Grundig 100 PE User manual

=CI

WORLD RECEIVER MINI WORLDBAND 100 PE

AUTHORIZED GRUNDIG STORE

agsradio.com

Toll Free US & Canada 1 866 282 4801

=CI

AUTHORIZED GRUNDIG STORE

As a proud representative o Grundigs radio products, the Authorized Grundig Store is pleased to o er this support manual, as

delivered OEM Grundig AG with Mini Worldband 100PE radio. It is available on the world wide web through our website in Postscript

Document Format (pd ) and may be downloaded ree o charge, viewable with the recommended utility Adobe Acrobat Reader 4.0 or later.

Toll Free US & Canada 1 866 282 4801

agsradio.com

Created by

Toronto Canada [email protected]

IMPORTANT NOTICE

NEED HELP?

CALL OUR HOTLINE OWNER’S RECORD

If,afterreadingthis owner’smanual,youneed

helplearningto operateyourMINI WORLDBAND 100PE,

callGRUNDIGtollfree,MondaythroughFriday,8.30am

to 4.30 pm, PST at:

1-800-872-2228 fromtheU.S.

1-800-637-1648 fromCanada

Thismodelis theGRUNDIGMINI WORLDBAND100

PROFESSIONALEDITION(PE),an AM/FM-Stereo with

Earphonesand6 Shortwave bands.

Theserialnumberislocatedonthe stickerinsidethebattery

compartment.Refertothisnumberwheneveryoucall

GRUNDIGregarding thisproduct.

CONTROLLOCATIONS

1. TelescopicAntennaforFM/SW

2. BandSelector

3. FrequencyTuning Dial ScaleDisplay

4. TuningDial

5. VolumeandPowerOn/OffSwitch

6. EarphoneJack

7. BatteryCompartment(onback)

8. LEDTuningIndicator

9. RemovableBeltClip(onback)

USINGTHERADIO

Install2AA sizebatteries(notincluded)into the Battery

Compartmentatthe rearofthe radio (SeeControlLocations

item#7 previouspage).

TurnONtheradio (#5) andadjusttheVolume(#5)tothe

desiredlisteninglevel.

Selecttherequiredfrequency range with the Band

Selector(#2).

Selectthedesiredradiostationbyturning theTuning Dial

(#4).When astrong signalis obtainedtheTuningLEDindica-

torwilllight(#8).

FORAMthe setis providedwitha builtin antennawhich

maybedirectedbyturning theentire set.

FORFM/SWthe TelescopicAntenna (#1)mustbe extended

completelyfor bestreception.

FORFM-STEREOuse theEarphones(included)inthe

EarphoneJack(#6).

SPECIFICATIONS

1. FrequencyRange

FM: 88 - 108 MHz

AM: 525 - 1710 KHz

SW1(49m): 5.80 - 6.40 MHz

SW2(41m): 6.90 - 7.50 MHz

SW3(31m): 9.40 - 10.00 MHz

SW4(25m): 11.65 - 12.15 MHz

SW5(19m): 15.00 - 15.65 MHz

SW6(16m): 17.50 - 18.14 MHz

2. PowerOutput: 100mw

3. Speaker: 0.45mm, 0.25mw, 4ohm

4. PowerSupply: 2xAA batteries(not included)

DC 3V

5. Earphone: 8-32ohm, 3.5mmdia.plug

6. Dimensions: 4 1/2”H x 2 5/8”W x 13/16”D
