Fujitsu AUXG07KVLA User manual

AIR CONDITIONER

4-unit multi-split type,

5-unit multi-split type

SERVICE MANUAL

INDOOR

AUXG07–22KVLA ARXG07–14KSLAP

ARXG18KSLAP

ARXG07–14KLLAP

ARXG18KLLAP

ARXG22KMLB

ASHG07–14KGTB ASHG07–14KGTE ASHG18–24KMTB

ASHG18–24KMTE

ASHG07–14KMTB

ASHG07–14KMCC

ASHG07–14KMCE

ASHG07–14KETA

ASHG07–14KETE

OUTDOOR

ASHG07–14KETA-B

ASHG07–14KETE-B

ABHG18–22KRTA AGHG09–14KVCA AOHG30KBTA4

AOHG36KBTA5

SR_MU004EG_13

2022.08.08

Notices:

• Product specifications and design are subject to change without notice for future improvement.

• For further details, please check with our authorized dealer.

Trademarks

FGLair™ is trademark of Fujitsu General Limited in the United States, other countries or both.

Google Play™ is trademark of Google LLC.

App Store® is a service mark of Apple Inc., registered in the U.S. and other countries.

CONTENTS

1. GENERAL INFORMATION

2. TECHNICAL DATA AND PARTS LIST

3. TROUBLESHOOTING

4. CONTROL AND FUNCTIONS

5. FILED WORKING

1. GENERAL INFORMATION

2022.08.08

SR_CH01_MU004EG_06

CONTENTS

1. GENERAL INFORMATION

1. Specifications..............................................................................................01-1

1-1. Indoor unit ......................................................................................................................01-1

1-2. Outdoor unit..................................................................................................................01-19

2. Dimensions................................................................................................01-23

2-1. Compact cassette type .................................................................................................01-23

2-2. Mini duct type ...............................................................................................................01-25

2-3. Slim duct type ...............................................................................................................01-28

2-4. Medium static pressure duct type .................................................................................01-31

2-5. Wall mounted type........................................................................................................01-33

2-6. Ceiling type...................................................................................................................01-47

2-7. Floor type .....................................................................................................................01-49

2-8. Outdoor unit..................................................................................................................01-51

1. Specifications

1-1. Indoor unit

¢Compact cassette type

Model name AUXG07KVLA AUXG09KVLA AUXG12KVLA AUXG14KVLA

Power supply 1Ø 230 V ~50 Hz

Available voltage range 198—264 V

Capacity kW class 2.0 2.5 3.5 4.0

Input power W 18 23 28

Running current A 0.15 0.19 0.22

Fan

Airflow rate

Cooling

HIGH

m3/h

540 610 680

MED 490 530 580

LOW 440 470 490

QUIET 390 410 410

Heating

HIGH 540 610 790

MED 490 530 680

LOW 440 470 580

QUIET 390 410 450

Type × Q'ty Turbo fan × 1

Motor output W 54

Sound pressure level *

Cooling

HIGH

dB (A)

33 37 38

MED 31 34 35

LOW 29 31 32

QUIET 27 28 29

Heating

HIGH 34 37 43

MED 32 34 38

LOW 29 31 34

QUIET 27 29 30

Sound power level Cooling dB (A) 46 49 50

Heating 47 49 55

Heat exchanger type

Dimensions (H × W × D) mm Main1: 210 × 1,310 × 13.3

Main2: 210 × 1,250 × 13.3

Fin pitch mm 1.2

Rows × Stages Main1: 1 × 10

Main2: 1 × 10

Pipe type Copper tube

Fin type Aluminum

Dimensions

(H × W × D)

Net mm 245 × 570 × 570

Gross 265 × 730 × 625

Weight Net kg 15

Gross 19

Connection pipe Size Liquid mm (in) Ø6.35 (Ø1/4)

Gas Ø9.52 (Ø3/8)

Method Flare

Drain hose Material PVC

Tip diameter mm Ø25 (I.D.), Ø32 (O.D.)

Operation range Cooling °C 18 to 32

%RH 80 or less

Heating °C 16 to 30

Cassette grille

(Grid type: Option)

Model name UTG-UFGF-W

Material Polystyrene

Color White

Approximate color of Munsell 9PB 9.1/0.2

Dimensions

(H × W × D)

Net mm 49 × 620 × 620

Gross 120 × 765 × 755

Weight Net kg 2.3

Gross 4.5

NOTES:

• The protective function might work when using it outside the operation range.

• *: Sound pressure level:

– These are the measured values in the manufacturer’s anechoic chamber.

– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.

1-1. Indoor unit - (01-1) - 1. Specifications

GENERAL

INFORMATION

GENERAL

INFORMATION

Model name AUXG18KVLA AUXG22KVLA

Power supply 1Ø 230 V ~50 Hz

Available voltage range 198—264 V

Capacity kW class 5.0 6.0

Input power W 39 84

Running current A 0.30 0.62

Fan

Airflow rate

Cooling

HIGH

m3/h

680 830

MED 580 740

LOW 490 600

QUIET 410 450

Heating

HIGH 790 860

MED 680 760

LOW 580 700

QUIET 450 530

Type × Q'ty Turbo fan × 1

Motor output W 54

Sound pressure level *

Cooling

HIGH

dB (A)

38 44

MED 35 42

LOW 32 36

QUIET 29 30

Heating

HIGH 43 45

MED 38 43

LOW 34 40

QUIET 30 33

Sound power level Cooling dB (A) 50 56

Heating 55 57

Heat exchanger type

Dimensions

(H × W × D) mm

Main1: 210 × 1,310 × 13.3

Main2: 210 × 1,250 × 13.3

Main1: 210 × 1,360 × 13.3

Main2: 210 × 1,295 × 13.3

Main3: 210 × 1,235 × 13.3

Fin pitch 1.2 1.45

Rows × Stages Main1: 1 × 10

Main2: 1 × 10

Main1: 1 × 10

Main2: 1 × 10

Main3: 1 × 10

Pipe type Copper tube

Fin type Aluminum

Dimensions

(H × W × D)

Net mm 245 × 570 × 570

Gross 265 × 730 × 625

Weight Net kg 15 16

Gross 19 20

Connection pipe Size Liquid mm (in) Ø6.35 (Ø1/4)

Gas Ø12.70 (Ø1/2)

Method Flare

Drain hose Material PVC

Tip diameter mm Ø25 (I.D.), Ø32 (O.D.)

Operation range Cooling °C 18 to 32

%RH 80 or less

Heating °C 16 to 30

Cassette grille

(Grid type: Option)

Model name UTG-UFGF-W

Material Polystyrene

Color White

Approximate color of Munsell 9PB 9.1/0.2

Dimensions

(H × W × D)

Net mm 49 × 620 × 620

Gross 120 × 765 × 755

Weight Net kg 2.3

Gross 4.5

NOTES:

• The protective function might work when using it outside the operation range.

• *: Sound pressure level:

– These are the measured values in the manufacturer’s anechoic chamber.

– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.

1-1. Indoor unit - (01-2) - 1. Specifications

GENERAL

INFORMATION

GENERAL

INFORMATION

¢Mini duct type

Model name ARXG07KSLAP ARXG09KSLAP ARXG12KSLAP ARXG14KSLAP

Power supply 1Ø 230 V ~50 Hz

Available voltage range 198—264 V

Capacity kW class 2.0 2.5 3.5 4.0

Input power Fan

HIGH

33 40 47 72

MED 23 23 26 44

LOW 20 20 22 30

QUIET 18 18 18 18

Running current A 0.29 0.33 0.38 0.58

Fan

Airflow rate

Cooling

HIGH

m3/h

550 600 650 800

MED 440 450 490 640

LOW 390 400 430 530

QUIET 360 360 360 360

Heating

HIGH 550 600 650 800

MED 440 450 490 640

LOW 390 400 430 530

QUIET 360 360 360 360

Type × Q'ty Sirocco fan × 2

Motor output W 75

Recommended static pressure Pa 0 to 30 0 to 50

Sound pressure level *

Cooling

HIGH

dB (A)

29 29 31 35

MED 26 26 27 30

LOW 24 24 25 27

QUIET 23 23 23 23

Heating

HIGH 29 29 31 35

MED 26 26 27 30

LOW 24 24 25 27

QUIET 23 23 23 23

Sound power level Cooling dB (A) 52 54 55 60

Heating 53 56 57 62

Heat exchanger type

Dimensions (H × W × D) mm 336 × 490 × 26.6

Fin pitch mm 1.3

Rows × Stages 2 × 16

Pipe type Copper tube

Fin type Aluminum

Enclosure Material Steel sheet

Color —

Dimensions

(H × W × D)

Net mm 198 × 700 × 450

Gross 250 × 930 × 580

Weight Net kg 15.5

Gross 19.0

Connection pipe Size Liquid mm (in) Ø6.35 (Ø1/4)

Gas Ø9.52 (Ø3/8)

Method Flare

Drain hose Material Hard PVC

Tip diameter mm Ø25 (I.D.), Ø32 (O.D.)

Operation range Cooling °C 18 to 32

%RH 80 or less

Heating °C 16 to 30

NOTES:

• Values mentioned in the table are based on the following conditions:

– Static pressure: 07-12 models: 10 Pa, 14 model: 15 Pa

• The protective function might work when using it outside the operation range.

• *: Sound pressure level:

– These are the measured values in the manufacturer’s anechoic chamber.

– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.

1-1. Indoor unit - (01-3) - 1. Specifications

GENERAL

INFORMATION

GENERAL

INFORMATION

Model name ARXG18KSLAP

Power supply 1Ø 230 V ~ 50 Hz

Available voltage range 198—264 V

Capacity kW class 5.0

Input power Fan

HIGH

MED 38

LOW 22

QUIET 19

Running current A 0.49

Fan

Airflow rate

Cooling

HIGH

m3/h

940

MED 750

LOW 540

QUIET 480

Heating

HIGH 940

MED 750

LOW 540

QUIET 480

Type × Q'ty Sirocco fan × 3

Motor output W 80

Recommended static pressure Pa 0 to 50

Sound pressure level *

Cooling

HIGH

dB (A)

MED 29

LOW 26

QUIET 23

Heating

HIGH 33

MED 29

LOW 26

QUIET 23

Sound power level Cooling dB (A) 58

Heating 59

Heat exchanger type

Dimensions (H × W × D) mm 336 × 690 × 26.6

Fin pitch 1.30

Rows × Stages 2 × 16

Pipe type Copper tube

Fin type Aluminum

Enclosure Material Steel sheet

Color ―

Dimensions

(H × W × D)

Net mm 198 × 900 × 450

Gross 250 × 1,130 × 580

Weight Net kg 18.5

Gross 23.0

Connection pipe Size Liquid mm (in) Ø6.35 (Ø1/4)

Gas Ø12.7 (Ø1/2)

Method Flare

Drain hose Material PVC

Tip diameter mm Ø25 (I.D.), Ø32 (O.D.)

Operation range Cooling °C 18 to 32

%RH 80 or less

Heating °C 16 to 30

NOTES:

• Values mentioned in the table are based on the following conditions:

– Static pressure: 15 Pa

• The protective function might work when using it outside the operation range.

• *: Sound pressure level:

– These are the measured values in the manufacturer’s anechoic chamber.

– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.

1-1. Indoor unit - (01-4) - 1. Specifications

GENERAL

INFORMATION

GENERAL

INFORMATION

Other manuals for AUXG07KVLA

This manual suits for next models

Table of contents

Other Fujitsu Air Conditioner manuals

Fujitsu

Fujitsu AOY25FNAKT User manual

Fujitsu

Fujitsu AUXG07KVLA User manual

Fujitsu

Fujitsu AUY36FUAS User manual

Fujitsu

Fujitsu AS A009GCGH Series User manual

Fujitsu

Fujitsu AR*G12LLTB Service manual

Fujitsu

Fujitsu AUYG12LVLB User manual

Fujitsu

Fujitsu ASBH27CMTA Service manual

Fujitsu

Fujitsu ABT14LBAJ User manual

Fujitsu

Fujitsu asyg18lfca User manual

Fujitsu

Fujitsu Inverter Halcyon ASU9RL Original operating manual

Fujitsu

Fujitsu ASYG07KETA User manual

Fujitsu

Fujitsu AG*G09LVCA User manual

Fujitsu

Fujitsu Airstage VR-II ARUH36TLAV User manual

Fujitsu

Fujitsu ASYG07KMCF User manual

Fujitsu

Fujitsu ARTG36LHTB User manual

Fujitsu

Fujitsu AWYZ24LBC User manual

Fujitsu

Fujitsu AU A30LBLU Series Service manual

Fujitsu

Fujitsu ARG45FUAN User manual

Fujitsu

Fujitsu Inverter Halcyon ASU24RL User manual

Fujitsu

Fujitsu ASYG09LLTB-T User manual

Fujitsu

Fujitsu ASYG07KGTF User manual

Fujitsu

Fujitsu Halcyon User manual

Fujitsu

Fujitsu AUXB04GALH User manual

Fujitsu

Fujitsu AG*F09LAC User manual

Popular Air Conditioner manuals by other brands

Spheros

Spheros CC 355 instructions

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE owner's manual

Panasonic

Panasonic CS-E12HKEW operating instructions

nedis

nedis ACMB1WT7 quick start guide

Samsung

Samsung AR KV Series User & installation manual

Daikin

Daikin FCFV50A Operation manual

Toshiba

Toshiba RAS-M10SMUV-E installation manual

Daikin

Daikin FXLQ20MAVE Operation manual

Hitachi

Hitachi RAS-E24CAK instruction manual

CIAT

CIAT Magister 2 Series Installation, Operation, Commissioning, Maintenance

Bestron

Bestron AAC6000 instruction manual

Hisense

Hisense 7K Use and Installation Instructions

Frigidaire

Frigidaire FFRE0533S1E0 Use & care guide

Samsung

Samsung AS09HM3N user manual

Frigidaire

Frigidaire CRA073PU11 use & care

Soleus Air

Soleus Air GB-PAC-08E4 operating instructions

McQuay

McQuay MCK020A Technical manual

Webasto

Webasto Frigo Top 25 DS Instructions for use
