Haier HD80-26A User manual

User Manual

HD80-26A-F

Heat Pump Dryer

HD80-26A-DF

HD80-26A

2 | English

TABLE OF CONTENTS

Dear customer ................................................................................................ 3

Scope of delivery ............................................................................................ 3

Intended use ................................................................................................... 3

Safety instructions ......................................................................................... 4

Unpacking .......................................................................................................6

Installation ......................................................................................................6

Using the dryer rack ....................................................................................... 7

Front view .......................................................................................................8

Rear view .........................................................................................................9

Control panel ................................................................................................ 10

Program modes ............................................................................................ 13

Preparing the dryer ...................................................................................... 14

Preparing the laundry .................................................................................. 14

Loading the dryer ......................................................................................... 15

Care chart ......................................................................................................15

Load reference .............................................................................................. 16

Set program & start ......................................................................................16

End of dry cycle ............................................................................................ 17

Empty the water tank ................................................................................... 17

........................................................................................ 18

............................................................................ 18

Heat pump technology ................................................................................. 19

Consumption table ....................................................................................... 19

Cleaning & care ............................................................................................ 20

Error codes ...................................................................................................20

Troubleshooting ........................................................................................... 21

Electric circuit diagram ................................................................................ 22

Customer service

......................................................................................... 24

Product fiche 23................................................................................................

English | 3

DEAR CUSTOMER

Thank you for your purchase of a Haier

product. Please read the manual and

safety instructions carefully and keep

them for future reference and pass

them on to any future owner.

SCOPE OF DELIVERY 1 2

Please check, if the accessories and

literature is in accordance with this list.

1 User manual

2 Rack

INTENDED USE

This heat pump tumble dryer is

designed for household use only. It

should be used to dry items which

have been washed in a water solution

and are marked on the manufacturer's

care label as being suitable for tumble

drying.

It is not intended for commercial or

outdoor use.

Haier cannot be held liable for

damage resulting from incorrect or

improper use or operation.

This tumble dryer conforms to current

safety requirements.

User Manual

HD80-26A-F

Heat Pump Dryer

HD80-26A-DF

HD80-26A

3 Drainpipe

Instructions showing this icon

need special attention for safe

handling.

Read the instructions.

4 | English

SAFETY INSTRUCTIONS

Children under 3 years of age must be kept away from the tumble dryer unless

they are constantly supervised.

The tumble dryer is not a toy! To prevent the risk of injury, do not allow children

to play with it or near it, or to play with the controls.

Before setting up the tumble dryer, check it for any externally visible damage.

Do not install or use a damaged tumble dryer.

Before connecting the tumble dryer, ensure that the connection data match the

mains electricity supply

The electrical safety of this tumble dryer can only be guaranteed when

correctly earthed.

Do not connect the tumble dryer to the mains electricity supply by an extension

lead.

If the supply cord is damaged, it must be replaced by the manufacturer, its

Faulty components must be replaced by original spare parts.

The tumble dryer must be isolated from the mains supply in the event of a fault

and during cleaning and maintenance.

Do not install the tumble dryer in a room where there is a risk of frost occurring.

The ambient temperature should be between 5 °C and 35 °C.

Do not install the tumble dryer behind a lockable door, a sliding door or a door

with hinges on the opposite side of the tumble dryer door as this limits the full

opening of the tumble dryer door.

Always keep the area around the tumble dryer free of dust and lint. Also make

sure that the area is dry and well ventilated.

The tumble dryer must not be used in a non-stationary location (e.g. a ship).

Do not make any alterations to the tumble dryer, unless authorised to do so by

Haier.

In areas which may be subject to infestation by cockroaches or other vermin,

pay particular attention to keeping the tumble dryer and its surroundings in a

clean condition at all times.

Do not dry unwashed items in the tumble dryer.

Do not load more than Nominal load.

acetone, alcohol, benzine, petrol, kerosene, spot removers, turpentine, waxes,

wax removers or other chemicals should not be dried in the tumble dryer.

If it is unavoidable to dry items that contain vegetable oil, cooking oil, hair care

or cosmetical products, they should be washed using additional detergent and

select a high temperature. If in doubt, wash the items several times.

This appliance can be used by children aged from 8 years and above and

persons with reduced physical, sensory or mental capabilities or lack of

experience and knowledge if they have been given supervision or instruction

concerning use of the appliance in a safe way and understand the hazards

involved. Children shall not play with the appliance. Cleaning and user

maintenance shall not be made by children without supervision.

English | 5

Items which contain a large proportion of rubber, foam rubber (latex foam)

or rubber like materials such as shower caps, waterproof textiles, rubberised

articles and items of clothing and pillow

dried in the tumble dryer.

Items which have been cleaned using chemicals such as professional

drycleaning agents, should not be dried in the tumble dryer.

Do not dry damaged items which conta

Remove all items such as lighters and matches from pockets.

The end of a dryer cycle runs without heat (cool down cycle) to ensure that the

items do not get damaged and are at a handleable temperature.

Warning: Do not switch the tumble dryer of

Afterwards, the laundry must be hung up or spread out to cool it down.

manufacturer's packaging.

Close the door once the laundry is removed to prevent children, animals and

objects getting into the drum.

Do not sit or lean on the door, as this can cause the tumble dryer to tilt.

Condensed water is not drinking water. It can cause health problems in both

people and animals.

Notice

This appliance contains the fluorinated greenhouse gas HFC-134a

(GWP:1430). This gas is hermetically sealed.

6 | English

UNPACKING 1 2

Remove all packaging material including

the polystyrene base. All packaging

material should be recycled.

1 Cut the strips.

2 Lift the cover upwards.

3 Remove the protective parts.

4 Remove the base.

Ensure that any plastic wrappings,

bags, etc are kept out of the reach of

babies and young children. Danger of

suffocation.

3 4

INSTALLATION 1 2

1 Check the dryer does not rock or

wobble.Adjust the four feet to level the

dryer before operation.

2 Make sure the socket meets the

requirements and connect it to an earthed socket outlet.

Do not install in a room which is susceptible to frost. Water may cause damage

once it starts to freeze.

Transport the dryer in a vertical upright position.

There may be residual water in the dryer.

This can leak out if the dryer is at an angle.

TECHNICAL DATA

Power 220 - 240 V~ / 50 Hz

Nominal load (kg)

Max. power (W) 800

Fuse (A) min. 10

Ambient temperature (°C) 5 - 35

Dimensions (H x D x W mm) 845 x 650 x 595

Net weight (kg) approx. 50,5

Water protection level IPX4

Warning: Following transportation and

installation, you MUST leave the dryer to

stand for two hours before use.

Fluorinated greenhouse gas HFC-134a

Volume 0.63kg

GWP

Tonne(s) of equivalent

1430

0.9

English | 7

USING THE DRYER RACK

DRYER RACK

The dryer rack is designed for use with items which are not recommended for

tumble drying such as trainers, sneakers, sweaters or delicate lingerie.

TO USE THE DRYER RACK

1. Open the dryer door.

2. Check that the drum is empty.

3. Put the dryer rack into the

drum.

4. Make sure the catches are

inserted in the hole of the

lint filter and locked in the

hook of basket.

PLEASE NOTE

Do not use this dryer rack when there are other clothes in the dryer.

During drying, please make sure the items are placed on the rack with

hile the drum is rotating.

The dryer rack must be used with the “Wool” or “shoe”cycle.

Maximum weight of wet items: 1.5 kg.

Hook of basket

Drum openings

Drum

Dryer rack

Do not dispose of electrical appliances as unsorted municipal

waste, use separate collection facilities.Contact your local

government for information regarding the collection systems

available. If electrical appliances are disposed of in landfills or

dumps, hazardous substances can leak into the groundwater

and get into the food chain, damaging your health and

well-being. When replacing old appliances with new ones, the

retailer is legally obligated to take back your old appliance for

disposals at least free of charge.

The heat exchanger of the dryer contains the greenhouse gas

HFC-134a. This must be disposed of properly.

For further technical information, please check the type plate on the appliance.

Timer+

ECO

emoTimerModeDry LevelSelectionFunc tion

Extra Dry

Wool

Shoe

rebiforciMtropS

Baby

Garment

Towel

Mix

Duvet

Ready to

Store

Iron

Syntheti c

Extra Dry

Cotton

Ready to

Iron

Ready to

Store

Ultra Care

Underwear

Ready to

8 | English

FRONT VIEW

The pictures may differ from the appliance you have purchased due to technical

improvements.

1 Water tank

2 Tumble dryer door

3 Service door

4 Control panel

1 4

English | 9

REAR VIEW

5 Power supply cord

6 Back plate

7 Drainage outlet

8 Adjustable feet

Extra Dry

Wool

Shoe

Sport Microfiber

Baby

Garment

Towel

Mix

Duvet

Ready to

Store

Ready to

Iron

Synthetic

Extra Dry

Cotton

Ready to

Iron

Ready to

Store

Ultra Care

Underwear

Timer ModeDry LevelSelectionFunction

ECO

emo

| English

CONTROL PANEL

Filters must be cleaned regularly.

See

Lint Filter Cleaning

Condenser

Filter Cleaning

section of the manual.

Child-lock indicator

To activate the Child-lock function at any time

when the dryer is powered on, press the

function

& selection

buttons for 3 sec. until the indicator

icon lights up. To deactivate press both buttons

for 3 sec. again.

Note: When the cycle ends or the power

supply i

interrupted, the function will not be

cancelled automatically.

10 12 13 14

Clean filter

indicators

Empty tank

indicator

Water tank must be emptied.

Important: Empty the water tank after each

drying cycle.

See

Empty the water tank section

of the manual.

Memory mode is set or you have activated the

memory cycle.

The display shows the remaining time, the delay

time and other related information.

Display

The remaining time.

The delay time.

The drying process(drying, cooling

and the end of cycle).

indicator

Note: When the indicators light during the

cycle, the drum lamp will be on too

Other manuals for HD80-26A

This manual suits for next models

Table of contents

Languages:

Other Haier Dryer manuals

Haier

Haier GDZ3.5-1 User manual

Haier

Haier HDY6-1 User manual

Haier

Haier GDZ5.0-61WH HA AA User manual

Haier

Haier RDE350AW - 6.5 Cu. Ft. Electric Dryer User manual

Haier

Haier HDY6-1 User manual

Haier

Haier HDHP80E1 User manual

Haier

Haier QFT15 Series Original instructions

Haier

Haier HDY-D60 User manual

Haier

Haier GDZ5-1 User manual

Haier

Haier T60-32 User manual

Haier

Haier HD70-A82 User manual

Haier

Haier GDZ607VA User manual

Haier

Haier HLP140E - 2.6 cu. Ft. Portable Vented Electric... User manual

Haier

Haier HDY6.1 HA AA User manual

Haier

Haier GE GFD14ESSNWW How to use

Haier

Haier Genesis CGDE700AW User manual

Haier

Haier Ginesis HLF103Q User manual

Haier

Haier HLF11PC User manual

Haier

Haier TCD60E User manual

Haier

Haier HD90-A3Q979SU1 User manual

Haier

Haier GDZ5.0-1 User manual

Haier

Haier EDC1070M User manual

Haier

Haier GDG900AW User manual

Haier

Haier HDHP80AN1 User manual

Popular Dryer manuals by other brands

Bosch

Bosch WTA79200GB Installation and operating instructions

Amana

Amana W10233410A Use and care guide

Miele

Miele TWH 780 WP operating instructions

Asko

Asko T760 user guide

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Original instructions

Bosch

Bosch Logixx 10 WTB76556GB Instruction manual and installation instructions

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Operation and installation

Electrolux

Electrolux EW2H328R2 user manual

Beko

Beko DS8433RX1M user manual

Dawlance

Dawlance Spinner DS 6000 C owner's manual

Electrolux

Electrolux TP5080TW user manual

AEG

AEG TR838P4OB user manual

Indesit

Indesit IDV 75 instruction manual

Infiniton

Infiniton SD-DG85C manual

BOMANN

BOMANN WT 5019 instruction manual

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Installation

Asko

Asko T793C operating instructions

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer installation instructions
