Electrolux EWP 1462 TDW User manual

EWP 1062 TDW

EWP 1462 TDW

................................................ .............................................

EN WASHING MACHINE USER MANUAL

CONTENTS

1. SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

2. SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

3. PRODUCT DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

4. CONTROL PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

5. WASHING PROGRAMMES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

6. CONSUMPTION VALUES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

7. OPTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

8. BEFORE FIRST USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

9. DAILY USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

10. HELPFUL HINTS AND TIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

11. CARE AND CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

12. TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

13. TECHNICAL DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

WE’RE THINKING OF YOU

Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it

decades of professional experience and innovation. Ingenious and stylish, it has been designed

with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great

results every time.

Welcome to Electrolux.

Visit our website for:

Get usage advice, brochures, trouble shooter, service information:

www.electrolux.com

www.electrolux.com/productregistration

Buy Accessories, Consumables and Original spare parts for your appliance:

www.electrolux.com/shop

CUSTOMER CARE AND SERVICE

We recommend the use of original spare parts.

When contacting Service, ensure that you have the following data available.

The information can be found on the rating plate. Model, PNC, Serial Number.

Warning / Caution-Safety information

General information and tips

Environmental information

Subject to change without notice.

2www.electrolux.com

1. SAFETY INFORMATION

Before the installation and use of the appliance, carefully

read the supplied instructions. The manufacturer is not

responsible if an incorrect installation and use causes in-

juries and damages. Always keep the instructions with

the appliance for future reference.

1.1 Children and vulnerable people safety

WARNING!

Risk of suffocation, injury or permanent disability.

• This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience and

knowledge if they have been given supervision or in-

struction concerning use of the appliance in a safe way

and understand the hazards involved.

• Do not let children play with the appliance.

• Keep all packaging away from children.

• Keep all detergents away from children.

• Keep children and pets away from the appliance door

when it is open.

• If the appliance has a child safety device, we recom-

mend you activate it.

• Cleaning and user maintenance shall not be made by

children without supervision.

1.2 General Safety

• Before maintenance, deactivate the appliance and dis-

connect the mains plug from the mains socket.

• Do not change the specification of this appliance.

• Obey the maximum load volume of 6 kg (refer to the

“Programme chart” chapter).

ENGLISH 3

2. SAFETY INSTRUCTIONS

2.1 Installation

• Remove all the packaging and the

transit bolts.

• Keep the transit bolts. When you move

the appliance again you must block the

drum.

• Do not install or use a damaged appli-

ance.

• Do not install or use the appliance

where the temperature is less than 0 °C

or where it is exposed to the weather.

• Obey the installation instruction sup-

plied with the appliance.

• Make sure that the floor where you in-

stall the appliance is flat, stable, heat

resistant and clean.

• Do not install the appliance where the

appliance door can not be fully opened.

• Always be careful when you move the

appliance because it is heavy. Always

wear safety gloves.

• Make sure that there is air circulation

between the appliance and the floor.

• Adjust the feet to have the necessary

space between the appliance and the

carpet.

Electrical connection

WARNING!

Risk of fire and electrical shock.

• The appliance must be earthed.

• Make sure that the electrical information

on the rating plate agrees with the pow-

er supply. If not, contact an electrician.

• Always use a correctly installed shock-

proof socket.

• Do not use multi-plug adapters and ex-

tension cables.

• Make sure not to cause damage to the

mains plug and to the mains cable.

Should the appliance power supply ca-

ble need to be replaced, this must be

carried out by our Service Centre.

• Connect the mains plug to the mains

socket only at the end of the installa-

tion. Make sure that there is access to

the mains plug after the installation.

• Do not pull the mains cable to discon-

nect the appliance. Always pull the

mains plug.

• Do not touch the mains cable or the

mains plug with wet hands.

• This appliance complies with the E.E.C.

Directives.

Water connection

• Make sure not to cause damage to the

water hoses.

• The appliance is to be connected to the

water mains using the new supplied

hose-sets. Old hose sets must not be

reused.

• Before you connect the appliance to

new pipes or pipes not used for a long

time, let the water flow until it is clean.

• The first time you use the appliance,

make sure that there is no leakage.

2.2 Use

WARNING!

Risk of injury, electrical shock, fire,

burns or damage to the appliance.

• Use this appliance in a household envi-

ronment.

• Do not change the specification of this

appliance.

• Obey the safety instructions on the de-

tergent packaging.

• Do not put flammable products or items

that are wet with flammable products

in, near or on the appliance.

• Do not touch the glass of the door

while a programme operates. The glass

can be hot.

• Make sure that you remove all metal

objects from the laundry.

• Do not put a container to collect possi-

ble water leakage under the appliance.

Contact the Service to ensure which

accessories can be used.

2.3 Care and Cleaning

WARNING!

Risk of injury or damage to the

appliance.

4www.electrolux.com

• Before maintenance, deactivate the ap-

pliance and disconnect the mains plug

from the mains socket.

• Do not use water spray and steam to

clean the appliance.

• Clean the appliance with a moist soft

cloth. Only use neutral detergents. Do

not use abrasive products, abrasive

cleaning pads, solvents or metal ob-

jects.

2.4 Disposal

WARNING!

Risk of injury or suffocation.

• Disconnect the appliance from the

mains supply.

• Cut off the mains cable and discard it.

• Remove the door catch to prevent chil-

dren and pets to get closed in the ap-

pliance.

3. PRODUCT DESCRIPTION

1 2 3

1Worktop

2Detergent dispenser

3Control panel

4Door handle

5Rating plate

6Feet for the appliance level

3.1 Child safety device

When you activate this device, you cannot

close the door. This prevents children or

pets to be closed in the drum. To activate

the device, turn it clockwise, until the

groove is horizontal. To deactivate the de-

vice, turn it counter-clockwise, until the

groove is vertical.

3.2 Fixing plate kit (405517114)

Use this special accessory, when you in-

stall the appliance on a plinth.

It prevents the movements of the appli-

ance when it operates.

Read carefully the instructions supplied

with this accessory.

You can buy it in all approved Service.

ENGLISH 5

4. CONTROL PANEL

Temperatură

Centrifugare

Start/Pauză

Pornire

intârziată

Sp ălare Cl ătire

suplimentar

Presp ălare

Mătase

Bumbac Eco

Bumbac

Draperii

Cl ătire

Centrifugare

Evacuare

Pături

Jeans

Sintetice

Delicate

Lână/

Sp ălare manuală

Sport

5 C ămăşi

20°

90° 40°

30°

800

60°

1200

1400

400

3h 6h 9h

Pornire

intârziată

1 2 3

1Programme knob

2Spin reduction touchpad and

functions indicators:

No spin indicator

Rinse hold indicator

3Temperature touchpad

4Prewash touchpad

5Delay start touchpad

6Extra rinse touchpad

7Quick touchpad

8Start/Pause touchpad

9Programme status indicators:

Door locked indicator

End cycle indicator

Child lock indicator

5. WASHING PROGRAMMES

Programme

Temperature range

Type of load and soil

Maximum load, Maximum spin

Bumbac

90°C — Cold ( )

White cotton and coloured cotton. Normal soil

and light soil.

6 kg, 1000 rpm (EWP 1062TDW), 1400 rpm

(EWP 1462TDW)

Bumbac Eco

60 °C – 40 °C

White cotton and colour-fast cotton. Normal soil.

6 kg, 1000 rpm (EWP 1062TDW), 1400 rpm

(EWP 1462TDW)

Sintetice

60 °C— Cold ( )

Synthetic items or mixed fabric items. Normal

soil.

3 kg, 1000 rpm (EWP 1062TDW), 1200 rpm

(EWP 1462TDW)

Delicate

40 °C - Cold ( )

Delicate fabrics as acrylics, viscose, polyester

items. Normal soil.

3 kg, 1000 rpm (EWP 1062TDW), 1200 rpm

(EWP 1462TDW)

6www.electrolux.com

Programme

Temperature range

Type of load and soil

Maximum load, Maximum spin

Lână/Spălare man-

uală

40 °C – Cold ( )

Machine washable wool, hand washable wool

and delicate fabrics with «hand washing» care

symbol.

2 kg, 1000 rpm (EWP 1062TDW), 1200 rpm

(EWP 1462TDW)

Mătase

30 °C

Special programme for silk and mixed synthetic

items.

1 kg, 800 rpm

Pături

60 °C – 30 °C

Special programme for one synthetic blanket, du-

vet, bedspread and so on.

2 kg, 800 rpm

Clătire To rinse and spin the laundry. All fabrics.

6 kg, 1000 rpm (EWP 1062TDW), 1400 rpm

(EWP 1462TDW)

Evacuare To drain the water in the drum. All fabrics.

6 kg

Centrifugare To spin the laundry and to drain the water in the

drum. All fabrics.

6 kg, 1000 rpm (EWP 1062TDW), 1400 rpm

(EWP 1462TDW)

Jeans

60 °C - Cold ( )

Items in denim and jersey. Also for items in dark

colors.

3 kg, 1000 rpm (EWP 1062TDW), 1200 rpm

(EWP 1462TDW)

Draperii

40 °C - Cold ( )

Special programme for curtains. The prewash

phase activates automatically.

2 kg, 800 rpm

Sport

30 °C

Synthetic and delicate items. Light soil or items or

items to refresh.

3 kg, 800 rpm

5 Cămăşi

30 °C

Synthetic and mixed fabric items. Light soil and

items to freshen up.

For 5 - 6 shirts.

800 rpm

1) Standard programmes for the Energy Label consumption values

According to regulation 1061/2010, the “Bumbac Eco 60 °C” and “Bumbac Eco 40 °C” are

respectively the “standard 60 °C cotton programme” and the “standard 40 °C cotton

programme”. They are the most efficient programmes in terms of combined energy and

water consumptions for washing normally soiled cotton laundry.

The water temperature of the washing phase may differ from the temperature de-

clared for the selected programme.

2) Do not use any detergent for prewash phase.

ENGLISH 7

Programme options compatibility

Programme

∎ ∎ ∎ ∎ ∎ ∎ ∎

Eco ∎ ∎ ∎ ∎ ∎ ∎ ∎

∎ ∎ ∎ ∎ ∎ ∎ ∎

∎ ∎ ∎ ∎

∎ ∎ ∎

∎∎

∎ ∎ ∎ ∎∎

∎

∎∎

∎ ∎ ∎ ∎ ∎ ∎ ∎

∎ ∎ ∎ ∎ ∎ ∎

∎ ∎ ∎

1) When you set the Quick option, we recommend that you decrease the quantity of the

laundry. It is possible to keep the full load but the washing results can be unsatisfactory.

Recommended load: cotton: 3 kg, synthetics and delicates: 1,5 kg.

6. CONSUMPTION VALUES

The data of this table are approximate. Different causes can change the data:

the quantity and type of laundry, the water and ambient temperature.

8www.electrolux.com

Pro-

grammes

Load

(kg)

Energy

consump-

tion (kWh)

Water

con-

sumption

(litre)

Approxi-

mate

pro-

gramme

duration

(mi-

nutes)

Remain-

ing

mois-

ture

(%)

EWP

1062TD

Remain-

ing

mois-

ture

(%)

EWP

1462TD

Cottons 60

°C 61.20 70 170 60 52

Cottons 40

°C 60.75 72 145 60 52

Synthetics

40 °C 30.60 57 95 37 35

Delicates

40 °C 30.60 65 75 37 35

Wool/Hand

wash 30 °C 20.30 48 55 32 30

Standard cotton programmes

Standard

60 °C cot-

ton

60.98 51 225 60 52

Standard

60 °C cot-

ton

30.67 42 153 60 52

Standard

40 °C cot-

ton

30.47 43 154 60 52

1) At the end of spin phase.

Off Mode (W) Left On Mode (W)

0.75 0.75

The information given in the charts above are in compliance with the EU Commi-

sion regulation 2015/2010 implementing directive 2009/125/EC.

7. OPTIONS

7.1 Temperature

Set this option to change the default tem-

perature.

Indicator = cold water.

The indicator of the set temperature

comes on.

7.2 Spin

With this option you can change the de-

fault spin speed.

The indicator of the set speed comes on.

ENGLISH 9

Additional spin options:

No Spin

• Set this option to deactivate all spin

phases. Only the drain phase is availa-

ble.

• The related indicator comes on.

• Set this option for very delicate fabrics.

• The rinses phase uses more water for

some washing programmes.

Rinse Hold

• Set this option to prevent the laundry

creases.

• The related indicator comes on.

• There is a water in the drum when the

programme is completed.

• The drum turns regularly to prevent the

laundry creases.

• The door stays locked.

• You must drain the water to unlock the

door.

To drain the water refer to ‘At the

end of the programme’.

7.3 Prewash

With this option you can add a prewash

phase to a washing programme.

Use this option for heavy soil.

When you set this option the programme

duration increases.

The related indicator comes on.

7.4 Delay Start

With this option you can delay the start of

a programme by 9, 6 or 3 hours.

The indicator of the option and the indica-

tor of the set value are on.

7.5 Extra Rinse

With this option you can add some rinses

to a washing programme.

Use this option for persons allergic to de-

tergents and in areas where the water is

soft.

The related indicator comes on.

7.6 Quick

With this option you can decrease the

programme duration.

Use this option for items with light soil or

items to refresh.

The related indicator comes on.

7.7 Child Lock

With this option you can prevent that the

children play with the control panel.

• To activate/deactivate the option,

press and at the same time

until the indicator comes on/goes

off.

You can activate this option:

• After you press , the options and

the programme knob are locked.

• Before you press : the appliance

cannot start.

7.8 Permanent extra rinse

With this option you can permanently

have an extra rinse when you set a new

programme.

• To activate/deactivate this option

press and at the same time until

the indicator comes on/goes off.

7.9 Acoustic signals

The acoustic signals operate when:

• The programme is completed.

• The appliance has a malfunction.

To deactivate/activate the acoustic sig-

nals, press and at the same time

for 6 seconds.

If you deactivate the acoustic sig-

nals, they continue operate when

the appliance has a malfunction.

10 www.electrolux.com

Table of contents

Other Electrolux Washer manuals

Electrolux

Electrolux EWF 14592 W User manual

Electrolux

Electrolux EW6S347S User manual

Electrolux

Electrolux EWF8024Q5WB User manual

Electrolux

Electrolux EWF 14112 User manual

Electrolux

Electrolux EWFLW65H - 27'' Front-Load Washer User manual

Electrolux

Electrolux EW 1235 F Quick guide

Electrolux

Electrolux Washing machines with EWM 1000 PLUS User manual

Electrolux

Electrolux EW 1478 F User manual

Electrolux

Electrolux EW7F8143OV User manual

Electrolux

Electrolux EWS 1056 EGU User manual

Electrolux

Electrolux EWF 167320 W User manual

Electrolux

Electrolux FOM 71 CLS User manual

Electrolux

Electrolux EWFLS65I User manual

Electrolux

Electrolux EWT1074N5WA User manual

Electrolux

Electrolux EWT 1100 User manual

Electrolux

Electrolux EWS 11266 EW User manual

Electrolux

Electrolux LI 1270 E User manual

Electrolux

Electrolux EWF 146410 W User manual

Electrolux

Electrolux EW7F4722NF User manual

Electrolux

Electrolux EWFLW65IMB - 27" Front-Load Washer User manual

Electrolux

Electrolux EWT 1276EVH User manual

Electrolux

Electrolux EWF12832 User manual

Electrolux

Electrolux EWT1074M5WA User manual

Electrolux

Electrolux EWG 147540 W User manual

Popular Washer manuals by other brands

Tricity Bendix

Tricity Bendix AW 1000 W Operating & installation instructions

Panasonic

Panasonic NA-F60L5WRB operating instructions

GE WSLP1500 Dimensions and installation information

Bosch

Bosch WAN2829BSN User manual and installation instructions

LG TV2516DV3B owner's manual

LG TH2517DSAV owner's manual

VESTEL

VESTEL CMH-XL 7510 TE user manual

AEG

AEG 74335 User information

Johnson

Johnson JWF721A user manual

Beko

Beko WTE7604XLW0 owner's manual

Danby

Danby DTT100A1WDB Owner's use and care guide

Amica

Amica WA 14 Ex operating instructions

Daewoo

Daewoo DWD-F1222 instruction manual

Bosch

Bosch WAS28461AU instruction manual

Miele

Miele PW 6080 Vario manual

Finlux

Finlux FLX108CF220 user manual

Whirlpool

Whirlpool 3LBR5132AN0 Use and care guide

Beko

Beko WKB 51231 PTMA manual
