Frigidaire FRA086AT7 User manual

frigidaire.com

Signature Features

Compact

Air Conditioner

Product Dimensions

Height 14-11/16"

Width 21-13/16"

Depth 18-1/8"

More Easy-To-Use Features

Energy and Cost Savings

The unit operates at a low voltage –

conserving energy and saving you money.

Multi-Speed Fan

Features three different fan speeds, for

more cooling flexibility.

Sleep Mode

Quiet operation keeps you cool without

keeping you awake. Plus, Sleep Mode

gradually increases room temperature

after being activated.

Quickly Cools

Comfort Control Design

Easily control the direction of your cool air,

wherever your unit is.

Eortless™ Restart

Automatically resumes operating at its

previous settings when power is restored

to your unit.

Clean Filter Alert

Power Cord

Comes with an extra long three-prong

cord that makes extension cords

unnecessary.

SpaceWise™ Adjustable Design

Optional Side Panels extend so you can

adjust your unit to fit your window.

ENERGY STAR®

Available in:

Eortless™

Temperature Control

Our air conditioners maintain the preset

room temperature, so you will remain

comfortable at all times.

Ready-Select™ Controls

Easily select options with the touch of a

button.

Eortless™ Clean Filter

Our anti-microbial filter cleans the air,

removing harmful bacteria.

Remote Control

Allows you to precisely control the

temperature and fan speed from across

the room.

Performance

Cool

BTUs

8,000

Home Comfort

FRA086AT7

Specifications

subject to change.

Product Dimensions

A - Height

B - Width

C - Depth

Window Dimensions

D -Height (Min.)

E -Width (Min. / Max.)

NOTE: For planning purposes only. Always consult local and national electric codes.

Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.

RAC Compact Models_Window

Frigidaire Baseline

Accessories information available

on the web at frigidaire.com

Performance

BTU (Cool)

Dehumidiﬁcation (Pints / Hour)

Cool Area (Sq. Ft.)

Energy Eciency Ratio

Electrical

Volts

Amps (Cool)

Watts (Cool)

Length of Power Cord (Min. / Max.)

Plug Type (NEMA)*

Features

Electronic Controls

Fan Speeds (Cool / Fan)

Low Voltage Start-Up

Auto Cool Function

Energy Save

Sleep Mode

Filter Check

24 Hour On / O Timer

Clean Air Ionizer

Remote Control

Air CFM (High / Med / Low)

Air Direction Control

Fresh Air / Exhaust Vent / Closed

Filter Type

Filter Access

Slide-Out Chassis

Cabinet Louvers

Rear Grille

Window Mounting Kit (Included)

Certiﬁcations

ENERGY STAR®

Performance

Speciﬁcations

Refrigerant

Shipping Weight (Approx.)

*Plug Type (NEMA)

(A) 5-15P

14"

23" / 36"

14-11/16"

21-13/16"

18-1/8"

8,000

1.7

350

10.8

115

7.0

740

6' / 6.5'

LCDI (A)

Ready-Select™ Controls

3 / 3

Yes

Full-Function Remote T’Stat

217 / 176 / 147

8-Way

No / No / Yes

Antimicrobial Mesh

Tilt-Out

Yes

Pleated Quick Mount

Yes

AHAM

R410a

55 Lbs.

USA

•

10200 David Taylor Drive

•

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

Home Comfort

FRA086AT7 Compact Air Conditioner
