Electrolux EWF 1404BR User manual

EWF 1404BR

EN Washing Machine User Manual 2

TR Çamaşır Makinesi Kullanma Kılavuzu 24

CONTENTS

1. SAFETY INFORMATION....................................................................................3

2. SAFETY INSTRUCTIONS..................................................................................4

3. PRODUCT DESCRIPTION................................................................................ 6

4. CONTROL PANEL............................................................................................. 6

5. PROGRAMME CHART...................................................................................... 7

6. CONSUMPTION VALUES..................................................................................9

7. OPTIONS..........................................................................................................10

8. SETTINGS........................................................................................................11

9. BEFORE FIRST USE....................................................................................... 12

10. DAILY USE.....................................................................................................12

11. HINTS AND TIPS........................................................................................... 15

12. CARE AND CLEANING..................................................................................16

13. TROUBLESHOOTING....................................................................................20

14. TECHNICAL DATA.........................................................................................23

WE’RE THINKING OF YOU

Thank you for purchasing an Electrolux appliance. You’ve chosen a product that

brings with it decades of professional experience and innovation. Ingenious and

stylish, it has been designed with you in mind. So whenever you use it, you can

be safe in the knowledge that you’ll get great results every time.

Welcome to Electrolux.

Visit our website for:

Get usage advice, brochures, trouble shooter, service information:

www.electrolux.com/webselfservice

www.registerelectrolux.com

Buy Accessories, Consumables and Original spare parts for your appliance:

www.electrolux.com/shop

CUSTOMER CARE AND SERVICE

Always use original spare parts.

When contacting our Authorised Service Centre, ensure that you have the

following data available: Model, PNC, Serial Number.

The information can be found on the rating plate.

Warning / Caution-Safety information

General information and tips

Environmental information

Subject to change without notice.

www.electrolux.com2

1. SAFETY INFORMATION

Before the installation and use of the appliance, carefully

read the supplied instructions. The manufacturer is not

responsible for any injuries or damages that are the

result of incorrect installation or usage. Always keep the

instructions in a safe and accessible location for future

reference.

1.1 Children and vulnerable people safety

•This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning the use of the appliance in a

safe way and understand the hazards involved.

•Do not let children play with the appliance.

•Children aged 3 years and under must be kept away

from this appliance when it is in operation at all times.

•Keep all packaging away from children and dispose of

it appropriately.

•Keep detergents away from children.

•Keep children and pets away from the appliance when

the door is open.

•Children shall not carry out cleaning and user

maintenance of the appliance without supervision.

1.2 General Safety

•Do not change the specification of this appliance.

•Do not exceed the maximum load of 10 kg (refer to the

"Programme chart" chapter).

•The operating water pressure at the water entry point

from the outlet connection must be between 0.5 bar

(0.05 MPa) and 8 bar (0.8 MPa).

•The ventilation opening in the base (if applicable) must

not be covered by a carpet, mat, or any floor covering.

ENGLISH 3

•The appliance must be connected to the water mains

using the new supplied hose sets, or other new hose

sets supplied by the Authorised Service Centre.

•Old hose sets must not be reused.

•If the mains power supply cable is damaged, it must

be replaced by the manufacturer, its Authorised

Service Centre or similarly qualified persons to avoid

an electrical hazard.

•Before any maintenance operation, deactivate the

appliance and disconnect the mains plug from the

socket.

•Do not use high pressure water sprays and/or steam

to clean the appliance.

•Clean the appliance with a moist cloth. Use only

neutral detergents. Do not use abrasive products,

abrasive cleaning pads, solvents or metal objects.

2. SAFETY INSTRUCTIONS

2.1 Installation

• Remove all the packaging and the

transit bolts.

• Keep the transit bolts in a safe place.

If the appliance is to be moved in

future they must be reattached to lock

the drum to prevent internal damage.

• Always take care when moving the

appliance as it is heavy. Always use

safety gloves and enclosed footwear.

• Do not install or use a damaged

appliance.

• Follow the installation instruction

supplied with the appliance.

• Do not install or use the appliance

where the temperature can be less

than 0°C or where it is exposed to the

weather.

• The floor area where the appliance is

to be installed must be flat, stable,

heat resistant and clean.

• Make sure that there is air circulation

between the appliance and the floor.

• Do not install the appliance directly

over the floor drain.

• Adjust the feet to have the necessary

space between the appliance and the

flooring.

• Do not install the appliance where the

appliance door cannot be fully

opened.

• Do not put a container to collect

possible water leakage under the

appliance. Contact the Authorised

Service Centre to ensure which

accessories can be used.

2.2 Electrical connection

• The appliance must be earthed.

• Always use a correctly installed

shockproof socket.

• Make sure that the parameters on the

rating plate are compatible with the

electrical ratings of the mains power

supply.

• Do not use multi-plug adapters and

extension cables.

• Make sure not to cause damage to

the mains plug and to the mains

cable. Should the mains cable need to

be replaced, this must be carried out

by our Authorised Service Centre.

• Connect the mains plug to the mains

socket only at the end of the

installation. Make sure that there is

www.electrolux.com4

access to the mains plug after the

installation.

• Do not touch the mains cable or the

mains plug with wet hands.

• Do not pull the mains cable to

disconnect the appliance. Always pull

the mains plug.

• This appliance complies with the

E.E.C. Directives.

2.3 Water connection

• Do not cause damage to the water

hoses.

• Before connection to new pipes, pipes

not used for a long time, where repair

work has been carried out or new

devices fitted (water meters, etc.), let

the water flow until it is clean and

clear.

• Ensure that there are no visible water

leaks during and after the first use of

the appliance.

2.4 Use

WARNING!

Risk of injury, electrical

shock, fire, burns or damage

to the appliance.

• This appliance is for household use

only.

• Follow the safety instructions on the

detergent packaging.

• Do not put flammable products or

items that are wet with flammable

products in, near or on the appliance.

• Make sure that all metal objects are

removed from the laundry.

• Do not wash fabrics which are heavily

soiled with oil, grease or other greasy

substances. It can damage rubber

parts of the washing machine.

Prewash such fabrics by hand before

loading them into the washing

machine.

• Do not touch the glass door while a

programme is in operation. The glass

can get hot.

2.5 Service

• To repair the appliance contact an

Authorised Service Centre.

• Use original spare parts only.

2.6 Disposal

WARNING!

Risk of injury or suffocation.

• Disconnect the appliance from the

mains electrical and water supplies.

• Cut off the mains electrical cable

close to the appliance and dispose of

it.

• Remove the door catch to prevent

children or pets from becoming

trapped in the drum.

• Dispose of the appliance in

accordance with local requirements

for the disposal of Waste Electrical

and Electronic Equipment (WEEE).

ENGLISH 5

3. PRODUCT DESCRIPTION

3.1 Appliance overview

1 2 3

1Worktop

2Detergent dispenser

3Control panel

4Door handle

5Rating plate

6Drain pump filter

7Feet for levelling the appliance

4. CONTROL PANEL

4.1 Control panel description

Erteleme

Açma/Kapama

Ba lat/Beklet

Pamuklular

Sentetikler

Hassas Giysiler

Yünlü/Elde Yıkama

Yorgan

Kısa 20 Dk.

Karışık 20°

Pamuklular ECO 1400

1200

800

Hızlı

Yoğun

Kolay Ütü

Durulama

Bo altma&

Sıkma

Program

987621 3 4 5

1Açma/Kapama button

2Programme selection touchpad

3Temperature selection touchpad

4Spin selection touchpad

5Options selection touchpad

6Start/Pause touchpad

7Erteleme touchpad

8Display

9Door locked indicator

www.electrolux.com6

4.2 Display

A B D C

Erteleme

A. The time area:

• : the programme duration

• : the "finish in" time

• : the alarm codes

•: the message of error

• : the programme is completed.

B. The child lock indicator:

• The indicator comes on when you

activate this device.

C. The extra rinse indicator:

• The indicator comes on when you

activate this option.

D. The Erteleme touchpad.

5. PROGRAMME CHART

Programme

Temperature

range

Maximum

load

Maximum

spin speed

Programme description

(Type of load and soil level)

Pamuklular

90 °C - Cold

10 kg

1400 rpm White cotton and coloured cotton. Normal

soil and light soil.

Pamuklular

ECO1)

60 °C - 40 °C

10 kg

1400 rpm White cotton and fast-coloured cotton. Nor‐

mal soil. The energy consumption decreases

and the time of the washing programme is ex‐

tended.

Sentetikler

60 °C - Cold

4 kg

1200 rpm Synthetic items or mixed fabric items. Nor‐

mal soil.

Hassas Giysiler

40 °C - Cold

4 kg

1200 rpm Delicate fabrics such as acrylics, viscose

and mixed fabrics requiring a mild washing.

Normal soil.

Yünlü/Elde Yıka‐

40 °C - Cold

1,5 kg

1200 rpm Machine washable wool, hand washable

wool and other fabrics with «hand washing»

care symbol2).

Yorgan

60 °C - Cold

3 kg

800 rpm

Special programme for one synthetic blanket,

duvet, bedspread and so on.

Kısa 20 Dk.

40 °C - 30 °C

1 kg

1200 rpm

A very short cycle for cotton and synthetic

items with light soil level or worn only once.

ENGLISH 7

Programme

Temperature

range

Maximum

load

Maximum

spin speed

Programme description

(Type of load and soil level)

Karışık 20°

20 °C

2 kg

1200 rpm

Special programme for cotton, synthetic and

mixed fabrics with light soil. Set this programme

to decrease the energy consumption. Make

sure that the detergent is for low temperature in

order to have good washing results3).

1) Standard programmes for the Energy Label consumption values. According to regu‐

lation 1061/2010, these programmes are respectively the «Standard 60°C cotton pro‐

gramme» and the «Standard 40°C cotton programme». They are the most efficient pro‐

grammes in terms of combined energy and water consumption for washing normally soiled

cotton laundry.

The water temperature of the washing phase may differ from the temperature

declared for the selected programme.

2) During this cycle the drum rotates slowly to ensure a gentle wash. It can seem that the

drum doesn't rotate or doesn't rotate properly, but this is normal for this programme.

3) No temperature indicator is on .

Programme options compatibility

Programme

Hızlı1)

Yoğun

Kolay Ütü

Durulama

Boşaltma & Sıkma

Pamuklular ■ ■ ■ ■ ■ ■ ■ ■ ■ ■

Pamuklular ECO ■ ■ ■ ■ ■ ■ ■ ■

Sentetikler ■ ■ ■ ■ ■ ■ ■ ■ ■ ■

Hassas Giysiler ■ ■ ■ ■ ■ ■ ■ ■ ■

Yünlü/Elde Yıkama ■ ■ ■ ■ ■ ■

Yorgan ■ ■ ■ ■ ■ ■

Kısa 20 Dk. ■ ■ ■ ■ ■ ■

Karışık 20° ■ ■ ■ ■ ■ ■ ■

1) When you set this option, we recommend that you decrease the quantity of the laundry. It

is possible to keep the full load but the washing results can be unsatisfactory. Recommen‐

ded load: cotton: 5 kg, synthetics and delicates: 2,5 kg.

www.electrolux.com8

5.1 Woolmark Apparel Care -

Blue

The wool wash cycle of this machine has

been approved by The Woolmark

Company for the washing of wool

garments labelled as «hand wash»

provided that the garments are washed

according to the instructions issued by

the manufacturer of this washing

machine. Follow the garment care label

for drying and other laundry instructions.

M1512

In UK, Eire, Hong Kong and India the

Woolmark symbol is a certification

trademark.

6. CONSUMPTION VALUES

Stated values are obtained in laboratory conditions with relevant stand‐

ards. Different causes can change the data: the quantity and type of

laundry and ambient temperature. Water pressure, the supply voltage

and the temperature of inlet water may also affect the washing pro‐

gramme duration.

Technical specifications may be changed without prior notice to improve

the quality of product.

At the start of the programme, the display shows the programme dura‐

tion for the maximum load capacity.

During the washing phase the programme duration is automatically cal‐

culated and can be greatly reduced if the laundry load is lower than the

maximum load capacity (e.g. Cotton 60°C, maximum load capacity 10

kg, the programme duration exceeds 2 hours; actual load 1 kg, the pro‐

gramme duration will be less than 1 hour).

When the appliance is calculating the real programme duration a dot

flashes in the display.

Programmes Load

(kg) Energy

consump‐

tion (kWh)

Water con‐

sumption

(litre)

Approxi‐

mate pro‐

gramme

duration

(minutes)

Remaining

moisture

(%)1)

Pamuklular 60°C 10 2,04 87 240 52

Pamuklular 40°C 10 1,40 83 210 52

Sentetikler 40°C 4 0,80 61 140 35

ENGLISH 9

Programmes Load

(kg) Energy

consump‐

tion (kWh)

Water con‐

sumption

(litre)

Approxi‐

mate pro‐

gramme

duration

(minutes)

Remaining

moisture

(%)1)

Hassas Giysiler

40°C 4 0,56 75 95 35

Yünlü/Elde Yıka‐

ma 30°C 2) 1,5 0,42 62 75 30

Standard cotton programmes

Standard 60°C

cotton 10 0.93 57 246 52

Standard 60°C

cotton 5 0,70 45 206 52

Standard 40°C

cotton 5 0,65 46 203 52

1) At the end of spin phase.

2) Not available for some models.

Off Mode (W) Left On Mode (W)

0.30 0.30

The information given in the chart above is compliant with the EU Commission regu‐

lation 1015/2010 implementing directive 2009/125/EC

7. OPTIONS

7.1 Temperature

With this option you can change the

default temperature.

Indicator = cold water.

The indicator of the set temperature

comes on.

7.2 Spin

With this option you can change the

default spin speed.

The indicator of the set speed comes on.

Additional spin options:

No Spin

• Set this option to deactivate all spin

phases. Only the drain phase is

available.

• The related indicator comes on.

• Set this option for very delicate

fabrics.

• The rinses phase uses more water for

some washing programmes.

Rinse Hold

• Set this option to prevent the laundry

creases.

• The related indicator comes on.

• There is a water in the drum when the

programme is completed.

• The drum turns regularly to prevent

the laundry creases.

• The door stays locked. You must

drain the water to unlock the door.

www.electrolux.com10

Other manuals for EWF 1404BR

Table of contents

Languages:

Other Electrolux Washer manuals

Electrolux

Electrolux EWF 148318 W User manual

Electrolux

Electrolux 500 TimeCare EW6T3226B3 User manual

Electrolux

Electrolux IQ-TOUCH EIFLS55I IW System manual

Electrolux

Electrolux WA L2 E100 User manual

Electrolux

Electrolux WA SL3 M Instruction Manual

Electrolux

Electrolux Affinity Setup guide

Electrolux

Electrolux WA SL1 E 101 User manual

Electrolux

Electrolux EWT 1011 User manual

Electrolux

Electrolux Swissline SL EWF 1880 Operation manual

Electrolux

Electrolux EWF 168547 W User manual

Electrolux

Electrolux EIFLS60JIW1 User manual

Electrolux

Electrolux EW6F528W User manual

Electrolux

Electrolux EWT 0862EWW User manual

Electrolux

Electrolux EWX 147410 W User manual

Electrolux

Electrolux EWT 1276EVH User manual

Electrolux

Electrolux EWT 2266AOW User manual

Electrolux

Electrolux EWF14822 User manual

Electrolux

Electrolux EWS 1476 FDW User manual

Electrolux

Electrolux EWF 147540 W User manual

Electrolux

Electrolux EWT 106510 W User manual

Electrolux

Electrolux EWS 86110W User manual

Electrolux

Electrolux EW7F447WIN User manual

Electrolux

Electrolux EWF 735 User manual

Electrolux

Electrolux EWT 1041 User manual

Popular Washer manuals by other brands

Tricity Bendix

Tricity Bendix AW 1000 W Operating & installation instructions

Panasonic

Panasonic NA-F60L5WRB operating instructions

GE WSLP1500 Dimensions and installation information

Bosch

Bosch WAN2829BSN User manual and installation instructions

LG TV2516DV3B owner's manual

LG TH2517DSAV owner's manual

VESTEL

VESTEL CMH-XL 7510 TE user manual

AEG

AEG 74335 User information

Johnson

Johnson JWF721A user manual

Beko

Beko WTE7604XLW0 owner's manual

Danby

Danby DTT100A1WDB Owner's use and care guide

Amica

Amica WA 14 Ex operating instructions

Daewoo

Daewoo DWD-F1222 instruction manual

Bosch

Bosch WAS28461AU instruction manual

Miele

Miele PW 6080 Vario manual

Finlux

Finlux FLX108CF220 user manual

Whirlpool

Whirlpool 3LBR5132AN0 Use and care guide

Beko

Beko WKB 51231 PTMA manual
