Epson Progression User manual

EPSON® PROGRESSION™

Setup Guide

This manual is printed on recycled paper and is 100% recyclable.

IMPORTANT NOTICE

DISCLAIMER OF WARRANTY

Epson America makes no representations or warranties, either express or implied, by or

with respect to anything in this manual, and shall not be liable for any implied warranties

of merchantability and fitness for a particular purpose or for any indirect, special or

consequential damages. Some states do not allow the exclusion of incidental or

consequential damages, so this exclusion may not apply to you.

system, or transmitted, in any form or by any means, electronic, mechanical,

photocopying, recording, or otherwise, without the prior written permission of Epson

America, Inc. No patent liability is assumed with respect to the use of information

contained herein. Nor is any liability assumed for damages resulting from the use of the

information contained herein Further, this publication and features described

herein are

subject to change without notice.

TRADEMARKS

Epson is a registered trademark and Epson Progression is a trademark of Seiko Epson

Corporation.

VirtualCache is a trademark of Epson Portland, Inc.

General notice: Other product names used herein are for identification proposes only and

may be trademarks of their respective companies.

1992 by Epson America, Inc.

Torrance,Califomia

Y74599100200

Read all of these instructions and save them for later reference.

Follow all warnings and instructions marked on the computer.

Unplug the computer from the wall outlet before cleaning. Use a

damp cloth for cleaning; do not use liquid or aerosol cleaners.

Do not spill liquid of any kind on the computer.

not

place the computer on an unstable cart, stand, or table.

Slots and openings in the cabinet and the back or bottom are

provided for ventilation; do not block or cover these

openings.

Do not place the computer near or over a radiator or

heat

Operate the computer using the type of power source indicated

on its label. If you are not sure of the type of power available,

consult your dealer or local power company.

If you plan to operate the computer in

Germany,

observe the

following safety precaution:

To provide adequate shortcircuit protection and over-current

protection for this computer, the building installation must be

protected by a 16 Amp circuit breaker.

Connect all equipment to properly grounded (earthed) power

outlets. If you are unable to insert the plug into an outlet,

contact your

electrician

to replace your outlet. Avoid using

outlets

on the

same circuit as photocopiers or air control

systems that regularly switch on and off.

Important Safety Instructions

10. Do not allow the computer’s cord to become damaged or frayed.

iii

11.

If you use an extension cord with the computer, make sure the

total of the ampere ratings of the devices plugged into the

extension cord does not exceed the ampere rating for the

extension cord. Also, make sure the total of all products

plugged into the wall outlet does not exceed 15 amperes.

12. Do not insert objects of any kind into this product through the

cabinet slots.

13. Except as specifically explained in this manual, do not attempt to

service the computer yourself. Refer all servicing to qualified

service personnel.

14.

Unplug the computer from the wall outlet and refer servicing to

qualified service personnel under the following conditions:

When the power cord or plug is damaged.

If liquid has entered the computer.

C. If the computer does not operate normally

when the

operating instructions are followed. Adjust only those

controls that are covered by the operating instructions.

Improper adjustment of other controls may result in

damage and often requires extensive work by a qualified

technician to restore the computer to normal operation.

If the computer has been dropped or the cabinet has

been

damaged.

E. If the computer exhibits a distinct change in performance.

Contents

Introduction

Chapter 1

Setting Up Your System

1 Choosing a Location.

.......................

1-2

2 Removing the Protective Card

..................

1-3

3 Connecting a Monitor

.......................

1-4

Using a Display Adapter Card

................

1-7

Connecting a Printer or Other Device

.............

1-8

Using the Parallel Port.

....................

1-9

Using

SeriaI

......................

1-11

5 connecting the Keyboard.

...................

1-12

6 Connecting the Mouse

......................

1-13

Connecting the

Power Cord

...................

1-15

8 Turning On the Computer

....................

1-16

Where To Go Next

..........................

1-17

Chapter 2

Running the SETUP Program

Starting the SETUP Program

....................

2-2

Selecting Options

........................

2-4

Setting the Date and Time

.....................

2-5

Setting the Processor Speed Options

...............

2-6

Setting the Fast Boot Option

....................

2-8

Setting the System and Video BIOS Options

...........

2-8

Setting the Keyboard Options

...................

2-10

InstaIled Equipment

.........................

2-11

Setting the Built-in Parallel and SeriaI Port Options

.......

2-12

Setting the Speaker

.........................

2-14

Setting the Disk Drive Controllers

.................

2-14

Setting the Password Options

...................

2-15

Changing a Password

.....................

2-17

Deleting a Password.

.....................

2-17

Setting the Diskette Drive Type(s)

................

2-18

Setting the Hard Disk Drive(s)

..................

2-19

Hard Disk Drive Types

....................

2-19

Setting the Non-cache Areas

....................

2-23

Setting the Cache Test and Use Control Options

........

2-24

Saving Your Settings and Exiting SETUP

............

2-25

You made changes, and want to save them and

exit SETUP

........................

2-26

You made no changes and want to exit SETUP

......

2-26

You made changes and want to exit SETUP

without saving the changes

...............

2-27

You saved your settings with

[F101

............

2-27

Post-SETUP Procedures

......................

2-29

Appendix A

Using Memory

Types of Memory . . . . . . . . . . . . . . . . . . . . . . . . . .

A-1

viii

This manual explains how to set up your Epson

Progression™

computer. Chapter 1 provides simple step-by-step instructions

for setting up your system and connecting peripheral devices

such as the monitor, mouse, and printer.

Chapter 2 describes how to run the SETUP program to define

your computer’s configuration. Do this before you use your

computer. If you change the configuration later, you will need

to run it again.

After you set up your system and run SETUP, you can install

your operating system and software. (For general installation

guidelines, see the Read This First card that came with your

system.)

Note

If your computer has already been configured, you don’t

need to run SETUP or install any software. Just set it up as

described in Chapter 1 and turn it on. (Ask your dealer if

you are not sure if your computer was preconfigured.)

For information on using system memory, see Appendix A.

The instructions in this manual are designed to get your system

up and running; for complete information about using your

computer, see the User’s Guide.

If you need help while you are setting up your computer in the

United States, you can contact your dealer or call the Epson

Customer Support Center at (800) 922-8911. If you purchased

your computer outside the United States, contact your nearest

Epson dealer. International Marketing locations are listed

inside the back cover of your User’s Guide.

Chapter 1

Setting Up Your System

To set up your computer, follow the eight steps in this chapter.

You may want to open this manual’s back cover foldout so you

can refer to the illustrations identifying the different parts.

Setting

Up Your System

1-1
