Electrolux FAS156N1 User manual

Product No. FAS156N1A

Series heavy duty

Color N/A

Volts 115

BTU-Cooling 15100 BTU

Owner's Guide 309000855

Market North America

P40L2006.eps FAS156N1A.eps Heavy Duty FAS Wiring Diagram.eps

ELECTROLUX HOME PRODUCTS, INC.

P.O. Box 212378, Augusta, GA 30917

Publication No.

5995409363

04/05/05

(EN/SERVICE/KC)

099

ROOM AIR

CONDITIONER

Model No.

FAS156N1

Publication No: 5995409363 FAS156N1A

05/04 2

RECOMMENDED SPARE PARTS

FAS156N1A Publication No: 5995409363

# Functional Parts 3 05/04

* Non-Illustrated Parts

RECOMMENDED SPARE PARTS

POS. NO PART NO. DESCRIPTION

1 5304414097 Rail, cabinet bottom, rear

2 5304408741 Grille, rear panel, aluminum

3 309623906 Cabinet, wrapper/sleeve

4 5303211056 Bracket, sash lock

5 5304414116 Rail, cabinet top, front

6 5304414933 Retainer, shutter mount, cabinet side

7 309645602 Shutter, accordion panel, RH/LH, window closure

8 5304414929 Frame, shutter, gray, RH, extension

9 5304416310 Rail, cabinet bottom, front

10 # 5304430864 Overload Protector

11 # 309603117 Compressor

12 # 5303306719 Condenser

13 309632910 Base, compressor mtg., with studs

14 309623201 Shroud, cond fan motor

15 309623501 Tray, evap drip

16 # 309634101 Evaporator

17 # 5303311048 Fan Blade, with clamp

18 # 309630615 Motor, fan, 1 Speed

19 309630302 Cover, blower wheel, top

20 309623602 Bulkhead, control system

21 309623401 Bulkhead, air system

22 309900101 Frame, cabinet front

23 309900301 Louver, horizontal

24 309630102 Housing, blower scroll

25 # 309633001 Blower Wheel, plastic, with clamp

26 309630203 Plate, scroll cover

27 # 309902201 Remote Control, transmitter, with lcd

28 309900201 Panel, front grille

29 309900601 Handle, vent opener

30 309639001 Filter, micro-biologic, framed

31 309902801 Detent, vent handle

32 309321402 Door, vent, with actuator

33 309901701 Overlay, control display

34 309900501 Enclosure, input pcb, control panel

35 # 309901601 PC Board, input/display

36 5304413781 Hardware, PCB support

37 309630404 Control Box

38 # 309900701 Ionizer

39 309111201 Grommet, wire protector

40 309904601 Louver, vertical

41 # 309901401 PC Board, power, 115 V, variable speed

42 309900401 Wheel, louver adjuster

43 # 5304430863 Capacitor, 370 V, 60+10 mfd

44 5304414108 Holder, thermistor clip, 5/16"

45 5303303077 Strap, capacitor mtg.

46 # 309343111 Power Cord, electric, 14 AWG, 115 V, type A

47 # 309201602 Sensor, thermistor, ambient temp

48 # 309201603 Sensor, thermistor, evap defrost

49 # 309330502 Manifold Assembly, with rings

50 5303302254 Nut, expansion type

55 # 309651801 Tube, suction, copper

Publication No: 5995409363 FAS156N1A

05/04 4

RECOMMENDED SPARE PARTS

FAS156N1A Publication No: 5995409363

# Functional Parts 5 05/04

* Non-Illustrated Parts

RECOMMENDED SPARE PARTS

POS. NO PART NO. DESCRIPTION

56 # 309651701 Tube, discharge, copper

57 # 309333001 Tube, capillary, copper, top

58 # 309333201 Tube, capillary, copper, middle

59 # 309333101 Tube, capillary, copper, bottom

60 # 309111001 Fitting, reducer, .101/.104 ID, copper tube

61 # 5303290357 Strainer

63 # 5304417722 Tube, process, copper, cond. outlet

64 5304414105 Bracket, cab support, RH

65 3001815 Support, angle bracket, window sill mt.

66 5304414106 Bracket, cab support, LH

67 5304414928 Frame, shutter, gray, LH, extension

Publication No: 5995409363 FAS156N1A

05/04 6

WIRING DIAGRAM

BK=Black(Noir)

BL=Blue(Bleu)

BR=Brown(Brun)

G=Green(Vert)

R=Red(Rouge)

W=White(Blanc)

Y=Yellow(Jaune)

Alternate Internal Overload

Compressor

(Autre Surcharge

Interne Du Compresseur)

Ion.

J3210

309902101/01

Fan(Ventilateur)

Room

Sensor

(Sonde D'

Ambiance)

Evap

Sensor (Sonde

Anti Givre)

Compressor

(Compresseur)

Fan motor

(Moteur Du

Ventilateur)

Compressor

capacitor

(Condensateur Du

Compresseur)

Fan motor capacitor

(Condensateur Du

Ventilateur)

Connector (Connecteur)

Compressor Overload

(Surcharge Du

Compresseur)

(Vert)

GND

Compressor Relay (Relais Du

Compresseur)

Ionizer(Ion)

(Optional)

(Facultatif)

(Vert)

GND

Ribbed

(Blue)

Raye(Bleu)

Plain

(Brown)

Ordinaire(Brun)

WOR Y

(OU)
