D-Link DCS-2136L User manual

DCS-2136L

Quick Install Guide

Wireless AC Day/Night Camera

with Color Night Vision

ENGLISH

Package Contents

Minimum Requirements

Computer with:

• PC with 1.3 GHz or above and at least 128 MB RAM

• Windows® 8, Windows® 7, Vista® or XP (32-bit or 64-bit)

• Mac OS® X 10.6 or higher

Web Browser:

• Internet Explorer® 7, Firefox 12, Safari 4, or Chrome 20 and above

• Installed and enabled Java and ActiveX® controls

Network Device and Service:

• A router (D-Link Cloud Router is recommended)

• An Internet connection

• An e-mail account (Required to register mydlink service)

CAT5 Ethernet Cable

DCS-2136L Wireless AC Day/Night Camera with Color Night Vision

If any of the above items are missing, please contact your reseller.

Power Adapter

Stand/Mounting Bracket

Quick Install Guide

ENGLISH

If you wish to connect your camera to your router with a wireless connection,

you can simply disconnect the Ethernet cable and move the camera to its

intended location.

Step 3

From any computer, open a web browser, go to

http://www.mydlink.com and log in to your

account.

Click on the device name when the new device

notication appears to add the camera to your

account.

Step 1

Connect the power cable and Ethernet cable to your

cloud camera.

Step 2

Connect the other end of the Ethernet cable to your

D-Link Cloud Router and connect the camera’s power

adapter to a power outlet.

Setting up your Camera

Using a D-Link Cloud Router (Zero Conguration)

If you have a D-Link Cloud Router, you can take advantage of Zero Conguration

Setup. This feature automatically congures your camera’s settings for you and

adds it to your mydlink account automatically. If you do not have a D-Link Cloud

router, refer to the next page to install and congure your camera.

DCS-2136L

ENGLISH

Using the Setup Wizard

If you do not have a D-Link Cloud Router, you can simply use any Windows or

Mac computer to go through the Setup Wizard, which will guide you through

the installation process from connecting your hardware to conguring your

camera and registering it with your mydlink account.

Download the Setup Wizard from http://www.mydlink.com/download.

Click your camera model and then under Wizard, click the link of the version

(Windows or Mac) you want to download. Depending on your web browser,

you may need to right-click the link and select Save link as.

Windows Users - Extract (“unzip”) the les to a folder on your computer and

then double-click the autorun.exe le.

Mac Users - Download the Mac OS Setup Wizard. Open the SetupWizard le

and launch the application.

After about 20-30 seconds, the Setup Wizard will open. Follow the on-screen

instructions.

ENGLISH

Getting Started with mydlink

mydlink is a web-based service which allows you to view and control your

mydlink-enabled devices through any computer connected to the Internet. If

you have cameras linked to your mydlink account, you will be able to see their

live views using the mydlink website. Follow the instructions below to access

your mydlink account.

• Open a web browser on any computer connected to the Internet.

• Type http://www.mydlink.com in the address bar and press Enter.

• Sign in using your mydlink account.

• From the home screen, you will be able to view all devices which have

been linked to your mydlink account.

• Ensure that your browser supports both Java and ActiveX, and that these

features have been installed and enabled.

• Windows does not have Java installed by default. You can download the latest

version from http://www.java.com.

• In Mac OS X 10.7.x, Java applets are disabled by default. To enable Java applets,

click the Finder > Applications > Utilities > Java Preferences and check the

Enable applet plug-in and Web Start applications option.

• The ActiveX® controls in IE will install automatically if needed. We suggest that

you make sure that you have enabled the related options in Tools > Internet

Options > Security > Custom Level.

ENGLISH

Mount the Camera

1. Place the mounting base where you want

to position the camera and use a pencil to

mark the holes.

4. Place the base cover on the base and

screw the camera stem clockwise into the

mounting base.

2. Depending on the material of the wall or

ceiling, use proper tools to drill two holes or

screws where you marked. If the wall is made

out of concrete, drill the holes rst, insert the

plastic anchors and then the screws.

3. Place the mounting base over the screw that

is mounted on the wall. Make sure to t the

screw-heads over the big holes and slide

it downward to lock rmly. Lightly pull the

base forward to make sure that it is locked.

Please refer to the steps below to assist you with mounting the camera.

The space between the camera and the screwheads should be 3mm.

We suggest that you congure the camera before mounting.

ENGLISH

Download mydlink Lite/mydlink + Apps

5. Adjust the angle of the camera as desired,

then tighten the collar on the camera stem

to lock it in place.

mydlink Lite App (Free)

Search for “mydlink lite” to download and install the app on your smartphone

or tablet when connected to the Internet. You can also nd the app by

scanning the QR code below with a QR code scan app.

mydlink+ App (Paid - Tablet Only)

Search for the word “mydlink+” to download and install the app on your

tablet when connected to the Internet. You can also nd the app by scanning

the QR code below with a QR code scan app.

System Requirements: iOS version 4.3 or above. Android version 2.1 or above.

ENGLISH

Technical Support

This guide is only for the rst time conguration. Please refer to the user manual

to learn more or visit http://www.mydlink.com for more information. Also feel

free to contact us. U.S. and Canadian customers can contact D-Link Technical

Support through our website.

http://support.dlink.com

USA

http://support.dlink.ca

Canada

Version 1.10

November 26, 2013

RMN0101032A

its subsidiaries. Other trademarks are the property of their respective owners. Maximum wireless signal rate derived

from IEEE Standard 802.11g and 802.11n specications. Actual data throughput will vary. Network conditions and

environmental factors, including volume of network trac, building materials and construction, and network

overhead, lower actual data throughput rate. Environmental factors will adversely aect wireless signal range.

Product specications, size and shape are subject to change without notice, and actual product appearance may

dier from that depicted on the packaging. Visit dlink.com (US) or dlink.ca (Canada) for more details.
