Electrolux EWS 1052 NDU User manual

EWS 1052 NDU

EN Washing Machine User Manual

CONTENTS

1. SAFETY INFORMATION...................................................................................... 3

2. SAFETY INSTRUCTIONS.....................................................................................4

3. PRODUCT DESCRIPTION................................................................................... 5

4. CONTROL PANEL...............................................................................................6

5. PROGRAMME CHART........................................................................................ 6

6. CONSUMPTION VALUES....................................................................................9

7. OPTIONS...........................................................................................................10

8. SETTINGS......................................................................................................... 10

9. BEFORE FIRST USE..........................................................................................11

10. DAILY USE...................................................................................................... 11

11. HINTS AND TIPS............................................................................................. 14

12. CARE AND CLEANING....................................................................................15

13. TROUBLESHOOTING......................................................................................19

14. TECHNICAL DATA...........................................................................................21

WE’RE THINKING OF YOU

Thank you for purchasing an Electrolux appliance. You’ve chosen a product that

brings with it decades of professional experience and innovation. Ingenious and

stylish, it has been designed with you in mind. So whenever you use it, you can be

safe in the knowledge that you’ll get great results every time.

Welcome to Electrolux.

Visit our website for:

Get usage advice, brochures, trouble shooter, service information:

www.electrolux.com

www.registerelectrolux.com

Buy Accessories, Consumables and Original spare parts for your appliance:

www.electrolux.com/shop

CUSTOMER CARE AND SERVICE

Always use original spare parts.

When contacting our Authorised Service Centre, ensure that you have the following

data available: Model, PNC, Serial Number.

The information can be found on the rating plate.

Warning / Caution-Safety information

General information and tips

Environmental information

Subject to change without notice.

www.electrolux.com2

1. SAFETY INFORMATION

Before the installation and use of the appliance, carefully

read the supplied instructions. The manufacturer is not

responsible if an incorrect installation and use causes

injuries and damages. Always keep the instructions with

the appliance for future reference.

1.1 Children and vulnerable people safety

•This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience and

knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe

way and understand the hazards involved.

•Do not let children play with the appliance.

•Keep all packaging away from children.

•Keep all detergents away from children.

•Keep children and pets away from the appliance door

when it is open.

•Cleaning and user maintenance shall not be made by

children without supervision.

1.2 General Safety

•Do not change the specification of this appliance.

•Obey the maximum load volume of 5 kg (refer to the

“Programme chart” chapter).

•The operating water pressure (minimum and maximum)

must be between 0,5 bar (0,05 MPa) and 8 bar (0,8

MPa).

•The ventilation openings in the base (if applicable) must

not be obstructed by a carpet.

•The appliance is to be connected to the water mains

using the new supplied hose-sets. Old hose sets must

not be reused.

•If the supply cord is damaged, it must be replaced by

the manufacturer, its Authorised Service Centre or

similarly qualified persons in order to avoid a hazard.

ENGLISH 3

•Before maintenance, deactivate the appliance and

disconnect the mains plug from the mains socket.

•Do not use water spray and steam to clean the

appliance.

•Clean the appliance with a moist soft cloth. Only use

neutral detergents. Do not use abrasive products,

abrasive cleaning pads, solvents or metal objects.

2. SAFETY INSTRUCTIONS

2.1 Installation

• Remove all the packaging and the

transit bolts.

• Keep the transit bolts. When you move

the appliance again you must block the

drum.

•Always be careful when you move the

appliance because it is heavy. Always

wear safety gloves.

• Do not install or use a damaged

appliance.

• Obey the installation instruction

supplied with the appliance.

• Do not install or use the appliance

where the temperature is less than 0

°C or where it is exposed to the

weather.

• Make sure that the floor where you

install the appliance is flat, stable, heat

resistant and clean.

• Do not install the appliance where the

appliance door can not be fully

opened.

• Make sure that there is air circulation

between the appliance and the floor.

• Adjust the feet to have the necessary

space between the appliance and the

carpet.

• Do not install the appliance where the

appliance door can not be fully

opened.

2.2 Electrical Connection

• The appliance must be earthed.

• Always use a correctly installed

shockproof socket.

• Make sure that the electrical

information on the rating plate agrees

with the power supply. If not, contact

an electrician.

• Do not use multi-plug adapters and

extension cables.

• Make sure not to cause damage to the

mains plug and to the mains cable.

Should the mains cable need to be

replaced, this must be carried out by

our Authorised Service Centre.

• Connect the mains plug to the mains

socket only at the end of the

installation. Make sure that there is

access to the mains plug after the

installation.

• Do not touch the mains cable or the

mains plug with wet hands.

• Do not pull the mains cable to

disconnect the appliance. Always pull

the mains plug.

• Only for UK and Ireland: The appliance

has a 13 amp mains plug. If it is

necessary to change the fuse in the

mains plug, use a 13 amp ASTA (BS

1362) fuse.

• This appliance complies with the E.E.C.

Directives.

2.3 Water connection

• Make sure not to cause damage to the

water hoses.

• Before you connect the appliance to

new pipes or pipes not used for a long

time, let the water flow until it is clean.

• The first time you use the appliance,

make sure that there is no leakage.

2.4 Use

WARNING!

Risk of injury, electrical

shock, fire, burns or damage

to the appliance.

www.electrolux.com4

• Use this appliance in a household only.

• Obey the safety instructions on the

detergent packaging.

• Do not put flammable products or

items that are wet with flammable

products in, near or on the appliance.

•Make sure that you remove all metal

objects from the laundry.

• Do not put a container to collect

possible water leakage under the

appliance. Contact the Authorised

Service Centre to ensure which

accessories can be used.

• Do not touch the glass of the door

while a programme operates. The

glass can be hot.

2.5 Disposal

WARNING!

Risk of injury or suffocation.

• Disconnect the appliance from the

mains supply.

• Cut off the mains cable and discard it.

• Remove the door catch to prevent

children and pets to get closed in the

appliance.

3. PRODUCT DESCRIPTION

3.1 Appliance overview

1Worktop

2Detergent dispenser

3Control panel

4Door handle

5Drain pump filter

6Rating plate

7Feet for the appliance level

ENGLISH 5

4. CONTROL PANEL

4.1 Control panel description

Start/Pauza

20°

90° 40°

30°

600

60°

800

1000

400

3h 6h 9h

Odložený Start

Odložený

Start

Krátký Extra

Máchání

Předpírka

Hedvábí

Bavlna

Záclony

Osvěžení

Máchání

Vypouštění

Odstřeďování

Lůžkoviny

Jeans

Syntetické

Jemné

Vlna/Ruční praní

Krátký

Teplota

Odstředění

Bavlna Eco

1 2 3

1Programme knob

2Spin reduction touchpad

(Odstřeďování)

3Temperature touchpad (Teplota)

4Prewash touchpad (Předpírka)

5Delay start touchpad (Odložený

Start)

6Extra rinse touchpad (Extra

Máchání)

7Quick touchpad (Krátký)

8Start/Pause touchpad (Start/

Pauza)

9Programme status indicators:

Door locked indicator

End cycle indicator

Child lock indicator

5. PROGRAMME CHART

Programme

Temperature

range

Maximum

load

Maximum

spin speed

Programme description

(Type of load and soil level)

Washing programmes

Bavlna

90°C - Cold

5 kg

1000 rpm

White cotton and coloured cotton. Normal soil

and light soil.

Bavlna Eco1)

60°C - 40°C

5 kg

1000 rpm

White cotton and colour-fast cotton. Normal

soil. The energy consumption decreases and the

time of the washing programme is extended.

Syntetiké

60°C - Cold

2.5 kg

1000 rpm

Synthetic items or mixed fabric items. Normal

soil.

www.electrolux.com6

Programme

Temperature

range

Maximum

load

Maximum

spin speed

Programme description

(Type of load and soil level)

Jemné

40°C - Cold

2.5 kg

1000 rpm

Delicate fabrics as acrylics, viscose, polyest-

er items. Normal soil.

Vlna/Ruční Praní

40°C - Cold

1.5 kg

1000 rpm

Machine washable wool, hand washable wool

and delicate fabrics with «hand washing» care

symbol.2)

Hedvábí

30°C

1 kg

800 rpm

Special programme for silk and mixed synthetic

items.

Lůžkoviny

60°C - 30°C

2 kg

800 rpm

Special programme for one synthetic blanket,

duvet, bedspread and so on.

Máchání

Cold

5 kg

1000 rpm

To rinse and spin the laundry. All fabrics.

Vypouštění

5 kg To drain the water in the drum. All fabrics.

Odstřeďování

5 kg

1000 rpm

To spin the laundry and to drain the water in the

drum. All fabrics.

Jeans

60°C - Cold

5 kg

1000 rpm

Items in denim and jersey. Also for dark col-

oured items.

Záclony

40°C - Cold

1 kg

800 rpm

Special programme for curtains. The prewash

phase is activated automatically.3)

Osvěžení

30°C

2.5 kg

800 rpm

Synthetic and delicate items. Light soil items or

items to refresh.

ENGLISH 7

Programme

Temperature

range

Maximum

load

Maximum

spin speed

Programme description

(Type of load and soil level)

Krátký

30°C

1 kg

800 rpm

Synthetic and mixed fabric items. Light soil and

items to freshen up.

1) Standard programmes for the Energy Label consumption values. According to regu-

lation 1061/2010, these programmes are respectively the «Standard 60°C cotton programme»

and the «Standard 40°C cotton programme». They are the most efficient programmes in terms

of combined energy and water consumption for washing normally soiled cotton laundry.

The water temperature of the washing phase may differ from the temperature de-

clared for the selected programme.

2) During this cycle the drum rotates slowly to ensure a gentle washing. It can seem that the

drum doesn't rotate or doesn't rotate properly. Consider this as a normal functioning of the ap-

pliance.

3) Do not use any detergent for prewash phase to rinse only with water.

Programme options compatibility

Programme 1)

■ ■ ■ ■ ■ ■ ■

■ ■ ■ ■

■ ■ ■

■ ■

■ ■ ■ ■ ■

■ ■

■ ■ ■ ■ ■ ■ ■

■ ■ ■ ■ ■ ■

■ ■ ■

www.electrolux.com8

Programme 1)

■ ■ ■

1) When you set the Krátký option, we recommend that you decrease the quantity of the laun-

dry. It is possible to keep the full load but the washing results can be unsatisfactory. Recom-

mended load: cotton: 2.5 kg, synthetics and delicates: 1.5 kg.

6. CONSUMPTION VALUES

The data of this table are approximate. Different causes can change the

data: the quantity and type of laundry, the water and ambient temperature.

Programmes Load

(kg)

Energy

consump-

tion (kWh)

Water con-

sumption

(litre)

Approxi-

mate pro-

gramme

duration

(minutes)

Remaining

moisture

(%)1)

Bavlna 60 °C 5 1.22 60 180 60

Bavlna 40 °C 5 0.79 60 157 60

Syntetiké 40 °C 2.5 0.53 37 106 37

Jemné 40 °C 2.5 0.45 49 51 37

Vlna/Ruční Praní

30 °C 1 0.45 59 69 32

Standard cotton programmes

Standard 60 °C

cotton 5 0.72 45 197 60

Standard 60 °C

cotton 2.5 0.54 39 169 60

Standard 40 °C

cotton 2.5 0.47 39 171 60

1) At the end of spin phase.

Off Mode (W) Left On Mode (W)

0,48 0,48

The information given in the chart above are in compliance with the EU Commission

regulation 1015/2010 implementing directive 2009/125/EC.

ENGLISH 9

7. OPTIONS

7.1 Teplota

Set this option to change the default

temperature.

Indicator = cold water.

The indicator of the set temperature

comes on.

7.2 Odstřeďování

With this option you can change the

default spin speed.

The indicator of the set speed comes on.

Additional spin options:

No Spin

• Set this option to deactivate all spin

phases. Only the drain phase is

available.

• The related indicator comes on.

• Set this option for very delicate fabrics.

• The rinses phase uses more water for

some washing programmes.

Rinse Hold

• Set this option to prevent the laundry

creases.

• The related indicator comes on.

• There is a water in the drum when the

programme is completed.

• The drum turns regularly to prevent the

laundry creases.

• The door stays locked. You must drain

the water to unlock the door.

To drain the water refer to ‘At

the end of the programme’.

7.3 Předpírka

With this option you can add a prewash

phase to a washing programme.

Use this option for heavy soil.

When you set this option the programme

duration increases.

The related indicator comes on.

7.4 Odložený Start

With this option you can delay the start of

a programme by 9, 6 or 3 hours.

The indicator of the option and the

indicator of the set value are on.

7.5 Extra Máchání

With this option you can add some rinses

to a washing programme.

Use this option for persons allergic to

detergents and in areas where the water is

soft.

The related indicator comes on.

7.6 Krátký

With this option you can decrease the

programme duration.

Use this option for items with light soil or

items to refresh.

The related indicator comes on.

8. SETTINGS

8.1 Child Lock

With this option you can prevent that the

children play with the control panel.

•To activate/deactivate this option,

press and at the same time

until the indicator comes on/goes

off.

You can activate this option:

• After you press : the options and

the programme knob are locked.

•Before you press : the appliance

cannot start.

8.2 Permanent Extra Rinse

With this option you can permanently have

an extra rinse when you set a new

programme.

www.electrolux.com10

Table of contents

Other Electrolux Washer manuals

Electrolux

Electrolux EW8T6337E6 User manual

Electrolux

Electrolux EWF 1215 User manual

Electrolux

Electrolux EWT 1540 User manual

Electrolux

Electrolux EW6S426BI User manual

Electrolux

Electrolux EWT718 User manual

Electrolux

Electrolux EWF 1697 HBW User manual

Electrolux

Electrolux EN6F5922BF User manual

Electrolux

Electrolux EW7F248S User manual

Electrolux

Electrolux EWF 6120 W User User manual

Electrolux

Electrolux EWF 1487 HDW2 User manual

Electrolux

Electrolux EWL 105410 W User manual

Electrolux

Electrolux TE1120HP User manual

Electrolux

Electrolux EWF 14112 User manual

Electrolux

Electrolux EW6F528W User manual

Electrolux

Electrolux EW2F7814FG User manual

Electrolux

Electrolux W4400H User manual

Electrolux

Electrolux EIFLS60JIW Service manual

Electrolux

Electrolux EWN 10470 W User manual

Electrolux

Electrolux EWT1254DCWA User manual

Electrolux

Electrolux EWIE06F3OMW User manual

Electrolux

Electrolux EWS 12610 W User manual

Electrolux

Electrolux EWP 1462 TDW User manual

Electrolux

Electrolux EWF 1045 User manual

Electrolux

Electrolux EIFLW55HIW0 User manual

Popular Washer manuals by other brands

Tricity Bendix

Tricity Bendix AW 1000 W Operating & installation instructions

Panasonic

Panasonic NA-F60L5WRB operating instructions

GE WSLP1500 Dimensions and installation information

Bosch

Bosch WAN2829BSN User manual and installation instructions

LG TV2516DV3B owner's manual

LG TH2517DSAV owner's manual

VESTEL

VESTEL CMH-XL 7510 TE user manual

AEG

AEG 74335 User information

Johnson

Johnson JWF721A user manual

Beko

Beko WTE7604XLW0 owner's manual

Danby

Danby DTT100A1WDB Owner's use and care guide

Amica

Amica WA 14 Ex operating instructions

Daewoo

Daewoo DWD-F1222 instruction manual

Bosch

Bosch WAS28461AU instruction manual

Miele

Miele PW 6080 Vario manual

Finlux

Finlux FLX108CF220 user manual

Whirlpool

Whirlpool 3LBR5132AN0 Use and care guide

Beko

Beko WKB 51231 PTMA manual
