Fujitsu Fi-4860C Manual

Operator's Guide

fi-4860C Image Scanner

P3PC-E167-01EN

●i

Thank you for purchasing the fi-4860C Duplex Color Scanner.

The fi-4860C is an image scanner designed to scan various documents in large

quantities. FUJITSU fi series image scanners are known for its high reliability and

this scaner is no exceptions. The fi-4860C is designed to give you the best results

for your scnning need.

The fi-4860C has the following features.

 High speed, high quality color scanning capabilities

Scans documents of A4 size at the speed of 60ppm/120ipm (200dpi).

 Highly reliable document handling

Accepts various thicknesses, sizes and types of documents.

 Production ready

High capacity hopper (500sheets, 20lb(75g/m2) A4 size) and imprinter

options. Duplex capability is provided as standard.

About this manual

The manual provides the following information.

1. BASIC OPERATIONS

This chapter describes basic scanner operations and basic document

scanning.

2. SCANNING DOCUMENTS

This chapter describes how to scan various type of documents.

3. DAILY CARE

This chapter describes how to clean the scanner.

4. REPLACING CONSUMABLES

This chapter describes how to replace scanner consumables.

5. SOLVING COMMON PROBLEMS

INTRODUCTION

●ii

This chapter describes how to remedy document jams, other trouble,

items to check before contacting the agent where you bought the

scanner, and how to check device labels.

6. ADF DOCUMENT SPECIFICATIONST

This chapter describes about documents can be used with this scanner.

7. OPERATOR PANEL MENUS

This chapter describes about Setup-mode and Test-mode.

8. OPTIONS

This chapter describes about options.

9. SCANNER SPECIFICATIONS

This chapter lists the scanner specifications.

The “Installation Guide” is attached to this Scanner.

This guide icontains necessary information for the scanner and the driver

installation, please also read the Installation Guide.

1. SCANNER BASICS

This chapter describes how to prepare the scanner for use.

2. INSTALLATION AND CONNECTIONS

This chapter describes how to install and connect the scanner, and how

to install the scanner application.

We hope that this manual is useful in taking full advantage of the fi-4860C Duplex

Color Scanner's features.

August, 2002

●iii

■ Revisions

FCC declaration

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instruction manual, may

cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the user is encouraged to

try to correct the interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conformme à la norme NMB-003 du

Canada.

CAUTION

Changes or modifications not expressly

approved by the party responsible for compli-

ance could void the user’s authority to operate

the equipment.

WARNING

•The use of a non-shielded interface cable

with the referenced device is prohibited.

The length of the parallel interface cable

must be 3 meters (10 feet) or less. The

length of the serial interface cable must be

15 meters (50 feet) or less.

•The length of the AC cable must be 3

meters (10 feet) or less.

●iv

Bescheimigung des Herstellers / Importeurs

Hiermit wird bescheinigt, daß der/dieldas

•fi-4120C in Übereinsstimmung mit den Bestimmungen der

•AmtsblVfg 243/1991 funkentstört ist. Der Deutschen Bundesport wurde das

Inverkehrbringen dieses Gerätes angezeigt und die Berechtigung zur Überprüfung

der Serie auf Einhaltung der Bestimmungen eingeräumt.

•Maschinenlärminformationsverordnung 3. GS GV, 18.01.1991:Der höchste

Schalldruckpegel beträgt 70 dB (A) order weniger gemäß ISO/7779.

●v

International Energy Star Program

As a participating operator of the International Energy Star Program,

PFU LIMITED. certifies that this product satisfies the requirements

of the International Energy Star Program.

The International Energy Star Program is an international program

for promoting energy conservation in computers and other office equipment. The

purpose of this program is to promote the development and propagation of products

provided with functions for efficiently limiting energy consumption. Operators opt to

participate in this program on a voluntary basis. Equipment covered by this program

are computers, displays, printers, facsimiles, copiers, and other office equipment.

The standards for each of these equipment Energy Star mark ( ) are unified by

each participating country.

Use in High-safety Applications

This product has been designed and manufactured on the assumption that it will be

used in office, personal, domestic, regular industrial, and general-purpose

applications. It has not been designed and manufactured for use in applications

(simply called "high-safety applications" from here on) that directly involve serious

danger to life and health when an extremely high degree of safety is required, for

example, in the control of nuclear reactions at nuclear power facilities, automatic

flight control of aircraft, air traffic control, operation control in mass-transport

systems, medical equipment for sustaining life, and missile firing control in weapons

systems, and when provisionally the safety in question is not ensured. The user

should use this product without adopting measures for ensuring safety in such high-

safety applications. FPU Co., Ltd. assumes no liability whatsoever for damages

arising from use of this product by the user in high-safety applications, and for any

claims or compensation for damages by the user or a third party.

●vi

About the use of mercury

Scanner lamp includes mercury.

Too avoid unexpected injury, read the followings carefully.

Doing following actions may result in serious personal injuries:

•Put the substance in the lamp into mouth as it contains mercury.

•Vaporize, crumb, condense the scanner.

•Aspirate the chemical liquid containd in scanner parts.

Dispose of the scanner should be conducted as required by local ordinances or

regulations.

Illegal Copying

Copying of bank notes, currency, government-issued bonds and passports, licenses

and permits issued by public and private organizations, official documents, private

documents, etc. is illegal and punishable by law.

photographs, etc. cannot be reproduced without the permission of the rightful

person except in individual or domestic applications, or in other similar applications

within a limited scope.

●vii

Trademarks

Microsoft®, Windows®and Windows NT®are registered trademarks of Microsoft

Corporation of the USA and other respective countries.

ISIS®is a registered trademark of Pixel Translations, A Division of Actionpoint Inc.

Adobe and the Adobe logo as well as Acrobat and the Acrobat Logo are trademarks

of Adobe Systems Incorporated.

Other product names referred to in this manual are registered trademarks or

trademarks of respective companies.

How Trademarks Are Indicated In This Manual

References to operating systems (OS) are indicated as follows:

Windows®95: Refers to Microsoft®Windows®98 operating system.

Windows®98: Refers to Microsoft®Windows®98 operating system.

Windows®Me: Refers to Refers to Microsoft®Windows®Millennium Edition

operating system.

Windows®2000: Refers to Microsoft®Windows®2000 Professional operating

system.

Windows®XP: Refers to Microsoft®Windows®XP Professional operating

system, and Microsoft®Windows®XP Home Edition operating

system.

Windows NT®: Refers to Microsoft®Windows NT®operating system Version4.0.

Where there is no distinction between the different versions of the above operating

system, the general term "Windows®" is used.

●viii

■ Preface

Safety Precautions

This manual describes important details for ensuring the safe and correct use of

this product. Thoroughly read this manual before you start to use this product. In

particular, be sure to read and fully understand the Safety Precautions described in

this manual before you use this product.

Also, store this manual in a safe place so that it can be easily referred to during use

of this product.

Warning Indications Used In This Manual

This manual uses the following indications to ensure safe and correct use of this

product, and to prevent possible danger and injury to the operator and other

persons.

CAUTION

This indication alerts operators to an opera-

tion that, if not strictly observed, may result in

severe injury or death.

WARNING

This indication alerts operators to an opera-

tion that, if not strictly observed, may result in

safety hazards to personnel or damage to

equipment.

●ix

Symbols Used In This Manual

This manual uses the following symbols in explanations in addition to warning

indications.

ATTENTION

This symbol alerts operators to particularly

important information. Be sure to read this infor-

mation.

HINT

This symbol alerts operators to helpful advice

regarding operation.

A TRIANGLE symbol indicates that special care

and attention is required.

The drawing inside the triangle shows the specific

caution.

A CIRCLE with a diagonal line inside shows

action which users are not

allowed to do.The drawing inside or under the cir-

cle shows the specific

action that is not allowed.

Outline characters on a colored background

shows instructions users

should follow. It may include the drawing which

shows the sepecific

instruction.
