DURAVIT C.1 Series Manual

Instructions for mounting and use Free-standing bath mixer

Notice de montage et d’utilisation Mitigeur de baignoire monocommande au sol

Instrucciones de montaje y uso Grifería monomando de bañera de pie

C.1

# C15250 000U 10

2 MAL_57164/19.03.2

MAL_57164/19.03.2 3

es fr en

Important information 4

Installation 5

Operation 12

Care & maintenance 14

Remarques importantes 17

Montage 18

Commande 25

Entretien & maintenance 27

Información importante 30

Montaje 31

Manejo 38

Conservatión y mantenimiento 40

Safety instructions

Cut and crush injuries

> Wear gloves when installing the product.

Product and/or property damage

> Observe the local installation regulations and

any country-specific standards at all times.

> Equalise pressure differences between cold

and hot water connections.

> Observe the manufacturer’s instructions for

installation with continuous flow heaters.

These instructions are part of the Duravit

product and must be read carefully and kept

available at all times.

Target readership and qualifications

The product may only be installed by a qualified

plumber.

Explanation of the key words

CAUTION Indicates a hazardous

situation which, if not

avoided, could result in minor

or moderate injury.

NOTICE Addresses practices not

related to physical injury.

Technical data

Operating pressure max. 72.5 PSI

Recommended 43.5 PSI

Test pressure 72.5 PSI

1 MPa = 10 bar = 145 PSI

Hot water temperature max. 140 °F

This unit meets or exceeds the

following:

• ASME A112.18.1

• CSA B125.1

4 MAL_57164/19.03.2

# GK5900 003U 00

# C15250 000U 10

CAUTION Cut and crush injuries

> Wear gloves during installation.

> Cut the plaster shield so that it extends

3/8” above the surface of the finished floor

NOTICE Water damage

> Turn the water off the main before

beginning.

NOTICE Water damage

> Seal the floor around the plaster shield

with silicone without acetic acid.

MAL_57164/19.03.2 5

2x 2x

> Pivot the tub filler so that it faces the

correct direction.

> Make sure that the tub filler is level.

> Position the tub filler on the rough.

> Remove the flush plate housing.> Remove the flush plate housing screws.

> Do not discard the screws.

6 MAL_57164/19.03.2

> Install the screws. > Tighten the screws.

NOTICE Water damage

> Seal the floor around the plaster shield with

silicone without acetic acid.

> Lower the escutcheon.

MAL_57164/19.03.2 7

2,5 mm

> Remove the handle.> Using 2.5 mm Allen wrench remove the set

screw.

> Check the position of the handle.Adjustments of the water flow.

8 MAL_57164/19.03.2

+ -

2,5 mm

> Using flat head screwdriver, adjust the flow.> Remove the escutcheon.

> Check the flow. > Attach the top faucet cover.

> Attach the handle.

MAL_57164/19.03.2 9

2,5 mm

> Remove the top faucet cover.> Remove the handle.

> Using Allen wrench, remove the screw.Temperature adjustments.

10 MAL_57164/19.03.2
