Dimplex BF33ST/DX User manual

INSTALLATION GUIDE FOR THE

ELECTRIC FIREPLACE

MODEL NUMBERS:

BF33ST/DX

BF39ST/DX

BF45ST/DX

7206350200REV06

CONTENTS

PAGE 1 Listings and Code Approvals

PAGE 1 Model Specifications

PAGE 1 Step-by-Step Installation

Section A

PAGE2 Framing

Section B

PAGE 2 Recommended Power Supply Wire

Specifications

PAGE 2 Recommended Wire and Fusing

Requirements

PAGE 3 Voltage Selector Switch Location

PAGE 3 Mounting Flanges

Section C

PAGE 4 Factory Setting Wiring 240 Volt

(Without Main Power Wall Switch)

PAGE 5 Factory Setting Wiring 120 volt

(Without Main Power Wall Switch)

Section D

PAGE 6 - 7 Main Power Wall Switch Wiring for 240 Volt

PAGE 8 - 9 Main Power Wall Switch Wiring for 120 Volt

Section E

PAGE 10 - 11 Heater Wall Switch Wiring for 120/240 Volt

PAGE 12 - 13 Wall Mounted Thermostat Wiring for

120/240 Volt

PAGE 14 - 15 Flame Override Switch Wiring for 120/240

Volt

Section F

PAGE 16 - 18 Wiring Diagrams

LISTINGS AND CODE APPROVALS

The BF series fireplaces have been tested in accordance with the UL 2021 and CSA C22.2 No. 46 standards for

fixed and location-dedicated electric room heaters.

MODEL SPECIFICATIONS

Model

Number Description Voltage Volts

Rated Power Watts

Remote

Control Wall

Thermostat Refractory

Brick Look

AMPS

No Heat

120 Volt

AMPS

120

Volt

AMPS

208

Volt

AMPS

240

Volt

BF33ST 33”

Standard 120/120/208/

240 245/1440/2100/

2700 Option Option N/A 2.0 12.0 10.10 11.25

BF33DX 33” Deluxe 120/120/208/

240 245/1440/2100/

2700 Option Option Included 2.0 12.0 10.10 11.25

BF39ST 39”

Standard 120/120/208/

240 245/1440/2100/

2700 Option Option N/A 2.0 12.0 10.10 11.25

BF39DX 39” Deluxe 120/120/208

/240 245/1440/2100/

2700 Option Option Included 2.0 12.0 10.10 11.25

BF45ST 45”

Standard 120/120/208/

240 245/1440/2100/

2700 Option Option N/A 2.0 12.0 10.10 11.25

BF45DX 45” Deluxe 120/120/208/

240 245/1440/2100/

2700 Option Option Included 2.0

12.0

10.10 11.25

NOTE: Power ratings shown include the light bulbs and motors (275 watts)

WARNING

The installation of the fireplace unit must comply with the applicable Local and/or National

Electrical Codes and utility requirements. This installation should be entrusted to duly qualified

personnel where required by law.

STEP-BY-STEP INSTALLATION(Note: Please read all instructions before installing)

1. Rough in framing opening following the recommended dimensions located in

(Section A: Framing).

2. Allow 8” of service cable for connecting power supply wire to junction box on fireplace

when installing before finishing wall. Allow up to 4 feet of service cable for connecting

power supply wire to junction box on fireplace when installing after finishing wall.

Remove the outer jacket and strip the individual conductors ½” from the end.

3. Loosen the screw securing the junction box cover and remove the cover.

4. Remove knockouts if necessary or use the provided cable clamp.

5. Place unit in position in the framed opening, level with shims if necessary and attach

unit to frame using mounting flanges provided (see figure 3 on page 3).

6. Unit is factory wired for 208/240 volt power supply (see figure 1 on page 3). If 120 volt

operation is required, slide the switch and reconfigure the wiring

(see figure 2 on page 3). Wires L1, L2, N & G are attached to the rear of the junction

box cable clamp for easy access.

Note

If wiring unit to operate with NO heat a dedicated circuit may not be required.

7. Wire a dedicated, properly fused circuit with a 15amp rating for the appropriate voltage

(120, 208/240). (see Section C for factory setting wiring)

8. Make wall switch and or wall mounted thermostat connections as outlined in Section D:

Wiring.

9. Place all connectors inside the unit and secure the junction box cover to unit. Ensure

that the cable clamp grips only the jacket of service cable, thermostat and if applicable

wall switch lines.

WARNING

Ensure method of installation does NOT obscure the air intake slots on bottom front of unit

in any manner. (see diagram in Section A)

SECTION A: FRAMING Dimensions

This fireplace is a zero clearance design. No combustibles can be placed on the top surface of the fireplace.

Combustibles may be installed to the edge of the unit. Four mounting flanges on the sides of the unit are provided

to facilitate installation. Insulation and vapor barrier should be placed a minimum of 2 inches from the unit.

SECTION B: RECOMMENDED POWER SUPPLY WIRE SPECIFICATIONS

For 120 volt installations use two conductor, non-metallic sheath cable with ground wire (3

wires total) for the incoming power supply on fireplace inserts. Use the appropriate wire to

meet local and national electrical codes for rated power consumption.

For 208 / 240 volt installations use three conductor, non-metallic sheath cable with ground

wire (4 wires total) for the incoming power supply on fireplace inserts. Use the appropriate wire

to meet local and national electrical codes for rated power consumption.

Two conductor, non-metallic sheath cable with ground wire (3 wires total) is recommended for

installation of a wall mounted thermostat and/or wall switch for use on fireplace inserts. Use

appropriate wire to meet local and national electrical codes for rated power consumption. All

wire gauges should match the recommended wire sizes shown below.

RECOMMENDED WIRE AND FUSING REQUIREMENTS

VOLTS WIRE GAUGE FUSE RATING

120 VOLT 12 GAUGE 15 AMP

208 VOLT 12 GAUGE 15 AMP

240 VOLT 12 GAUGE 15 AMP

MODEL A B C D E F G H I J K L

BF33ST/DX 15.0” 33.5” 29.5” 23.0” 14.3” 29.6” 32.8” 18.8” 28.5” 48.0” 34.0” 34.0”

BF39ST/DX 16.0” 39.5” 33.5” 26.6” 15.3” 36.0” 38.7” 22.8” 32.7” 54.0” 38.0” 38.0”

BF45ST/DX 16.0” 45.5” 33.5” 26.6” 15.3” 42.0” 44.7” 22.8” 32.7” 60.0” 42.0” 42.0”

Rough-in framing dimensions

Rough-in corner framing

Surface

ir Intake Slots

Firebox dimensions

VOLTAGE SELECTOR SWITCH LOCATION

IMPORTANT:

Ensure that the incoming power supply

voltage matches the setting of the voltage

selector switch.

NOTE:

The voltage selector switch is located

inside the exhaust panel on the top

right hand corner.

CAUTION:

When changing the voltage selector

switch from 240 volts to 120 volts

ensure that the power supply is turned

off.

NOTE:

Carefully insert a flat headed

screwdriver inside the exhaust panel

to change the switch from 240 volts

(230 position) to 120 volts (115 position).

When wiring the unit for 208 / 240 volts

the voltage selector switch should be

in the 230 volt position. (see figure 1)

When wiring the unit for 120 volts

the voltage selector switch should be

in the 115 volt position. (see figure 2)

MOUNTING FLANGES

There are two mounting flanges located

on each side of the fireplace insert.

Bend tabs and mount to framing using

suitable hardware.

FIGURE 1

FIGURE 2

Mounting

Flanges

FIGURE 3 3

SECTION C: FACTORY SETTING WIRING

(WITHOUT MAIN POWER WALL SWITCH)

IMPORTANT:

The unit is factory configured for 208/240 volt operation

NOTE:

Use 3 conductor wire with ground (4 wires total) from the power supply (breaker panel) to the

junction box on the unit.

NOTE:

All wiring must be completed prior to installing the unit.

NOTE:

Ensure that the voltage selector switch is in the proper position for the required supply voltage

prior to connecting the unit to the power supply.

240 VOLT INSTALLATION

1. Locate the voltage selector switch inside the exhaust panel on the top right hand

corner of the unit. (see figure 1 on page 3)

2. Ensure that the switch is in the 240 volt position. (230 is printed on switch)

3. Loosen the screw securing the junction box cover and remove the cover.

4. Remove the knockouts (if necessary) or use the provided cable clamp.

5. Pull out the four wires marked L1, L2, N, and G.

6. Connect the black L1 wire from the unit to the black L1 from the power supply.

7. Connect the red L2 wire from the unit to the red L2 from the power supply.

8. Connect the white N wire from the unit to the to the white neutral from the power

supply.

9. Connect the green ground wire from the unit to the ground from the power supply.

10.Ensure that all connections are tight.

11. Insert all the wiring back into the unit and secure with a cable clamp.

FIREPLACE JUNCTION BO

240 V

POWER

SUPPLY

(BREAKER

PANEL)

WHITE WIRE - N

RED WIRE

–

BLACK WIRE

–

GREEN WIRE - G

WHITE WIRE - N

RED WIRE

–

BLACK WIRE

–

GROUND WIRE - G

SECTION C: FACTORY SETTING WIRING

(WITHOUT MAIN POWER WALL SWITCH)

IMPORTANT:

The unit is factory configured for 208/240 volt operation

NOTE:

Use 2 conductor wire with ground (3 wires total) from the power supply (breaker panel) to the

junction box on the unit.

NOTE:

All wiring must be completed prior to installing the unit.

NOTE:

Ensure that the voltage selector switch is in the proper position for the required supply voltage

prior to connecting the unit to the power supply.

120 VOLT INSTALLATION

1. Locate the voltage selector switch inside the exhaust panel on the top right hand corner

of the unit. (see figure 2 on page 3)

2. Flip the switch from 240 volt to 120 volt configuration. (230 and 115 is printed on switch)

3. Loosen the screw securing the junction box cover and remove the cover.

4. Remove the knockouts (if necessary) or use the provided cable clamp.

5. Pull out the four wires marked L1, L2, N, and G.

6. Connect the black L1 wire from the unit to the black L1 from the power supply.

7. Connect the red L2 and white N wire from the unit to the white neutral wire from the

power supply.

8. Connect the green ground wire from the unit to the ground from the power supply.

9. When the unit has been configured for the appropriate power supply voltage, ensure

that all connections are tight.

10.Insert all the wiring back into the unit and secure with a cable clamp.

FIREPLACE JUNCTION BO

120 V

POWER

SUPPLY

(BREAKER

PANEL)

WHITE WIRE - N

RED WIRE

–

BLACK WIRE

–

GREEN WIRE - G

WHITE WIRE - N

BLACK WIRE

–

GROUND WIRE - G

SECTION C: FACTORY SETTING WIRING

(WITHOUT MAIN POWER WALL SWITCH)

(NO HEAT INSTALLATION)

IMPORTANT:

The unit is factory configured for 208/240 volt operation

NOTE:

Use 2 conductor wire with ground (3 wires total) from the power supply (breaker panel) to the

junction box on the unit.

NOTE:

All wiring must be completed prior to installing the unit.

NOTE:

Ensure that the voltage selector switch is in the proper position for the required supply voltage

prior to connecting the unit to the power supply.

120 VOLT INSTALLATION (NO HEAT INSTALLATION)

1. Locate the voltage selector switch inside the exhaust panel on the top right hand corner

of the unit. (see figure 2 on page 3)

2. Flip the switch from 240 volt to 120 volt configuration. (230 and 115 is printed on switch)

3. Loosen the screw securing the junction box cover and remove the cover.

4. Remove the knockouts (if necessary) or use the provided cable clamp.

5. Pull out the four wires marked L1, L2, N, and G.

6. Connect the black L1 wire from the unit to the black L1 from the power supply.

7. Install a wire nut on the red L2. (wire nut not included).

8. Connect the white N wire from the unit to the white neutral wire from the power supply.

9. Connect the green ground wire from the unit to the ground from the power supply.

10.When the unit has been configured for the appropriate power supply voltage, ensure

that all connections are tight.

11.Insert all the wiring back into the unit and secure with a cable clamp.

FIREPLACE JUNCTION BO

120 V

POWER

SUPPLY

(BREAKER

PANEL)

WHITE WIRE - N

RED WIRE

–

BLACK WIRE

–

GREEN WIRE - G

WHITE WIRE - N

BLACK WIRE

–

GROUND WIRE - G

Wire Nut

SECTION D: MAIN POWER WALL SWITCH WIRING OPTIONS

MAIN POWER WALL SWITCH WIRING

FOR 240 VOLT

NOTE:

This option should not be used with the remote control kit.

NOTE:

Before installing the unit you must have the following wires installed:

1. A 3 conductor wire with ground (4 wires total) from the power supply panel to the

main switch wall box.

2. A 3 conductor wire with ground (4 wires total) from the main switch wall box to the

junction box on the unit.

NOTE:

Use a double pole, single throw (on/off) wall switch that is rated for a minimum of 15 amps.

240 VOLT INSTALLATIONS

1. Locate the voltage selector switch inside the exhaust panel on the top right hand corner

of the unit. (see figure 1 on page 3)

2. Ensure that the switch is in the 240 volt position. (230 is printed on switch)

3. Loosen the screw securing the junction box cover and remove the cover.

4. Remove the knockouts (if necessary) or use the provided cable clamp.

5. Pull out the four wires marked L1, L2, N, and G. (black, red, white and green)

6. Connect the (black) L1 wire from the unit to the (black) L1 wire from the main power wall

switch by using a wire connector (not supplied).

7. Connect other end of (black) L1 wire from the main power wall switch to the L1 terminal

of the main power wall switch.

8. Connect the (red) L2 wire from the unit to the (red) L2 wire from the main power wall

switch by using a wire connector (not supplied).

9. Connect the other end of the (red) L2 wire from the main power wall switch to the L2

terminal of the main power wall switch.

10.Connect the (white) Neutral wire from the unit to the (white) Neutral wire from the main

power wall switch by using a wire connector (not supplied).

11.Connect the (green) Ground wire from the unit to the (green) Ground wire from the main

power wall switch by using a wire connector (not supplied).

12.Connect the (red or black) L1 wire from the power supply to the L1 terminal of the main

power wall switch.

13.Connect the (black) L2 wire from the power supply to the L2 terminal of the main power

wall switch.

14.Connect the (white) Neutral wire from the power supply to the remaining (white) Neutral

wire from the unit by using a wire connector.

15.Secure the 2 remaining (green) Ground wires with a ground screw in the main switch

wall box.

16.Ensure that all connections are tight.

17.Insert all the wiring of the main power wall switch into the main switch wall box.

18.Insert all the wiring back into the unit and secure with a cable clamp.

240 VOLT MAIN WALL SWITCH

WIRING DIAGRAM

FIREPLACE JUNCTION BO

240 V

POWER

SUPPLY

(BREAKER

PANEL)

WHITE - N

RED

–

BLACK

–

WHITE

–

BLACK

–

GROUND - G

WALL

SWITCH

RED

–

GROUND - G

This manual suits for next models

Table of contents

Other Dimplex Indoor Fireplace manuals

Dimplex

Dimplex Vivente VVT775 Instruction Manual

Dimplex

Dimplex Sierra 48 User manual

Dimplex

Dimplex CDFI1000-PRO User manual

Dimplex

Dimplex DF2600 User manual

Dimplex

Dimplex 7207380100REV00 User manual

Dimplex

Dimplex Juneau JUN User manual

Dimplex

Dimplex DFO2607 User manual

Dimplex

Dimplex DF1135M User manual

Dimplex

Dimplex BF33STP User manual

Dimplex

Dimplex Opti-V User manual

Dimplex

Dimplex BF33STP/DXP User manual

Dimplex

Dimplex DF3033ST User manual

Dimplex

Dimplex VCX1525 User manual

Dimplex

Dimplex OS2527GB User manual

Dimplex

Dimplex MIDI FIRE MIDI32B User manual

Dimplex

Dimplex PF2325 User manual

Dimplex

Dimplex Avola AVA20 User manual

Dimplex

Dimplex Michigan Fire MCN20 User manual

Dimplex

Dimplex SNG20 User manual

Dimplex

Dimplex Americana AMR20R User manual

Dimplex

Dimplex Juneau XL User manual

Dimplex

Dimplex Revillusion Haydn User manual

Dimplex

Dimplex DFR2651L User manual

Dimplex

Dimplex COMPACT FIREPLACE User manual

Popular Indoor Fireplace manuals by other brands

Brigantia

Brigantia 35-DVRS31N-2 User's installation, operation and maintenance manual

Nordpeis

Nordpeis Bergen Installation and user manual

Superior

Superior BCT2536TMN Installation and operation instructions

Quadra-Fire

Quadra-Fire 5100I-GD-B owner's manual

Renaissance

Renaissance RUMFORD 1000 user manual

Lacunza

Lacunza IV-800 Instruction book

Baxi

Baxi 940 Installer and owner guide

Dru

Dru Maestro 60/2 Tall RCH installation manual

Diamond Fireglass

Diamond Fireglass SS-O22 General assembly, installation, and operation instructions

HearthStone

HearthStone Windsor Bay 8830 Owner's manual and installation guide

Napoleon

Napoleon ASCENT B42 quick start guide

Enviro

Enviro E33GI owner's manual

Smeg

Smeg L30 FABE Installation & user's instructions

KEDDY

KEDDY K700 Installation instructions care and firing instructions

Godin

Godin 3451 manual

Jøtul

Jøtul Jotul GI 535 DV IPI New Harbor Installation and operation instructions

Austro Flamm

Austro Flamm Heidi Back 2.0 945048 operating manual

Desa

Desa CCFPDFT Owner's operating & installation manual
