Denon AVR-X3100W User manual
Lisez-moi en premier.... / Lea esto primero....
English
Français
EsPaÑOl
AVR-X3100W
INTEGRATED NETWORK AV RECEIVER
Quick Start Guide
Read Me First....
Please do not return this unit to the store – call for assistance.
If you need help… :
If you need additional help in solving problems, contact Denon customer service in your area.
1-855-MY.Denon
1-855-693-3666
Call for Assistance: Monday – Friday 10:00AM to 10:00PM E.S.T, Saturday 12:00PM to 8:00PM E.S.T
For frequently asked questions please visit www.usa.denon.com/FAQ
For US and Canada only
Guide de conguration rapide / Guía de conguración rápida
1
Thank you for choosing a Denon AV receiver. This guide
provides step-by-step instructions for setting up your AV
receiver.
Welcome Before You Begin
Required for Setup
TV HDMI cable
Speaker systems Speaker cables
Optional
LAN cable Wi-Fi router
or
2
What’s In the Box
Quick Start Guide
Power cord
Owner’s Manual FM indoor antenna
Safety Instructions AM loop antenna
Notes on radio Sound calibration
microphone
Warranty
(for North America
model only)
Sound calibration
microphone stand
Cable labels Remote control
unit
Receiver R03/AAA batteries
The supplied Sound calibration microphone stand is
convenient for use when performing Speaker Calibration.
Using your own tripod or the supplied Sound calibration
microphone stand enables settings to be automatically
configured to the optimum listening environment, providing
exceptionally high performance.
•When connecting this unit to a device that is compatible
with the Deep Color, 4K and ARC functions, use an “High
Speed HDMI cable with Ethernet” that comes with the
HDMI logo.
•These drawings are for illustrative purposes only and may
not represent the actual product(s).
3
1Installing batteries in the
remote control unit
R03/AAA batteries
There are three steps to the setup
process.
1Install batteries in the remote control unit
2Connecting the receiver
3Follow the On-Screen Setup Assistant
Setup
4
2Connecting the receiver
nPlace the receiver near your TV and
connect the power cable.
TV
Receiver
Power cord
(supplied)
Connect to household
power outlet
(AC 120 V, 60 Hz)
5
nConnect to the network.
Wired LAN
When connecting cables (wired connection), connect a LAN
cable between your receiver and your network router.
Internet Modem
Router
To WAN side
To LAN port
Wireless LAN
When using a wireless connection (Wi-Fi), rotate the
antennas upword.
Router with
access point To WAN side
Internet Modem
6
nTurn on the TV.
TV remote control unit
nSelect the appropriate HDMI input
on your TV.
HDMI TV/
VIDEO
INPUT or
TV remote control unit
nConnect the receiver to your TV with
an HDMI cable.
(ARC)
HDMI IN
MONITOR
HDMI OUT
MONITOR
(ARC)
ARC
HDMI cable
Receiver (Rear panel)
7
nTurn on the receiver.
•Press Xto turn on the receiver.
nVerify the connection.
•Verify that you can see this screen on your TV.
AV Reciever Setup Assistant
Please select a language...
Español
Français
English
When this screen is not displayed, please read operation
from the beginning.
8
3Follow the On-Screen Setup Assistant
The Setup Assistant will walk you through connecting and
configuring your speakers and components to your Denon
receiver. Please use the remote control and follow the
on-screen instructions.
AV Reciever Setup Assistant
Please select a language...
Español
Français
English
9
nPDF Manual
To read the owner's manual on your computer or to print it
out, please open the included CD-ROM or select the “PDF
Download” link from the Web Manual.
Insert the disc into
your PC.
Follow the screen or double click on
the PDF le.
1
2
Owner’s Manual
nWeb Manual
To read it on your tablet or PC, please access to Web
Manual site.
manuals.denon.com/AVRX3100W/NA/EN/
Overview
Connections
Playback
Settings
Tips
Appendix
PDF Download
INTEGRATED NETWORK AV RECEIVER
INTEGRATED NETWORK AV RECEIVER
WEB Manual
Copyright 2014 D&M Holdings Inc. All Rights Reserved.
c
PDF
Contents
AVR-X3100W
Web Manual
Please reference these manuals for more details about the setup and operation of the receiver and it’s features.
This Web Manual is optimized for
tablets and mobile devices.
