Foscam FI9902P User manual
1
User
User Manual
Manual
Foscam 1080P Starlight Outdoor
Wi-Fi IP Security Camera
Model: FI9902P FI9912P G2
V3.0
2
Table of Contents
1 Overview............................................................................................................................................................................. 3
1.1 Key Features...........................................................................................................................................................3
1.2 Read before Use.................................................................................................................................................... 3
1.3 Packing Contents................................................................................................................................................... 3
1.4 Physical Description.............................................................................................................................................. 4
1.5 SD Card Management...........................................................................................................................................5
1.6 Add Device: Connection via the Foscam App................................................................................................... 5
1.7 Installation............................................................................................................................................................... 5
1.8 Waterproof Lid Installation Guide........................................................................................................................ 6
2 Default Parameters........................................................................................................................................................... 7
3 Specification....................................................................................................................................................................... 7
3
1 Overview
1.1 Key Features
2MP FHD Waterproof IP Camera
H.264 video Compression
Supports Human detection, Motion Detection
Compatible with free Foscam Video Management Software
Compatible with free Foscam iOS and Android APP
Support 2.4GHz WiFi
Supports WDR(Wide-Dynamic Range)
Supports 256GB Micro SD Card storage(External)
Night Vision Range up to 20m(66 feet)
P2P Feature for Easy Remote Access
Supports image snapshot
Supports dual-stream
Supports remote viewing & record from anywhere anytime
Multi-level users management with password protection
Supports multiple network protocols: IP, TCP, UDP, SMTP, FTP, DHCP, RTSP
Supports Alexa
Supports Google Assistant
1.2 Read before Use
Please first verify that all contents received are complete according to the Package Contents listed below.
Before the Network Camera is installed, please carefully read and follow the instructions in the Quick Setup
Guide to avoid damage due to faulty assembly and installation. This also ensures the product is used properly
as intended.
1.3 Packing Contents
● Camera× 1
● Ethernet Cable× 1
● Quick Setup Guide × 1
● Expansion Screws× 1
● Waterproof Lid × 1
● Wi-Fi Antenna * 1
● Surveillance sign× 1
●Power Adapter × 1
4
1.4 Physical Description
1.4.1 Front Panel
1 WIFI Antenna: Wireless Antenna
2 Infrared LED: 30 IR LEDs
3 LENS: All Glasses Material
1.4.2 Interface
1 LAN
10/100M adaptive Ethernet interface. Through this interface, IP camera can be connected with various network
devices, such as hub, router, etc.
2 Audio input interface
The jack is used to plug external input device such as sound pick up device directly. Here microphone cannot
directly insert to the interface, it must connect to adapter first.
1
3
2
1
2
3
4
5
5
3 Audio output interface
The jack is used to plug external output device such as loud speaker directly. Here microphone cannot directly
insert to the interface, it must connect to adapter first.
4 Power Interface
Connect the external power adapter, request for 12V / 1A power.
5 Reset button
Press and hold on the reset button for 5 seconds. Releasing the reset button, the password will back to the
factory default administrator password. The default administrator user is admin with no password.
1.5 SD Card Management
This camera supports Micro SD Card.
When you plug in the SD card during the camera work process, please reboot the camera again, or else the
SD card might not work well.
On Foscam app go to the SettingsDevice StatusDevice Status page, you can see the SD card status.
1.6 Add Device: Connection via the Foscam App
Scan the QR code below to download and install the Foscam APP.
Please refer to the Quick Setup Guide.
1.7 Installation
Please refer to the Quick Setup Guide.
Point the camera at the desired location and use the screws provided to mount it.
Please Note:
6
Ensure that rain or water will not reach the connector ports at the end of the pig tail wiring. These connectors
are not weather-resistant.
1.8 Waterproof Lid Installation Guide
When mounting your PoE camera outdoors, you are suggested to install the waterproof lid for it. You may
follow the steps for installation.
1. Thread the Ethernet cable through the top cover and then the waterproof connector.
2. Put the rubber seal ring around the Ethernet cable between the top cover and the waterproof connector.
Note: The rubber seal ring provided has been cut. If not, you may manually cut it.
3. Put on the rubber O-ring to the Ethernet port of the camera and plug the Ethernet cable into the Ethernet
port.
4. Align the waterproof connector with the Ethernet port, then twist it clockwise to tighten the two parts.
5. Push the rubber seal ring into the waterproof connector, then screw the top cover and lock it into position
firmly to finish installation.
7
2 Default Parameters
Default network parameters
IP address: obtain dynamically
Subnet mask: obtain dynamically
Gateway: obtain dynamically
3 Specification
ITEMS
G2 V3 / FI9902P V3 / FI9912P V3
Image Sensor
Sensor Type
High Definition Color CMOS Sensor
Display Resolution
2.0Megapixels(1920 x 1080)
Min. Illumination
0 Lux (With IR Illuminator)
Lens
Lens Type
f.2.8mm; F1.6
Angle of view
Diagonal: 110.8°, Horizontal: 96°, Vertical: 52.56°
Video
Image Compression
H.264
Resolution
1080P(1920x1080), 720P(1280 x 720), VGA(640 x 480),
QVGA(320 x 240)
Stream
Dual stream
Image Adjustment
The hue, brightness, contrast, saturation, sharpness are
adjustable
Flip Image
Flip and mirror
Infrared Mode
Automatic or manual
Night Visibility
With 30pcs IR-LED, Night Vision Range up to 20m
Audio
Input/Output
External RCA interface for Full Duplex two-way audio
Network
Ethernet
One 10/100Mbps RJ45 port
Wireless Standard
IEEE802.11b/g/n
Data Rate
IEEE802.11b: 11Mbps(Max.);
IEEE802.11g: 54Mbps(Max.);
IEEE802.11n: 150Mbps(Max.).
Wireless Security
WPA, WPA2
Remote Access
P2P
8
Network Protocol
IP, TCP, UDP, SMTP, FTP, RTSP, DHCP
System
Requirements
Operating System
Microsoft Windows (Foscam VMS), MacOS (Foscam VMS),
Android (Foscam app), iOS (Foscam app)
Other Features
Motion Detection
Alarm via E-Mail, FTP and Foscam app when an event is
detected
Human Detection
Alarm via E-Mail, FTP and Foscam app when an event is
detected
User Accounts
Three levels user role
WDR
Improve image clarity in complex scenario
Zoom
6X digital zoom function
Storage
Support max. 256GB Micro SD card, local and FTP
storage,Foscam cloud storage
Intelligent Assistant
Supports Alexa, Google Assistant
Power
Power Supply
DC 12V/1.0A
Power Consumption
6 Watts (Max.)
Physical
Dimension(LxWxH)
97(L)x67 (W)x64 (H)
Net Weight
375g
Environment
Waterproof
IP66
Operating Temperature
-20°C~ 60°C (-4°F ~ 140°F)
Operating Humidity
10% ~ 80% non-condensing
Storage Temperature
-20°C ~ 60°C (-4°F ~ 140°F)
Storage Humidity
0% ~ 90% non-condensing
Certification
FCC, CE, RoHS, WEEE, IP66
For other parts, please refer to the “FOSCAM Camera User Manual”
