Dimplex LST100 User manual

This guide is for quick reference only. Please refer to the operating section for further information.

How Does the Heater Control Work?

The control allows you to choose when you want heat and at what temperature.

When using a timer mode (see below), Comfort On will display on the home screen to tell you when the heater is maintaining

the temperature displayed. Comfort Off will display when the heater is outside of a timed heating period.

When Manual, Eco or Frost modes are being used the heater will always maintain the temperature shown on the home

screen.

Set the Time

To set the date and time on the heater, press Menu, then press the Enter with Time / Date highlighted. Press or until

the correct value is shown, then press Enter to conrm and move on to the next value. Repeat until all details are correct,

and Set displays, then press Back.

The time is automatically adjusted in spring and autumn between Greenwich Mean Time (GMT) and British Summer Time

(BST).

Set the Temperature

The temperature shown on the display is the room temperature set point. This is the temperature that the

heater will maintain during heating periods. If the room temperature is above this temperature then the

heater will not operate. The heater leaves the factory with this temperature set at 21°C which represents a

typical, comfortable room temperature. If you require a dierent room temperature then press either or

on the home screen until the display shows the temperature you require.

Timer Modes

Your Quantum heater comes pre-programmed with four timer

modes. These modes dene the periods when the heater will

operate in Comfort On mode. The four modes are:

Timer Mode Description

Out All Day 6 hours heating per day in two periods

Home All Day 9 hours heating per day in one period

Holiday Set the number of days for which you are

on holiday

User Timer Customise times in four periods

Low Surface Temperature Heater

Quick Start Guide

8/53222/0 ISSUE 0

• In order to avoid overheating, Do Not Cover the heater. Do not place matrerial or garments on the heater, or obstruct

the air circulation around the heater.

• Ensure that both supply swtiches next to the heater are turned on. During the summer when no heat is required, both

wall switches can be turned o. Remember to turn both of these back on in Autumn when heat is required.

• CAUTION as some parts of this product can become very hot and cause burns. Particular attention has to be given where

children and vulnerable people are present.

• Note that due care and consideration must be taken when using this heater in series with thermal control, a program

controller, a timer or any other device that switches on the heat automatically, since a re risk exists when the heater is

accidentally covered or displaced.

Mode

Timer Mode

Manual

Eco Mode

Frost Protect

O

Which Timer Mode is Best for Me?

The heater leaves the factory set in Out All Day mode. If you are out during the day and only require heat in the

mornings and evenings then this mode will suit your lifestyle and you won’t need to alter anything. If you are in

during the day then you should select the Home All Day mode which is a single heating period.The times of these

modes can be modied, or the User Timer mode can be used to give you four periods of heating split throughout

the day. If you are away for an extended period then you can use the Holiday mode. This allows you to reduce the

heating during the period that you are away, reverting to the previously selected mode on the day you return.

To choose a timer mode press Menu followed by Enter to select Mode then Timer Mode. Select the mode

required by pressing or then Enter. For options Out All Day, Home All Day and User Timer, three

choices are available - Select, Preview and Modify.

Select - Choose this timer option

Preview - View the times currently set

Modify - Change the times currently set

(Please refer to the operating section of this manual for information on how to modify the programmed times.)

Advance

Sometimes you may be at home when you had not planned to be, or need

to leave when you had planned to have the heating on. You can change the

way you use your heating temporarily, this temporary change is achieved by

using the Advance function.

When a timer has been selected, the Advance function allows you to begin

the next Comfort On period early. If the heater is in a Comfort Off period

and you want heat – press the Advance button. If the heater is in Comfort

On and you don’t want heat, press the Advance button and it will go o

until the beginning of the next Comfort On period.

Advance Boost

The Advance button is also used to give a Boost which provides temporary

heating for one, two, three or four hours. Press the Advance button twice to

begin a one hour Boost. Continue pressing the Advance button to enter the

longer Boost periods.

21 C

Comfort On

Main Menu

Date/Time

Mode

Options

Timer Mode

Out All Day

Home All Day

Holiday

User Timer

Out All Day

Select

Preview

Modify

Out All Day

Child Lock

If you need to lock the controls so that the settings

cannot be changed then activate the Child Lock.

To lock the controls press and hold both the Back

button and Enter for three seconds. Child Lock

will appear at the bottom of the screen. To unlock the

control repeat the action by pressing both the Back

button and Enter for three seconds.

Press and hold both

the Back button and

Enter for three seconds

20C

Dimplex UK, a division of GDC Group, Millbrook house, Grange Drive, Hedge End, Southampton SO30 2DF

For further assistance please contact Dimplex Customer Services on 08448793588 or go to www.dimplex.co.uk
