HERO HF-DELUXE PROGRAMMED FI User manual
PREFACE
Let us make this world a safer, healthier and more environment friendly place.
Thank you for selecting a We wish Hero MotoCorp HF-DELUXE PROGRAMMED FI.
you many miles of continued riding pleasure in the years ahead.
We, at Hero MotoCorp, are committed to demonstrate excellence in our environment
performance on a continual basis, as an intrinsic element of our corporate philosophy. To
achieve this we commit ourselves to continue product innovations to improve environment
compatibility, comply with and all applicable legislation including environment legislation
strengthen the green supply chain.
Your Authorised dealer will be glad to provide further information or Hero MotoCorp
assistance and is equipped to handle your future service needs.
Your vehicle is conforming to latest (Bharat stage- norms) regulation for emission, safety & VI
noise levels. We are also using non asbestos brake shoes/pads and engine gaskets which are
environment friendly in nature.
This booklet is your guide to the basic operation and maintenance of your new Hero
MotoCorp HF-DELUXE PROGRAMMED FI. Please take time to read it carefully. As with
any fine machine, proper care and maintenance are essential for trouble-free operation and
optimum performance.
This vehicle is fitted with a lighting feature known as “Automatic Headlamp ON”. The feature
is mandated for all 2 Wheelers by Ministry of Road Transport & Highways (Government of
India) vide notification GSR 188 (E) dated 22nd February 2016. This feature helps in
conspicuity for improving rider safety. The headlamp of this vehicle will always be lit ON when
the engine gets ON.
ALL INFORMATION, ILLUSTRATION, PHOTOGRAPH, DIRECTIONS,
SPECIFICATIONS AND OTHER CONTENTS COVERED IN THIS OWNER'S
MANUAL ARE BASED ON THE LATEST PRODUCT INFORMATION AVAILABLE
AT THE TIME OF ITS PRINTING APPROVAL, AND THE ACCURACY OR
CORRECTNESS OF THE SAME IS NOT UNDERTAKEN OR GUARANTEED.
Hero MotoCorp Ltd RESERVES THE RIGHT TO MAKE CHANGES IN ITS
CONTENTS AT ANY TIME WITHOUT NOTICE AND/OR INCURRING ANY
OBLIGATION, WHATSOEVER. NO ONE IS ALLOWED TO REPRODUCE ANY
PART OF THIS PUBLICATION WITHOUT OBTAINING PRIOR WRITTEN
PERMISSION FROM Hero MotoCorp Ltd.
NOTE
ACCESSORIES SHOWN MAY NOT BE THE PART OF STANDARD FITMENT. IT
IS OUR ENDEAVOUR TO CONSTANTLY IMPROVE OUR PRODUCTS. THIS
COULD LEAD TO CHANGE IN PRODUCT SPECIFICATIONS WITHOUT
NOTICE. Hero MotoCorp Ltd ‘HF-DELUXE PROGRAMMED FI’ COMPLIES
WITH THE LATEST EMISSION NORMS.
As per Ministry of Road Transport & Highways (Government of India) vide
Notification G.S.R. 540(E), Hemostatic agent is excluded from first aid kit in
reduction from existing kit effective from 31st August 2020.
ADDENDUM
Pg. No.Pg. No.
CONTENTS
Pg. No.
VEHICLE IDENTIFICATION 1
ANTI-THEFT TIPS 7
VEHICLE VIEWS 2
ACCESSORIES & MODIFICATIONS 7
VEHICLE SAFETY 8
VEHICLE SPECIFICATION 5
STARTING THE ENGINE 20
PARKING/UTILITY BOX 23
TOOL KIT/FIRST AID KIT 23
MAINTENANCE 24
CLEANING AND WASHING OF VEHICLE 24
SIDE STAND INDICATOR/SWITCH 18
PRE-RIDE INSPECTION 19
RIDING/BRAKING 22
FUEL TANK 18
SAFE RIDING TIPS 10
•Instruments & Indicators 13
HANDLEBAR SWITCHES CONTROLS 14
i3s (IDLE STOP START SYSTEM) 16
TIPS FOR HEALTHY ENVIRONMENT 11
PARTS FUNCTION 12
•Ignition switch 12
•Important safety information 8
•Protective apparel 9
FEATURES 14
ZONAL/REGIONAL/AREA OFFICES
MAINTENANCE SCHEDULE 27
SAFETY PRECAUTION 26
POLISHING OF VEHICLE 54
CATALYTIC CONVERTER 53
HERO GENUINE PARTS
ROAD SIGNS 57
HEADLAMP FOCUS ADJUSTMENT 52
EVAPORATIVE EMISSION CONTROL SYSTEM 54
WARRANTY
BASIC TROUBLESHOOTING 55
VALVE CLEARANCE ADJUSTMENT 35
SPARK PLUG INSPECTION 30
ENGINE OIL 30
DRIVE CHAIN SLACKNESS 39
AIR CLEANER 33
DRIVE CHAIN SLIDER INSPECTION 41
CLUTCH LEVER FREE PLAY 37
THROTTLE OPERATION 38
OIL FILTER SCREEN & CENTRIFUGAL FILTER 32
MAIN/SIDE STAND LUBRICATION 47
BATTERY 49
FUSE REPLACEMENT 51
TYRES 47
WHEEL 45
NUTS, BOLTS & FASTENERS 49
STOP LAMP SWITCH 52
SUSPENSION 44
BRAKES 41
VIN and Engine No. may be required:
2. For dealing with legal & insurance departments.
1. During registration of the vehicle.
HA11EX#
#######
VIN Engine
Variants
Kick Start/Drum/Spoke Wheel
Kick Start/Drum/Cast Wheel
Electric Start/Drum/Cast Wheel
MBLHAW10#########
1
VIN: MBLHAW10#########
MBL HAW10 # # # #####
Manufacturer
code Vehicle
Description Model Year Plant
Code Month of
Manufacturing Production
Serial Number
#
Check
Digit
Engine No.: HA11EX########
Model: HF-DELUXE PROGRAMMED FI
HA11EX # # # #####
Engine
Description Year of
Manufacturing Assembly Plant Month of
Manufacturing Serial Number
Electric Start/Drum/Cast Wheel/i3s
HA11ER
HA11ER
HA11ES
HA11EX
HA504
HAC04
HAW14
HAW10
VEHICLE IDENTIFICATION
Engine No.
Location: Stamped on the lower side of the
left crankcase.
Location: Stamped on the right side of the
steering head tube.
Vehicle Identification Number (VIN)
(2) Side stand indicator
(4) Turn signal lamp switch
(5) Clutch lever
(6) Rear view mirror
(8) Odometer
(9) Speedometer
(10) i3s indicator (optional)
(3) Horn switch
(1) Turn signal indicator
(7) Headlamp dimmer switch
(11) Neutral indicator (21) Fuel tank cap
(12) Programmed FI malfunction indicator
lamp (MIL)
(14) High beam indicator
(13) Fuel gauge
(15) i3s switch (optional)
(16) Front brake lever
(17) Throttle grip
(18) Electric starter switch (optional)
(19) Ignition switch with steering lock
(20) Leg guard
TOP VIEW
3
5
6
15
13
17
16
21
20
18
2
VEHICLE VIEWS
4
7
1
2
8 109 11 12 14
19
*Accessories and features shown may not be part of standard fitment.
LEFT SIDE VIEW
107
1256
4
12
3
(7) Left side cover
(8) Saree guard with
women pillion step
(9) Rear turn signal lamp
(10) Rear reflex reflector
(5) Side stand
(3) Side stand switch
(4) Main stand
(6) Left pillion footrest
(2) Left rider footrest
(1) Gear shift pedal
(13) Throttle body/ECU
(11) Tail/stop lamp
(15) Side reflex reflector
(14) Front turn signal lamp
(12) Rear grip
3
8
9
10
11
14
15
*Accessories and features shown may not be part of standard fitment.
13
(6) Rear brake pedal
(8) Utility box
(10) Headlamp
(7) Oil level dipstick
(9) Front suspension
(15) Exhaust muffler
(13) Seat
(11) Front visor
(14) Rear shock absorber
(12) Fuel tank
RIGHT SIDE VIEW
(1) Right pillion footrest
(2) Battery compartment (Inside)
(5) Starter motor (Optional)
(3) Kick starter pedal
(4) Left rider footrest
10
11
234
*Accessories and features shown may not be part of standard fitment.
1
4
5
9
78
9
12
13
14
15
SPECIFICATIONSITEM
Dimensions
Overall length 1965 mm
Overall width 720 mm
Overall height 1045 mm
Wheelbase 1235 mm
Saddle height 805 mm
Ground clearance 165 mm
Kerb weight 110 kg (Kick start)
112 kg (Electric start)
Engine oil 1 litres at disassembly and 0.85 litre at draining
Front fork oil 163 ± 1.75 ml
Weight
Capacities
Maximum power 5.9 0 r/min kW @ 8 00
Maximum torque 0.82 kgf-m (8.05 N-m) 6 @ 000 r/min
Bore and stroke 50.0x49.5 mm
Displacement 97.2 cc
Engine
Spark plug gap 0.6-0.7 mm
Idle speed 1400 100 r/min± in hot condition
Front suspension Telescopic hydraulic shock absorbers
Valve clearance 0.10 mm
0.10 mm
Intake
Exhaust
Chassis and suspension
Spark plug NGK-CR7HSA, BOSCH-UR4AC,
Champion-P-RZ9HC (Federal Mogul)
Rear suspension Swing arm with 2 step adjustable hydraulic shock
absorbers
5
Compression ratio 9.9:1
VEHICLE SPECIFICATION
Fuel tank 9 1 . litres
Side stand indicator LED
Hi beam indicator 12V-1.7W
Alternator 1 W25 @ 5000 r/min
Neutral indicator 12V-1.7W
Headlamp (High/Low) 12V-35/35W (Halogen Bulb, Trapezoidal **MFR)
Tail/Stop lamp 12V-5/21W-**MFR
Meter illumination 12V-1.7Wx2
rd
31.238 (26/21)
th
40.958 (23/24)
1.706 (29/17)
nd
2
Electricals
SPECIFICATIONSITEM
Trail length 89 mm
Brakes Internal expanding shoe type, 130 mm
Internal expanding shoe type, 130 mm
(Integrated braking system)
Front
Rear
st
Gear ratio, 1 3.182 (35/11)
Primary reduction 3.722 (67/18)
Final reduction 3.143 (44/14)
Transmission
Tyre size Front
Rear 2.75x18-4 PR/42P
2.75x18-6 PR/48P
Turn signal lamp 12V-10Wx4 **MFR
Turn signal indicator 12V-3.0Wx2
6
* MF stands for Maintenance Free
** MFR stands for Multi-Focal Reflector
i3s indicator LED
Battery *MF Battery, 12V-3Ah, ETZ-3 (Kick Start),
12V-3Ah/ETZ-4 (Electric Start)
Caster angle 26°
VEHICLE SPECIFICATION
Fuse 15A,10A (Circuit fuse) & 15A, 10A (Spare fuse)
Programmed-Fi Malfunction indicator lamp (MIL) LED
Fuse box (1)
Fuse box (2) 10A (Circuit fuse) & 10A (Spare fuse)
