Hikvision Technical Manual

DS-2DF1-574D

Key feature

System function:

1/3" SONY high performance sensor, up to 1280x960 resolution

±0.1°Preset Accuracy

CGI(Common Gateway Interface)、PSIA(Physical Security Interoperability Alliance), to ensure greater

interoperability between different platforms and compatibility

3D intelligent positioning function

Power-off memory function: restore PTZ & Lens status after reboot

IP66 standard (outdoor dome)

3D DNR

Fiber optical interface optional

Scheduled PTZ movement

Camera function:

Auto iris, auto focus, auto white balance, backlight compensation and auto day & night switch

PTZ function:

360°endless pan range and -5°-90°tilt range

540°/s Pan Preset Speed and 400°/s Tilt Preset Speed

0.1°-300°/s Manual Pan Speed and 0.1°-240°/s Manual Tilt Speed

256 presets programmable, preset image freezing capability

8 patrols, up to 32 presets per patrol

4 patterns, with the recording time not less than 10 min per pattern

Park action: auto callup of PTZ movement, after a defined time of inactivity

7 alarm inputs and 2 alarm outputs

Network function:

H.264/MJPEG video compression and the latest DaVinci processing chip and platform

Built-in Web server

SD/SDHC card local storage

Dual stream

Multiple network protocols supported: TCP/IP,HTTP,DHCP,DNS,RTP/RTCP,RTSP,PPPoE,SMTP,NTP(FTP,SNMP

optional )

Hikvision Technical Manual

1 audio input and 1 audio output

Application Scenarios

It can be widely applied to places requiring wide-area monitoring and high-definition display, such as rivers, forests,

highways, railways, airports, ports, sentries, squares, parks, scenic sites, streets, stations, large venues, outside of

residential areas, etc

Specification

Model

Parameter

DS-2DF1-574D(Outdoor)

DS-2DF1-5704D(Indoor)

DS-2DF1-5734D(In-ceiling)

1.3 Megapixel 5 Inch Network High Speed Dome

Camera

Image Sensor

1/3’’ Progressive Scan CMOS

Effective Pixel

1300K pixels

Min.Illuminati

Color: 0.05Lux@( F1.4, AGC ON)

B/W: 0.005Lux@( F1.4, AGC ON)

White Balance

Auto / Manual / One Touch WB / ATW

AGC

Auto / Manual

S / N Ratio

≥ 50dB

DNR

off/normal/expert

BLC

On / Off

Shutter Time

50HZ: 1/25-1/100,000s

60HZ: 1/30-1/100,000s

Day & Night

IR Cut Filter

Digital Zoom

一

Privacy Mask

24 privacy masks programmable

Focus Model

Auto / Semiautomatic / Manual

Lens

Focal Length

4.3-86.0mm, 20x

Zoom Speed

Approx.5s(Optical Wide-Tele)

Angle of View

54.1-3.2 degree (Wide-Tele)

Min. Working

Distance

10-1,500mm(Wide-Tele)

Aperture

Range

F1.4- F2.6

Pan and

Tilt

Pan Range

360°endless

Pan Speed

Pan Manual Speed: 0.1°-300°/s,

Pan Preset Speed: 540°/s

Tilt Range

-5°-90°(Auto Flip)

Tilt Speed

Tilt Manual Speed: 0.1°-240°/s,

Tilt Preset Speed: 400°/s

Hikvision Technical Manual

Proportional

Zoom

Rotation speed can be adjusted automatically according to zoom multiples

Number of

Preset

256

Patrol

8 patrols, up to 32 presets per patrol

Pattern

4 patterns, with the recording time not less than 10 min per pattern

Power-off

Memory

Support

Park Action

Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan

PTZ Position

Display

On / Off

Freeze Frame

Support

Alarm

Alarm Input

Alarm Output

2 relay outputs, alarm response actions configurable

Alarm Actions

Preset, Patrol, Pattern, SD/SDHC card recording, Relay output, Notification on Client

Input/

Output

Monitor

Output

1.0V[p-p] / 75Ω, NTSC (or PAL) composite, BNC

Audio Input

Audio input (Line input), 2-2.4V[p-p]; output impedance: 1KΩ, ±10%

Audio Output

Line level, impendance: 600Ω

Networ

Ethernet

10Base-T / 100Base-TX, RJ45 connector

Max.Image

Resolution

1280×960

Frame Rate

50HZ:25fps(1280×960P), 25fps (1280×720P)

60HZ:30fps(1280×960P), 30fps (1280×720P)


Compression

H.264

Audio

Compression

G.711 / 16kbps

Audio Mode

Off / Audio input / Audio output

Protocols

TCP/IP,HTTP,DHCP,DNS,RTP/RTCP,RTSP,PPPoE,SMTP,NTP(FTP,SNMP optional )

No. of

Simultaneous

Users

Up to 6 users

Dual Streams

Support

Mini SD

Memory Card

Manual REC / Alarm REC.

Built-in SD/SDHC Slot, up to 32GB

User/Host

Level

3 Levels: Administrator, Camera control, Live view only

Security

Measures

User authentication (ID and PW),

Host authentication (MAC address)

Client

Camera

Pan /Tilt, Zoom, Focus, Click centering, Drag zoom, Iris, Preset position call and program, Auto mode.

Hikvision Technical Manual

GUI

Control

Camera Name

Up to 18 characters

Date & Time

Display

Time: Week: Date, 6 formats on the Client

Reading

Patrol

Message

Display and reading of preset message contained in each patrol via client software

Fiber

Optical

Interfac

(availab

le for

fiber

dome

only)

Data Mode

10Base-T / 100Base-TX

Physical

Interface

FC(SC optional)

Fiber

Wavelength

TX1310/RX1550nm

Fiber Type

Single Fiber/Singlemode

Transmission

Distance

20Km, 40Km / 60Km/ 80Km optional

General

Language

English

RS-485

Protocols(opti

onal)

HIKVISION, Pelco-P, Pelco-D, self-adaptive

Power Supply

24VAC (12V DC optional)

Power

Consumption

Outdoor dome:Max.45 W(Max.25 W with heater on)

Indoor/In-ceiling dome:Max.20 W

Working

Temperature

/ Humidity

-30 ℃-65℃(-22℉-149℉)(outdoor dome) / -10℃-50℃(14℉-122℉)(indoor dome )

90% or less

Protection

Level

IP66 standard (outdoor dome)

TVS 3,000V lightning protection, surge protection and voltage transient protection

Mounting

Various mounting modes optional

Dimension

Φ220×299.2mm (Φ8.66”×11.78”)(Outdoor)

Φ183.4×247mm(Φ7.22”×9.72”) (Indoor)

Φ245×240mm(Φ9.65”×9.45”) (In-ceiling)

Weight

(approx.)

5Kg (11.02Ibs)

Mount Option

Long-arm wall mount: DS-1614ZJ; Indoor short-arm wall mount: DS-1615ZJ

Corner mount: DS-1633ZJ; Pole Mount: DS-1622ZJ;Power box mount:DS-1634ZJ

Hikvision Technical Manual

Dimension

Outdoor Indoor In-ceiling

Bore Size

Unit: mm

Accessories

DS-1614ZJ Long-arm Wall Mount Bracket
