Focal Point EF461LB-E Assembly Instructions

INSTALLATION & USER INSTRUCTIONS

MODELS COVERED BY THESE INSTRUCTIONS

EF461LB-E

MEDFORD LED ELECTRIC SUITE

-EAN 5023539026018

FLOOR MOUNTED ELECTRIC FIRE

Revision B - 03/21

GB IE

All instructions must be handed to the user

for safekeeping.

MODEL SHOWN: MEDFORD LED ELECTRIC SUITE

Image used for illustration purposes only

This product is only suitable for well insulated spaces or

occasional use.

Please note: Except where otherwise stated, all rights,

including copyright in the text, images and layout of this

booklet is owned by Focal Point Fires Ltd. You are not

per-mitted to copy or adapt any of the content without

the prior written permission of Focal Point Fires Ltd.

Focal Point Fires Ltd

Christchurch, Dorset BH23 2BT

Tel: 01202 49933049933

Fax: 01202 499326

www.focalpointfires.co.uk

e : [email protected]

Focal Point Fires Ltd

RBK House, Irishtown, Athlone,

Co. Westmeath, N37 XP52,

Ireland Tel: 01202 499330

Fax: 01202 499326

www.focalpointfires.co.uk

e: [email protected]

1.0 PRELIMINARY NOTES

I N S TA L L AT I O N & U S E R I N S T R U C T I O N S

GB IE

Section Contents Page No.

Preliminary Notes

Installation Requirements

Appliance Data

Unpacking the Appliance

Component Checklist

Installing the Appliance

1.0

2.0

3.0

4.0

5.0

6.0

Section Contents Page No.

7.0

8.0

9.0

10.0

11.0

Operating the Appliance

Safety Cut-Out System

Cleaning and Maintenance

Servicing

Guarantee - Terms and Conditions

IMPORTANT - THESE INSTRUCTIONS SHOULD BE READ CAREFULLY

AND RETAINED FOR FUTURE REFERENCE.

The appliance is designed for indoor use, and can be simply floor mounted in the

majority of floor positions anticipated. It can be located in any household room, with

the exception of bathrooms. Read all of the instructions before commencing installa-

tion. Retain for future reference and pass on as necessary to subsequent owners of the

appliance.

•DO NOT use this appliance immediately below a fixed socket outlet.

•DO NOT use this appliance in an open flue.

When using this electrical appliance, basic precautions should be followed to reduce the risk

of fire, electric shock and injury to person, including the following:

•This heater must be used on an AC supply only and the voltage marked on the heater’s

rating label must correspond to the supply voltage.

•DO NOT switch the appliance on until it is properly installed as described in this

manual.

•This appliance can be used by children aged from 8 years and above and persons with

reduced physical, sensory or mental capabilities or lack of experience and knowledge if they

have been given supervision or instruction concerning use of the appliance in a safe way and

understand the hazards involved. Children shall not play with the appliance. Cleaning and

user maintenance shall not be made by children without supervision.

• Children of less than 3 years should be kept away unless continuously supervised.

Children aged from 3 years and less than 8 years shall only switch on/off the appliance pro-

vided that it has been placed or installed in its intended normal operating position and they

have been given supervision or instruction concerning use of the appliance in a safe way and

understand the hazards involved. Children aged from 3 years and less than 8 years shall not

plug in, regulate and clean the appliance or perform user maintenance.

•CAUTION: Some parts of this product can become very hot and cause burns.

Particular attention has to be given where children and vulnerable people are present.

• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or

similarly qualified persons in order to avoid a hazard.

•The heater must not be located immediately below a socket-outlet.

•DO NOT use this heater in the immediate surroundings of a bath, a shower or a swim-

ming pool, or other area where water/moisture could present a hazard.

•WARNING: In order to avoid overheating, do not cover the heater.

•DO NOT use this heater with a separate remote-control system or any other device

that switches the heater on automatically, since a fire risk exists if the heater is covered or

positioned incorrectly.

•CAUTION: In order to avoid a hazard due to inadvertent resetting of the thermal

cutout, this appliance must not be supplied through an external switching device, such as a

DO NOT -site in a position where curtains or drapes could cover the appliance.

-site in a position where other soft materials could cover e.g. below a coat rack.

-site behind an opening door where mechanical impact/damage could occur.

-site where the supply cable would become a trip hazard.

-sit, stand or forcefully pull on the appliance.

-obstruct, cover or force items into the openings.

-use the heater to dry clothes.

-site/use in an outdoor location(s).

-run the supply cable under carpets.

-Mount on a wall.

•DO NOT run the mains cable under carpets, rugs etc.

•DO NOT cover or obstruct the heater in any way. Overheating will result if it is acci-

dentally covered.

• Never immerse the product in water or any other liquids.

•DO NOT use the appliance outdoors.

• Before cleaning the appliance, ensure it is unplugged from the power and that it is com-

pletely cool.

•DO NOT clean the appliance with abrasive chemicals.

• Never use accessories that are not recommended or supplied by the manufacturer. It

could cause danger to the user or damage to the appliance.

•DO NOT insert or allow foreign objects to enter the inlet or outlet vents as this may

result in electric shock, fire or damage to the appliance.

•DO NOT install the fire using an extension cord.

• Unplug from the mains supply if the appliance is not to be used for long periods.

•This product is only suitable for well insulated spaces or occasional use.

timer, or connected to a circuit that is regularly switched on and off by the utility.

• Keep furniture, curtains and other fabric material away from the appliance.

•DO NOT leave the appliance unattended during use.

• From time to time, check the cord for damage. Never use the appliance if the cord or any

part of the appliance shows signs of damage.

1.0 PRELIMINARY NOTES - CONTINUED GB IE

3.0 APPLIANCE DATA

Voltage (Volts):

Rated Power

Supply Plug:

Supply Cord:

Location:

Lighting:

220-240V a.c. 50Hz

2000W

BS 1363, 13Amp

1.7 Meters

Indoor Use

LED

The appliance is supplied with a pre-wired three pin plug (13 Amp fuse rated) and 1.7 metres of electrical cable. It is therefore necessary for a

suitable electrical socket to be located within this distance and be easily accessible. This appliance is designed to be fixed to the wall, using the wall

fixtures/fixings provided. DO NOT recess any part of appliance into the wall. This appliance is suitable for installation in static holiday/park homes.

2.0 INSTALLATION REQUIREMENTS

Caution: This appliance is heavy. Always seek assistance whilst unpacking and/or during installation. Please read all the

instructions before continuing to unpack or install appliance.

Before starting the installation of this fireplace , please read the following:

1. The installation should be carried out by two adults to avoid injury or damage . If for any reason it is considered too heavy,

please obtain assistance.

2. When lifting the electric suite, always keep your back straight. Bend your legs and not your back. Avoid twisting at the waist.

It is better to reposition your feet.

3. Avoid upper body / top heavy bending. Always bend from the knees rather than the waist. Do not lean forward or sideways

while handling the heater.

4. Always grip the heater with the palm of the hand. Do not use the tips of fingers for support.

5. Always keep the heater as close to the body as possible. This will minimize the cantilever action.

6. Use gloves to provide additional grip.

7. Unpack the package and lift the product gently out of the box, put it on a flat surface with the front panel facing forward. Check that the

remaining packaging contents correlate with the component checklist. Please dispose of all packaging with care at your local recycling centre.

4.0 UNPACKING THE APPLIANCE

3.0 APPLIANCE DATA - CONTINUED GB IE

All Models EF461LB-E

Item Symbol Value Unit Item Unit

Heat output Types of heat input, for electric storage local

space heaters only

Nominal

heat output

Pnom 2.0 KW Manual heat charge control with

integrated thermostat

N/A

Minimum heat

output

(indicative)

Pmin 1.0 KW Manual heat charge control with

room and/or outdoor temperature

feedback

N/A

Maximum

continuous heat

output

Pmax, c 2.0 KW Electronic heat charge control with

room and/or outdoor temperature

feedback

N/A

Auxiliary electricity consumption Fan assisted heat output N/A

At nominal

heat output

elmax 0.014 (fan motor) KW Type of heat output/room temperature control

At minimum

heat output

elmin KW Single stage heat output and no

room temperature control

In standby mode elSB 0.48 W Two or more manual stages no tem-

perature control

With mechanical thermostat room

temperature control

With electronic room temperature

control

Electronic room temperature con-

trol plus day timer

Electronic room temperature con-

trol plus week timer

Yes

Other control options

Room temperature control with

presence detection

Room temperature control with

open window detection

With distance control option No

With adaptive start control Yes

With working time limitation No

With black bulb sensor No

Contact details Focal Point Fires, Avon Trading Park, Christchurch Dorset, BH23 2BT

0.014 (fan motor)

5.0 COMPONENT CHECKLIST

GB IE

6.0 INSTALLING THE APPLIANCE

QUANTITY DESCRIPTION

1 Heater main body

1 Remote control

1 Instruction booklet

2 Securing brackets

4 Surround screws

2 Wall plugs

2 Fixing screws

CAUTION: DO NOT CONNECT THE APPLIANCE TO THE

ELECTRICAL SUPPLY AT THIS TIME.

Focal Point Fires Ltd. assumes absolutely no responsibility for injuries and damages

that may occur due to improper installation or handling.

Remove any protective film coatings from the finished/decorative surfaces of the

appliance, if any. After having selected the final position of the appliance taking into

account the integrity of the wall the electric suite may be secured to the wall.

To ensure customer safety, be sure to design the installation so that the strength of

both the wall and any wall fixings used are sufficient. The appliance should not be

installed until all wet plastering and/or dry wall sanding and wall painting has been

completed. Do not block the ventilation holes of the appliance. The wall onto which

the appliance is installed must be flat. Install only on a vertical surface. Avoid sloped

surfaces. Installation onto anything other than a vertical wall may result in fire,

damage or injury.

If the appliance is to be mounted on the inner leaf of a conventional cavity brick

wall, or a solid wall, then the wall plugs and fixing screws provided may be used.

Depending on the condition of the wall it may be necessary to use additional fixings.

In this situation, any additional fixings and wall plugs should be of the same size and

type as the ones provided.

The wall where the appliance is to be

installed must be capable of

long-term support of the total load of

the appliance. Measures should also

be taken to ensure sufficient strength

to withstand the force of

earthquakes, vibration and other

external forces. Plasterboard alone is

not considered to be a structural

material. It is not recommended to

rely on plasterboard fixings alone to

support the weight of the appliance.

WARNING



If the appliance is to be mounted on a dry lined wall or a timber framed construction wall then efforts should be made to fix

one position vertically, into one of the wooden studs, or supporting wooden members of the wall using the fixing screws

provided. If this is not achievable then the wall should be strengthened using appropriate building materials.

Please note: Before drilling into walls, always check that there are no hidden wires, pipes, etc. Make sure that screws and wall plugs

supplied are suitable for supporting the unit in your surface. Consult a qualified person if you are not sure.

GB IE

Installation Requirements

· Do not connect the heater to the mains power supply until all of the instructions have been read and the appliance has been properly and

securely fitted.

· The minimum safe distances must be observed.

1. Secure the appliance to the wall using the securing brackets and screws supplied.

2. Press each bracket against the inside wall of the surround, ensuring that the bracket is

located as high as possible.

3. Mark the location of the 2 holes on the inside wall of the surround.

4. Carefully drill two 5 mm deep holes using a 2 mm drill bit. Do not exceed 5 mm depth to

prevent damage to the outside surface of the surround. These holes are to ensure that you

do not crack the wood when using the self tapping surround screws to fix the bracket onto

the surround.

5. Place the bracket on the 2 holes and secure it in place with 2 surround screws.

6. Repeat this for the other side of the appliance, so that you have 1 bracket on the left and

1 on the right of the appliance.

7. Carefully place the appliance against the wall and mark the holes of the brackets on either

side.

8. Carefully remove the appliance from the wall and use a 8 mm diameter drill bit, to

drill two 40 mm deep holes where the two markings are, and place the wall plugs in the

holes.

6.0 INSTALLING THE APPLIANCE - CONTINUED GB IE

Surround

screw

Securing

bracket

Wall

plug

9. Place the suite aligning the two holes with the brackets, and use 2 fixing screws to fix the

fireplace to the wall.

The fireplace must be secure so that it is not possible to pull away using normal loads.

WARNING: This product is heavy. Failure to install this product securely and in

accordance with these instructions could lead to a serious or fatal injury!

screws

Fixing

7.0 OPERATING THE APPLIANCE

GB IE

Manual Operation

NOTE: The heater only starts working if the set temperature is higher than the ambient room temperature.

Switching ON/OFF

Use the ON/OFF switch to power on the heater (set it to standby mode).

In standby mode, the heater can be operated either manually, by the switches located at the front and right hand side of heater or by the

supplied remote control.

Heater powered OFF

Heater powered ON, set to standby mode

Press to switch flame effect ON/ OFF

Press and hold to toggle between 5 different flame settings

POWER

Press once to activate low level heating (1000W)

Press twice to activate high level heating (2000W)

Press three to switch off heating

BACK LIGHT Press to toggle between 7 different back light effects

Go up in the menu

(change day)

Switch the appliance ON

Set to standby mode

Set day/time

Increase temperature

Increase hour/ minute

Decrease temperature

Decrease hour/ minute

Confirm selection

Set automatic heating mode

Press once to activate the low level heating

Press twice to activate the high level heating

Press a third time to switch off the heating

Toggle between 7

different back light effects

Toggle between 5

different flame effects

Timer on/off key

Cancel key

Go down in the menu

(change day)

Set timer key

Remote Operation

NOTE: The heater should be powered on using the ON/OFF switch before it can be operated using remote control.

7.0 OPERATING THE APPLIANCE - CONTINUED

GB IE

The remote control requires 2xAAA size batteries (Not included).

Open the battery compartment by sliding the cover down and insert the batteries noting the polarity indicated in the battery compartment.

Keep batteries out of reach of children.

Remote control operations are identical to the functions on the control panel.

The remote control must be point directly at the sensor on control pad.

2x AAA, 1.5V

Display Standby mode icon

Timer icon

Timer OFF

Temperature/ timer number

Timer ON

Time/ temperature display

Automatic heating

Flame effect brightness

Heating level

Low heating level

High heating level

Day of the week

Settings

Setting weekday and time

Press the DAY/TIME key. When the day is flashing press the ▲ or ▼ key to select the day.

Press the DAY/TIME key again, then press the + or – key to set the hour.

Press the DAY/TIME key again, then press the + or – key to set the minute.

Press the OK key to confirm the setting.

Setting temperature

NOTE: This setting is only applicable for the temperature in standard heating mode, not for the temperature in the timer mode.

The default set temperature is 25℃.

NOTE: The heater only starts working when the set temperature is higher than the room temperature.

Press the + or – key to set the temperature, which ranges from 15 to 30℃.

After the temperature setting has been completed, the display flashes about 5 seconds, then shows the room temperature.

Setting timer

There can be up to 10 different timer settings that can be programmed.

Each timer setting has its day, power-on time and power-off time.

The maximum duration of each timer setting is 23 hours 50 minutes.

If the power-off time of the timer setting falls on the following day, it is unnecessary to set the day-just set the power-off time.

Press the TIMER SET key, the timer number starts blinking (01-10).

Press the + or – key to select a timer number.

7.0 OPERATING THE APPLIANCE - CONTINUED

GB IE

Press the TIMER SET key, the cursor on the left side of the day blinks.

Press the ▲ or ▼ key to move the cursor to the corresponding day. Press the + key to add a corresponding day, or press the - key to delete

a day.

Press the TIMER SET key to set the on time. The hour digit starts blinking.

Press the + or – key to set the hour.

Press the TIMER SET key. The minute digit starts blinking.

Press the + or – key to set the minute.

Press the TIMER SET key to set the off time. The hour digit starts blinking.

Press the + or – key to set the hour.

Press the TIMER SET key. The minute digit starts blinking.

Press the + or – key to set the minute.

Press the TIMER SET key. The temperature digit starts blinking.

Press the + or – key to set the temperature.

Press the TIMER SET key to continue with the timer setting or press the OK key to confirm the setting.

Viewing the timer setting

Press the TIMER SET key.

Press the + or – key to check the power-on time of the set timers one by one.

To check the power-off time, press the ▲ key.

Press the + or – key to check the power-off time of the set timers one by one.

To delete selected setting, press the C key.

Activation timer

Press the TIMER ON/OFF key to activate the timer function.

NOTE: When the timer is active, the heating level must be manually selected. If the heater function is not selected; only the flame effect goes

on at the set power-on time.

Automatic heating mode

Press the IC key to activate automatic heating mode. The AUTO icon appears on the display.

When the automatic heating is turned on, the heater automatically changes the heating level depending on the set temperature and the

ambient room temperature.

8.0 SAFETY CUT-OUT SYSTEM

This appliance has a safety cut-out system fitted which will activate if the air inlets or heater outlets are obstructed. For safety reasons the fire

WILL NOT switch on again automatically.

The following procedure must be carried out before the fire can be operated again:

1. Unplug the power supply cable at the outlet socket and place all switches to off at the appliance.

2. Leave the fire OFF for a period of not less than 15 minutes, ensuring any obstructions are removed.

3. Plug in the power supply cable at the outlet socket, and then switch on at the appliance.

If the appliance fails to operate correctly, repeat the above procedure. If an attempt to switch on is made before the safety cut-out has reset,

the heaters may cut-out for a further period of time. If the sequence has been followed correctly and the heaters still fail to function, check the

power supply cable plug is plugged in at the outlet socket. If this is not the cause, call an electrician.

ALWAYS DISCONNECT THE APPLIANCE AT THE SUPPLY OUTLET SOCKET BEFORE UNDERTAKING ANY CLEANING.

Except for periodic cleaning of dust, there are no specific requirements for care, other than regular cleaning of the general appliance. A wipe

with a dry cloth is normally sufficient. DO NOT use abrasive cleaners as they can damage the finish. Make sure the heater outlet grille (locat-

ed next to the switches) are kept clear of dust, pet hair and other airborne household matter. These should be vacuum cleaned periodically

using a brush attachment.

Replacing the light bulbs.

The LED lights inside the appliance are not replaceable.

Battery Replacement

Battery Requirements: 2x AAA 1.5V (batteries not included)

1. Remove the battery bracket and the used batteries from the back of the remote control.

2. Insert the 2x replacement batteries the correct way into the battery holder, making sure the batteries are firmly seated.

3. Then insert the battery bracket back into position.

9.0 CLEANING AND MAINTENANCE

11.0 GUARANTEE - TERMS AND CONDITIONS

F861574

There are no internal user serviceable parts.

Check regularly for security of wall fixings as appropriate. Also check security of supply cable and connections. If the supply cable

becomes damaged, it must be replaced by a service agent or competent person, such as a qualified electrician.

This appliance is supplied with a BS1363 3 pin plug fitted with a 13 Amp fuse. Should

the fuse require replacing, it must be replaced with a fuse rated at 13 Amp and

approved to BS1362. In the event of the mains plug being removed/ replaced for any

reason, please note : IMPORTANT: The wires in the mains lead are coloured in

accordance with the following code:

Blue - Neutral

Brown - Live

Green/ Yellow - Earth

As the colours of the wires in the mains lead of this appliance may not correspond

with the colour markings identifying the terminals in your plug, proceed as follows.

The blue wire must be connected to the terminal marked with an N or coloured

black. The brown wire must be connected to the terminal marked with an L or coloured red. The green/yellow wire must be

connected to the earth terminal which is marked with an E or with the earth symbol. WARNING: Never connect live or

neutral wires to the earth terminal of the plug.

NOTE: If a moulded plug is fitted and has to be removed take great care in disposing of the plug and severed cable, it must be

destroyed to prevent engaging into a socket.

Refer to Section 2.0, Appliance Data for fuse specification. Excluding fuses, use only genuine manufacturers spare parts available

from your supplier.

10.0 SERVICING GB IE

Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your local

authority or retailer for recycling advice.

As our policy is one of continuous improvement and development, we therefore hope that you will understand we must retain the right

to amend details and/or specifications without prior notice.

Registration is not required.

The 3 year guarantee only covers products purchased on or after 1st February 2009. The 3 year guarantee commences from the date of purchase,

provided that the following the terms and conditions are adhered to:

1. For any claim to be made within the 3 years from date of purchase you will be required to provide and supply us with your proof of purchase.

Please note all consumable items such as any ceramics including coals, pebbles, matrix, front strips, panels and bulbs are not covered by the 3 year

guarantee.

We reserve the right to reject any claim or make a charge for any visit where the cause of the defect is due to non-compliance with the installation

and/or servicing instructions or misuse of the appliance.

If a repair is chargeable during the warranty period, we will inform you and where possible, provide a quote or price guide before starting work. We

cannot always give a firm cost until we commence the repair as it is not always possible to identify which components have been damaged. Repaired

or replaced products are covered only for the remainder of the original guarantee period and the guarantee period will not be extended even if we

repair or replace any product or part.

If we replace any component or product, the component or product removed will become our property.

We will not accept or reimburse the cost(s) of any third party who undertakes any work carried out on the product or fits parts, unless we have

approved such work in advance of it being carried out.

The Manufacturer’s guarantee does not apply to:

• Damaged caused by faulty installation, theft, tampering, neglect, misuse, normal wear and tear, accident, fire, flood, explosion, lightning, storms, frost

or other bad weather conditions.

• Damage caused by the non-observance of the Manufacturer’s Installation Instructions.

• Any unauthorised adjustments made to the product by a third party.

• Servicing and its associated costs.

• Self-maintenance tasks such as cleaning.

Making a claim is easy.

If you wish to make a claim under our 3 year guarantee, and all of the terms and conditions for your product have been met then please submit the

following information for the attention of the 3G Service Department to [email protected]. Alternatively, you can fax to 01202 499326 or post

to Focal Point Fires Ltd, 3G Service Department, Reid Street, Christchurch, Dorset, BH23 2BT. Please note that this does not affect your statutory

rights.

Details required:

1. Name, full address (including post code) and contact telephone numbers.

2. Receipt of purchase or credit card statement.

This product complies with conformity requirements of the

applicable European Regulations or Directives.

This product complies with conformity requirements of the

applicable UK Regulations.

This manual suits for next models

Table of contents

Other Focal Point Indoor Fireplace manuals

Focal Point

Focal Point ExcelsiorRadiant MAN User manual

Focal Point

Focal Point NERO CUBE LCD ELECTRIC COMPLETE SUITE IVORY-... Assembly Instructions

Focal Point

Focal Point ALVOR Assembly Instructions

Focal Point

Focal Point BLENHEIM STYLE Guide

Focal Point

Focal Point EVOKE LED ELECTRIC Assembly Instructions

Focal Point

Focal Point EF11-36 PASADENA Assembly Instructions

Focal Point

Focal Point LEXINGTON EF655SLB-E Assembly Instructions

Focal Point

Focal Point elysee radiant Assembly Instructions

Focal Point

Focal Point Wickes User manual

Focal Point

Focal Point Vogue Guide

Focal Point

Focal Point Purist Guide

Focal Point

Focal Point L23S MIDNIGHT Assembly Instructions

Focal Point

Focal Point PI27 BLENHEIM Assembly Instructions

Focal Point

Focal Point AMERSHAM LED ELECTRIC SUITE Assembly Instructions

Focal Point

Focal Point EF11-36 PASADENA Assembly Instructions

Focal Point

Focal Point JEMEZ User guide

Focal Point

Focal Point L23S MIDNIGHT Assembly Instructions

Focal Point

Focal Point BLENHEIM LCD INSET ELECTRIC FIRE Assembly Instructions

Focal Point

Focal Point EF11-36 PASADENA LIMOUSIN Assembly Instructions

Focal Point

Focal Point ATHERSTONE SLATE ELECTRIC SUITE Assembly Instructions

Focal Point

Focal Point 18" High-Tech User manual

Focal Point

Focal Point Charmouth Assembly Instructions

Focal Point

Focal Point L23 Series Assembly Instructions

Focal Point

Focal Point KAVACHI F500181 Assembly Instructions

Popular Indoor Fireplace manuals by other brands

Brigantia

Brigantia 35-DVRS31N-2 User's installation, operation and maintenance manual

Nordpeis

Nordpeis Bergen Installation and user manual

Superior

Superior BCT2536TMN Installation and operation instructions

Quadra-Fire

Quadra-Fire 5100I-GD-B owner's manual

Renaissance

Renaissance RUMFORD 1000 user manual

Lacunza

Lacunza IV-800 Instruction book

Baxi

Baxi 940 Installer and owner guide

Dru

Dru Maestro 60/2 Tall RCH installation manual

Diamond Fireglass

Diamond Fireglass SS-O22 General assembly, installation, and operation instructions

HearthStone

HearthStone Windsor Bay 8830 Owner's manual and installation guide

Napoleon

Napoleon ASCENT B42 quick start guide

Enviro

Enviro E33GI owner's manual

Smeg

Smeg L30 FABE Installation & user's instructions

KEDDY

KEDDY K700 Installation instructions care and firing instructions

Godin

Godin 3451 manual

Jøtul

Jøtul Jotul GI 535 DV IPI New Harbor Installation and operation instructions

Austro Flamm

Austro Flamm Heidi Back 2.0 945048 operating manual

Desa

Desa CCFPDFT Owner's operating & installation manual
