AVR-988

12-6-1 FORMAT：SHARP

DATA CONSTRUCTION 15bits C14 0 C15 0=NOT INVERTED,1=INVERTED

Genre

System Address(C1～C5):０１０００, Extension Bit(C12,C13):１１

Genre

System Address(C1～C5):０１０００, Extension Bit(C12,C13):１１

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

64 ００００００ 16 ００００１０

1 １０００００ 17 １０００１０

2 ０１００００ 18 ０１００１０ FUNC.CDR/TAPE

3 １１００００ FUNC.PHONO 19 １１００１０

4 ００１０００ FUNC.CD 20 ００１０１０

5 １０１０００ FUNC.TUNER 21 １０１０１０

6 ０１１０００ FUNC.AUX 22 ０１１０１０

7 １１１０００ 23 １１１０１０

8 ０００１００ FUNC.DBS/SAT 24 ０００１１０ VIDEO SELECT

9 １００１００ FUNC.TV 25 １００１１０

10 ０１０１００ FUNC.HDP 26 ０１０１１０

11 １１０１００ 27 １１０１１０

12 ００１１００ FUNC.V.AUX, 28 ００１１１０

13 １０１１００ FUNC.VCR-1(VCR) 29 １０１１１０ CURSOR RIGHT

14 ０１１１００ FUNC.VCR-2(DVR) 30 ０１１１１０ STATUS

15 １１１１００ 31 １１１１１０ ON SCREEN

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

32 ０００００１ ENTER 48 ００００１１ MUTING

33 １００００１ POWER ON 49 １０００１１ MASTER VOLUME UP

34 ０１０００１ POWER OFF 50 ０１００１１ MASTER VOLUME DOWN

35 １１０００１ FUNC.DVD 51 １１００１１

36 ００１００１ DOLBY/DTS SURROUND 52 ００１０１１

37 １０１００１ 53 １０１０１１

38 ０１１００１ DSP SIMULATION 54 ０１１０１１

39 １１１００１ 55 １１１０１１

40 ０００１０１ 56 ０００１１１

41 １００１０１ 57 １００１１１

42 ０１０１０１ TEST TONE 58 ０１０１１１

43 １１０１０１ 59 １１０１１１

44 ００１１０１ 60 ００１１１１

45 １０１１０１ SPEAKER 61 １０１１１１

46 ０１１１０１ 62 ０１１１１１

47 １１１１０１ 63 １１１１１１

AV AMP

CONFIDENTIAL

Genre

System Address(C1～C5):００１１０, Extension Bit(C12,C13):０１

Genre

System Address(C1～C5):００１１０, Extension Bit(C12,C13):０１

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

64 ００００００ 16 ００００１０ FUNC.CD( MULTI )

1 １０００００ 17 １０００１０ FUNC.TUNER( MULTI )

2 ０１００００ 18 ０１００１０ FUNC.HDP( MULTI )

3 １１００００ 19 １１００１０ FUNC.V.AUX( MULTI )

4 ００１０００ 20 ００１０１０ FUNC.VCR-1(VCR)( MULTI )

5 １０１０００ 21 １０１０１０

6 ０１１０００ 22 ０１１０１０

7 １１１０００ 23 １１１０１０

8 ０００１００ 24 ０００１１０ FUNC.AUX( MULTI )

9 １００１００ 25 １００１１０ FUNC.VCR-2( MULTI )

10 ０１０１００ FUNC.SAT( MULTI ) 26 ０１０１１０

11 １１０１００ 27 １１０１１０ FUNC.TV( MULTI )

12 ００１１００ 28 ００１１１０ FUNC.CDR/TAPE( MULTI )

13 １０１１００ MULTI VOLUME UP 29 １０１１１０

14 ０１１１００ MULTI VOLUME DOWN 30 ０１１１１０

15 １１１１００ FUNC.PHONO( MULTI ) 31 １１１１１０

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

32 ０００００１ SYSTEM SET UP 48 ００００１１

33 １００００１ SURROUND PARAMETER 49 １０００１１

34 ０１０００１ 50 ０１００１１

35 １１０００１ CURSOR UP 51 １１００１１

36 ００１００１ CURSOR DOWN 52 ００１０１１

37 １０１００１ 53 １０１０１１

38 ０１１００１ 54 ０１１０１１ INPUT MODE

39 １１１００１ 55 １１１０１１

40 ０００１０１ 5CH/7CH STEREO 56 ０００１１１

41 １００１０１ 57 １００１１１

42 ０１０１０１ 58 ０１０１１１

43 １１０１０１ 59 １１０１１１

44 ００１１０１ 60 ００１１１１

45 １０１１０１ 61 １０１１１１

46 ０１１１０１ 62 ０１１１１１ FUNC.DVD( MULTI )

47 １１１１０１ 63 １１１１１１

AVP

CONFIDENTIAL

Genre

System Address(C1～C5):０１０００, Extension Bit(C12,C13):１０

Genre

System Address(C1～C5):０１０００, Extension Bit(C12,C13):１０

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

64 ００００００ 16 ００００１０

1 １０００００ 17 １０００１０

2 ０１００００ 18 ０１００１０

3 １１００００ 19 １１００１０

4 ００１０００ 20 ００１０１０

5 １０１０００ 21 １０１０１０

6 ０１１０００ 22 ０１１０１０

7 １１１０００ 23 １１１０１０

8 ０００１００ 24 ０００１１０

9 １００１００ 25 １００１１０

10 ０１０１００ 26 ０１０１１０

11 １１０１００ 27 １１０１１０

12 ００１１００ 28 ００１１１０

13 １０１１００ 29 １０１１１０

14 ０１１１００ 30 ０１１１１０

15 １１１１００ 31 １１１１１０

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

32 ０００００１ 48 ００００１１

33 １００００１ 49 １０００１１

34 ０１０００１ 50 ０１００１１

35 １１０００１ 51 １１００１１

36 ００１００１ 52 ００１０１１

37 １０１００１ 53 １０１０１１

38 ０１１００１ 54 ０１１０１１

39 １１１００１ 55 １１１０１１

40 ０００１０１ 56 ０００１１１

41 １００１０１ 57 １００１１１ MAIN ZONE ON

42 ０１０１０１ PURE DIRECT 58 ０１０１１１ MAIN ZONE OFF

43 １１０１０１ 59 １１０１１１ MULTI ZONE ON

44 ００１１０１ 60 ００１１１１ MULTI ZONE OFF

45 １０１１０１ 61 １０１１１１

46 ０１１１０１ 62 ０１１１１１

47 １１１１０１ 63 １１１１１１

PRE AMP

CONFIDENTIAL

Genre

System Address(C1～C5):０００１０, Extension Bit(C12,C13):０１ＤＶＤ：ＤＥＮＯＮＡ

Genre

System Address(C1～C5):０００１０, Extension Bit(C12,C13):０１

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

64 ００００００ 16 ００００１０

1 １０００００ 0 17 １０００１０ MENU

2 ０１００００ 1 18 ０１００１０ RETURN

3 １１００００ 2 19 １１００１０

4 ００１０００ 3 20 ００１０１０

5 １０１０００ 4 21 １０１０１０

6 ０１１０００ 5 22 ０１１０１０

7 １１１０００ 6 23 １１１０１０

8 ０００１００ 7 24 ０００１１０ DVD ＞＞｜

9 １００１００ 8 25 １００１１０ DVD ｜＜＜

10 ０１０１００ 9 26 ０１０１１０ DVD ＞＞

11 １１０１００ 27 １１０１１０ DVD ＜＜

12 ００１１００ +10 28 ００１１１０

13 １０１１００ SUBTITLE 29 １０１１１０ DVD ｜｜

14 ０１１１００ AUDIO 30 ０１１１１０

15 １１１１００ 31 １１１１１０

No. Data(C6～C11) ｷｰ名称 No. Data(C6～C11) ｷｰ名称

32 ０００００１ DVD ＞ 48 ００００１１

33 １００００１ DVD STOP 49 １０００１１ DVD POWER

34 ０１０００１ 50 ０１００１１

35 １１０００１ 51 １１００１１

36 ００１００１ 52 ００１０１１

37 １０１００１ 53 １０１０１１

38 ０１１００１ 54 ０１１０１１

39 １１１００１ DISPLAY 55 １１１０１１

40 ０００１０１ 56 ０００１１１

41 １００１０１ 57 １００１１１

42 ０１０１０１ 58 ０１０１１１

43 １１０１０１ DVD DISC SKIP 59 １１０１１１ DVD ENTER

44 ００１１０１ DVD CURSOR UP 60 ００１１１１ DVD SET UP

45 １０１１０１ DVD CURSOR DOWN 61 １０１１１１

46 ０１１１０１ DVD CURSOR →62 ０１１１１１

47 １１１１０１ DVD CURSOR ←63 １１１１１１

VIDEO CD

CONFIDENTIAL

Genre

System Address(C1～C5):０００１０, Extension Bit(C12,C13):１０

Genre

System Address(C1～C5):０００１０, Extension Bit(C12,C13):１０

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

64 ００００００ 16 ００００１０

1 １０００００ 17 １０００１０

2 ０１００００ 18 ０１００１０

3 １１００００ 19 １１００１０

4 ００１０００ 20 ００１０１０

5 １０１０００ 21 １０１０１０

6 ０１１０００ 22 ０１１０１０

7 １１１０００ 23 １１１０１０

8 ０００１００ 24 ０００１１０ CD ＞＞｜

9 １００１００ 25 １００１１０ CD ｜＜＜

10 ０１０１００ 26 ０１０１１０ CD ＞＞

11 １１０１００ 27 １１０１１０ CD ＜＜

12 ００１１００ 28 ００１１１０ CD ＞

13 １０１１００ 29 １０１１１０ CD ｜｜

14 ０１１１００ 30 ０１１１１０ CD STOP

15 １１１１００ 31 １１１１１０

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

32 ０００００１ 48 ００００１１

33 １００００１ 49 １０００１１

34 ０１０００１ 50 ０１００１１

35 １１０００１ 51 １１００１１

36 ００１００１ 52 ００１０１１

37 １０１００１ 53 １０１０１１

38 ０１１００１ 54 ０１１０１１

39 １１１００１ 55 １１１０１１

40 ０００１０１ 56 ０００１１１

41 １００１０１ 57 １００１１１

42 ０１０１０１ 58 ０１０１１１

43 １１０１０１ CD DISC SKIP+ 59 １１０１１１

44 ００１１０１ 60 ００１１１１

45 １０１１０１ 61 １０１１１１

46 ０１１１０１ 62 ０１１１１１

47 １１１１０１ 63 １１１１１１

CONFIDENTIAL

Genre

System Address(C1～C5):００１００, Extension Bit(C12,C13):１０

Genre

System Address(C1～C5):００１００, Extension Bit(C12,C13):１０

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

64 ００００００ 16 ００００１０

1 １０００００ 17 １０００１０

2 ０１００００ 18 ０１００１０

3 １１００００ 19 １１００１０ TAPE A / B

4 ００１０００ 20 ００１０１０

5 １０１０００ 21 １０１０１０

6 ０１１０００ 22 ０１１０１０

7 １１１０００ 23 １１１０１０ TAPE ＜

8 ０００１００ 24 ０００１１０

9 １００１００ 25 １００１１０

10 ０１０１００ 26 ０１０１１０ TAPE ＞＞

11 １１０１００ 27 １１０１１０ TAPE ＜＜

12 ００１１００ 28 ００１１１０ TAPE ＞

13 １０１１００ 29 １０１１１０

14 ０１１１００ 30 ０１１１１０ TAPE STOP

15 １１１１００ 31 １１１１１０

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

32 ０００００１ 48 ００００１１

33 １００００１ 49 １０００１１

34 ０１０００１ 50 ０１００１１

35 １１０００１ 51 １１００１１

36 ００１００１ 52 ００１０１１

37 １０１００１ 53 １０１０１１

38 ０１１００１ 54 ０１１０１１

39 １１１００１ 55 １１１０１１

40 ０００１０１ 56 ０００１１１

41 １００１０１ 57 １００１１１

42 ０１０１０１ 58 ０１０１１１

43 １１０１０１ 59 １１０１１１

44 ００１１０１ 60 ００１１１１

45 １０１１０１ 61 １０１１１１

46 ０１１１０１ 62 ０１１１１１

47 １１１１０１ 63 １１１１１１

TAPE

CONFIDENTIAL

Genre

System Address(C1～C5):０００１０, Extension Bit(C12,C13):１１ＣＤＲ：ＤＥＮＯＮＡ

Genre

System Address(C1～C5):０００１０, Extension Bit(C12,C13):１１

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

64 ００００００ 16 ００００１０

1 １０００００ 17 １０００１０ CDR STOP

2 ０１００００ 18 ０１００１０

3 １１００００ 19 １１００１０

4 ００１０００ 20 ００１０１０ CDR ｜＜＜

5 １０１０００ 21 １０１０１０ CDR ＞＞｜

6 ０１１０００ 22 ０１１０１０ CDR ＜＜

7 １１１０００ 23 １１１０１０ CDR ＞＞

8 ０００１００ 24 ０００１１０

9 １００１００ 25 １００１１０

10 ０１０１００ 26 ０１０１１０

11 １１０１００ 27 １１０１１０

12 ００１１００ 28 ００１１１０

13 １０１１００ 29 １０１１１０

14 ０１１１００ CDR ＞ 30 ０１１１１０

15 １１１１００ CDR ｜｜ 31 １１１１１０

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

32 ０００００１ 48 ００００１１

33 １００００１ 49 １０００１１

34 ０１０００１ 50 ０１００１１

35 １１０００１ 51 １１００１１

36 ００１００１ 52 ００１０１１

37 １０１００１ 53 １０１０１１

38 ０１１００１ 54 ０１１０１１

39 １１１００１ 55 １１１０１１

40 ０００１０１ 56 ０００１１１

41 １００１０１ 57 １００１１１

42 ０１０１０１ 58 ０１０１１１

43 １１０１０１ 59 １１０１１１

44 ００１１０１ 60 ００１１１１

45 １０１１０１ 61 １０１１１１

46 ０１１１０１ 62 ０１１１１１

47 １１１１０１ 63 １１１１１１

CDR

CONFIDENTIAL

Genre

System Address(C1～C5):００１００, Extension Bit(C12,C13):０１

Genre

System Address(C1～C5):００１００, Extension Bit(C12,C13):０１

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

64 ００００００ 16 ００００１０

1 １０００００ 17 １０００１０

2 ０１００００ 18 ０１００１０

3 １１００００ 19 １１００１０

4 ００１０００ 20 ００１０１０

5 １０１０００ 21 １０１０１０ CINEMA MODE

6 ０１１０００ 22 ０１１０１０ MUSIC MODE

7 １１１０００ 23 １１１０１０

8 ０００１００ 24 ０００１１０ NIGHT MODE

9 １００１００ 25 １００１１０

10 ０１０１００ 26 ０１０１１０

11 １１０１００ 27 １１０１１０

12 ００１１００ 28 ００１１１０

13 １０１１００ 29 １０１１１０ ROOM EQ

14 ０１１１００ 30 ０１１１１０

15 １１１１００ 31 １１１１１０

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

32 ０００００１ DVD PICTURE ADJUST 48 ００００１１

33 １００００１ 49 １０００１１

34 ０１０００１ 50 ０１００１１

35 １１０００１ 51 １１００１１

36 ００１００１ 52 ００１０１１

37 １０１００１ 53 １０１０１１

38 ０１１００１ 54 ０１１０１１

39 １１１００１ 55 １１１０１１

40 ０００１０１ 56 ０００１１１

41 １００１０１ 57 １００１１１

42 ０１０１０１ 58 ０１０１１１

43 １１０１０１ 59 １１０１１１

44 ００１１０１ 60 ００１１１１

45 １０１１０１ 61 １０１１１１

46 ０１１１０１ 62 ０１１１１１

47 １１１１０１ 63 １１１１１１

CAR

CONFIDENTIAL

Genre

System Address(C1～C5):００１１０, Extension Bit(C12,C13):１０

Genre

System Address(C1～C5):００１１０, Extension Bit(C12,C13):１１

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

32 ０００００１ 48 ００００１１

33 １００００１ 49 １０００１１

34 ０１０００１ 50 ０１００１１

35 １１０００１ 51 １１００１１

36 ００１００１ 52 ００１０１１

37 １０１００１ 53 １０１０１１

38 ０１１００１ 54 ０１１０１１

39 １１１００１ 55 １１１０１１

40 ０００１０１ 56 ０００１１１

41 １００１０１ 57 １００１１１

42 ０１０１０１ 58 ０１０１１１

43 １１０１０１ 59 １１０１１１

44 ００１１０１ 60 ００１１１１

45 １０１１０１ 61 １０１１１１

46 ０１１１０１ 62 ０１１１１１

47 １１１１０１ 63 １１１１１１ CURSOR LEFT

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

64 ００００００ 16 ００００１０

1 １０００００ 17 １０００１０

2 ０１００００ 18 ０１００１０

3 １１００００ 19 １１００１０

4 ００１０００ 20 ００１０１０

5 １０１０００ 21 １０１０１０ TUNER CHANNNEL-

6 ０１１０００ 22 ０１１０１０ TUNER CHANNNEL+

7 １１１０００ 23 １１１０１０ TUNER BAND

8 ０００１００ 24 ０００１１０ TUNER MODE

9 １００１００ 25 １００１１０ TUNER TUNING UP

10 ０１０１００ 26 ０１０１１０ TUNER TUNING DOWN

11 １１０１００ 27 １１０１１０

12 ００１１００ TUNER MEMORY 28 ００１１１０

13 １０１１００ TUNER SHIFT 29 １０１１１０

14 ０１１１００ 30 ０１１１１０

15 １１１１００ 31 １１１１１０ DIMMER

RCVR

TUNER

CONFIDENTIAL

Genre

System Address(C1～C5):０１１００, Extension Bit(C12,C13):０１

Genre

System Address(C1～C5):０１１００, Extension Bit(C12,C13):０１

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

64 ００００００ 16 ００００１０

1 １０００００ VDP POWER 17 １０００１０

2 ０１００００ 18 ０１００１０

3 １１００００ VDP STOP 19 １１００１０

4 ００１０００ VDP ＞ 20 ００１０１０

5 １０１０００ VDP ｜｜ 21 １０１０１０

6 ０１１０００ VDP ＞＞｜ 22 ０１１０１０

7 １１１０００ VDP ｜＜＜ 23 １１１０１０

8 ０００１００ VDP ＞＞ 24 ０００１１０

9 １００１００ VDP ＜＜ 25 １００１１０

10 ０１０１００ 26 ０１０１１０

11 １１０１００ 27 １１０１１０

12 ００１１００ 28 ００１１１０

13 １０１１００ 29 １０１１１０

14 ０１１１００ 30 ０１１１１０

15 １１１１００ 31 １１１１１０

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

32 ０００００１０48 ００００１１＋１０

33 １００００１１49 １０００１１

34 ０１０００１２50 ０１００１１

35 １１０００１３51 １１００１１

36 ００１００１４52 ００１０１１

37 １０１００１５53 １０１０１１

38 ０１１００１６54 ０１１０１１

39 １１１００１７55 １１１０１１

40 ０００１０１８56 ０００１１１

41 １００１０１９57 １００１１１

42 ０１０１０１ 58 ０１０１１１

43 １１０１０１ 59 １１０１１１

44 ００１１０１ 60 ００１１１１

45 １０１１０１ 61 １０１１１１

46 ０１１１０１ 62 ０１１１１１

47 １１１１０１ 63 １１１１１１

Other manuals for AVR 988 - AV Receiver

This manual suits for next models

Table of contents

Popular Receiver manuals by other brands

Garmin

Garmin GA 23 Owner's manual and reference guide

Aiphone

Aiphone PS-12F instructions

IMES

IMES TCS-01CA-PMI Original Operating Instruction

BWI Eagle

BWI Eagle AIR-EAGLE SR Product information bulletin

AMIMON

AMIMON AMN12310 WHDI datasheet

Dual

Dual DMCPA79BT Installation & owner's manual

Sound Associates

Sound Associates SA652P Operation manual

Sherwood

Sherwood NewCastle R-772 Service manual

Audio

Audio A10-RX Series user guide

AllSee

AllSee PushShare PSRV1.1 user manual

DEMAG

DEMAG DRC-DR D2 operating instructions

Teleco

Teleco TVRCL868A02 manual

Bosch

Bosch RF3222E installation instructions

Kramer

Kramer 631R user manual

Xpress

Xpress xmc10 installation guide

JVC

JVC KD-MR1BTS instruction manual

Omega Engineering

Omega Engineering UWTC-REC3 user guide

e-survey

e-survey E300 Pro user manual
