DayStar Digital Genesis MP User manual

DayStar Digital, Inc.

Technical Support Department

5556 Atlanta Highway

Flowery Branch, GA 30542

770-967-2077 fax: 770-967-3018

http://daystar.com/

Service Guide

Genesis MP

Notices

The information contained in this maintenance and service guide is sub-

ject to change without notice.

DayStar Digital, Inc. shall not be held liable for technical or editorial

errors or omissions; nor for incidental or consequential damages

resulting from the performance or usage of this manual.

This manual is protected by copyright. No part of this manual may be

photocopied, reproduced, stored in a retrieval system, or transmitted

in any form (i.e., mechanically, electronically, or otherwise) without

prior written consent from DayStar Digital, Inc.

No licenses, expressed or implied, are granted with regard to any of

the technology documented in this Service and Maintenance Guide.

Genesis MP™ is a trademark of DayStar Digital, Inc.

Genesis MP System Utilities is a trademark of DayStar Digital, Inc.

PowerFrax is a freeware product of DayStar Digital, Inc.

nPOWER is a trademark of DayStar Digital, Inc.

Apple, LocalTalk, and Macintosh are all trademarks of Apple Computer, Inc.

AppleCD, Disk First Aid, GeoPort, Mac, are trademarks of Apple Computer, Inc.

Microsoft and MS-DOS are registered trademarks of Microsoft Corporation.

Windows is a registered trademark of Microsoft Corporation.

FCC Statement

This equipment has been tested and found to comply with the limits for a Class

A digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference when

the equipment is operated in a commercial environment. This equipment gener-

ates, uses, and can radiate radio frequency energy and, if not installed and

used in accordance with the instruction manual, may cause harmful interference

to radio communications. Operation of this equipment in a residential area is

likely to cause harmful interference in which case the user will be required to

correct the interference at his own expense.

IMPORTANT:

Changes or modifications to this product not authorized by DayStar Digital, Inc., could

void the FCC Certification and negate your own authority to operate the product.

This product was tested for FCC compliance under conditions that included the

use of DayStar peripheral devices and DayStar shielded cables and connectors

between system components. It is important that you use FCC compliant

peripheral devices and shielded cables and connectors between system compo-

nents to reduce the possibility of causing interference to radios, television sets,

and other electronic devices. You can obtain DayStar peripheral devices and the

proper shielded cables and connectors through a DayStar-authorized dealer.

For non-DayStar peripheral devices, contact the manufacturer or dealer for

assistance.

Notices

Genesis MP2 ◆

∆

Preface

Genesis MP

About Genesis MP

The Media-Publishing Workstation for the Next Century

The machine you have before you is the new standard in the com-

puter industry—the DayStar Genesis MP. Now Macintosh users

can have the speed they associate with expensive, high-end work-

stations—but at a reasonable price.

Genesis MP is the fastest Mac OS based system available—the

first Mac OS based computer with speed built-in. Using its exper-

tise in multiprocessing, DayStar created Genesis MP with internal

multiprocessing hardware and software. Adopted by Apple,

DayStar’s nPOWER multiprocessing extensions to the Mac OS

are now the official standard for multiprocessing on the Mac.

As computer software becomes more sophisticated, designers,

illustrators, video editors, animators and multimedia producers will

require a machine that’s fast enough to keep pace with their flow

of ideas. Genesis MP is a Media-Publisher’s dream come true.

First— Genesis MP begins with a fast, upgradable PCI-bus moth-

erboard, featuring 2 SCSI busses, Ethernet, 16-bit stereo sound

and room for ample memory expansion.

Then— DayStar adds its nPOWER scalable multiprocessing tech-

nology, a fast tray-loading CD-ROM drive and a solidly-built tower

case with 10 drive bays, 350 watt power supply and three large

cooling fans for improved system reliability.

At the heart of Genesis MP is nPOWER—DayStar’s upgradable

processor card, which features up to four PowerPC 604 processors.

Since the processors are on a card, Genesis may be upgraded as

faster and more advanced processor technology becomes available.

To allow programs to take advantage of nPOWER’s speed,

DayStar has developed an open multiprocessing API (Application

Programming Interface). The API makes it very easy for program-

mers to add multiprocessing support to applications. The API stan-

dard is available to all interested developers.

Apple has acquired the rights to DayStar’s nPOWER architecture.

With Apple’s commitment, nPOWER (now known as the Apple

Multiprocessing Application Programming Interface) is assured of

software support in future versions of the Macintosh operating sys-

tem. Software developers that provide support for nPOWER include

Adobe, Metrowerks, Strata, Elastic Reality and many others.

◆3

Preface – About Genesis MP

Genesis MP4 ◆

Conventions Used in this Guide

The following conventions are used to distinguish elements of the text

in this guide:

Keyboard names will appear in all CAPS and BOLDFACE type. For

example: HOME, TAB.

When keys must be pressed simultaneously, the action is represented

by the keyboard key name and the plus (+) symbol. For example:

<COMMAND> + <OPTION> + <P> + <R>.

The filenames are presented in

UPPERCASE, ITALIC

type. For exam-

ple:

FILENAME

When referring to the closed Genesis MP unit, the words top, bottom,

left and right refer to the unit as viewed from the front in standard

operating position.

When referring to the open Genesis MP chassis or the Genesis

MP motherboard, the words top, bottom, left and right refer to the

unit as viewed from the open side panel in standard operating

position.

The word front always refers to the front panel of the Genesis MP

(floppy disk side). The word rear always refers to the rear panel of the

Genesis MP (cable side).

The following words and symbols denote special messages through-

out this guide:

WARNING

TEXT SET OFF IN THIS MANNER INDICATES THAT FAILURE

TO FOLLOW DIRECTIONS PROVIDED IN THE WARNING

COULD RESULT IN BODILY HARM OR IN EXTREME CASES

EVEN LOSS OF LIFE.

CAUTION

Text set off in this manner indicates that failure to follow directions

provided in the Caution could result in damage to equipment or

even loss of information.

IMPORTANT

Text set off in this manner indicates specific instructions or clarify-

ing information is being defined.

Text set off in this manner indicates commentary, sidelights, or interesting information

is being defined.

∆

Genesis MP

Preface – About Genesis MP

◆5

Standard Abbreviations

The following abbreviations (units of measure) and the

corresponding terms used in this guide are defined below:

A amperes mA milliamperes

dB decibels mA microamperes

GB gigabytes MB megabytes

Hz hertz MHz megahertz

in. inches mm millimeters

k 1000 ms milliseconds

K 1024 ms microseconds

KB kilobytes ns nanoseconds

kg kilograms Ωohms

kHz kilohertz sec. seconds

kΩkilohms V volts

lb. pounds W watts

Preface – About Genesis MP

Genesis MP6 ◆

Other Abbreviations

Other abbreviations used in this guide are defined below:

AC alternating current

A/D analog to digital

CD-ROM compact-disc read-only memory

CPU central processing unit

DC direct current

DIMM dual inline memory module

DMA direct memory access

DRAM dynamic RAM

GND ground

IC integrated circuit

I/O input and output

ISDN Integrated Services Digital Network

MMU memory management unit

n.c. no connection

NVRAM non-volatile random-access memory

PCI Peripheral Component Interconnect

(industry-standard expansion bus)

PRAM parameter random-access memory

PROM programmable read-only memory

RAM random access memory

ROM read-only memory

SCC serial communications controller

SCSI small computer system interface

SIMM single inline memory module

SVGA super video graphics adapter

VCC positive supply voltage

VGA video graphics adapter

VRAM video RAM (used for display buffers)

Genesis MP

Preface – About Genesis MP

◆7

Electrostatic Discharge (ESD) Rules

This section covers the proper procedures for grounding and utiliza-

tion of recommended equipment and materials for preventive damage

from Electrostatic Discharge (ESD).

Static electricity can be discharged from one’s self or by a conductor

thereby destroying static-sensitive devices or micro-circuitry. Often,

static discharge may not be detected by sight, touch, or sound,

although damage occurs. Electronic devices exposed to ESD may not

be affected at all and will continue to function properly. Or, this

device(s) may function properly for awhile, then gradually degrade

internally, thus reducing the life of the device(s).

When handling a device consider the following ways static electricity

can be emitted, thereby producing various levels of electrostatic volt-

age levels:

• Working in extreme low humidity

• Walking across carpet with device

• Walking across a vinyl floor

• Body motion within an unprotected ESD work area

• Removing device(s) from plastic packaging

• Removing device(s) from vinyl packaging

• Removing device(s) from Styrofoam packaging

• Removing device(s) from bubble-wrap packaging

• Packing or Unpacking device(s) wrapped in foam

CAUTION

The Genesis MP uses electronic components that are sensitive to

static electricity. Use care when handling and installing these com-

ponents to prevent damage which can be caused by static cur-

rents. Always work in an area of low static electricity on a ground-

ed surface to prevent static discharge.

∆

Preface – About Genesis MP

Genesis MP8 ◆

ESD SAFE WORK AREA

IMPORTANT

Many electronic devices are ESD sensitive. Be sure to take the follow-

ing precautions when handling an electronic device:

• When seated, always wear an Anti-static Wrist Strap

• When standing, wear footstraps on a grounded floor mat

• Never attempt installation on a carpeted floor

• Never wear leather shoes (rubber soles are recommended)

• Never attempt installation in an overly dry environment

• Never wear silk or polyester clothing during an installation

• Always remove all jewelry (i.e., rings, bracelets, watches, etc.)

• Always transport electronic devices in static-safe containers:

(i.e., tubes, bags, boxes)

• Always protect parts and assemblies with conductive ESD

approved containers and/or packaging

• Always remove electronic devices in a grounded work area

• Always use field service tools (i.e., screwdrivers, snips, vac-

uums) that are conductive.

Genesis MP is Shipped Complete with an Anti-Static Wrist Strap

The Anti-static Wrist Strap shipped with the Genesis MP is a one-use

disposable safety strap intended for the customer’s use. If you do not

have a re-usable Anti-static Wrist Strap, be sure to purchase one for

each employee that will be handling, installing, servicing, and/or main-

taining equipment.

Grounding Using The Anti-static Wrist Strap

These straps hold a minimum of 1 megaohm resistance. To ensure

proper grounding, this strap must be worn in direct contact with the

skin.

Grounding Using A Grounding Mat

This mat should be used when standing in an electro-static area and

when handling electronic devices. Alligator clips may be substituted

for banana-plug connectors connected to a wrist strap.

Grounding Using Heelstraps/Toestraps/Bootstraps

These straps can be used when standing. These straps may be sub-

stituted for most shoes or boots. The conductive strips must be worn

in direct contact with the skin to be effective.

∆

Genesis MP

Preface – About Genesis MP

◆9

PREVENTING DAMAGE TO DISK DRIVES

To prevent ESD and physical shock damage to floppy diskette

drive and/or hard disk drive(s), ensure the following safety precau-

tions:

• Always utilize anti-static techniques when handling drives

• Always re-package drives in their original shipping packaging

• Never drop a drive onto any surface (hard/or soft)

• Shield work surface with a minimum of 1-inch shock-proof foam

• Always place drives “assembly-side-down” on shock-proof foam

CD-ROM Drive

CAUTION

Making adjustments or performing procedures other than those

specified in your equipment’s manual may result in hazardous

exposure.

CAUTION

Do not attempt to disassemble the cabinet containing the laser.

The laser beam used in this product is harmful to the eyes. The

use of optical instruments, such as magnifying lenses, with this

product increases the potential hazard to your eyes. For your safe-

ty, have this equipment serviced only by a DayStar-authorized ser-

vice provider.

If you have an internal DayStar CD-ROM drive in your Genesis

MP, your computer is a Class 1 laser product. The Class 1 label,

located in a user-accessible area, indicates that the drive meets

minimum safety requirements. A service warning label is located in

a service-accessible area.

∆

Preface – About Genesis MP

Genesis MP10 ◆

Lithium Battery

Genesis MP uses a lithium battery to store users’ preferences and

time and date information while the unit is not turned on.

CAUTION

Danger of explosion if battery is incorrectly replaced. Replace only

with the same or equivalent type recommended by the manufac-

turer. Dispose of used batteries according to the manufacturer’s

instructions.

Lithium batteries cannot be recharged, therefore require disposal

when exhausted. In addition to its explosive potential, lithium is

water-reactive. Genesis MP’s lithium battery must be disposed of

as hazardous waste, therefore, DayStar Digital, Inc. recommends

the following battery disposal procedure:

After removing the exhausted lithium battery from the mother-

board, place the battery into a zip-lock wrapper and packaging

provided with the replacement battery. Mark the zip-lock wrapper

DEAD and return it to DayStar Digital, Inc, where it will be dis-

posed of according to EPA guidelines.

Disposal of a used battery should be handled in accordance with

county, state, province, or local battery disposal regulations.

WARNING

NEVER ATTEMPT TO OPEN OR SERVICE A USED BATTERY.

OPENING A BATTERY CAN DAMAGE THE BATTERY AND

EXPOSES POTENTIALLY HARMFUL AND HAZARDOUS COM-

PONENTS INTO THE ENVIRONMENT.

THERE ARE NO SERVICEABLE PARTS LOCATED INSIDE THE

BATTERY.

More Information about Genesis MP. . .

The following documentation is available to support the Genesis MP:

Genesis MP User Guide

Genesis MP Service Guide

Genesis MP Conversion Guide

Appendix A - External Connections

Appendix B - Internal Connections

Appendix C - Voltage Readings

White Paper: Multiprocessing on the Macintosh

Genesis MP Product Brochure

∆

Other manuals for Genesis MP

Table of contents

Other DayStar Digital Desktop manuals

DayStar Digital

DayStar Digital Genesis MP User manual

Popular Desktop manuals by other brands

HP m9060n - Pavilion - Elite Quick setup

Asus

Asus E210 Series user guide

Dell

Dell Inspiron 600m quick start

Dell

Dell Inspiron 3662 Service manual

TotalFlow

TotalFlow uFLO user manual

HP Presario SV7000 - Desktop PC manual

HP ProDesk 400 G5 Maintenance and service guide

Logitech

Logitech MK320 quick start guide

Dell

Dell XPS 730 H2C Service manual

Sony

Sony Vaio Series operating instructions

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer quick start

Alto

Alto MD 250 instruction manual

Lenovo

Lenovo ThinkCentre Edge 72 Manual

Lenovo

Lenovo ThinkStation D20 Manual

Arbor Technology

Arbor Technology FPC-7800 Series user manual

Sony

Sony VAIO VGX-TP1 Series user guide

Asus

Asus Eee Box B204 user manual

Dell

Dell Optiplex 9010 All In One owner's manual
