GE PRO AIR 107 User manual

gGE Consumer & Industrial Appliances

Service Manual & Installation Manual

Split System Air Conditioner

Model numbers:

PRO AIR 107

PRO AIR 109

PRO AIR 112

PRO AIR I109

PRO AIR I112

PRO AIR 218

GE AIR 326

GE AIR 428

—1—

Summary and features

Model Remark

PRO AIR 107 IN / PRO AIR 107 OUT

1Ph 230V 50Hz R410A

—2—

Model Remark

PRO AIR 109 IN / PRO AIR 109 OUT PRO AIR 112 IN / PRO AIR 112 OUT

PRO AIR I109 IN / PRO AIR I109 OUT PRO AIR I112 IN / PRO AIR I112 OUT

1Ph 230V 50Hz R410A

—3—

Model Remark

PRO AIR 218 IN / PRO AIR 218 OUT

1Ph 230V 50Hz R410A

—4—

Model Remark

GE AIR 326 IN1 / GE AIR 326 IN2 / GE AIR 326 OUT

1Ph 230V 50Hz R407C

—5—

Model Remark

GE AIR 428 IN / GE AIR 428 OUT

1Ph 230V 50Hz R407C

—6—

Technical and specifications

Model PRO AIR 107 IN / PRO AIR 107 OUT PRO AIR 109 IN / PRO AIR 109 OUT

Function Cooling Heating Cooling Heating

Rated voltage 230V

Rated frequency 50Hz

Capacity (W) 2000 2200 2500 2600

Nominal power (W) 660 700 765 800

Max. power (W) 900 920 990 1050

Greatest currency (A) 4.1 4.3 4.8 5.5

Air flow (m3/h) 360 450

Dry capacity (L/h) 0.7 1.2

C.O.P/EER (W/W) 3.05 3.15 3.2 3.2

Model KFR-20G/NaA121-E KFR-25G/NaA121-E

Fan speed (r/min)(H/M/L) 1000/940/880 1160/1010/890

Output power (W) 8 14

Auxiliary electric heater power /

Fan capacitor 1

Fan motor running current 0.035 0.12

Fan type-piece Axial flow fan－1

Diameter-length (mm) Φ97×583

Evaporator Aluminum fin-copper tube

Pipe diameter Φ7

Row-fin distance (mm) 2-1.4

Developed area of heat

exchanger (I×H×L) 580mm ×228.6mm×25.4mm

Swing motor model MP24GA

Motor power (W) 2

Fuse (A) PCB3.15A Transformer 0.2A

Noise (sound pressure level)

dB(A) 41/38/35 42/39/36

Noise (sound pressure level)

dB(A) 51/49/45 52/49/46

Outline dimension (W/D/H)

(mm) 770×180×250

Package dimension (W/D/H)

(mm) 855×270×336

Indoor

unit

Net weight/gross weight (kg) 8.5/12.5

—7—

Model PRO AIR 107 IN / PRO AIR 107 OUT PRO AIR 109 IN / PRO AIR 109 OUT

Compressor type GK080PAD C-1RV096H1A

Compressor type Rotary type

Locked rotor current 17 17

Compressor running current 3.2 3.8

Compressor input power 682 810

Compressor overload model M RA12009-12026 M RA98635-9201

Throttling method Capillary

Starting mode Capacitor CBB65 (22.5uF/450VAC)

Working temperature range －7～43℃

Condenser Aluminum fin-copper tube

Pipe diameter Φ9.52

Row-fin distance (mm) 2-1.6 2-1.4

Developed area of heat exchanger

(I×H×L) 673×406×44 791×508×44

Fan motor speed (rpm) 950 830

Motor rated power (W) 20 30

Fan motor running current (A) 0.42 0.26

Fan capacitor (μf) 1.5 2

Fan type-piece /

Fan type-piece Axial flow fan -1

Fan diameter (mm) Φ320 Φ400

Defrosting method Auto

Climate type T1

Insulation class I

Waterproof level IP24

Maximum working pressure of

exhaust side (Mpa)

3.8

Maximum working pressure of

exhaust side (Mpa)

1.2

Noise（sound pressure level）

dB(A) 52 56

Noise (sound pressure level)

dB(A) 62 66

Outline dimension (W/D/H)(mm) 660×260×430 848×320 ×540

Package dimension (W/D/H)(mm) 765×350×500 878×360 ×600

Net weight/gross weight (kg) 25/29 30/34

Outdoor

unit

Refrigerant/refrigerant charge (kg) R410A /0.88 R410A /1.1

Length 4

Liquid pipe (mm) Φ6Outer

diameter Gas pipe (mm) Φ9.52

Height (m) 5

Connection pipe

Maximu

distance Length (m) 10

—8—

Model PRO AIR 112 IN PRO AIR I109 IN

Function Cooling Heating Cooling Heating

Rated voltage 230V

Rated frequency 50Hz

Capacity (W) 3200 3400 2500 2700

Nominal power (W) 1060 1220 730 800

Max. power (W) 1390 1370 1246 1297

Greatest currency (A) 7.2 7.4 5.7 6

Air flow （m3/h）450 450

Dry capacity (L/h) 1.2 1.2

C.O.P/EER (W/W) 3 2.8 3.4 3.4

Model KFR-32G/NaA121-E KFR-25G/NaA12F-E

Fan speed (r/min)(H/M/L) 1160/1010/890 1190/1090/990

Output power (W) 14 14

Auxiliary electric heater power /

Fan capacitor 1

Fan motor running current 0.12 0.12

Fan type-piece Cross flow fan-1

Diameter-length (mm) Φ97×583

Evaporator Aluminum fin-copper tube

Pipe diameter Φ7

Row-fin distance (mm) 2-1.4

Developed area of heat exchanger

(I×H×L) 580mm ×228.6mm×25.4mm

Swing motor model MP24GA

Motor power (W) 2

Fuse (A) PCB3.15A Transformer 0.2A

Noise (sound pressure level)

dB(A) 42/39/36 42/39/36

Noise (sound pressure level)

dB(A) 52/49/46 52/49/46

Outline dimension (W/D/H) (mm) 770×180×250

Package dimension (W/D/H) (mm) 855×270×336

Indoor

unit

Net weight/gross weight (kg) 8.5/12.5

—9—

Model PRO AIR 112 OUT PRO AIR 109 OUT

Compressor type C-RV133H1A EU1011DV

Compressor type Rotary type

Locked rotor current 24 33.5

Compressor running current 5.25 4

Compressor input power 1125 628

Compressor overload model B210-145-241E 4CYC11233

Throttling method Capillary

Starting mode Capacitor

Working temperature range －7～43℃

Condenser Aluminum fin-copper tube

Pipe diameter Φ9.52

Row-fin distance (mm) 2-1.4 2-1.4

Developed area of heat exchanger

(I×H×L) 791×508×44 645×508×44

Fan motor speed (rpm) 830 830

Motor rated power (W) 30 30

Fan motor running current (A) 0.26 0.3

Fan capacitor (μf) 2.5 2.5

Fan type-piece /

Fan type-piece Axial flow fan-1

Fan diameter (mm) Φ400 Φ400

Defrosting method Auto

Climate type T1

Insulation class I

Waterproof level IP24

Maximum working pressure of

exhaust side (Mpa) 3.8

Maximum working pressure of

exhaust side (Mpa) 1.2

Noise (sound pressure level) dB(A) 56 54

Noise (sound pressure level) dB(A) 66 64

Outline dimension (W/D/H) (mm) 848×320 ×540 848×320 ×540

Package dimension (W/D/H) (mm) 878×360 ×600 878×360 ×600

Net weight/gross weight (kg) 30/34 41/43

Outdoo

r unit

Refrigerant/refrigerant charge (kg) R410A /1.3 R410A /1.2

Length 4

Liquid pipe (mm) Φ6Outer

diameter Gas pipe (mm) Φ9.52

Height (m) 5

Connection

pipe

Maximum

distance Length (m) 10
