Frigidaire FRQG7000LW Installation instructions

Front Load Dryer

FRQG7000L W

7 Dry Cycles

7.0 Cu. Ft. Gas

frigidaire.com

Product Dimensions

Height 36"

Width 27"

Depth 28-1/2"

More Easy To Use Features

Reversible Door

Choose which direction you want the door

to open to accommodate your space.

Ready-Select® Controls

Easily select options with the touch of

a button.

Timed Dry Cycles

Multiple Dryness Levels

Auto Dry Cycles

Control Lock

Quick Dry

Optional Pedestal Drawer

Available in:

Signature Features

White

(W)

Balanced Dry System

Dries clothes more evenly for better

results.

Wrinkle Release

Technology

This option features a Wrinkle Release

System that finishes by tumbling

without heat, preventing wrinkles, so

your clothes look great every time.

Precision Dry™

Moisture Sensor

Dries your clothes more precisely,

reducing wrinkles.

Super Capacity

Dries even extra-large loads quickly

and efficiently.

Optional Pedestal Drawer Shown

Features

Total Capacity (Cu.Ft.)

Controls

Dryer Drum Interior

Interior Light

Door Trim

Ready Steam™

DrySense™ Technology

Wrinkle Release Technology

TimeWise™ Technology

Moisture Sensor

Time Remaining Indicator

Cycle Status Lights

Cycle Signal

Cycle Signal “On/O”

Cycle Signal Volume Control

Control Lock

Start/Pause/Cancel Buttons

Energy Saver Option

Delay Start

Tumble Speed (RPM)

Reversible Door

Lint Screen

Sound Package

Adjustable Leveling Legs

Cycles

Dry Cycles

Specialty Cycles

Options

Temperature Selections

Dryness Level Selections

Timed Dry

Optional Accessories

Dryer Stacking Kit

15" Frigidaire Anity® Pedestal Drawers

Classic Black (B)

Classic White (W)

Mobile Home Installation Kit

LP Gas Conversion Kit

Drying Rack

Certiﬁcations

NSF® Certiﬁed Sanitize

Speciﬁcations

Gas Connection

Power Cord Location

Voltage Rating

Connected Load (kW Rating) @ 120 Volts1

Amps @ 120 Volts

Heating Element (BTU/HR)

Shipping Weight (Approx.)

Front Load Laundry - Electric/Gas Dryer

Frigidaire Next Level

Front Load Dryer

FRQG7000L W 7.0 Cu. Ft. Gas

USA

•

10200 David Taylor Drive

•

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

Specifications

subject to change.

Product Dimensions

A-Height (Single)

Height (Stacked)

B-Width

C-Depth

Depth with Door Open 90˚

Pedestal Dimensions

A-Height

B-Width

C-Depth

36"

72"

27"

28-1/2"

48-1/2"

15-1/4"

27"

24"

Accessories information available

on the web at frigidaire.com

7.0

Ready-Select®

Painted Steel

Yes

White

Yes

15, 30, 45, 60, 75, 90

PN# STACKIT7

(W) PN# CFPWD15W

PN# 137067200

PN# PCK4200

PN# 137067300

Left Bottom Rear

Right Bottom Rear

120V/60Hz/15A

0.5

20,000

129 Lbs.

1For use on adequately wired 120V, dedicated circuit having 2-wire service

with a separate ground wire. Appliance must be grounded for safe operation.

NOTE: For planning purposes only. Always consult local and national

electric, gas and plumbing codes. Refer to Product Installation Guide

on the web at frigidaire.com for detailed instructions.
