HP Compaq d330 DT Manual

Chassis Identification Guide

Compaq, HP Compaq, and HP Business PCs

Document Part Number: 376216-004

November 2005

This document allows you to identify different HP and Compaq chassis by presenting

illustrations of the chassis along with chassis name and the geographic region in which it is

available.

HP, Hewlett Packard, and the Hewlett-Packard logo are trademarks of Hewlett-Packard Company in the U.S. and

other countries.

Compaq and the Compaq logo are trademarks of Hewlett-Packard Development Company, L.P. in the U.S. and

other countries.

Intel, Pentium, Intel Inside, and Celeron are trademarks of Intel Corporation in the U.S. and other countries.

All other product names mentioned herein may be trademarks of their respective companies.

Hewlett-Packard Company shall not be liable for technical or editorial errors or omissions contained herein or for

incidental or consequential damages in connection with the furnishing, performance, or use of this material. The

information in this document is provided “as is” without warranty of any kind, including, but not limited to, the

implied warranties of merchantability and fitness for a particular purpose, and is subject to change without notice.

The warranties for HP products are set forth in the express limited warranty statements accompanying such

products. Nothing herein should be construed as constituting an additional warranty.

This document contains proprietary information that is protected by copyright. No part of this document may be

photocopied, reproduced, or translated to another language without the prior written consent of Hewlett-Packard

Company.

ÅWARNING: Text set off in this manner indicates that failure to follow directions could result in bodily

harm or loss of life.

ÄCAUTION: Text set off in this manner indicates that failure to follow directions could result in damage to

equipment or loss of information.

Chassis Identification Guide

Compaq, HP Compaq, and HP Business PCs

First Edition (October 2004)

Fourth Edition (November 2005)

Document Part Number: 376216-004

Chassis Identification Guide 376216-004 iii

Contents

1 Desktop Computers

2 Ultra-Slim Desktop Computers

3 Convertible Minitower Computers

4 Small Form Factor Computers

5 E-PC Computers

6 Microtower Computers

7 Slim Tower Computers

iv 376216-004 Chassis Identification Guide

Contents

Chassis Identification Guide 376216-004 1–1

Desktop Computers

■Compaq Evo D300 DT (Worldwide)

■Compaq Evo D500 DT (Worldwide)

■HP Compaq d330 DT (EMEA and APJ only)

1–2 376216-004 Chassis Identification Guide

Desktop Computers

Chassis Identification Guide 376216-004 2–1

Ultra-Slim Desktop Computers

■Compaq Evo D500 USDT (Worldwide)

■Compaq Evo D510 USDT (Worldwide) ■HP Compaq d530 USDT (Worldwide)

■HP Compaq dc7100 USDT (Worldwide)

■HP Compaq dc7600 USDT (Worldwide)

2–2 376216-004 Chassis Identification Guide

Ultra-Slim Desktop Computers

Chassis Identification Guide 376216-004 3–1

Convertible Minitow erComputers

Convertible Minitower Computers

■Compaq Evo D300 CMT (Worldwide)

■Compaq Evo D500 CMT (Worldwide)

■HP Compaq d538 CMT (China only) ■HP Compaq d530 CMT (Worldwide)

■HP Compaq dc7100 CMT (Worldwide)

■HP Compaq dc7600 CMT (Worldwide)

■Evo D510 CMT (Worldwide)

3–2 376216-004 Chassis Identification Guide

Convertible Minitow erComputers

■HP Compaq dc7608 CMT (China only)
