Digital Equipment DECstation 5000 Quick start guide

Upgrade Instructions

Order Number: EK–DS523–UP. A01

DECstation 5000

Model 2xx to DEC

3000 Model 300 AXP

MLO-010693

Can Upgrade Cannot Upgrade

Graphics

Options:** PMAGB-BA/BB PMAG-AA/AB

PMAGB-BC/BD PMAG-DA/DB

PMAGB-JA/JB AV10U-AA/DA

PMAG-GB PMAG-EA/EB

PMAGB-BE/BF PMAG-FA/FB

PMAG-HA PMAGB-ED/EC

PMAGB-FA/FB*+ PMAGB-DC/DD

PMAGB-EA/EB+ PMAG-CA/CB

PMAGB-DA/DB+ PMAG-JA/JB

PMAG-BA/BB

TURBO-

channel

Options:** PMAD-AA/AB

Monitors: VRC16-Cx VR262-Ax

VRC16-Hx VR290-Dx

VRM17-Ax VR297-Dx

VRM17-Hx VR299-Dx

VR319-Dx** VRT19-Dx

VR320-Dx** VR319-Cx

VRT16-Hx** VR320-Cx

VRT19-Hx** VRT13

VRT16-Dx

Expansion

Boxes: SZ03,12,16

PMTcE***

*PMTcE required for support on DEC 3000/300.

**Supported on Model 300 only.

+DEC Open3D required for software support.

Options You Can Upgrade

Can Upgrade Cannot Upgrade

Hard

Disks:**** RZ24, 25, 26 RZ57

RZ23L, 24L

RZ55, 56, 58

Removable

Media:**** RRD42 RW100-AA

TZ30 RW100-BA

TLZ04,06 RW100-CA

TKZ08, 09, 10* CITCA-AA

TSZ07* TK50Z

RRD40

RX23, 26, 33

Monitors: VR319-Dx VR262

VR320-Dx V290

VRC16-Cx/Hx VR297

VRM17-Ax/Hx VR299

VRT16-Hx VRT13

VRT19-Hx

Input

Devices: LK201, 401 LK501

VSX10AA/A3** VSxxx-BB

VSX20AA/A3**

VSX30-AA/A3**

VSxxx-AA/AB

VSxxx-FA/GA

VSxxx-GB

VSxxx-JA

VSxxx-XX

*Support planned.

**DEC Open3D required for software support.

***Minimum revision of host module required is D03.

****Available only in expansion boxes.

Options You Can Upgrade

Check the Box Contents

Monitor

Video Cable

Antistatic

Wrist Strap

Monitor

Power Cord

System Power

Cord

Screwdriver

System Unit

Documentation

Modem Loopback

Connector

10BASE-T Loopback

Connector

SCSI

Terminator

Universal

Strain Relief

Strap

Keyboard/Mouse

Extension Cable

System Kit:

Accessory Kit:

MLO-010839

Network

Cable

Screws (8)

Mounting

Brackets (2)

xxxxxxx

xxxxxxxxxxx

xxx

Upgrade

Card

Return

Address

Label

Mouse

with Mousepad

Keyboard

External

SCSI Cable

1. To shut down the software and put the

system into console mode, enter:

shutdown -h now

2. Turn off the system unit by pressing O

on the On/Off switch on the rear of the

system unit. Wait 15 seconds before

unplugging the power cord.

3. Unplug all cables from the system unit

4. Unscrew the captive screw. Grasp each

side of the cover and pull the cover

straight toward the front about 2 inches

(5.5 cm). Pull the cover up and off.

Caution: You may damage the equipment

if you do not wear an antistatic

wrist strap when working inside

the system unit.

Turn Off System/Remove Cover

PMAG-C

V~100-120 A 3.0

V~220-240 A 1.7

V~100-120/220-240

A 7.9/4.2

Hz 50-60

W 359

MLO-010006

Captive

Screw

Turbochannel option modules and graphics

option modules can be single, double, or tri-

ple width to occupy one, two, or three option

slots.

Remove Option Modules

MLO-010663

5. Use a Phillips screwdriver to remove the

option slot screws, then the support post

screws.

6. Lift the front of the module to discon-

nect the slot connectors, then lift the

back of the module.

Remove Option Modules

Support

Post Screws Option

Slot Screws

MLO-010664

System

Connector

7. Follow the instructions in the DEC

3000 Model 300/300L AXP Reference

Guide to install the options in your

new system.

8. Follow the instructions in the DEC

3000 Model 300/300L Setting Up Your

System card to install the system.

9. Test the installation by turning on

your system and entering the show

device command at the console

prompt (>>>).

The options you upgraded should

appear in the display. If an option does

not display, it was not installed prop-

erly.

10. Return your DECstation and any

devices that are not upgradeable to

Digital:

•Pack the DECstation and devices

securely in packing material.

•Attach the return-address label that was

in your upgrade kit.

•Contact your Digital service representa-

tive to upgrade your service contract.

Complete the Upgrade

Printed in U.S.A.

S2305
