Dimplex Opti-V User manual

Owner’s Manual

6909410210

6909410110

6909680110

Model

VF5452L

VF2927L

VFA2927

7213460100R09

IMPORTANT SAFETY INFORMATION: Always read this manual rst

before attempting to install or use this

Opti-V

. For your safety, always

comply with all warnings and safety instructions contained in this manual

to prevent personal injury or property damage.

To view the full line of Dimplex products, please visit

www.dimplex.com

2 www.dimplex.com

Table of Contents

Always use a qualied

technician or service agency

to repair this Opti-V.

!NOTE: Procedures and

techniques that are

considered important enough

to emphasize.

CAUTION: Procedures and

techniques which, if not

carefully followed, will result in

damage to the equipment.

WARNING: Procedures

and techniques which, if not

carefully followed, will expose

the user to the risk of re,

serious injury, or death.

Welcome & Congratulations .................3

IMPORTANT SAFETY INSTRUCTIONS ......4

Opti-V Installation .........................6

Locating the Opti-V ........................6

Hardwire Installation .......................6

Operation ...............................10

Maintenance ............................12

Warranty ...............................13

Technical Support ........................15

MADEIN IRELAND

FAITEN IRLANDE

HECHOEN IRLANDA

MODEL

MODELE

MODELO

CAT.#

No.de Cat.

PROTECTEDBY THE FOLLOWING PATENTS / PROTEGE PAR LES BREVETS SUIVANTS/PROTEGIDO POR LAS SIGUIENTES

PATENTES: US PATENTS / BREVETS DE ETATS UNIS / PATENTES DE ESTADOS UNIDOS : 8,361,367

OTHERPATENTS PENDING / AUTRES BREVETS EN INSTANCE / OTRAS PATENTES PENDIENTES

DIMPLEXNORTH AMERICA

1367INDUSTRIAL ROAD

CAMBRIDGE,ON, N1R 7G8

CANADA

6909410100

VF2927L

100-240V ~, 50/60HZ, 35W

Intertek

North America Limited

xxxxxxx

SERIAL No./No DE SERIE/No DE SERIE

DDDYYSLF - XXX

Welcome & Congratulations

Model Number

Serial Number

Thank you and congratulations for purchasing an Opti-V from Glen

Dimplex Americas. Please use our convenient online registration page

to record your model and serial numbers for future reference at

www.dimplex.com/register

NO NEED TO RETURN TO THE STORE

Questions with operation or assembly? Require Parts Information?

Product Under Manufacturer’s Warranty?

For Troubleshooting and Technical Support

OR Toll-Free 1-888-346-7539

In order to better serve you, please have your model and serial number

ready or register your product online before calling (See above)

Please carefully read and save these instructions.

CAUTION: Read all instructions and warnings carefully before

starting installation. Failure to follow these instructions may result in

a possible electric shock, re hazard and will void the warranty.

4 www.dimplex.com

IMPORTANTSAFETYINSTRUCTIONS

When using electrical appliances, basic

precautions should always be followed

to reduce the risk of fire, electric shock,

and injury to persons, including the

following:

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near

water.

6. The appliance shall not be exposed

to dripping or splashing and that

no objects lled with liquid, such

as vases, shall be placed on the

apparatus.

WARNING: To reduce the risk of re

or electric shock, do not expose this

apparatus to rain or moisture.

7. Clean only with dry cloth.

8. Do not block any ventilation

openings. Install in accordance with

the manufacturer’s instructions.

9. Do not install near any heat

sources such as radiators, heat

registers, stoves, or other apparatus

(including ampliers) that produce

heat.

10. No naked ame sources, such as

candles should be placed on this

apparatus.

11. Do not defeat the safety purpose

of the polarized or grounding-type

plug. A polarized plug has two

blades with one wider than the

other. A grounding type plug has

two blades and a third grounding

prong. The wide blade or the third

prong are provided for your safety.

If the provided plug does not t into

your outlet, consult an electrician for

replacement of the obsolete outlet.

WARNING: This appliance is of

Class I construction and must be

connected to a power outlet with a

protective grounded connection.

12. Protect the power cord from being

walked on or pinched particularly

at plugs, convenience receptacles,

and the point where they exit from

the apparatus.

13. Only use attachments/accessories

specied by the manufacturer.

14. Use only with the cart, stand, tripod,

bracket, or table specied by the

manufacturer, or sold with the

apparatus. When a cart is used,

use caution when moving the cart/

apparatus combination to avoid

injury from tip-over.

15. Disconnect power at the service

panel during lightning storms or

when unused for long periods of

time.

16. Refer all servicing to qualied

service personnel. Servicing is

required when the apparatus has

been damaged in any way, such

as power-supply cord or plug is

damaged, liquid has been spilled

SAVE THESE INSTRUCTIONS

IMPORTANTSAFETYINSTRUCTIONS

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

NO USER-SERVICEABLE PARTS INSIDE

or objects have fallen into the

apparatus, the apparatus has been

exposed to rain or moisture, does

not operate normally, or has been

dropped.

17. If the appliance is damaged, check

immediately with the supplier before

installation and operation.

18. Do not operate any unit with a

damaged cord, or if the Opti-V has

been dropped or damaged in any

manner, contact Technical Service

at 1-888-346-7539.

19. Do not modify the Opti-V. Use it

only as described in this manual.

Any other use not recommended by

the manufacturer may cause re,

electric shock or injury to persons.

20. When transporting or storing the

unit and cord, keep in a dry place,

free from excessive vibration and

store so as to avoid damage.

21. Do not install the remote control

battery backwards; charge; put

in excessive heat such as re,

sunshine or the like; or mix with

used or other battery types - may

explode or leak causing injury.

22. When replacing the battery ensure

that it is replaced with alkaline

1.5 Volt (AAA) batteries. Battery

must be recycled or disposed of

properly. Check with your Local

Authority or Retailer for recycling

advice in your area.

NOTE: To disconnect from mains

- set the mains switch to 'O'. The

mains (power) switch is located

at the top left hand side of the

appliance above the manual

controls - see 'O/I' Figure 2.

Mains switch shall remain readily

operable.

WARNING: To prevent injury,

this apparatus must be securely

attached to the oor/wall in

accordance with the installation

instructions.

WARNING: Remote control

contains small batteries. Keep away

from children. If swallowed, seek

medical attention immediately.

NOTE: Changes or modications

not expressly approved by the party

responsible for compliance could

void user's authority to operate the

equipment.

6 www.dimplex.com

Opti-V Installation

WARNING: ANY

INSTALLATION AND SERVICE

WORK CAN ONLY BE

PERFORMED BY QUALIFIED AND

AUTHORIZED PERSONNEL. ALL

INSTALLATIONS MUST COMPLY

WITH ALL LOCAL CODES AND

BYLAWS, AND INSPECTED AND

APPROVED FOR OPERATION BY

LOCAL GOVERNING AUTHORITY

PRIOR TO USE.

WARNING: Construction and

electrical outlet wiring must comply

with local building codes and other

applicable regulations to reduce the

risk of re, electric shock and injury

to persons.

Locating the Opti-V

The Opti-V uses an illusory reection

technique and is designed to work

best when ambient light levels

are low. If the Opti-V is installed

in brightly lit areas, the strong

reections may diminish the ame.

Depending on your specic

application, installation of the unit

at a height appropriate for the

viewers enjoyment is important. It

is recommended that the following

guidelines be used for locating the

unit.

NOTE: Measurements are to

the bottom of the viewing area

of the ame.

For standing applications:

Maximum - 51" (129.5 cm)

Minimum - 26" (66.0 cm)

For sitting applications:

Maximum - 36" (91.4 cm)

Minimum - 26" (66.0 cm)

Hardwire Installation

The Opti-V is supplied in an

assembled state and is designed

to be permanently installed. The

unit comes ready for hardwire

installation.

WARNING: Do not attempt

to wire your own new outlets or

circuits. To reduce the risk of re,

electric shock or injury to persons,

always use a licensed electrician.

WARNING: Ensure that the

On/O󰀨 switch is set to the O󰀨

position (refer to Operation section)

and that the circuit on which the

Opti-V is to be installed has the

power cut o󰀨 at the service panel

until installation is complete.

NOTE: Please read all

instructions before installing.

1. For rough in framing, the

opening should follow the

recommended dimensions

located in Figure 1.

NOTE: Dimensions provided

are minimum clearances and will

vary depending on type of support

framing and nishing options.

Opti-V Installation

NOTE: Framing should be

constructed to support:

VF2927L / VFA2927 - 63 lbs (29 kg)

VF5452L - 116 lbs (52 kg)

A B C1 D1 E1 F1 G

VF5452L

54.5"

(1380 mm)

17.7"

(450 mm)

14"

(355 mm)

2.75"

(70 mm)

9.8"

(249 mm)

51.8"

(1316 mm)

0.9"

(23 mm))

VF2927L

30.0"

(762 mm)

17.7"

(450 mm)

14"

(355 mm)

2.75"

(70 mm)

9.8"

(249 mm)

27.4"

(696 mm)

0.9"

(23 mm)

VFA2927

30.0"

(762 mm)

17.7"

(450 mm)

14"

(355 mm)

2.75"

(70 mm)

9.8"

(249 mm)

27.4"

(696 mm)

0.9"

(23 mm)

C2 D2 E2 F2 H I

VF5452L

13"

(330 mm)

2.96"

(75 mm)

9.45"

(240 mm)

51.5"

(1308 mm)

18.6"

(474 mm)

55.3"

(1404 mm)

VF2927L

13"

(330 mm)

2.96"

(75 mm)

9.45"

(240 mm)

27.1"

(688 mm)

18.6"

(474 mm)

30.5"

(775 mm)

VFA2927

13"

(330 mm)

2.96"

(75 mm)

9.45"

(240 mm)

27.1"

(688 mm)

18.6"

(474 mm)

30.5"

(775 mm)

Figure 1

*Outside dimensions

Removable

Trim

Without

Trim

8 www.dimplex.com

Opti-V Installation

2. Allow up to 4 ft. (121.9 cm) of

service cable for connecting a

power supply wire to the cable

clamp on the Opti-V when

installing before nishing wall.

NOTE: A 15 amp, 120 volt

alternating current (VAC) circuit

is recommended, but the unit is

constructed that it can operate

using voltages from 120-

240VAC.

NOTE: Use minimum 14 AWG

supply cable with two insulated

copper conductors (white and

black) and one bare ground

wire. Do not use cable with

aluminum conductors.

NOTE: It is recommended

that all drywall installation and

nishing be completed after

unit is fully installed.

3. In the upper left hand corner

of the unit, loosen the two

securing screws and remove

the electrical cover panel.

(Figure 2)

4. Install a ⅜ in. (10 mm) or ½in.

(13 mm) cable connector, not

included, suitable for mounting

in a ⅞ in. (22 mm) hole, to

the cable plate and feed the

supply cable through the

connector and secure.

5. Place the unit in the framed

opening, level with shims if

necessary and attach unit to

frame using mounting anges

provided (Figure 3).

Figure 2

Electrical

Cover Panel

Cable Clamp

Hole

Figure 3

Mounting

Flanges

Cable Plate

Grounding

Screw

Opti-V Installation

CAUTION: When inserting the

unit take care not to damage or

pinch any of the power cables

that are concealed in the wall.

6. Remove the outer jacket and

strip the individual conductors

½ in. (1.3 cm) from the end.

7. Connect the black wire from

the unit to the Live (120V) or

Line 1 (240V) wire from the

power supply using a wire

connector (included).

8. Connect the white wire from

the unit to the Neutral (120V)

or Line 2 (240V) from the

power supply using a wire

connector (included).

NOTE: Cap any additional

wires from the power supply

not used in the installation.

9. Ensure that the green

grounding wire is securely

attached to the back plate.

CAUTION: Ensure the wire

connectors are securely

tightened, so no bare wires

(live or neutral) are exposed.

10. Ensure the grounding wire of

the supply cable is securely

attached to the grounding

screw.

NOTE: The wire connections

on the Opti-V feed into a

3-prong plug just below the

electrical cavity opening, before

closing the electrical cover

ensure that the plug is fully

installed.

11. Reinstall the electrical cover

panel.

12. Reinstall the protector sheet

to prevent dust from entering

the unit while nishing the

surround.

13. Finish surrounding wall. There

are 3 di󰀨erent options for

nishing the wall:

• Permanent - install drywall

right up to the ange that

surrounds the opening.

• Semi Permanent - nish

around edge using ashing

material (not included)

• Flexible - create opening big

enough to access mounting

anges and a false front that

can be removed.

10 www.dimplex.com

Operation

WARNING: This Opti-V must

be properly installed before it

is used.

The power switch (Figure 2A) must

rst be switched "I" to operate the

appliance.

An ‘Opti-V’ logo will appear on

the screen for about 3 seconds

before the ame picture starts .

!NOTE:The user may notice

a blank screen for

approximately 5 seconds,

every 30 minutes. This is

normal and should not be a

cause for concern.

Manual Operation

The manual controls for the

screen are located at the inner

top left hand side of the appliance

above the glass.(Figure 2).

The mains (power) switch (Figure

2A) may be used to switch the

Figure 2

IR Remote Sensor

appliance O󰀨 ('O') when it is not

required, for example, overnight

or for long periods, to avoid

unnecessary energy use.

!NOTE: Ensure that the mains

(power) switch shall remain

readily operable.

The standby button " "(Figure

2B) is located just below the

power switch. A red light will

indicate when the unit is in

standby mode. (Figure 2)

The volume of the sound e󰀨ects

may be adjusted up or down

by pressing the volume control

buttons (Figure 2C & 2D).

BDC

This manual suits for next models

Table of contents

Languages:

Other Dimplex Indoor Fireplace manuals

Dimplex

Dimplex BF362SD User manual

Dimplex

Dimplex CLEMENT CMT20BL User manual

Dimplex

Dimplex EMP-075-W User manual

Dimplex

Dimplex Bach User manual

Dimplex

Dimplex Mini Mozar DFP15-1131 User manual

Dimplex

Dimplex BFSL33 User manual

Dimplex

Dimplex CHT20LE User manual

Dimplex

Dimplex OS2527GB User manual

Dimplex

Dimplex DWF1203B User manual

Dimplex

Dimplex DFB8842 User manual

Dimplex

Dimplex ELECTRALOG CFP3913 User manual

Dimplex

Dimplex BF33ST User manual

Dimplex

Dimplex CAS500R User manual

Dimplex

Dimplex RWF-DG User manual

Dimplex

Dimplex BLF50 User manual

Dimplex

Dimplex CAS20N-AU User manual

Dimplex

Dimplex Mini Mozart User manual

Dimplex

Dimplex Navara Nav15 Log User manual

Dimplex

Dimplex VCX1525 User manual

Dimplex

Dimplex LYM28E Lymington Installation instructions

Dimplex

Dimplex 25 FIREBOX User manual

Dimplex

Dimplex Optiflame BF3600 User manual

Dimplex

Dimplex Xpression SP220 User manual

Dimplex

Dimplex 6901860100 Quick start guide

Popular Indoor Fireplace manuals by other brands

Brigantia

Brigantia 35-DVRS31N-2 User's installation, operation and maintenance manual

Nordpeis

Nordpeis Bergen Installation and user manual

Superior

Superior BCT2536TMN Installation and operation instructions

Quadra-Fire

Quadra-Fire 5100I-GD-B owner's manual

Renaissance

Renaissance RUMFORD 1000 user manual

Lacunza

Lacunza IV-800 Instruction book

Baxi

Baxi 940 Installer and owner guide

Dru

Dru Maestro 60/2 Tall RCH installation manual

Diamond Fireglass

Diamond Fireglass SS-O22 General assembly, installation, and operation instructions

HearthStone

HearthStone Windsor Bay 8830 Owner's manual and installation guide

Napoleon

Napoleon ASCENT B42 quick start guide

Enviro

Enviro E33GI owner's manual

Smeg

Smeg L30 FABE Installation & user's instructions

KEDDY

KEDDY K700 Installation instructions care and firing instructions

Godin

Godin 3451 manual

Jøtul

Jøtul Jotul GI 535 DV IPI New Harbor Installation and operation instructions

Austro Flamm

Austro Flamm Heidi Back 2.0 945048 operating manual

Desa

Desa CCFPDFT Owner's operating & installation manual
