GXV3240 Wi-Fi User Guide
Grandstream Networks, Inc.
GXV3240 IP Multimedia Phone for AndroidTM
Wi-Fi User Guide
GXV3240 Wi-Fi User Guide
Page 1 of 18
GXV3240 Wi-Fi User Guide
Index
INTRODUCTION ........................................................................................... 3
CONNECT TO WI-FI ..................................................................................... 4
TURN ON/OFF WI-FI...........................................................................................................................4
ADD WI-FI NETWORKS......................................................................................................................6
CONFIGURING WI-FI FROM PROVISIONING...................................................................................8
WI-FI SETTINGS........................................................................................... 9
ACCESS WI-FI SETTINGS ................................................................................................................. 9
SCAN...................................................................................................................................................9
ADD WI-FI NETWORK MANUALLY..................................................................................................10
WPS PUSH BUTTON.........................................................................................................................11
WPS PIN ENTRY...............................................................................................................................13
WI-FI DIRECT....................................................................................................................................15
ADVANCED SETTINGS .................................................................................................................... 16
PORTABLE HOTSPOT............................................................................... 18
GXV3240 Wi-Fi User Guide
Page 2 of 18
Table of Figures
GXV3240 Wi-Fi User Guide
Figure 1: Turn On/Off Wi-Fi From Status Bar.............................................................................................. 4
Figure 2: Turn On/Off Wi-Fi From Settings.................................................................................................. 5
Figure 3: Turn On/Off Wi-Fi From Web UI................................................................................................... 5
Figure 4: GXV3240 Wi-Fi Settings..............................................................................................................6
Figure 5: GXV3240 Connect to Wi-Fi..........................................................................................................7
Figure 6: GXV3240 Connect to Wi-Fi via Web UI.......................................................................................8
Figure 7: GXV3240 Available Wi-Fi Network List........................................................................................9
Figure 8: GXV3240 Wi-Fi Settings - Scan................................................................................................. 10
Figure 9: GXV3240 Add Wi-Fi Network Manually ......................................................................................11
Figure 10: GXV3240 WPS available network............................................................................................ 12
Figure 11: GXV3240 Wi-Fi WPS Push Button........................................................................................... 12
Figure 12: GXV3240 Connect to a WPS Network.....................................................................................13
Figure 13: GXV3240 Wi-Fi WPS Pin Entry ............................................................................................... 14
Figure 14: GXV3240 Connected to a Wi-Fi WPS Pin Entry Network........................................................14
Figure 15: GXV3240 Wi-Fi Direct: Search Available Device.....................................................................15
Figure 16: GXV3240 Wi-Fi Direct: Connected ..........................................................................................16
Figure 17: GXV3240 Wi-Fi Settings - Advanced.......................................................................................16
Figure 18: GXV3240 Wi-Fi Advanced Settings .........................................................................................17
Figure 19: GXV3240 Wi-Fi Hotspot........................................................................................................... 18
GXV3240 Wi-Fi User Guide
Page 3 of 18
INTRODUCTION
The GXV3240 has integrated Wi-Fi that supports 802.11b/g/n for network flexibility. This User Guide
describes how to use the Wi-Fi function to connect the GXV3240 into your local network. To learn more
about GXV3240's basic and advanced features, please visit link http://www.grandstream.com/support to
download the latest "GXV3240 User Guide" and "GXV3240 Administration Guide".
GXV3240 Wi-Fi User Guide
Page 4 of 18
CONNECT TO WI-FI
Wi-Fi is supported and built-in on the GXV3240. GXV3240 can be connected to network if Wi-Fi is
available within the area. By default, Wi-Fi is turned off on the GXV3240. Users can turn on Wi-Fi from
web UI, LCD settings->system settings or provisioning.
TURN ON/OFF WI-FI
To turn on/off Wi-Fi from status bar
1. On the top of the LCD screen, slide down the status bar.
2. Select System Settings.
3. Tap on the Wi-Fi icon to turn it on/off.
Figure 1: Turn On/Off Wi-Fi From Status Bar
To turn on/off Wi-Fi from system settings
1. On the GXV3240 idle screen, press MENU softkey on the bottom of the LCD to bring up the LCD
menu.
2. Select Settings .
3. Select Wireless & Network.
4. Tap on Wi-Fi turn it on/off.
GXV3240 Wi-Fi User Guide
Page 5 of 18
Figure 2: Turn On/Off Wi-Fi From Settings
To turn on/off Wi-Fi from web UI
1. Log in the GXV3240 web UI.
2. Go to Maintenance->Wi-Fi Settings: Wi-Fi Basics.
3. Click on "Enable" or "Disable" for "Wi-Fi Function".
Figure 3: Turn On/Off Wi-Fi From Web UI
GXV3240 Wi-Fi User Guide
Page 6 of 18
ADD WI-FI NETWORKS
Add Wi-Fi networks from LCD
1. Once Wi-Fi is turned on, GXV3240 will automatically start the scanning within the range.
2. On GXV3240 idle screen, press MENU softkey on the bottom of the LCD.
3. Select Settings .
4. Select Wireless & Network.
5. Select Wi-Fi Settings.
Figure 4: GXV3240 Wi-Fi Settings
6. A list of Wi-Fi networks will be displayed as scanning result. Tap on the SSID and enter the correct
password information to connect to the selected Wi-Fi network. See [Figure 5: GXV3240 Connect to
Wi-Fi].
GXV3240 Wi-Fi User Guide
Page 7 of 18
Figure 5: GXV3240 Connect to Wi-Fi
7. The phone will start connecting to the Wi-Fi. The status bar will show Wi-Fi signal strength.
8. Once authenticated, the phone will obtain IP address via DHCP and connect to the Wi-Fi network.
9. After successfully connected, the password will be remembered. When the GXV3240 has Wi-Fi
turned on in the future, it will connect to this network if the SSID is within the range.
Add Wi-Fi networks from web UI
1. Log in the GXV3240 web UI.
2. Go to Maintenance->Wi-Fi Settings. Click on "Enable" for "Wi-Fi Function".
3. Click on "Scan" to start searching for the Wi-Fi networks within the area. A list of available ESSIDs
will be displayed.
4. Select the ESSID and click on "Select". The ESSID will be filled into the "ESSID" field under "Wi-Fi
security".
5. Enter the password for the ESSID.
6. Save the change.
7. The phone will start connecting to the Wi-Fi network. Please check the phone's LCD.
GXV3240 Wi-Fi User Guide
Page 8 of 18
Figure 6: GXV3240 Connect to Wi-Fi via Web UI
CONFIGURING WI-FI FROM PROVISIONING
Users could configure the P value in the config file to provision the phone to connect to Wi-Fi network.
The following are the P values for Wi-Fi configuration.
Option
P Value
Example
Wi-Fi Function
P7800
P7800=0 - for "Enable"
or
P7800=1 - for "Disable" (default value)
ESSID
P7812
P7812=OfficeWiFi1
Password
P7830
P7830=officewifinetwork
This is the WEP default key. The maximum
length allowed is 64 characters.
For more details about the GXV3240 configuration template and provisioning, please refer to the
configuration tool, templates and documentation in the following link:
http://www.grandstream.com/support/tools
GXV3240 Wi-Fi User Guide
Page 9 of 18
WI-FI SETTINGS
ACCESS WI-FI SETTINGS
1. When the GXV3240 is on idle screen, press MENU softkey on the bottom of the LCD.
2. Select Settings .
3. Select Wireless & Networks.
4. Tap on Wi-Fi Settings. A list of available Wi-Fi network within the range will be displayed in "Wi-Fi
Settings" menu. Users can set up to connect to Wi-Fi network and configure advanced settings for
Wi-Fi connections here.
Figure 7: GXV3240 Available Wi-Fi Network List
Note:
"Wi-Fi Settings" is available only when Wi-Fi is turned on.
SCAN
Under "Wi-Fi Settings" menu, press MENU button and select "Scan" to initate scan for the Wi-Fi
networks within the range. The available Wi-Fi networks will be updated and displayed there.
