Dimplex PRISM BLF3451-AU User manual

INSTRUCTION MANUAL

8/55062/0 Issue 2

OCN 11905

For domestic household use only.

Prism 1.2kW Wall Mounted

Electric Fire

Models: BLF3451-AU, BLF5051-AU & BLF7451-AU

IMPORTANT

THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND

RETAINED FOR FUTURE REFERENCE.

CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS MAY CAUSE INJURY AND/

OR DAMAGE AND MAY INVALIDATE YOUR WARRANTY

Please read the operating instructions carefully before using your product for

the first time and keep them in a safe place.

• When using electrical appliances, basic precautions should always be followed

to reduce the risk of fire, electrical shock and injury to persons, including the

following:

• If the appliance is damaged, check with the supplier before installation and

operation.

- Do not use outdoors.

- Do not use in the immediate surroundings of a bath, shower or a

swimming pool.

- Do not use this heater if it has been dropped.

- Do not use if there are visible signs of damage to the heater.

- Use this heater on a horizontal and stable surface, or fix it to the

wall, as applicable.

• Do not locate the appliance immediately below a fixed socket outlet or

connection box.

• This appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction concerning

use of the appliance by a person responsible for their safety.

• Children should be supervised to ensure that they do not play with the

appliance.

• Do not use this appliance in series with a thermal control, a program controller,

a timer or any other device that switches on the heat automatically, since a

fire risk exists when the appliance is accidentally covered or dis-placed.

• In the event of a fault, unplug the appliance.

• Unplug the appliance when not required for long periods.

• This product is only intended for INDOOR RESIDENTIAL applications only.

• DO NOT cover cord with carpeting, throw rugs, runners, or similar coverings.

• DO NOT route cord under furniture or appliances. Take care to position the

cord away from traffic areas and where it will not be a tripping hazard.

• This appliance must not be used in a bathroom.

• Although this appliance complies with safety standards, we do not recommend

its use on deep pile carpets or on long hair type of rugs

• The appliance must be positioned so that the plug is accessible.

• If the supply cord is damaged it must be replaced by the manufacturer or

service agent or a similarly qualified person in order to avoid a hazard.

• Keep the supply cord away from the front of the appliance.

• Do not use this heater in small rooms when they are occupied by persons

not capable of leaving the room on their own, unless constant supervision is

provided.

• To reduce the risk of fire, keep textiles, curtains and or flammable material a

minimum distance of 1m from the air outlet.

• In order to avoid overheating, DO NOT COVER the appliance. Do not place

material or garments on the appliance, or obstruct the air circulation around

the appliance, for instance by curtains or furniture, as this could cause

overheating and a fire risk.

• This Heater carries the warning symbol indicating that it must not

be covered.

• In order to avoid a hazard due to inadvertent resetting of the thermal cut-out,

this appliance must not be supplied through an external switching device,

such as a timer, or connected to a circuit that is regularly switched on and off

by the utility.

• CAUTION Some parts of this product can become very hot and cause burns.

Particular attention has to be given where children and vulnerable people are

present.

• Children shall not turn on/off the appliance.

• Ensure that furniture, curtains or other combustible material are positioned

no closer than 1 metre from the appliance.

• Unplug the appliance when not required for long periods.

• Keep the supply cord away from the front of the appliance.

• This product is only suitable for well insulated rooms or occasional use.

WARNING: KEEP BATTERIES OUT OF REACH OF CHILDREN

• Swallowing may lead to serious injury in as little as 2 hours or death, due to

chemical burns and potential perforation of the oesophagus.

• If you suspect your child has swallowed or inserted a button battery

immediately call the 24-hour Poisons Information Centre on 13 11 26 (in

Australia) or 0800 764 766 (in New Zealand) for fast, expert advice.

• Examine devices and make sure the battery compartment is correctly secured,

e.g. that the screw or other mechanical fastener is tightened. Do not use if the

compartment is not secure.

• Dispose of used button batteries immediately and safely. Flat batteries can

still be dangerous.

CAUTION: No obvious symptoms

Unfortunately, it is not obvious when a button or coin battery is stuck in a

child's oesophagus (food pipe).

There are no specific symptoms associated with this. The child might:

• cough, gag or drool a lot

• appear to have a stomach upset or virus

• be sick

• point to their throat or stomach

• have a pain in their abdomen, chest or throat

• be tired or lethargic

• be quieter or more clingy than usual or otherwise 'not themselves'

• lose their appetite or have a reduced appetite

• not want to eat solid food/be unable to eat solid food

These types of symptoms vary or fluctuate. with the pain increasing and then

subsiding.

A specific symptom to button and coin battery ingestion is vomiting fresh

(bright red) blood. If the child does this seek immediate help. The lack of clear

symptoms is why it is important to be vigilant with 'flat' or spare button or

coin batteries in the home and the products that contain them.

Exposed to the

weather outdoors

Near water If the power cable

wires are frayed or cut

Where small children

may be left unattended

No extension leads or

power boards

Where there is risk

of fire or close to

a naked flame

Where the power

cable may be

damaged

On a slope or

uneven surface

Where it may be

damaged by

chemicals

If there is a risk

of water falling on

the unit

Where there is a risk

of interference by

foreign objects

This product is not

made for DIY repair

Model no. BLF3451-AU BLF5051-AU BLF7451-AU

Colour/Finish Self-trimming black

Wattage

1200

Heat Settings

Thermostat Control Yes

LED effect Yes

Remote Control Yes

Warranty 2 Years

Dimensions (w x d x h) 867w x 179d x

494h

1280w x 179d x

494h

1883w x 187d x

494h

Specifications

For greater precision, please always refer to the rating label placed on the product.

General Information

Unpack the heater carefully and retain the packaging for possible future use, in the

event of moving or returning the fire to your supplier.

The fire incorporates a flame effect, which can be used with or without heating, so that

the comforting effect may be enjoyed at any time of the year. Using the flame effect

on its own only requires little electricity.

Before connecting the heater check that the supply voltage is the same as that stated

on the heater.

Please note: Used in an environment where background noise is very low, it may be

possible to hear a sound which is related to the operation of the flame effect. This is

normal and should not be a cause for concern.

Electrical Connection

WARNING: THIS APPLIANCE MUST BE EARTHED

This heater must be used on an AC ~ supply only and the voltage marked on the heater

must correspond to the supply voltage.

Before switching on, please read the safety warnings and operating instructions.

Fixed Wiring

In some jurisdictions this appliance is supplied without a plug this is to comply with

the local regulations. In such instances this appliance must be installed by a suitably

qualified installer and the means for disconnection must be incorporated in the fixed

wiring in accordance with the local wiring rules.

Thermal Safety Cut-out

The built-in overheat cut-out, switches off the appliance automatically in the event of

a fault! Should this occur switch off the appliance or disconnect the mains plug from

the socket.

Remove any obstructions which may have caused the overheating. After a short cooling

down phase, the appliance is ready for use again! If the fault should occur again, contact

your local dealer!

WARNING: In order to avoid a hazard due to inadvertent resetting of the thermal cut-

out, this appliance must not be supplied through an external switching device, such

as a timer, or connected to a circuit that is regularly switched on and off by the utility.

Light Emitting Diode

This fire is fitted with LED (Light Emitting Diode) lamps. These LED lamps are

maintenance-free and should not require replacing during the life of the product.

Setup

Product Dimensions

34" Prism BLF3451-AU

50" Prism BLF5051-AU

74" Prism BLF7451-AU

A H B F G C D E

WARNING: The Electric Firebox must be installed properly before it is used.

CAUTION: Except for installation and cleaning described in this manual, an

authorized service representative should perform any other servicing. The manual

controls are located at the top left hand side as pictured below. The selected setting

displays on the right side of the front panel.

Control Panel & Remote

Remote Control

The maximum range of use is ~ 5 metres.

NOTE: It takes time for the receiver to respond to the transmitter.

NOTE: The receiver for the remote control is located in the display, aim the remote

control in this direction when inputting commands.

Do not press the buttons more than once within two seconds for correct operation.

Battery Information - See above

1. To activate the remote control remove the clear battery isolation strip at the base of the

remote control, which is used to ensure your remote control reaches you fully charged.

2. To replace the remote control battery, turn over the remote control and follow the

diagram embossed on the remote control. Remove the screw and push down on the

battery cover located on the back of the remote control. Slide the battery cover open.

Insert new battery with the (+) side up, and then close and replace the screw.

3. Only use CR2025 or CR2032 size of batteries.

Controls

Remote

Installation

3 4

5 6
