbs) and its length to 396 mm (15,6").

The Paper Cutter can be tilted forward in order to facilitate

cleaning and paper load. A microswitch prevents unintentional

cutting operations when the cutter is tilted forward.

The printer's built-in label-taken sensor does not work in con-

nection with a cutter.

Note!

Thecutterwillreturntohomepositionwhenthepoweristurnedonandwhen

the printer is rebooted. During firmware update, the cutter will perform

repeated cutting operations. It is therefore recommended to disconnect the

cutter'scablefromtheprinter'sfrontbeforetheprinter'sfirmwareisupdated.

EasyCoder 301 Paper Cutter

Installation Instructions

Edition 1, April 1999

Part No. 1-960457-00

Power

Feed

Intermec EasyCoder 301 Paper Cutter– Installation Instructions Ed. 1

Paper Cutter

The cutter is activated by CUT or CUT ON instructions in the

EasyCoder 301 Direct Protocol.

The following values are recommended for cutting between

labels and for variable length strip. In both cases, the start

adjustment is calculated to allow the paper web be pulled back

after cutting, so printing can start directly at the forward edge.

Labels:

Start adjust ....................................: -250

Stop adjust ....................................: +100

Strip:

Start adjust ....................................: -250

Stop adjust ....................................: +180

• Turn off the main switch and remove the power cord and

interface cable.

• Open the printer's front cover

• Turn the printer upside down and use a piercer to pry out the

two L-shaped hinge pins that hold the front cover.

• Remove the front cover completely.

Controlling the

Cutter

Installation

Hinges

Front Cover

(open)

Intermec EasyCoder 301 Paper Cutter– Installation Instructions Ed. 1

Paper Cutter

Installation,

cont'd.

• Fit the two hooks at the rear of the cutter unit on either side

of the tear off edge and press down firmly.

• Theholesinthetabsatthebottomofthecutterunitshouldbe

aligned with the hinges on the bottom moulding.

• Insert the hinge pins as shown above.

• Connect the cable from the cutter to the upper (circular) one

of the two connectors on the printer's front.

• Thread the paper through the slot in the cutter.

• Close the cutter, connect the interface cable and power cord

and, finally, turn on the power.

Intermec EasyCoder 301 Paper Cutter– Installation Instructions Ed. 1

Paper Cutter

Information in this manual is subject to change without prior notice and does not represent a

commitment on the part of Intermec Printer AB.

EasyCoder is a trademark of Intermec Technologies Corp.

Cleaning on a regular basis is required for trouble-free opera-

tion. Should the cutter inadvertently have been used to cut

through any adhesive, you should clean the cutter immediately.

Tilt down the cutter and use a cotton swab moistened with

isopropyl alcohol, or a similar solvent, to wipe clean cutting

parts.

Cleaning
