GE DSXH47EG Manual

For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

Specification Revised 12/09 360472

Listed by

Underwriters

Laboratories

Dimensions and Installation Information (in inches)

Exhaust Options: 4-way via rear, right, left and bottom.

Circuit Requirements: An individual, properly grounded

branch circuit, protected by a 30-amp circuit breaker or

a time-delay fuse, is required.

Note: Dryer wall outlet must be located within 36”

of service cord entry and accessible when dryer is

mounted in position.

Installation Information: For complete information, see

installation instructions packed with your dryer.

SIDE VIEW

28-1/2

48-1/2

4-3/4

Optional

Vent Knockout

Door Open

90°

4-3/8

REAR VIEW

2-1/4

Under

Counter

3/16"

Gas Pipe Connection

Electric

Connection

13-9/16

Electric Dryer Rating

240V 5600W, 24A, 60Hz

208V 4400W, 22A, 60Hz

DSXH47EG

GE®5.8 Cu. Ft. Extra-Large Capacity Frontload Electric Dryer

For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

360472

Specification Revised 12/09

Special Installation Requirements:

Stacked Installation:

•Bracketsforstackingdryerareincludedaspartofthedryer,DSXH43EF/GF.SeedryerUse&Carefordetails.

•Bracketforstackingdryer,DSXH47EG/GG,orderPub.No.14-A026orSTACKIT1WWatadditionalcost.

Undercounter installation:

•TheWSSH300GandDSXH47EG/GGrequireacustom-sizedcountertop(36inchestotheundersideofthecountertop).

Nospecialwasherordryertopisrequired.

Alcove or Closet Installation:

•Ifyourdryerisapprovedforinstallationinanalcoveorcloset,itwillbestatedonalabelonthedryerback.

•ThedryerMUSTbeexhaustedtotheoutside.

•Minimumclearancesbetweendryercabinetandadjacentwallsorothersurfacesare:0"eitherside,3"frontandrear

•Minimumverticalspacefromfloortooverheadcabinets,ceilings,etc.is52".

•Closetdoorsmustbelouveredorotherwiseventilatedandmustcontainaminimumof60sq.in.ofopenareaequallydistributed.

Ifthisclosetcontainsbothawasherandadryer,doorsmustcontainaminimumof120sq.in.ofopenareaequallydistributed.

•Nootherfuel-burningapplianceshallbeinstalledinthesameclosetwithagasdryer.

Bathroom or Bedroom Installation:

•ThedryerMUSTbeexhaustedtotheoutdoors.

•Theinstallationmustconformwiththelocalcodes,orintheabsenceof

localcodes,withtheNationalElectricCodeandNationalFuelGasCode,ANSIZ223forgasdryers.

Minimum Clearance other than Alcove or Closet Installations:

•Minimumclearancestocombustiblesurfaces0"bothsides,3"rear.

For more information on venting kits and accessories,

please call 1-800-GE-CARES.

DSXH47EG

GE®5.8 Cu. Ft. Extra-Large Capacity Frontload Electric Dryer

Listed by

Underwriters

Laboratories

Specification Revised 12/09 360472

Dryer Exhausting Information – Metal Duct Only

For complete information, see installation instructions packed with your dryer.

Ducting Materials: For best performance, this dryer should be vented with 4” diameter

allrigidmetalexhaustduct.Ifrigidmetalductcannotbeused,thenUL-listedflexible

metal(semi-rigid)ductingcanbeused(KitWX08X10077).Inspecialinstallations,itmay

benecessarytoconnectthedryertothehouseventusingaflexiblemetal(foil-type)duct.

AUL-listedflexiblemetal(foil-type)ductmaybeusedONLYininstallationswhererigid

metalorflexiblemetal(semi-rigid)ductingcannotbeusedANDwherea4”diametercan

be maintained throughout the entire length of the transition duct. Please see installation

instructionpackedwithyourdryerforcompleteinstructionswhenusingflexiblemetal(foil

type)ducting.

Exhaust Length Calculation:

1. Determinethenumberof90°turnsneededforyourinstallation.Ifyouexhausttothe

side or bottom of dryer, add one turn.

2. Themaximumlengthof4’rigid(aluminumorgalvanized)ductwhichcanbetoleratedis

shown in the table.

 Aturnof45°orlessmaybeignored.Two45°turnswithintheductlengthshouldbe

 treatedasa90°elbow.

 Aturnover45°shouldbetreatedasa90°elbow.

Dryers must be exhausted to the outside.

Caution: For personal safety do not terminate exhaust into a chimney, under any enclosed

housefloor(crawlspace),orintoanattic,sincetheaccumulatedlintcouldcreateafire

hazardormoisturecouldcausedamage.Neverterminatetheexhaustintoacommonduct

or plenum with a kitchen exhaust, since the combination of lint and grease could create a

fire hazard.

Exhaust ducts should be terminated in a dampered wall cap to prevent back drafts, bird

nesting,etc.Thewallcapmustalsobelocatedatleast12"abovethegroundoranyother

obstruction with the opening pointed down.

For more information on venting kits and accessories, please call 1-800-GE-CARES.

Listed by

Underwriters

Laboratories

0 60 ft. 48 ft.

1 52 ft. 40 ft.

Frontload dryers: 2 44 ft. 32 ft.

DSXH43EF/GF 3 32 ft. 24 ft.

DSXH47EG/GG 4 28 ft. 16 ft.

Number

90°

turns

Maximum length of

4” dia. rigid metalduct

Exhaust hood type

4" opening

2-1/2"

opening

2-1/2

Best performance

DSXH47EG

GE®5.8 Cu. Ft. Extra-Large Capacity Frontload Electric Dryer

Specification Revised 12/09 360472

DRYNESS

SENSORDRY

TIMEDDRY

TEMPERATURE

OPTIONS SELECT START PAUSE

CANCEL

DSXH47EG_GGWW

Features and Benefits

• 5.8Cu.Ft.Extra-LargeCapacity-Handlesanylarge-sizeitems

and family-size loads

• RotaryElectronicControlswithCycleStatusLights-Makeit

easy to select and monitor wash cycles

• PaintedDrum-Painteddrumcoatedwitharustprooffinishto

stand up to heavy use

• FourTemperatureOptions-Providestherighttemperaturefor

the right drying results

• On/OffEnd-Of-CycleSignal-Canbeturnedonsoyoucanhear

it from another room, or turned off when you do not want to

disturb others

• SensorDry™- Continually monitors moisture levels to help

clothes look better longer

• InteriorDryerLight-Letsyouseeeverythinginsideforeasy

loading and unloading

• Reverse-A-Door-Offersaddedinstallationflexibility

• ModelDSXH47EGWW–Whiteonwhite

DSXH47EG

GE®5.8 Cu. Ft. Extra-Large Capacity Frontload Electric Dryer
