Dimplex DF3033ST User manual

Owner’s Manual

Model

DF3033ST

To view the full line of Dimplex products, please visit

www.dimplex.com

7209120100R05

IMPORTANT SAFETY INFORMATION: Always read this manual rst

before attempting to install or use this replace. For your safety, always

comply with all warnings and safety instructions contained in this manual

to prevent personal injury or property damage.

2 www.dimplex.com

Table of Contents

Always use a qualied technician

or service agency to repair

this replace.

!NOTE: Procedures and

techniques that are

considered important

enough to emphasize.

CAUTION: Procedures and

techniques which, if not

carefully followed, will result

in damage to the equipment.

WARNING: Procedures

and techniques which, if not

carefully followed, will expose

the user to the risk of re,

serious injury, or death.

Welcome & Congratulations . . . . . . . . . . . . . . . . .3

IMPORTANT INSTRUCTIONS ................4

Quick Reference Guide . . . . . . . . . . . . . . . . . . . . .7

Site Selection and Preparation ...............7

Fireplace Installation .......................8

Operation...............................11

Maintenance.............................16

Warranty ...............................18

Replacement Parts List . . . . . . . . . . . . . . . . . . . .22

Welcome & Congratulations

Thank you and congratulations for choosing to purchase an electric

replace from Dimplex, the world leader in electric replaces.

Please carefully read and save these instructions.

CAUTION: Read all instructions and warnings carefully before

starting installation. Failure to follow these instructions may result in a

possible electric shock, re hazard and will void the warranty.

Please record your model and serial numbers below for future

reference: model and serial numbers can be found on the Model and

Serial Number Label of your replace.

Model Number

Serial Number

NO NEED TO RETURN TO THE STORE

Questions with operation or assembly? Require Parts Information?

Product Under Manufacturer’s Warranty?

For Troubleshooting and Technical Support

OR Toll-Free 1-888-DIMPLEX (1-888-346-7539)

Monday to Friday 8:00 a.m. to 4:30 p.m. EST

Please have your model number and product serial

number ready. (See above)

4 www.dimplex.com

When using electrical appliances,

basic precautions should always

be followed to reduce the risk of

fire, electric shock, and injury to

persons, including the following:

①Read all instructions before

using the electric replace.

②The heater is hot when in use.

To avoid burns, do not let bare

skin touch hot surfaces. The trim

around the heater outlet becomes

hot during heater operation.

Keep combustible materials, such

as furniture, pillows, bedding,

papers, clothes, and curtains at

least three (3) feet

(0.9 m) from the front of the unit.

③Extreme caution is necessary

when any heater is used by or

near children or invalids and

whenever the unit is left operating

and unattended.

④Always unplug the electric

replace when not in use.

⑤Do not operate any unit with

a damaged cord or plug, or if

the heater has malfunctioned,

or if the electric replace has

been dropped or damaged in

any manner. Return heater

to authorized service facility

IMPORTANT INSTRUCTIONS

for examination, electrical or

mechanical adjustment, or repair.

⑥Do not use outdoors.

⑦ The electric replace is not

intended for use in bathrooms,

laundry areas and similar indoor

locations. Never locate heater

where it may fall into a bathtub or

other water container.

⑧Do not run the cord under

carpeting. Do not cover cord with

throw rugs, runners, or the like.

Arrange cord away from trafc

area and where it will not be

tripped over.

⑨To disconnect the unit, turn

the controls off, then remove the

plug from the outlet.

⑩Do not insert or allow foreign

objects to enter any ventilation

or exhaust opening as this may

cause an electric shock or re, or

damage to the heater.

⑪ To prevent a possible re, do

not block air intake or exhaust

in any manner. Do not use on

soft surfaces, like a bed, where

openings may become blocked.

⑫All electrical heaters have

SAVE THESE INSTRUCTIONS

IMPORTANT INSTRUCTIONS

hot and arcing or sparking parts

inside. Do not use in areas where

gasoline, paint, or ammable

liquids are used or stored or

where the unit will be exposed to

ammable vapors.

⑬Do not modify the electric

replace. Use it only as described

in this manual. Any other use not

recommended by the

manufacturer may cause re,

electric shock or injury to persons.

⑭Avoid the use of an extension

cord or power bar. Extension

cords and power bars may

overheat and cause a risk of re.

If you must use an extension cord

or power bar, it must be No. 14

AWG minimum size and rated for

no less than 1875 Watts.

⑮ Do not burn wood or other

materials in the electric replace.

⑯ Do not strike the replace

glass.

⑰ Always use a certied

electrician should new circuits or

outlets be required.

⑱Always use properly

grounded, fused and polarized

outlets.

⑲Disconnect all power supply

before performing any cleaning,

maintenance or relocation of the

unit.

⑳When transporting or storing

the unit and cord, keep in a

dry place, free from excessive

vibration and store so as to avoid

damage.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

NO USER-SERVICABLE PARTS INSIDE

6 www.dimplex.com

IMPORTANT INSTRUCTIONS

CAUTION: This equipment has been

tested and found to comply with the limits

for a Class B digital device, pursuant to

Part 15 of the FCC Rules. These limits

are designed to provide reasonable

protection against harmful interference in

a residential installation. This equipment

generates uses and can radiate radio

frequency energy and, if not installed and

used in accordance with the instructions,

may cause harmful interference to radio

communications. However, there is no

guarantee that interference will not occur

in a particular installation. If this equipment

does cause harmful interference to radio

or television reception, which can be

determined by turning the equipment off

and on, the user is encouraged to try to

correct the interference by one of the

following measures:

Reorient or relocate the receiving•

antenna.

Increase the separation between the•

equipment and receiver.

Connect the equipment into an outlet•

on a circuit different from that to

which the receiver is connected.

Consult the dealer or an experienced•

radio/TV technician for help.

This device complies with Part 15 of the

FCC Rules. Operation is subject to the

following two conditions: (1) This device

may not cause harmful interference,

and (2) this device must accept any

interference received, including

interference that may cause undesired

operation.

FCC CAUTION: Any changes or

modications not expressly approved by

the party responsible for compliance could

void the user's authority to operate this

equipment.

This device complies with Industry

Canada licence-exempt RSS standard(s).

Operation is subject to the following

two conditions: (1) this device may not

cause interference, and (2) this device

must accept any interference, including

interference that may cause undesired

operation of the device.

Under Industry Canada regulations, this

radio transmitter may only operate using

an antenna of a type and maximum (or

lesser) gain approved for the transmitter

by Industry Canada. To reduce potential

radio interference to other users, the

antenna type and its gain should be so

chosen that the equivalent isotropically

radiated power (e.i.r.p.) is not more

than that necessary for successful

communication.

WARNING: Remote control

contains small batteries. Keep away

from children. If swallowed, seek

medical attention immediately.

WARNING: Do not install battery

backwards, charge, put in re or mix

with used or other battery types - may

explode or leak causing injury.

!NOTE: Changes or modications

not expressly approved by the party

responsible for compliance could

void user's authority to operate the

equipment.

Site Selection and Preparation

Quick Reference Guide

① Prior to the rst use of the

replace verify the following:

• Are the circuit breakers for the

unit on?

• Are the light bulbs in your

replace loose? (To check, follow

the instructions for replacing the

light bulbs under the Maintenance

section of this manual.)

② The heater on your replace

may emit a slight, harmless odor

when rst used. This odor is a

normal condition caused by the

initial heating of internal heater

parts and will not occur again.

③The information regarding the

model of your replace can be

found on the rating plate located

on the front of the unit.

!NOTE 1: A 15 Amp, 120

Volt circuit is required. A

dedicated circuit is preferred

but not essential in all cases. A

dedicated circuit will be required

if, after installation, the circuit

breaker trips or fuse blows on a

regular basis when the heater is

operating. Additional appliances

on the same circuit may exceed

the current rating of the circuit

breaker.

WARNING: Ensure the power

cord is not installed so that it is

pinched or against a sharp edge

and ensure that the power cord is

stored or secured to avoid tripping

or snagging to reduce the risk

of re, electric shock or injury to

persons.

Construction and electrical

outlet wiring must comply with

local building codes and other

applicable regulations to reduce

the risk of re, electric shock and

injury to persons.

Do not attempt to wire your own

new outlets or circuits. To reduce

the risk of re, electric shock or

injury to persons, always use a

licensed electrician.

This section provides instructions

for selecting a location and

preparing the site to install the

replace into your Dimplex mantel

surround.

Select a suitable location that1.

is not susceptible to moisture

and is away from drapes,

8 www.dimplex.com

Site Selection and Preparation

furniture and high trafc.

For ease of electrical hook2.

up you may wish to locate

the replace near an existing

outlet (refer to NOTE 1).

Store the replace in a safe 3.

dry and dust free location.

!NOTE: The dimensions of

the replace are 31 ½ inches

Fireplace Installation

(800 mm) wide x 22 ⅜ inches

(568 mm) high x 9 ⅛ inches

(232 mm) deep. The replace

does not require any additional

venting.

CAUTION: Clearance for

air circulation beneath the

replace insert is provided by

two (2) rubber feet.

Do not install the replace

insert directly on carpet or

similar surfaces which may

restrict air circulation.

CAUTION: If installing the

replace in a carpeted area, place

a one-piece, solid, at surface

under the replace insert. Ensure

that both of the insert’s feet rest

securely on this surface.

Mantel Installation

Install the replace assembly

into the mantel (refer to mantel

assembly instructions).

!IMPORTANT: If not using

a Dimplex mantel, the replace

must be installed in an enclosure

with the following minimum

internal/opening dimensions

(Figure 1).

New Wall Construction

Select a suitable location that1.

Figure 1

22 ¾”

(578 mm)

31 ¾”

(807 mm)

9 ½”

(241 mm)

Fireplace Installation

is not susceptible to moisture

and is away from drapes,

furniture and high trafc.

Place the replace in the 2.

desired location to see how it

will look in the room.

Mark the desired location3.

on the oor and store the

replace in a safe, dry and

dust free location.

Use studs to frame an4.

opening of 31 ¾ inches (807

mm) wide x 22 ¾ inches (578

mm) high x 9 ½ inches (241

mm) deep.

Option #1 - The power cord can

be lead from behind the trim and

along the wall to an outlet near

the replace.

Option #2 - A new outlet can be

installed inside the new frame

construction. Plug the unit into

a 15 Amp, 120 Volt outlet. If the

cord does not reach, you may

use an extension cord rated for a

minimum of 1875 Watts.

Option #3 - Hardwire

Wire a dedicated, properly1.

fused circuit with 120 Volt, 15

Amp rating. Allow up to eight

(8) feet (2.4 m) of service

cable for connecting power

supply to junction box on

replace when installing after

nishing wall.

CAUTION: Use two

conductor, non-metallic sheath

cable with ground wire (three

(3) wires total) for the incoming

power supply on replace inserts.

Use appropriate wire to meet

local and national electrical codes

for rated power consumption.

Remove the outer jacket and2.

strip the individual conductor

from the end.

Loosen the screw securing3.

the junction box cover and

remove the cover.

Take the cables out from the4.

junction box, loosen the two

wire twist nuts and remove

the power cord (Figure 2).

Route the power supply wire5.

through the knockout on

supplied alternative junction

Figure 2

10 www.dimplex.com

Fireplace Installation

box cover and secure with

a wire clamp (not supplied)

(Figure 3).

Connect the black wire (live)6.

from the unit to the black wire

from power supply (Figure 3).

Connect the white wire7.

(neutral) from the unit to the

white wire from power supply

(Figure 3).

Connect the green wire8.

(ground) from the unit to the

green wire from power supply

(Figure 3).

Place all connectors inside9.

the unit and secure the

junction box cover to unit.

Ensure that the cable clamp

grips only the jacket of

service cable.

Fireplace

Junction

Box

White wire (N)

Black wire (L)

Green wire (G) Green wire (G)

Black wire (L)

White wire (N)

120 V Power

Supply

(Breaker Panel)

Figure 3
