Hunter 44905 User manual
Owner’s Manual
Model
44905
Form# 44050-01
20100603
©2010 Hunter Fan Co.
English
7 Day Programmable
I N S T A L L A T I O N
5 MINUTE
M T WT F S S
44040-01 • 03/24/2010
2
Table Of Contents
At A Glance
Know Your ermostat .............................................................3
Setup
Setting Day, Time, and System ......................................................8
Scheduling
Scheduling Introduction ...........................................................10
Setting Your Schedule .............................................................12
Temporary Temperature Change ..................................................18
Turning Off Scheduling ............................................................20
Home Today. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Save Away .........................................................................24
Features
Alerts ..............................................................................26
Menu Options .....................................................................30
Advanced Menu Options .........................................................34
Energy Saver Bar ...................................................................46
Additional Features ...............................................................48
ermostat Assistance
Troubleshooting and Support .....................................................50
Technical Support .................................................................52
Warranty
1 Year Guarantee ..................................................................53
©2010 Hunter Fan Company 3
Your thermostat has been pre-programmed from the factory with no programming necessary.
We recommend using these pre-programmed settings for a few days before altering them as
they offer maximum energy saving benets. If you do decide to alter your programs, use the
charts on page 11 to write out your scheduled times and temperatures. After you have recorded
your preferences, follow the instructions on page 12 to alter your temperature settings.
There is no need to program the thermosat at the wall where it is mounted! Remove the thermostat
from the backplate by gripping the sides rmly and pulling it straight off. This allows you to
program the thermostat in comfort.
After you have programmed your thermostat, no other setting changes are necessary unless you
wish to browse through the menu to see how you may further adjust the independent settings of
your thermostat to meet your lifestyle. The features section starting on page 30 of this manual will
describe these settings. All settings have been preset for optimal performance.
If you need any assistance with installation or setup of your new Hunter Thermostat, please call
us, our technical support staff is ready to help!
USA: 1-888-830-1326
Canada: 1-866-268-1936
Hours of operation are from 7:00 am to 7:00 pm Monday - Friday and 8:00 am to 5:00 pm on
Saturday, Central Time. You may also contact us over the Internet at:
www.hunterfan.com
3Know Your ermostat
At A Glance
44040-01 • 03/24/2010
4
3
At A Glance
1. Returns you to the Home screen.
2. Main display.
3. Allows access to scheduling options.
4. Adjusts time and temperature settings as well as moving up or down menu lists.
5. Allows access to the advanced features of the thermostat.
6. Escapes to the home screen or resumes normal schedule from overrides.
7. Moves you back to the previous step while setting up features or schedules.
8. Sets the Home Today feature for when you are home during a regularly scheduled away
period.
9. Allows you to turn on or off your set schedules.
10. Sets the Save Away feature for when you will not be home during a regularly programmed
time.
11. Takes you to the next step while setting up features or schedules.
12. Conrms completion of an action or returns you to the Home screen.
13. Indicates whether the system is set to Auto, Cool, Off, or Heat.
14. Shows if the fan is set to Auto, Refresh, or On modes.
15. Allows you to switch between Auto, Cool, Off, or Heat modes.
16. Allows you to switch between fan Auto, Refresh, and On modes.
Know Your ermostat
©2010 Hunter Fan Company 5
At A Glance
3Know Your ermostat
Auto
Heat to
Energy Savings:
Good Best!
At home
Next
Back
Cancel
Resume
Home
Today Save
Away
Done
Turn
Schedule
On Off
Home
Schedule
Menu
C
OO
AUTOCOOL HEAT AUTOREFRESH ONOFF
Friday 10:53 AM
Schedule Running - At Home
70 73
1
8
5
4
3
2
7 119 106 12
13 14
15 16
44040-01 • 03/24/2010
6
3
At A Glance
1. Will show when your thermostat or system is reporting a problem.
2. Displays time/day, instructions, help messages, and warnings.
3. Indicates help messages are available for this screen.
4. Shows when the thermostat is on the Home screen.
5. Indicates you are in scheduling options.
6. Shows the current mode of the fan: Auto, Refresh, On, or Off.
7. Indicates the current room temperature.
8. C will display when in Celsius mode. Nothing will display when set to Fahrenheit.
9. On when the current operating mode, Heat or Cool, is running.
10. Current operating mode, Heat or Cool.
11. Indicates the active schedule period.
12. Shows the system fan is running.
13. Current Set temperature.
14. Indicates you are in the Menu options.
15. Energy Savings Bar helps you make decisions on conserving energy.
16. Indicates the thermostat is locked and will not accept input without a passcode.
Know Your ermostat
©2010 Hunter Fan Company 7
At A Glance
3Know Your ermostat
Energy Savings:
Good Best!
Auto Heat to
73
At home
70O
O
FRIDAY 10:53 AM
SCHEDULE RUNNING - AT HOME ?
1
3
7
9
2
15 16
6
4
5
11 12
8
10
13
c
14
44040-01 • 03/24/2010
8
4
Setup
Setting Day, Time, and System
Once you install the batteries, the thermostat will prompt you to set the current date,
time, and system type.
1. “01” for current day will be ashing. Use the or button to select your current day,
then Next to move to month, and then year, until each is set. Next will advance you to time
setup.
2. Use the the or buttons to set the current time of day, AM or PM and then use Next to
advance to hours, and again to set minutes. Pressing Next again will advance you to system
setup.
3. Press [conventl] or [heat pump] to select your system type. You may also use the or
buttons to make your selection.
Note: At anytime, if you see the ? icon on the screen, you can press it for more
information about that setup, scheduling step, or menu option.
4. If you selected [conventl], select [gas/oil] or [electric] as your furnace type.
Note: Furnace type should be [electric] for heat pump systems.
5. Press Next . Choose [Schedule] if you want to setup your schedules or [manual] to set
one temperature and ignore scheduling. Press Next and See “Setting Your Schedule”
on page 12 if you chose [Schedule] or use the or buttons to set your temperature
and press
Done
for [manual] mode.
©2010 Hunter Fan Company 9
4Setting Day, Time and, System
Setup
Home
Menu
Schedule
Set current date
01/01/2010
Next
1
Home
Menu
Schedule
Set current time
00:00 AM
Back
Next
2
pick system type
[ conventl] [ heat pump]
Back
Next
3
?
Home
Menu
Schedule
Pick Furnace type
[ gas/oil] [ electric]
Back
Next
4
?
44040-01 • 03/24/2010
10
* The schedule time can be set in 15 minute increments, and remains the same for both
Heat and Cool programs.
* The scheduled temperature can be set in increments of 1°F (1°C).
* After 10 minute without a key press, the thermostat will return to the home display
screen.
* When setting the schedule time, note the AM / PM indicator.
* At any stage during your scheduling, you can use the Back or Next buttons to move
forward or backwards through the steps. Home/
Done will save any changes, even if you have
not scheduled or altered all settings.
* Arrows beside each schedule mode and beside heat/cool modes will indicate which
ones are active.
* A [Brackets] around a word in the message window at the top indicates it can be
pressed as a button.
* If the ? shows up on the screen, pressing it will give you more information about
that step.
Read the scheduling section thoroughly to ensure you understand your scheduling options and
which will best t with your lifestyle. The following notes should help you with scheduling:
5
Scheduling
Scheduling Introduction
