Electrolux EDE 425 M User manual

EDE 411

Torktumlare

Tørretumbler

Tørketrommel

Tumble Dryer

Stegnwthrio

Bruksanvisning Brugsanvisning Bruksanvisning Instruction booklet

Odhg’e§ crÆsh§

S DK N GB GR

125996611

EDE 411 M

CONGRATULATIONS ON YOUR NEW TUMBLE DRYER

Before using your new tumble dryer,

please read this instruction booklet carefully.

To avoid risks ensuing from the use of an electrical

appliance, please make sure that the tumble dryer

is installed correctly and that you read the information

regarding safety contained in this instruction booklet,

in order to avoid mistakes and unnecessary risks.

Please keep this booklet in the vicinity of the

appliance.

INDEX

ENGLISH

Warnings 44

■Installation 44

■Using your tumble dryer 44

■Disposing of tumble dryer 44

INSTRUCTIONS FOR USER

Description of tumble dryer 45

Description of control panel

■Drying time selector dial 46

■Control buttons 46

Programme chart 47

How to use your tumble dryer

■Options 48

■Programming 48

■End of drying cycle 48

Important information on using the

tumble dryer

■Not all items can be dried in your tumble dryer 49

■Starched fabrics 49

■Shrinking 49

■What is fluff? 49

■Energy and time consumption 49

■Washing labels 49

Maintenance and cleaning

■External cleaning 50

■Cleaning the door 50

■Fluff filter 50

Your tumble dryer is not working 51

■Service and spare parts 51

INSTALLATION INSTRUCTIONS

Technical specifications 52

Installation 52

■Positioning 52

■Fitting the vent hose 53

■Door reversal 54

■Electrical connections 54

■Stacking kit (optional accessory) 54

WARNINGS

Installation and technical

assistance

■This tumble dryer is designed for domestic use

only. When using this appliance, please comply

with the instructions in this booklet. Failure to do

so may result in injury to people or damage to

objects.

■This appliance must be installed and/or serviced

(e.g. modifying tumble dryer’s electrical supply

cable) by qualified personnel only. Servicing

carried out by non-qualified personnel may

damage the appliance or cause injury to people and

damage objects.

■Servicing and repairs must be carried out by a

service centre authorised by the manufacturer. Do

not attempt to repair appliance yourself.

■Make sure that the appliance is not standing on its

electrical supply cable.

■If the tumble dryer is placed on top of a washing

machine, it is compulsory to use the stacking kit

(optional accessory).

Using your tumble dryer

■Do not allow children to play with appliance or

touch the control panel.

■When the appliance is working, the drum and rear

panel reach very high temperatures. Therefore, do

not touch these parts. Please make sure that

children are kept well away from appliance when it

is working.

■Pet animals or children may climb inside the

appliance’s drum; always make sure that the drum

is empty before loading.

■Do not overload appliance (see programme chart).

■Please make sure that no gas lighters have

accidentally been left in pockets of garments to be

loaded into appliance.

■Danger of explosion: Never tumble dry items that

have been in contact with inflammable solvents

(petrol, methylated spirits, dry cleaning fluid and

the like). As these substance are volatile, they

could cause an explosion. Tumble dry only items

washed with water.

■In order to avoid danger of fires caused by

excessive drying, do not use appliance to dry the

following items:

■Cushions, quilts and the like (these items

accumulate heat).

■Items containing rubber foam or materials similar

to rubber foam.

■Canvas shoes or sports shoes, as they could get

stuck between the door and the drum, thus

blocking the latter.

■Leave the door slightly ajar when the appliance is

not being used. This will allow the seal to be

preserved.

■Clean fluff filter after using tumble dryer. To

prevent fire risks, do not use the appliance if the

fluff filter is damaged.

Disposing of tumble dryer

■All materials marked with the symbol are

recyclable and should be taken to a special disposal

point.

■You are kindly requested to participate in the

safeguarding of the environment, even when you

decide to dispose of the appliance. Disconnect

electrical supply cable from mains. Cut off

electrical supply cable. For information regarding

waste collection points, please contact local

authorities or your nearest Electrolux Service

Centre.

Please read all the information contained in this instruction booklet before installing and using your tumble

dryer. By doing so, the tumble dryer will function correctly and to the highest degree of efficiency.

All those using the appliance must be familiar with the relevant safety information.

Please store this instruction booklet with care. Should the appliance be sold or transferred to another owner, or

should you move house and leave the appliance, please make sure that this booklet is supplied with the

appliance.

DESCRIPTION OF THE APPLIANCE

ENGLISH

1 Worktop

2 Programme chart

3 Low Temperature Button

4 Cool Tumbling Button

5 Time Selector Dial

6 Mains-On Light

7 Rating Plate

8 Fluff filter

9 Door Handle

10 Adjustable feet

11 Side vent outlets

12 Ring nut

13 Rear vent outlet

1 3 4 5 6

EDE 411 M

USE

1 Programme Chart

This will help you to select the correct time for

drying.

2Low Temperature Button

Press this button to reduce the temperature when

drying particularly delicate cotton or linen items.

In this case you should select a longer drying time.

On the programmes for synthetics the temperature is

automatically reduced.

Therefore it is not necessary to depress this button.

3 Cool tumbling

By depressing this button the heat is cut off. This is

particularly useful to freshen the laundry (e.g. to

remove a persistent odour of moth-balls). Select 20-30

mins max.

4 Drying Time Selector Dial

The selector dial incorporates two drying cycles, one

of up to 150 minutes at a high temperature for cotton

and linen, and one of up to 100 minutes at a low

temperature for synthetic fabrics.

To set the machine to the selected time, turn the dial

clockwise until the time you want coincides exactly

with the pointer.

NEVER attempt to turn the dial in an anticlockwise

direction.

When selecting the drying time, you should remember

that it includes a 10 minute cooling phase (position

on the dial).

This phase should not be shortened, stopped or

avoided, as this could cause skin burns or damages to

the laundry.

5 Mains-On Light

This lights up when the machine starts operating and

goes out at the end of the programme.

Control panel

EDE 411 M

1 2 3 4 5

PROGRAMME CHART

ENGLISH

Cotton and linen

Heating element - 2000 W

Type of laundry:

Cotton

Towelling

Shirts

Sheets

Hand towels

Tablecloths

Table napkins

Degree of drying

Store dry

(wardrobe dry)

5.0

2.5

95-115

60-75

90-110

55-70

5.0

2.5

80-100

40-55

75-95

35-50

Iron dry

(not completely dry;

suitable for ironing

Amount

of laundry

in kg

Drying time in minutes for

laundry spun at

800/1000 rpm 1000/1200 rpm

ATTENTION! If you are drying delicate cotton, select the ‘low temperature’ optional function

Synthetics

Heating element - 1400 W

Type of laundry:

Synthetics or mixed fabrics

which do not require

ironing.

Delicate and heat-sensitive

fabrics.

(Please see labels on items)

Degree of drying

Store dry

2.0 30-40

25-30

20-25

25-35

20-30

15-20

1.5

0.5

2.0

1.5

0.5

Iron dry

Amount of laundry

in kg Drying time in minutes for laundry

spun at a minimum speed of 650 rpm

ATTENTION! Please follow the instructions on labels when drying mixed fabrics.

HOW TO USE YOUR TUMBLE DRYER

Before using your tumble dryer for

the first time

There may be dust or dirt inside a brand new tumble

dryer. Place a few damp cloths inside the appliance

and dry for approximately 20 minutes.

1. Loading laundry

Open the door. Load spun laundry. Do not press

laundry in appliance. Close door making sure that

there are no laundry items preventing the door from

being closed.

2. Select the required option.

3. Select drying time

Turn the dial clockwise until the desired drying time is

under the symbol on the front panel. The mains-on

light will then light up and the machine starts

operating.

4. End of cycle

When the selected cycle has come to an end, the

tumble dryer will stop and the mains-on light will

switch off automatically. The selector dial will return

to the ‘zero’ position.

Open door and take out cooled laundry.

IMPORTANT! Clean filter after every drying

programme.

100°

IMPORTANT INFORMATION ON USING THE TUMBLE DRYER

ENGLISH

Sort and prepare laundry before

drying

Sort laundry to be dried according to fabric type (see

label on each item) and desired degree of dryness.

Close all zips and tie all strings. Close pillowcases and

quilt covers to prevent small items from getting

tangled inside them.

Never tumble dry the following:

■Particularly delicate items such as synthetic

curtains, silk and nylon stockings.

■Items containing rubber foam or materials similar

to rubber foam.

■Woollens or mixed-wool garments, as these will

shrink and felt.

Do not tumble dry items treated with

inflammable liquids (petrol, methylated

spirits, dry cleaning fluid) to avoid fire risks.

Starched fabrics

Starched fabrics may also be dried in this appliance.

To obtain the best results, select ‘iron dry’ drying time

with residual dampness. When the cycle has been

completed, clean tumble dryer drum with a damp

cloth and then with a dry cloth in order to remove any

remaining starch.

Shrinking

Some items (such as shirts and the like) may easily

shrink to a greater or lesser extent. This is due to the

fact that these items are ‘suspended’ inside the tumble

dryer, as opposed to being hung on a washing line to

dry, which is usually the case.

Do not over-dry these items. Select ‘iron dry’ drying

time for these items.

What is fluff?

When you begin to use your tumble dryer, you will be

surprised at the amount of fluff that accumulates in the

fluff filter.

This is perfectly normal and does not mean that the

tumble dryer is damaging the laundry being dried.

When the tumble dryer is being used, as well as when

items are washed by hand or in a washing machine,

fibres and fluff are released by any laundry item and

adhere to its surface. This also happens when fabrics

are hung out to dry in outdoor environments. In a

tumble dryer fibres and fluff accumulate in the fluff

filter and increase in volume because of the heat

inside the appliance.

Time and energy consumption

Energy consumption and drying times vary according

to the quantity, residual dampness after spinning, size

and nature of the fabrics being dried and the degree of

dryness.

If the appliance is overloaded, mediocre drying results

will be obtained and the laundry will be creased.

In order to reduce energy consumption and drying

times, it is necessary to spin the laundry adequately.

The use is recommended of a washing machine

capable of spinning laundry at a speed of 800 rpm or

more.

Garments which are not ironed, such as shirts, must

also be spun for 10 - 30 seconds before they are dried

in the tumble dryer.

How much does dry laundry weigh?

Please use the following values to load the appliance

correctly. These values refer to cotton garments:

Approximate weight in grammes

Bathrobes...............................................................1200

Quilt covers..............................................................700

Sheets.......................................................................500

Handtowels, pillowcases..........................................200

Shirts, night-gowns..................................................200

Pyjamas, blouses......................................................100

Underpants, socks....................................................100

Leggings ..................................................................300

The labels on the garments indicate exactly which drying method to choose.

DRYING Flat On the line On clothes

hanger Tumble dry

high

temperature

low

temperature

Do not

tumble dry

MAINTENANCE

You must

disconnect

the appliance from the

electricity supply, before you can carry out any

cleaning or maintenance work.

External cleaning

Use only soap and water and then dry thoroughly.

Important: do not use methylated spirit, diluents or

Popular Dryer manuals by other brands

Bosch

Bosch WTA79200GB Installation and operating instructions

Amana

Amana W10233410A Use and care guide

Miele

Miele TWH 780 WP operating instructions

Asko

Asko T760 user guide

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Original instructions

Bosch

Bosch Logixx 10 WTB76556GB Instruction manual and installation instructions

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Operation and installation

Beko

Beko DS8433RX1M user manual

Dawlance

Dawlance Spinner DS 6000 C owner's manual

AEG

AEG TR838P4OB user manual

Indesit

Indesit IDV 75 instruction manual

Infiniton

Infiniton SD-DG85C manual

BOMANN

BOMANN WT 5019 instruction manual

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Installation

Asko

Asko T793C operating instructions

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer installation instructions

Frigidaire

Frigidaire CAQE7077KW0 use & care

Bosch

Bosch WTX8HKM9SN User manual and installation instructions
