Focal CMS 40 User manual

CMS 40

Professional analog

monitoring speaker

Tweeter power unit:

25W rms / 9V /ms slew rate

Reproduction of the slightest details

Al/Mg inverted dome tweeter

Width, depth and accuracy

of the soundstage

Woofer ampliﬁcation unit:

25W rms / 0.01% THD

Sound transparency and power in

the midbass register

Aluminum cabinet optimized

for maximum rigidity and

damping

Acoustically transparent cabinet,

compact monitor

Polyglass cone

Neutral sound, no coloration

Fixing points compatible with

K&M® and Omnimount® ﬁxing kits

Numerous integration possibilities

(ﬁxing on stand, ceiling, wall, structure...)

Low frequencies and high

frequencies shelvings

Optimum acoustic integration

Supplied accessories

1 decoupling table stand

4 rubber feet

2 height adjustable spikes

1 phase optimization plug (tweeter)

2 removable grilles (tweeter and woofer)

Optional ﬁxing accessories

Description Brand Reference

Stand (37 3/8"-56 5/16"/950-1430mm) K&M 26740

Table stand (microphone stand 14-22 13/16"/355-580mm) K&M 23300

Wall ﬁxing (rotating / distance from wall 4 1/8"-105mm) K&M 24180

Wall ﬁxing (adjustable / rotating) OMNIMOUNT 20.5 WA

Wall ﬁxing (adjustable / rotating) OMNIMOUNT 20.5 CA

Wall ﬁxing (adjustable / rotating) OMNIMOUNT 20.5 ST

Structure ﬁxing (to use with OMNIMOUNT Ballshaft 20.5 ﬁxing kits) OMNIMOUNT 20.5C CLAMP

Focal® is a trademark of Focal-JMlab® - www.focalprofessional.com

BP 374 - 108, rue de l'Avenir - 42353 La Talaudière cedex - France - Tel. (+33) 04 77 43 57 00 - Fax (+33) 04 77 43 57 04

Focal® is a trademark of Focal-JMlab® - www.focalprofessional.com

Due to constant technological advances, Focal-JMlab reserves its right to modify technical specifications without notice. Images may not exactly conform to specific

product. SCAZ-100215/1

Technical speciﬁcations

System

• Frequency response (+/- 3dB) 60Hz - 28kHz

• Maximum SPL 97dB SPL (peak @ 1m)

Electronic section

• Input - Type/Impedance

- Connectors

Balanced 10 kOhms / Unbalanced 47 kOhms

XLR/RCA

• LF amplier stage

• HF amplier stage

25W rms, class AB

• Power supply - Mains Voltage

- Connection

220-230V (0.5A fuse)

120V (0.8A fuse)

100V (1A fuse)

IEC inlet and detachable power cord

• User controls - Sensitivity

- Volume

- LF shelving (0-450 Hz)

- HF shelving (4,5 kHz - 20 kHz)

- Power ON / OFF

Adjustable, +4dBu / 0 / -10dBV

Adjustable, -66dB / 0dB

Adjustable, 0 / -2 / +2dB

Power ON/OFF switch

• Indicators Power ON/OFF LED

Audio clip LED

Transducers

• Woofer 4" Focal drive unit, Polyglass cone

• Tweeter Aluminum/Magnesium inverted dome Focal tweeter

• Shielding Integral by compensation magnet

Cabinet

• Construction Reinforced and damped die cast Aluminum cabinet

• Finish Black powdered paint

• Dimensions with 4 rubber spikes (HxWxD)

• Dimensions with rubber table stand (HxWxD)

93/8 x 61/8 x 61/8" (238 x 156 x 155mm)

99/16 x 61/8 x 61/8" (243.2 x 156 x 155mm)

• Weight 11lb (5.5kg)

CMS 40

Professional analog

monitoring speaker
