Denon AVR-X4400H User manual

SOUND MODE

POWER

AVR CONTROL

QUICK SELECT

PURE

MOVIE

GAME

MUSIC

GAME

CBL/

SAT

Blu-ray

AUX1

AUX2

INTERNET

ADIO

VOLUME

INFO

SETUP

Z2

Z 3

1 2 3 4

2 3

4 5 6

7 8 9

ENTER

ENTER0

+10

GHI

JKL

MNO

PQRS

TUV

ABC

. /

DEF

DEF SLE

WXYZ

MAIN

PHONO

V. TV AVR

DEVICE

DEVICE TV

MED

PLAY

Bluetooth

TUNER

AUDIO

INP

INPUT

MUTE

ECO

ENTER

TUNE

CH/

PAGE

BACK

OPTION

RC-1219

USB

uio p

ENTER SETUP

MAIN

BACK

Menu operations

1Press MAIN on the remote control unit to set the

operating zone to the MAIN ZONE.

The MAIN button lights.

2Press SETUP.

The menu is displayed on the TV screen.

3Use ui p to select the menu to be set or operated,

then press ENTER.

4Use o p to change to desired setting.

5Press ENTER to enter the setting.

0To return to the previous item, press BACK.

0Exiting the menu, press SETUP while the menu is displayed. The

menu display disappears.

Contents Connections Playback Settings Tips Appendix

169

Front panel Display Rear panel Remote Index

Audio

Make audio-related settings.

Dialog Level Adjust

This setting adjusts the output level to clarify the dialogue output from the

center channel.

oDialog Level Adjust

Set whether to adjust the dialog level or not.

On: Enables the adjustment of the dialog

level.

Off

(Default):

Disables the adjustment of the dialog

level.

oLevel

Adjusts the volume output from the center channel.

–12.0 dB – +12.0 dB (Default: 0.0 dB)

Subwoofer Level Adjust

This setting adjusts the volume level for the subwoofer.

oSubwoofer Level Adjust

Set whether to adjust the subwoofer level.

On: Enables the adjustment of the subwoofer

level.

Off

(Default):

Disables the adjustment of the subwoofer

level.

oSubwoofer 1 Level / Subwoofer 2 Level

Adjusts the volume level for the Subwoofer 1 and Subwoofer 2.

–12.0 dB – +12.0 dB (Default: 0.0 dB)

Contents Connections Playback Settings Tips Appendix

170

Front panel Display Rear panel Remote Index

Bass Sync

For contents recorded in multi-channel such as Blu-ray discs, the

recorded low frequency effects (LFE) may be out of synch and delayed.

This function corrects such a delay of low frequency effects (LFE).

0 ms – 16 ms (Default : 0 ms)

0How low frequency effects (LFE) are delayed differ according to the disc. Set this

to the desired value.

0“Bass Sync” settings are stored for each input source.

0This can be set when the LFE signal is included in the input signal.

0This cannot be set when the sound mode is “Direct” or “Pure Direct”.

Surround Parameter

You can adjust the surround audio sound field effects to match your

preferences.

The items (parameters) that can be adjusted depend on the signal being

input and the currently set sound mode. For details on the adjustable

parameters, see “Sound modes and surround parameters” (v p. 299).

0Some setting items cannot be set while playback is stopped. Make the settings

during playback.

0“Surround Parameter” settings are stored for each sound mode.

oCinema EQ

Gently softens the upper treble range of movie soundtracks to reduce

possible harshness and improve clarity.

On: “Cinema EQ” is used.

Off

(Default):“Cinema EQ” is not used.

Contents Connections Playback Settings Tips Appendix

171

Front panel Display Rear panel Remote Index

oLoudness Management

This sets whether to output as specified in “Dynamic Compression” or

output directly without compressing the dynamic range of audio

recorded in the disc.

(Default):

Outputs are given based on enabling the

settings made in “Dynamic Compression”

and Dialogue normalization function.

Off:

“Dynamic Compression” settings and

Dialogue normalization are disabled, and

the signals on the disc are output as is.

0“Loudness Management” can be set when Dolby Digital, Dolby Digital Plus,

Dolby TrueHD and Dolby Atmos signal is input.

oDynamic Compression

Compress dynamic range (difference between loud and soft sounds).

Auto: Automatic dynamic range compression

on/off control according to source.

Low / Medium / High: These set the compression level.

Off: Dynamic range compression is always

off.

0“Dynamic Compression” can be set when Dolby Digital, Dolby Digital Plus,

Dolby TrueHD, Dolby Atmos or DTS signal is input.

0The default setting is “Off”. When the input signal is the Dolby TrueHD or

Dolby Atmos source, the default setting is “Auto”.

0“Auto” cannot be set when inputting a DTS signal.

Contents Connections Playback Settings Tips Appendix

172

Front panel Display Rear panel Remote Index

oDialog Control

Adjust the volume of dialog in movies, vocals in music, etc. so these

can be heard more easily.

0 – 6 (Default : 0)

0This can be set when a DTS:X signal that is compatible with the Dialog Control

function is input.

oLow Frequency Effects

Adjust the low frequency effects level (LFE).

-10 dB – 0 dB (Default: 0 dB)

0For proper playback of the different sources, we recommend setting to the

values below.

0Dolby Digital sources: 0 dB

0DTS movie sources: 0 dB

0DTS music sources: -10 dB

oCenter Spread

Center Spread expands the center channel signal to left and right front

speakers to create a wider frontal audio image for the listener. It is

optimized and designed primary for playback of stereo music content.

On: Use “Center Spread”.

Off

(Default):Do not use “Center Spread”.

0You can set this when sound mode is “Dolby Surround”.

oDTS Neural:X

DTS Neural:X Expands the non-object based audio signals and

optimizes them for your speaker configuration.

(Default):Use “DTS Neural:X”.

Off: Do not use “DTS Neural:X”.

0You can set this when sound mode is “DTS:X” or “DTS:X MSTR”.

Contents Connections Playback Settings Tips Appendix

173

Front panel Display Rear panel Remote Index

oAuro-Matic 3D Preset

Selects the Auro-Matic 3D Preset for fine tuning the Auro-3D

experience to specific audio material.

Small:

Small is ideal for pop and chamber music

or movies with a lot of dialog. (e.g.

comedy)

Medium

(Default):

Medium is best used on jazz music or

typical movies and TV shows.

Large:

Large is ideal for recordings that were

recorded in large spaces. (e.g. orchestral

recordings or action movies with big

explosions.)

Speech:

Speech is ideal for recordings which are

mostly dialog (e.g. news broadcast), and

that have virtually no inherent spatial

information.

0You can set this when the sound mode is set to Auro-3D.

0This cannot be set if the input signal contains Auro-3D signals containing a

Height channel.

oAuro-Matic 3D Strength

Changes the level of the up-mixed channels in relation to the original

input signal.

The value ranges from 1 (no up-mixing) to 16 (Maximum level,

providing maximum effect).

1 - 16 (Default:10)

0You can set this when the sound mode is set to Auro-3D.

0This cannot be set if the input signal contains Auro-3D signals containing a

Height channel.

Contents Connections Playback Settings Tips Appendix

174

Front panel Display Rear panel Remote Index

oDelay Time

Adjust the audio delay time against video to extend the sound field

image.

0 ms – 300 ms (Default: 30 ms)

0You can set this when the sound mode is “Matrix”.

oEffect Level

Adjust the sound effect level of the current sound mode.

1 – 15 (Default: 10)

0Set to a lower level if the positioning and sense of phase of the surround

signals seems unnatural.

oRoom Size

Determine size of acoustic environment.

Small: Simulate acoustics of a small room.

Medium small: Simulate acoustics of a medium-small

room.

Medium

(Default):Simulate acoustics of a medium room.

Medium large: Simulate acoustics of a medium-large

room.

Large: Simulate acoustics of a large room.

0“Room Size” does not indicate the size of the room in which sources are

played.

Contents Connections Playback Settings Tips Appendix

175

Front panel Display Rear panel Remote Index

oSpeaker Select

Makes settings for the speakers outputting sound.

Floor: Plays back without height speakers.

Floor & Height

(Default):Plays back with height speakers.

0This can be set when the sound mode is the original sound mode.

oSubwoofer

Turn subwoofer output on and off.

(Default):The subwoofer is used.

Off: The subwoofer is not used.

0You can set this when the sound mode is “Direct” or “Stereo” and in the menu

“Subwoofer Mode” is set to “LFE+Main”. (v p. 231)

oSet Defaults

The “Surround Parameter” settings are returned to the default settings.

Contents Connections Playback Settings Tips Appendix

176

Front panel Display Rear panel Remote Index

Restorer

Compressed audio formats such as MP3, WMA (Windows Media Audio)

and MPEG-4 AAC reduce the amount of data by eliminating signal

components that are hard for the human ear to hear. The “Restorer”

function generates the signals eliminated upon compression, restoring the

sound to conditions near those of the original sound before compression.

It also restores the original bass characteristics for a rich and expanded

tonal range.

oMode

High:

Optimized mode for compressed sources

with very weak highs (64 kbps and

under).

Medium:

Apply suitable bass and treble boost for

all compressed sources (96 kbps and

under).

Low: Optimized mode for compressed sources

with normal highs (96 kbps and over).

Off: Do not use “Restorer”.

0This item can be set with analog signals or PCM signal (Sample Rate =

44.1/48 kHz) is input.

0This item default setting for “HEOS Music” is “Low”. All others are set to “Off”.

0This cannot be set when the sound mode is set to “Direct” or “Pure Direct”.

0“Restorer” settings are stored for each input source.

Contents Connections Playback Settings Tips Appendix

177

Front panel Display Rear panel Remote Index

Audio Delay

Compensates for incorrect timing between video and audio.

0Audio Delay for game mode can be set when “Video Mode” is set to “Auto” or

“Game”. (v p. 193)

0“Audio Delay” settings are stored for each input source.

oAuto Lip Sync

Automatically adjusts the audio processing time to compensate for

delays in audio/video timing from TV compatible with Auto Lip Sync.

(Default):Correct automatically.

Off: Do not correct automatically.

0Automatic correction may not be performed depending on the specifications of

your TV even when “Auto Lip Sync” is set to “On”.

oAdjust

The timing mismatch between the picture and sound needs to be

corrected manually.

0 ms – 500 ms (Default : 0 ms)

0You can also finely adjust the delay correction value set by “Auto Lip Sync”.

0Adjust for game mode can be set when “Video Mode” is set to “Auto” or

“Game”. (v p. 193)

Contents Connections Playback Settings Tips Appendix

178

Front panel Display Rear panel Remote Index

Other manuals for AVR-X4400H

Table of contents

Other Denon Receiver manuals

Denon

Denon AVR-1801 User manual

Denon

Denon AVR1910 - Multi-Zone Home Theater Receiver User manual

Denon

Denon AVR-1708 Administrator guide

Denon

Denon AVR-3808CI Administrator guide

Denon

Denon AVR-4810 User manual

Denon

Denon AVR-X7200W User manual

Denon

Denon AVR-3808CI User manual

Denon

Denon AVR-3312CI User manual

Denon

Denon AVR1910 - Multi-Zone Home Theater Receiver User manual

Denon

Denon AVR-X2400H User manual

Denon

Denon DHT-591BA User guide

Denon

Denon ADV-1000 User manual

Denon

Denon AVR-X7200W User manual

Denon

Denon AVR-1613 User manual

Denon

Denon AVR-3808CI User guide

Denon

Denon RCD-N7 User manual

Denon

Denon RC-7001RCI - Remote Control RF/IR Base... User manual

Denon

Denon AVR-X4100W User manual

Denon

Denon AVR-X4100W User manual

Denon

Denon AVR-S900W User manual

Denon

Denon AVR-1712 User manual

Denon

Denon AVC-1930 User manual

Denon

Denon AVR-X4300H User manual

Denon

Denon AVR-4806CI User manual

Popular Receiver manuals by other brands

Garmin

Garmin GA 23 Owner's manual and reference guide

Aiphone

Aiphone PS-12F instructions

IMES

IMES TCS-01CA-PMI Original Operating Instruction

BWI Eagle

BWI Eagle AIR-EAGLE SR Product information bulletin

AMIMON

AMIMON AMN12310 WHDI datasheet

Dual

Dual DMCPA79BT Installation & owner's manual

Sound Associates

Sound Associates SA652P Operation manual

Sherwood

Sherwood NewCastle R-772 Service manual

Audio

Audio A10-RX Series user guide

AllSee

AllSee PushShare PSRV1.1 user manual

DEMAG

DEMAG DRC-DR D2 operating instructions

Teleco

Teleco TVRCL868A02 manual

Bosch

Bosch RF3222E installation instructions

Kramer

Kramer 631R user manual

Xpress

Xpress xmc10 installation guide

JVC

JVC KD-MR1BTS instruction manual

Omega Engineering

Omega Engineering UWTC-REC3 user guide

e-survey

e-survey E300 Pro user manual
