Electrolux 134066300 User manual

OPERATING INSTRUCTIONS

Printed in U.S.A.

Read Drying Procedures in your Owner's Guide.

It explains these operating steps in detail.

1. Prepare items for drying.

Operating Steps

P/N 134066300 (0107)

Versión en español

Si desea obtener una copia en español de estas

Instrucciones de Funcionamiento, sírvase escribir a la

dirección que se incluye a continuación.

Solicite la P/N 131972200.

Spanish Owner's Guides

Electrolux Home Products

P. O. Box 212378

Augusta, Georgia 30917

The

REGULAR-HIGH HEAT, PERM PRESS-MEDIUM

HEAT

,and

KNITS/DELICATES-LOWHEAT

temperature

settings may be used with any cycle setting. The

AIR

FLUFF-NO HEAT

setting can be used only in the Timed

Dry cycle.

AIR FLUFF-NO HEAT

setting tumbles the load without

heat. Use Air Fluff to freshen clothing, pillows or

blankets, or to dust draperies.

Cycle Selection

Turn cycle selector clockwise to desired cycle and

setting.

Each cycle ends with a cool down period. The heat

automaticallyturnsoffandtheloadcontinuestotumble

duringthecooldownperiod.Thisreduceswrinklingand

makes items easier to handle during unloading.

Drying time varies depending on size and dampness of

load, weight and fabric type. Room temperature and

humidity, type of installation and electrical voltage or

gas pressure can also affect drying time.

2. Check that lint screen is clean and in place.

3. Load the dryer.

If desired, add a dryer fabric

softener sheet.

4. Close the dryer door.

5. Set Dry Temperature control. Select PRESS

SAVER if desired.

6. Turn cycle selector clockwise to desired

setting.

7. Start dryer.

Push the Start button and hold for 1-

2 seconds, or turn the Turn to Start control

clockwisetoON.Holdfor1-2secondsandrelease.

8. A signal will sound toward the end of the cool

down period when the End of Cycle chime is

turned on.

9. Remove items immediately and hang or fold.

10. Clean lint screen after every load.

Temperature Selection

Always follow directions on fabric care

labels.

To avoid fire hazard, do not use heat

todryitemscontainingfeathersordown,foamrubber,

plastics, or similarly textured, rubber-like materials.

Use Air Fluff-No Heat setting only.

Before Operating Your Dryer

Read your dryer Owner's Guide.

It has important

safety and warranty information. It also has many

suggestions for best drying results.

To reduce the risk of fire, electric

shock, or injury to persons, read the IMPORTANT

SAFETY INSTRUCTIONS in your dryer owner's guide

before operating this appliance.

PRESS SAVER

COLORS/

WHITES/

COLORS

PRESS

SAVER

WHITES

PRESS

SAVER

ON OFF

END OF CYCLE

SIGNAL

P/N 134066300 (0107)

Cycle Selection

(continued)

Auto

Regular/Whites Cycle

This cycle is best for cotton items. Drying time is

determinedautomatically at the temperature selection

of your choice.

• High heat is suggested for cotton items.

• Initially set cycle selector on

NORMAL DRY.

• For items requiring more drying time, set cycle

selector on

MORE.

• For items requiring less drying time, set cycle

selector on

LESS.

Auto Delicate Cycle

Thiscycleis best for knit anddelicate items. Drying time

isdeterminedautomaticallyatthetemperatureselection

of your choice.

• Low heat is suggested for knit and delicate items.

• Initially set cycle selector on

NORMAL DRY

• For items requiring more drying time, set cycle

selector on

• For items requiring less drying time, set cycle

selector on

LESS

• A signal will sound toward the end of the cool down

period when the End of Cycle chime is turned on.

• If the

Press Saver

option is turned on, the cycle

selector will advance to the

Press Saver

setting.

Unheatedtumblingcontinuesduring

PressSaver

for

16 minutes tohelp reduce wrinkling if the driedload

cannot be removed promptly. A signal will sound

briefly every five minutes as a reminder to remove

the load when the End of Cycle chime is turned on.

Timed Dry Regular Cycle

Thiscycleprovides approximately 60 minutes of drying

time at the temperature selection of your choice.

Auto Perm Press/Colors Cycle

This cycle is best for permanent press items. Drying

time is determined automatically at the temperature

selection of your choice.

• Medium heat is suggested for permanent press

items.

• Initially set cycle selector on

NORMAL DRY.

• For items requiring more drying time, set cycle

selector on

MORE.

• Foritemsrequiring less drying time, set cycle selector

LESS.

• A signal will sound toward the end of the cool down

period when the End of Cycle chime is turned on.

• If the

Press Saver

option is turned on, the cycle

selector will advance to the

Press Saver

setting.

Unheatedtumblingcontinuesduring

PressSaver

for

16minutes to help reduce wrinklingif the dried load

cannot be removed promptly. A signal will sound

briefly every five minutes as a reminder to remove

the load when the End of Cycle chime is turned on.

Energy Saving Tips

• Keep the lint screen clean and exhaust the dryer

correctly.

• Sortlaundry properly and select proper temperature

and cycle settings. Choose an automatic dry cycle

whenever possible for accurate drying time.

• Dry only full loads. Single items and small loads

usually take longer to dry.

• Avoid overloading, adding wet items to a partially

dry load, and overdrying.

• Dry one load after another to take advantage of a

warm dryer.

• Opening the door needlessly causes warm air to

escape, which prolongs drying time.

• If possible, use the dryer on low humidity days.

• Install the dryer in an area where the room

temperature is at least 45°F (7°C).

PRESS SAVER

COLORS/

WHITES/

COLORS

PRESS

SAVER

WHITES

PRESS

SAVER

ON OFF

END OF CYCLE

SIGNAL
