Frigidaire Affinity FASE7074LA Installation instructions

Signature Features

Ultra-Capacity Dryer

The largest in its class1, so you can fin-

ish more laundry, even faster.

Ready Steam™

Removes wrinkles and refreshes

clothes.

frigidaire.com

Optional SpaceWise® Pedestal Drawer Shown

Specialty Cycles

Dry everything from teddy bears to

pet beds and active wear.

DrySense™ Technology

Dries your clothes more precisely,

reducing wrinkles.

Product Dimensions

Height 36"

Width 27"

Depth 30-5/16"

More Easy To Use Features

Specialty Options

Dry special items, prevent static and

reduce allergens.

Energy Saver Option

Reduces energy use up to 35%.2

Useful Dryer Options

Anti-Static, Line Dry, Delay Start and

Wrinkle Release Technology.

Allergen Option

SilentDesign™ Premium

for quiet operation.

Moisture Sensor

Optional SpaceWise®

Pedestal Drawer

Express-Select® Controls

Easily select options with the touch of

a button.

Delay Start 1 to 12 Hours

Sanitize Option

Sanitize without washing.

Triple Element Heat

Reversible Door

NSF® International Certiﬁcation

Available in:

1Based on I.E.C. std. 60456 4th Edition for dryers

37" or less in height and 27" or less in width.

2Based on a 3 lb. delicate AHAM load as compared

to not using energy saver option for the same

model.

Front Load Dryers

FASE7074L R / N / A / W

10 Dry Cycles

7.0 Cu. Ft. Electric

Classic

White

(W)

Classic

Red

(R)

Classic

Blue

(N)

Classic

Silver

(A)

Front Load Laundry - Dryers (E & G)

Frigidaire Affinity (L models)

Specifications

subject to change.

Product Dimensions

A - Height (Single)

Height (Stacked)

B - Width

C - Depth

Depth with Door Open 90˚

Pedestal Dimensions

A - Height

B - Width

C - Depth

36"

71-1/2"

27"

30-5/16"

51-7/16"

15-1/4"

27"

26-1/4"

Features

Total Capacity (Cu. Ft.)

Controls

Dryer Drum Interior

Interior Light

Door Trim

Ready Steam™

DrySense™ Technology

Wrinkle Release Technology

TimeWise™ Technology

Moisture Sensor

Time Remaining Indicator

Cycle Status Lights

Cycle Signal

Cycle Signal “On/O ”

Cycle Signal Volume Control

Control Lock

Start / Pause / Cancel Buttons

Energy Saver Option

Delay Start

Tumble Speed (RPM)

Reversible Door

Lint Screen

Sound Package

Adjustable Leveling Legs

Cycles

Dry Cycles

Specialty Cycles

Options

Temperature Selections

Dryness Level Selections

Timed Dry

Optional Accessories

Dryer Stacking Kit

15" Frigidaire Anity® Pedestal Drawers

Classic Red (R)

Classic Blue (N)

Classic Silver (A)

Classic Black (B)

Classic White (W)

Mobile Home Installation Kit

Drying Rack

Certiﬁcations

NSF® Certiﬁed Sanitize

Speciﬁcations

Power Supply Connection Location

Voltage Rating

Connected Load (kW Rating) @ 240 Volts

Amps @ 240 Volts

Heating Element @ 240 Volts (Watts)

Shipping Weight (Approx.)

Accessories information available

on the web at frigidaire.com

NOTE: For planning purposes only. Always consult local and national

electric and plumbing codes. Refer to Product Installation Guide for

detailed installation instructions on the web at frigidaire.com.

7.0

Express-Select®

Stainless Steel

Yes

Chrome

Yes

Music

Yes

1 to 12 Hours

Yes

SilentDesign™ Premium

Yes

15, 30, 45, 90

PN # STACKIT4X

(R) PN # CFPWD15R

(N) PN # CFPWD15N

(A) PN # CFPWD15A

(W) PN # CFPWD15W

PN # 137067200

PN # 137067300

Yes

Right Bottom Rear

240V / 60Hz / 30A

5.0

5,500

140 Lbs.

Front Load Dryers

FASE7074L R / N / A / W 7.0 Cu. Ft. Electric

USA

•

10200 David Taylor Drive

•

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca
