Dimplex DC09MINI User manual

DC09MINI

2.6kW Portable

Air Conditioner

www.dimplex.com.au

INSTRUCTION MANUAL

PLEASE READ THE INSTRUCTION MANUAL CAREFULLY BEFORE USING THE UNIT.

www.dimplex.com.au

CONTENTS

WARNINGS AND PRECAUTIONS 1

STRUCTURE 3

OPERATION 4

CLEANING AND MAINTENANCE 9

TECHNICAL REFERENCE DATA 10

WARRANTY 10

IMPORTANT INFORMATION

Carefully read this instruction manual before you install or use

your portable air conditioner. Please retain this manual for product

warranty and for future reference.

CAUTION

• Make sure the inlet and outlet vents are never blocked.

• Ensure the appliance is on a stable, even surface when operating to

avoid water leakage.

• Do not operate this unit in an explosive or corrosive atmosphere.

• When switched to cooling, only operate this unit in ambient

temperatures between 17°C and 35°C.

• Clean the air lter frequently to ensure efcient operation.

• To prevent compressor damage when the unit has been operating and

is turned off, please wait at least 3.5 minutes before restarting.

• This unit needs to be plugged into a 220-240V ~ 50Hz AC, 7 Amp

power outlet.

• Do not use any extension cords with this unit.

• This unit is for indoor operation only.

• Open the adjustable air vent and extend the exhaust pipe (and drain

pipe, if tted) to the closest window before using.

• After starting the unit, the fan will run rst and the cooling display light will

be ash for 3 minutes until then compressor starts working.

• Only professional technicians, manufacturers or service agents can

replace a damaged power cord.

• When the batteries no longer work, they must be removed from the

remote control and disposed of safely.

WARNINGS & PRECAUTIONS

• This appliance is not intended for use by persons (including children)

with reduced physical, sensory or mental capabilities, or lack of

experience and knowledge, unless they have been given supervision or

instruction concerning use of the appliance by a person responsible for

their safety.

• Children should be supervised to ensure that they do not play with the

appliance.

• The appliance can only be connected to power source less than

0.219Ω.

• Clear the water before move the unit.

IMPORTANT

The air conditioner must always be stored and transported

upright. In case of doubt we suggest you wait at least 24 hours

before operation. (Please keep the unit upright at all times)

PACKAGE CONTENTS

• Portable air conditioner

• Extendable window kit (0.48m X 2 pcs)

• Water tray

WARNINGS & PRECAUTIONS

1. Controls

2. Cool air outlet

3. Cool air lter

4. Cool air inlet

5. Upper drain plug

6. Hot air outlet

7. Hot air lter

8. Hot air inlet

9. Lower drain plug

STRUCTURE

OPERATION

BEFORE FIRST USE

•

Please read these instructions carefully before use and keep them for

future reference.

•

Check your local main voltage whether it is the same as stated on the

appliance.

•

Before using for the rst time, remove any protective lms or stickers

from the appliance and ensure the control knob is in the “OFF” position.

•

Make sure drain plugs (5 & 9) are tted before use.

CONTROLS

OPERATION

INSTALLATION

Unpack the unit and remove the exhaust hose

and the hose connector from the storage

compartment at the bottom of the unit.

EXHAUST HOSE INSTALLATION

1. Remove the 2 x joints from the exhaust hose. See picture (1) below,

and connect joint (a) and joint (b) together.

2. Attach the joint to the exhaust hose in an anticlockwise direction. See

picture (2) below.

3. Rotate the exhaust hose clockwise as shown in picture (3), so that

the exhaust hose can be installed on the inner joint.

4. Attach the inner joint to the product. See picture (4).

OPERATION

LOCATION

Ensure the portable air conditioner is

installed on a at surface with adequate

space, to ensure the air inlets and outlets

are not blocked.

Keep a minimum clearance of 50cm from

walls and other objects. Locate the unit, so

the exhaust pipe and drain hose can reach

a suitable window, as shown.

Avoid sharp bends or kinks in the exhaust

pipe. The optional adjustable window slider

is included to ensure the exhaust pipe is

held in place (in the window) and prevents

expelled hot air re-entering the room.

The appliance should not be used in damp areas such as a laundry or

bathroom. Do not place the unit where it will be in direct sunlight, as it

may overheat and turn off.

ADJUSTABLE WINDOW SLIDER KIT

The adjustable window slider kit is installed as below:

OPERATION

DIRECTIONS

1. Plug the unit into a suitable power outlet.

2. Turn the control knob to the “FAN” position. This will put the

appliance into “FAN MODE”.

3. Turning the control knob to the “COOL” position, will put the

appliance in “COOLING MODE”.

4. The “FULL” indicator light will illuminate when the internal water tank

is full. Note: The unit will also stop working until the tank is emptied.

5. The “OPERATION” indicator light will illuminate when the unit is on

and working.

6. Turn the control knob to the position, to turn the unit off.

OPERATION

DRAINING THE WATER TANK

When the air conditioner is used, condensation may be produced that

cannot be removed via the exhaust hose. This water is captured by an

internal water tank. When the water tank is full, the unit will stop working

and the FULL indicator light will turn on.

When the FULL indicator light has turned on, the water tank must be

manually drained by following the below steps:

1. Switch off and unplug the unit.

2. Move the unit to a suitable place to drain the water. Consider placing

a tray or container under the outlet to catch the water.

3. Remove the lower drain plug (9) - refer to parts illustration on page 3.

4. Slightly tilt the unit to the rear to drain the water.

5. Once the water has completely drained, replace the drain plug (9).

IMPORTANT:

• Ensure the drain plug is re-tted to the drain outlet before use.

• Extend the exhaust back out the window before restarting the unit.
