11 EN
Useful information
C
10 EN
Using the appliance
B
Clothing type
Approximate
residual
moisture
level
Capacity
(kg) Programmes Drying level NOTE
Cotton
70% 7/3.5/1 Cotton Extra Please
select the
programme
and drying
degree
according to
the type of
clothes and
capacity.
60% 7/3.5/1 Cotton Standard
7/3.5 Cotton Low
Blend 70% 7/3.5/1 Blend Extra
60% 7/3.5/1 Blend Standard
Synthetics 50% 3.5/1 Synthetics Extra
40% 3.5/1 Synthetics Standard
Cotton ______ 1 1 hour ______
NOTE
• The cold air function means that only cold air is blown in for 3 minutes before the
drying process is completed. (Excluding the 1-hour programme, which activates
cold air for 10 minutes).
• When the Anti-crease option is selected, the cycle can take up to 2 hours. When
not selected, the cycle takes 30 minutes less.
• Both the indoor temperature and humidity have an impact on the drying time.
• Refer to the label on your clothes to select the time and temperature according
to the instructions.
• Recommendation:
when the weight of the loaded laundry is less than 0.5 kg, select the 1-hour
programme and the Extra function.
Drying programme table
Cleaning the filter
• Clean the filter after each use.
• Pull up to remove it.
• Cleaning the filter
Use a cloth or your fingers.
• Reinsert the filter
If the filter is cleaned with a damp cloth or water, let it dry before reinstalling it.
Cleaning the machine body and drum
• Clean the body and inner drum with a soft damp cloth.
• Do not rinse directly with water.
• Do not use a scouring product.
• Do not use spirits or alcohol.
• Be sure to leave the appliance door open for ventilation after cleaning the drum.
Safety Reset
•
This dryer has an integrated safety circuit breaker that is activated depending on the
temperature.
• The safety reset button is located on the back of the unit. If your dryer stops drying, this
button must be pressed before the dryer can be operated again. You must wait 10 minutes
for the appliance to cool down completely.
• Overheating is most often caused by a clogged filter.
• Clean the filter after each use to prevent the appliance from overheating.
The circuit breaker may trip for the following reasons:
• The filter is clogged.
• The exhaust vents at the back of the unit are clogged.
• There is insufficient ventilation within the laundry room. Open a window or door.
• A small piece of cloth, such as a handkerchief, has passed into the filter.
Safety reset button
With your finger or a pen, press the button until you feel the “click”.
Cleaning and maintenance
