TECHNICAL DATA

Split-Sky Air

FH(Y)GZ/BZ/FHYP-B

Ceiling Suspended Unit

Split

Sky Air

Zandvoordestraat 300, B-8400 Oostende

Internet http://www.daikin.be

Daikin units comply with the European

regulations that guarantee the safety of

the product.

Daikin Europe NV is participating

in the EUROVENT Certification Programme.

Products are as listed in the EUROVENT

Directory of Certified Products.

Prepared in Belgium by Goekint Graphics • 05/2001

ISO14001 assures an effective environmental

management system in order to help protect

human health and the environment from the potential

impact of our activities, products and services and to

assist in maintaining and improving the quality of

the environment

Daikin Europe NV is approved by LRQA for its Quality

Management System in accordance with the ISO9001

standard. ISO9001 pertains to quality assurance regarding

design, development, manufacturing as well as to services

related to the product.

DAIKIN PRODUCTS ARE DISTRIBUTED BY :

Specifications are subject to change without prior notice

TABLE OF CONTENTS

FH(Y)-GZ/BZ/FHYP-B

1 Features ...................................................................................................... 2

2 Speciﬁcations ........................................................................................ 3

Nominal capacity, capacity steps and nominal input

Technical speciﬁcations

Electrical speciﬁcations

3 Dimensional drawings ................................................................. 9

4 Piping diagrams ................................................................................. 13

5 Wiring diagrams ................................................................................ 14

6 Sound level ............................................................................................. 16

Sound level data

Sound pressure spectrum

7 Accessories .............................................................................................. 19

Standard accessories

Optional accessories

8 Control systems ................................................................................. 21

9 Safety device settings ................................................................... 24

10 Installation ............................................................................................... 24

* For capacity tables, please refer to the outdoor units concerned

•Ceiling Suspended Unit •R-407C •FH(Y)-GZ/BZ/FHYP-B

•Split - Sky Air •Indoor Units

Features

+Leaves maximum ﬂoor and wall space for furniture,

decoration and ﬁttings

+New and even more compact casing (only 960 mm width)

+Extremely quiet in operation both indoors and outdoors

+Automatic air ﬂow director ensures uniform airﬂow and

temperature distribution (FHY-only)

+Air ﬂow distribution for ceilling heights up to 3.8m without

loss of capacity

+The outdoor unit can easily be mounted on a roof, a terrace

or placed against an outside wall

+For equal distribution in larger rooms, up to 3 indoor units

can be connected to 1 outdoor. They are operated from 1

remote control

+The (wired) remote control has a programmable timer

+Centralised control of several units can be achieved via 3

wired controls

– centralised remote control

– uniﬁed ON/OFF control

– schedule timer

13r 8qx6

6()z4

Optional Optional FHY FHY

2 steps 35∼125 FH35∼60

•Ceiling Suspended Unit •R-407C •FH(Y)-GZ/BZ/FHYP-B

2•Split - Sky Air •Indoor Units

Speciﬁcations

NOMINAL CAPACITY and NOMINAL INPUT

For indoor units only:

INDOOR UNITS FH35BZV1 FH45BZV1 FH60BZV1

NOMINAL INPUT Cooling kW 0.111 0.111 0.115

For combination indoor units + outdoor units:

INDOOR UNITS FH35BZV1 FH45BZV1 FH60BZV1

OUTDOOR UNITS R35GZ7V11 R45GZ7V11/W11 R60GZ7W1

NOMINAL CAPACITY

(2) Cooling (1) kW 3.75 5.20/5.20 6.50

NOMINAL INPUT Cooling kW 1.50 2.15/2.05 2.67

TECHNICAL SPECIFICATIONS

For indoor units only:

INDOOR UNITS FH35BZV1 FH45BZV1 FH60BZV1

DIMENSIONS Unit H mm 195 195 195

W mm 960 960 1,160

D mm 680 680 680

WEIGHT Unit kg 23 24 26

MATERIAL Unit - - -

COLOUR Unit White

SOUND LEVEL Sound pressure (3) high dB(A) 37 38 38

low dB(A) 32 33 33

Sound power (4) high dB(A) 53 54 54

low dB(A) 48 49 49

FAN Air ﬂow rate

(cooling) high m

/min 13 13 16

medium

/min - - -

low m

/min 10 10 13

Speed steps 2 steps 2 steps 2 steps

high rpm - - -

low rpm - - -

Type Sirocco fan

Qty x model 1 x 3D12K1AA1 1 x 3D12K1AA1 1 x 4D12K1AA1

Qty x motor output W 1 x 62 1 x 62 1 x 62

HEAT EXCHANGER Type Cross ﬁn coil (Multi louver ﬁns and N-HiX tubes)

Rows x stages x ﬁn pitch mm 2 x 12 x 1.75 3 x 12 x 1.75 3 x 12 x 1.75

Face area m

0.182 0.182 0.233

AIR FILTER - - -

AIR DIRECTION CONTROL - - -

TEMPERATURE CONTROL - - -

PIPING CONNECTIONS liquid mm φ6.4 (ﬂare) φ6.4 (ﬂare) φ6.4 (ﬂare)

gas mm φ12.7 (ﬂare) φ15.9 (ﬂare) φ15.9 (ﬂare)

drain

mm VP20 (I.D. φ20) VP20 (I.D. φ20) VP20 (I.D. φ20)

drain

mm VP20 (O.D. φ26) VP20 (O.D. φ26) VP20 (O.D. φ26)

INSULATION

MATERIAL Heat insulation Foamed polystyrene / Foamed polyethylene

Sound absorbing insulation Foamed polyurethane/Glass wool

For outdoor units

only: Pair application See chapter R-GZ7/RP-B7

Multi model application See chapter MA-GZ7

•Ceiling Suspended Unit •R-407C •FH(Y)-GZ/BZ/FHYP-B

•Split - Sky Air •Indoor Units

NOMINAL CAPACITY and NOMINAL INPUT

For indoor units only:

INDOOR UNITS FHYP71BV1 FHYP100BV1 FHYP125BV1

NOMINAL INPUT Cooling kW 0.117 0.135 0.144

For combination indoor units + outdoor units:

INDOOR UNITS FHYP71BV1 FHYP100BV1 FHYP125BV1

OUTDOOR UNITS RP71B7V1/W1/T1 RP100B7V1/W1/T1 RP125B7W1/T1

NOMINAL CAPACITY

(2) Cooling (1) kW 7.1/7.1/7.1 10.0/10.0/10.0 12.5/12.5

NOMINAL INPUT Cooling kW 2.65/2.61/2.61 3.82/3.62/3.62 4.69/4.69

TECHNICAL SPECIFICATIONS

For indoor units only:

INDOOR UNITS FHYP71BV1 FHYP100BV1 FHYP125BV1

DIMENSIONS Unit H mm 195 195 195

W mm 1,160 1,400 1,590

D mm 680 680 680

WEIGHT Unit kg 27 32 35

MATERIAL Unit - - -

COLOUR Unit White

SOUND LEVEL Sound pressure (3) high dB(A) 39 42 44

low dB(A) 35 37 39

Sound power (4) high dB(A) 55 58 60

low dB(A) 51 53 55

FAN Air ﬂow rate

(cooling) high m

/min 17 24 30

medium

/min - - -

low m

/min 14 20 25

Speed steps 2 steps 2 steps 2 steps

high rpm - - -

low rpm - - -

Type Sirocco fan

Qty x model 1 x 4D12K1AA1 1 x 3D12K2AA1 1 x 4D12K2AA1

Qty x motor output W 1 x 62 1 x 130 1 x 130

HEAT EXCHANGER Type Cross ﬁn coil (Multi louver ﬁns and N-HiX tubes)

Rows x stages x ﬁn pitch mm 3 x 12 x 1.75 3 x 12 x 1.75 3 x 12 x 1.75

Face area m

0.233 0.293 0.341

AIR FILTER - - -

AIR DIRECTION CONTROL - - -

TEMPERATURE CONTROL - - -

PIPING CONNECTIONS liquid mm φ9.5 (ﬂare) φ9.5 (ﬂare) φ9.5 (ﬂare)

gas mm φ15.9 (ﬂare) φ19.1 (ﬂare) φ19.1 (ﬂare)

Drain

mm VP20 (I.D. φ20) VP20 (I.D. φ20) VP20 (I.D. φ20)

Drain

mm VP20 (O.D. φ26) VP20 (O.D. φ26) VP20 (O.D. φ26)

INSULATION

MATERIAL Heat insulation Foamed polystyrene / Foamed polyethylene

Sound absorbing insulation Foamed polyurethane/Glass wool

For outdoor units

only: Pair application See chapter R-GZ7/RP-B7

•Ceiling Suspended Unit •R-407C •FH(Y)-GZ/BZ/FHYP-B

Speciﬁcations

4•Split - Sky Air •Indoor Units

ELECTRICAL SPECIFICATIONS

For indoor units only: FH35BZV1 FH45BZV1 FH60BZV1

CURRENT Nominal running

current

cooling

A---

For combination indoor units + outdoor units: FH35BZV1 FH45BZV1 FH60BZV1

R35GZ7V11 R45GZ7V11/W11 R60GZ7W1

CURRENT Nominal running

current

cooling

A 6.4 10.8/3.98 5.6/6.35

Maximum running

current

cooling

A - - 6.8/7.7

Starting current

cooling

A 33.5 48/19 26

For indoor units only: FH35BZV1 FH45BZV1 FH60BZV1

POWER SUPPLY V1 V1 V1

NOMINAL

DISTRIBUTION

SYSTEM VOLTAGE

Phase 1∼1∼1∼

Frequency Hz 50 50 50

Voltage V 220-240 220-240 220-240

ELECTRICAL SPECIFICATIONS

For indoor units only: FHYP71BV1 FHYP100BV1 FHYP125BV1

CURRENT Nominal running current A - - -

For combination indoor units + outdoor units: FHYP71BV1 FHYP100BV1 FHYP125BV1

RP71B7V1/W1/T1 RP100B7V1/W1/T1 RP125B7W1/T1

CURRENT Nominal running

current

cooling

A---

Maximum running current A - - -

For indoor units only: FHYP71BV1 FHYP100BV1 FHYP125BV1

POWER SUPPLY V1 V1 V1

NOMINAL

DISTRIBUTION

SYSTEM VOLTAGE

Phase 1∼1∼1∼

Frequency Hz 50 50 50

Voltage V 220-240 220-240 220-240

NOTES

1 Nominal cooling capacities are based on: indoor temperature: 27°CDB/19°CWB * outdoor temperature: 35°CDB/24° CWB * refrigerant

piping length: 7.5m * level difference 0m.

2 Capacities are net, including a deduction for cooling for indoor fan motor heat.

3 The sound pressure level is measured in an anechoic room at 1m distance from the unit. It is a relative value, depending on the distance

and acoustic environment. For measuring conditions: please refer to item 6 of this chapter.

4 The sound power level is an absolute value indicating the ’’power’’ which a sound source generates.

•Ceiling Suspended Unit •R-407C •FH(Y)-GZ/BZ/FHYP-B

Speciﬁcations

•Split - Sky Air •Indoor Units

NOMINAL CAPACITY and NOMINAL INPUT

For indoor units only:

INDOOR UNITS FHY35GZ7V1 FHY45GZ7V1 FHYP60BV1

NOMINAL INPUT Cooling kW - - 0.115

Heating kW - - -

For combination indoor units + outdoor units:

INDOOR UNITS FHY35GZ7V1 FHY45GZ7V1 FHYP71BV1

OUTDOOR UNITS - - -

NOMINAL CAPACITY

(3) Cooling (1) kW

For twin / triple / double twin application only

Heating (2) kW

NOMINAL INPUT Cooling kW

Heating kW

TECHNICAL SPECIFICATIONS

For indoor units only:

INDOOR UNITS FHY35GZ7V1 FHY45GZ7V1 FHYP60BV1

DIMENSIONS Unit H mm 188 188 195

W mm 1,100 1,100 1,160

D mm 600 600 680

WEIGHT Unit kg 26 27 26

MATERIAL Unit Cold rolled steel plate -

COLOUR Unit White

SOUND LEVEL Sound pressure

(cooling/heating) (4) high dB(A) 38/38 39/39 38/38

low dB(A) 33/33 34/34 33/33

Sound power

(cooling/heating) (5) high dB(A) 54/54 55/55 54/54

low dB(A) - - 49/49

FAN Air ﬂow rate

(cooling/heating) high m

/min 13/13 13/13 16/16

medium

/min - - -

low m

/min 10/10 10/10 13/13

Speed

(cooling/heating) steps 2 steps

high rpm - - -

low rpm - - -

Type Sirocco fan

Qty x model - - 1 x 4D12K1AA1

Qty x motor output W 1 x 57 1 x 57 1 x 62

HEAT EXCHANGER Type J7Hi-XAtube J7 Hi-XA tube Cross ﬁn coil (Multi louver

ﬁns and N-HiX tubes)

Rows x stages x ﬁn pitch mm 2 x 10 x 1.75 3 x 10 x 1.75 3 x 12 x 1.75

Face area m

0.181 0.181 0.233

AIR FILTER Resin net (with mold resistant)

AIR DIRECTION CONTROL

TEMPERATURE CONTROL Computerised control

PIPING CONNECTIONS liquid mm φ6.35 φ6.35 φ9.5 (ﬂare)

gas mm φ12.7 φ15.9 φ15.9 (ﬂare)

drain

mm VP20 (I.D. φ20) VP20 (I.D. φ20) VP20 (I.D. φ20)

drain

mm VP20 (O.D. φ26) VP20 (O.D. φ26) VP20 (O.D. φ26)

INSULATION

MATERIAL Heat insulation Both liquid and gas pipes Foamed polystyrene /

Foamed polyethylene

Sound absorbing insulation Flame and heat resistant foamed polyethylene, regular

foamed polyethylene Foamed polyurethane/

Glass wool

•Ceiling Suspended Unit •R-407C •FH(Y)-GZ/BZ/FHYP-B

Speciﬁcations

6•Split - Sky Air •Indoor Units

NOMINAL CAPACITY and NOMINAL INPUT

For indoor units only:

INDOOR UNITS FHYP71BV1 FHYP100BV1 FHYP125BV1

NOMINAL INPUT Cooling kW 0.117 0.135 0.144

Heating kW - - -

For combination indoor units + outdoor units:

INDOOR UNITS FHYP71BV1 FHYP100BV1 FHYP125BV1

OUTDOOR UNITS RYP71B7V1/W1 RYP100B7V1/W1 RYP125B7W1

NOMINAL CAPACITY

(3) Cooling (1) kW 7.1/7.1 10.0/10.0 12.5

Heating (2) kW 7.7/7.7 11.0/11.0 14

NOMINAL INPUT Cooling kW 2.61/2.61 3.62/3.62 4.69

Heating kW 2.67/2.67 3.78/3.78 5.30

TECHNICAL SPECIFICATIONS

For indoor units only:

INDOOR UNITS FHYP71BV1 FHYP100BV1 FHYP125BV1

DIMENSIONS Unit H mm 195 195 195

W mm 1,160 1,400 1,590

D mm 680 680 680

WEIGHT Unit kg 27 32 35

MATERIAL Unit - - -

COLOUR Unit White

SOUND LEVEL Sound pressure

(cooling/heating) (4) high dB(A) 39/39 42/42 44/44

low dB(A) 35/35 37/37 39/39

Sound power

(cooling/heating) (5) high dB(A) 55/55 58/58 60/60

low dB(A) 51/51 53/53 55/55

FAN Air ﬂow rate

(cooling/heating) high m

/min 17/17 24/24 30/30

medium

/min - - -

low m

/min 14/14 20/20 25/25

Speed

(cooling/heating) steps 2 steps 2 steps 2 steps

high rpm - - -

low rpm - - -

Type Sirocco fan

Qty x model 1 x 4D12K1AA1 1 x 3D12K2AA1 1 x 4D12K2AA1

Qty x motor output W 1 x 62 1 x 130 1 x 130

HEAT EXCHANGER Type Cross ﬁn coil (Multi louver ﬁns and N-HiX tubes)

Rows x stages x ﬁn pitch mm 3 x 12 x 1.75 3 x 12 x 1.75 3 x 12 x 1.75

Face area m

0.233 0.293 0.341

AIR FILTER - - -

AIR DIRECTION CONTROL - - -

TEMPERATURE CONTROL - - -

PIPING CONNECTIONS liquid mm φ9.5 (ﬂare) φ9.5 (ﬂare) φ9.5 (ﬂare)

gas mm φ15.9 (ﬂare) φ19.1 (ﬂare) φ19.1 (ﬂare)

Drain

mm VP20 (I.D. φ20) VP20 (I.D. φ20) VP20 (I.D. φ20)

Drain

mm VP20 (O.D. φ26) VP20 (O.D. φ26) VP20 (O.D. φ26)

INSULATION

MATERIAL Heat insulation Foamed polystyrene / Foamed polyethylene

Sound absorbing insulation Foamed polyurethane/Glass wool

For outdoor units

only: Pair application See chapter RYP-B7

•Ceiling Suspended Unit •R-407C •FH(Y)-GZ/BZ/FHYP-B

Speciﬁcations

•Split - Sky Air •Indoor Units

ELECTRICAL SPECIFICATIONS

For indoor units only: FHY35GZ7V1 FHY45GZ7V1 FHYP60BV1

CURRENT Nominal running

current

cooling

A---

heating

A---

For combination indoor units + outdoor units: FHY35GZ7V1 FHY45GZ7V1 FHYP60BV1

---

CURRENT Nominal running

current

cooling

Twin/triple/double twin application only

heating

Maximum running

current

cooling

heating

For indoor units only: FHY35GZ7V1 FHY45GZ7V1 FHYP60BV1

POWER SUPPLY V1 V1 V1

NOMINAL

DISTRIBUTION

SYSTEM VOLTAGE

Phase 1∼1∼1∼

Frequency Hz 50 50 50

Voltage V 230 230 220-240

ELECTRICAL SPECIFICATIONS

For indoor units only: FHYP71BV1 FHYP100BV1 FHYP125BV1

CURRENT Nominal running

current

cooling

A---

heating

A---

For combination indoor units + outdoor units: FHYP71BV1 FHYP100BV1 FHYP125BV1

RYP71B7V1/W1 RYP100B7V1/W1 RYP125B7W1

CURRENT Nominal running

current

cooling

A---

heating

A---

Maximum running

current

cooling

A---

heating

A---

For indoor units only: FHYP71BV1 FHYP100BV1 FHYP125BV1

POWER SUPPLY V1 V1 V1

NOMINAL

DISTRIBUTION

SYSTEM VOLTAGE

Phase 1∼1∼1∼

Frequency Hz 50 50 50

Voltage V 220-240 220-240 220-240

NOTES

1 Nominal cooling capacities are based on: indoor temperature: 27°CDB/19°CWB * outdoor temperature: 35°CDB/24° CWB * refrigerant

piping length: 7.5m * level difference 0m.

2 Nominal heating capacities are based on: indoor temperature: 20°CDB/15 °CWB * outdoor temperature: 7°CDB/6°CWB * refrigerant

piping length: 7.5m * level difference 0m.

3 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.

4 The sound pressure level is measured in an anechoic room at 1m distance from the unit. It is a relative value, depending on the distance

and acoustic environment. For measuring conditions: please refer to item 6 of this chapter.

5 The sound power level is an absolute value indicating the ’’power’’ which a sound source generates.

•Ceiling Suspended Unit •R-407C •FH(Y)-GZ/BZ/FHYP-B

Speciﬁcations

8•Split - Sky Air •Indoor Units

This manual suits for next models

Table of contents

Other Daikin Air Conditioner manuals

Daikin

Daikin RN60HV1A User manual

Daikin

Daikin RXS42K2V1B User manual

Daikin

Daikin Inverter FTXS85LVMA User manual

Daikin

Daikin UATYA-BBY1 User manual

Daikin

Daikin FXAQ12MVJU User manual

Daikin

Daikin Air Conditioner User manual

Daikin

Daikin RZQG100L9V1B User manual

Daikin

Daikin Altherma 3 H HT ETSXB16E7 User manual

Daikin

Daikin WinterSpa RHR-C Series User manual

Daikin

Daikin FCQG-F Instruction manual

Daikin

Daikin FDA125A5VEB User guide

Daikin

Daikin D-Series User manual

Daikin

Daikin RZVF50BRV169 User manual

Daikin

Daikin RXYSCQ-TV1 Series Instruction manual

Daikin

Daikin 2MXS40G2V1B User manual

Daikin

Daikin Altherma 3 RW User manual

Daikin

Daikin FT50GVEA User manual

Daikin

Daikin FTXN09KEVJU User manual

Daikin

Daikin Comfora FTXTP-M Product information sheet

Daikin

Daikin FT24HEV1K User manual

Daikin

Daikin RXS09JEVJU User manual

Daikin

Daikin FMA50RVMA User manual

Daikin

Daikin FT20FV1M User manual

Daikin

Daikin ERLA03DAV3 How to use

Popular Air Conditioner manuals by other brands

Spheros

Spheros CC 355 instructions

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE owner's manual

Panasonic

Panasonic CS-E12HKEW operating instructions

nedis

nedis ACMB1WT7 quick start guide

Samsung

Samsung AR KV Series User & installation manual

Fujitsu

Fujitsu Inverter ASBA30JFC operating manual

Toshiba

Toshiba RAS-M10SMUV-E installation manual

Hitachi

Hitachi RAS-E24CAK instruction manual

CIAT

CIAT Magister 2 Series Installation, Operation, Commissioning, Maintenance

Bestron

Bestron AAC6000 instruction manual

Hisense

Hisense 7K Use and Installation Instructions

Frigidaire

Frigidaire FFRE0533S1E0 Use & care guide

Samsung

Samsung AS09HM3N user manual

Frigidaire

Frigidaire CRA073PU11 use & care

Soleus Air

Soleus Air GB-PAC-08E4 operating instructions

McQuay

McQuay MCK020A Technical manual

Webasto

Webasto Frigo Top 25 DS Instructions for use

Frigidaire

Frigidaire FAZ12ES2A installation instructions
