Genie GS5360VDC User manual
0
COLOR WEATHERPROOF INRARED CAMERA
GS5360VDC
1/3" High-Resolution Weatherproof Vari-Focal IR Camera
Before operating this unit, please read this manual
thoroughly and retain it for future reference.
1
Instruction Manual
Features:
Patent External Focus / Zoom Adjustment Design.
Built-in AES, BLC, AGC, ATW.
Optional IR-Cut Filter & Heater device available.
1/3” Sony CCD, 550TV Lines / 420TV Lines of Resolution
For Vari-Focal Lens: Optional 4~9mm / 9~22mm Auto Iris Vari-Focal Lens.
For Fixed Lens: Optional 4.0mm / 6.0mmm / 8.0mm / 12.0mm Board Lens.
Low Illumination, no color noise.
Weatherproof design, pass IP66 rating.
Dual Voltage AC/DC (12~24)V or AC 99~240V (Switching Power).
Precautions:
Do not point the camera lens toward the sun or other strong light.
Use AC 110V or AC 220V power supply.
Be careful while handling or installing the camera. Do not drop it or subject it to strong shock or
vibration to prevent damages to it.
When using adaptors, be sure to choose the following types:
1) DC 12V 2A
2) DC 15V 1.5A
3) DC 18V 1A
4) AC 24V 800mA
If extending power cord is necessary, be sure to use the cord with more than 50 cores inside.
Installation Instructions:
To connect the camera’s power and video as the following:
1. Connect AC power on.
2. Connect the BNC Video Output to the desired video line.
3. Position the camera on place you desired.
4. The camera comes set up from the factory. If you need to make minor adjustments, use the
external magnetic controller to adjust focus/zoom. (Only camera with vari-focal lens needs to
adjust the focus.)
5. It is not recommended to take apart the camera, which will cause possible damage to the
weatherproof function.
2
Specification
◎Sony Color Weatherproof IR Camera w/ Vari-Focal Lens
Description 1/3" High-Resolution Weatherproof
Vari-Focal IR Camera 1/3" Weatherproof Vari-Focal IR
Camera
Pick up Element Sony Ex-View
CCD + Sony HQ1
DSP
Sony Super-Had
CCD + Sony SS-11X DSP Sony SS-11
CCD Image Sensor
Number of Pixels <NTSC> 768(H)×494(V)
<PAL> 752(H)×582(V) <NTSC> 510(H)×492(V)
<PAL> 512(H)×582(V)
Back
Light
Compensation ON
Auto Electronics
Shutter ON
Line Lock ON -
AGC ON
ATW ON
Sync. Mode Internal Sync.
Scanning System 2:1 Interlace
Resolution 550 TV Lines 420 TV Lines
S/N Ratio More than 48dB
Gamma 0.45
Minimum illumination
0.03 Lux, F 1.4
(0 Lux with IR) 0.5 Lux, F 1.4
(0 Lux with IR)
Infrared
LED
Quantity 28
Peak
Wavelength
850nm
Radiant
Distance 25 meters (at least)**
Horizontal Sync.
Frequency <NTSC> 15.734 KHz
<PAL> 15.625 KHz
Video Output 1.0 Vp-p, 75 ohm
Power Source AC / DC (12~24)V or AC 99V~240V (Switching Power)
Power Consumption
12 W
Operating
Temperature -10℃to +60℃
Lens Amount 4.0mm~9.0mm Auto Iris Vari-Focal Lens (Standard)
9.0mm~22mm Auto Iris Vari-Focal Lens (Optional)
Shutter Control <NTSC> 1/60~1/100,000 sec.
<PAL> 1/50~1/100,000 sec.
Dimension 235(L)×100(ø) mm
Net Weight 1.6 kg
Ext. Model With Heater / IR-Cut Filter
* Specifications are subject to change without prior notice.
** Depending on screen reflection.
3
Specification
◎Sony Color Weatherproof IR Camera w/ Board Lens
Description 1/3" High Resolution Weatherproof IR Camera
1/3" Color Weatherproof IR
Camera
Pick up Element Sony Ex-View
CCD + Sony
HQ1 DSP
Sony
Super-Had
CCD + Sony
SS-11X DSP
Sony CCD Image Sensor
Number of Pixels <NTSC> 768(H)×494(V)
<PAL> 752(H)×582(V) <NTSC> 510(H)×492(V)
<PAL> 512(H)×582(V)
Back Light
Compensation ON
Auto Electronics
Shutter ON
Line Lock ON - ON -
AGC ON
ATW ON
Sync. Mode Internal Sync.
Scanning System 2:1 Interlace
Resolution 550 TV Lines 420 TV Lines
S/N Ratio More than 48dB
Gamma 0.45
Minimum
illumination 0.03 Lux, F 1.4
(0 Lux with IR)
0.5 Lux, F 1.4
(0 Lux with IR)
Infrared
LED
Quantity 64
Peak
Wavelength
850nm
Beam
Spread 30∘(f=6mm), 35∘(f=8mm)
Radiant
Distance 25 meters (at least)**
Horizontal Sync.
Frequency <NTSC> 15.734 KHz
<PAL> 15.625 KHz
Video Output 1.0 Vp-p, 75 ohm
Power Source AC / DC (12~24)V or AC 99V~240V (Switching Power)
Power Consumption
12 W
Operating
Temperature -10℃to +60℃
Lens Amount 6.0mm, F2.0 Board Lens (Standard)
4.0mm /8.0mm / 12.0mm, F2.0 Board Lens (Optional)
Shutter Control
<NTSC> 1/60~1/100,000 sec.
<PAL> 1/50~1/100,000 sec.
Dimension 235(L)×100(ø) mm
Net Weight 1.6 kg
Ext. Model With Heater
* Specifications are subject to change without prior notice.
** Depending on screen reflection.
4
Camera Layout
1/3”Color Weatherproof IR Camera W/ Board lens
1/3”Color Weatherproof IR Camera W/
Vari
-
Focal lens
5
CR200000156
